Brief Description

The main purpose of the ACC system is to control the climate unit in order to achieve comfortable climate conditions as soon as possible after starting the car and then to maintain them. The ACC unit consists of a control panel with knobs and buttons as well as an integrated control module. Under normal conditions, the control module automatically controls the following functions

Description of operation

The ACC unit supplies the heating element with a B+ voltage from K2 pin 1 which is then grounded via G 14. The heating element in the passenger seat is supplied with a B+ voltage from K2 pin 6 and is grounded via G 24.

The temperature sensor (254) is grounded internally in the ACC unit via K1 pin 23 for both driver's seat and passenger seat

The driver's seat sensor is supplied from K2 pin 4 with 5V via a 6.8 Kohms resistor built into the ACC unit. The characteristics of the NTC resistor mean that resistance decreases afterwards as the temperature increases. This means that the voltage measured over the resistor will at the same time decrease during rising temperatures.

The passenger seat sensor is supplied from K2 pin 5 with 5V via a 6.8 Kohms resistor built into the ACC unit. The characteristics of the NTC resistor mean that resistance decreases afterwards as the temperature increases. This means that the voltage measured over the resistor will at the same time decrease during rising temperatures.

The voltage value from the sensor is A/D converted and is then available in digital form. The digital voltage value is then converted to temperature and is added to the ACC unit's operating memory. Voltage values close to 0 or 5V are interpreted as faults in the circuit.

The fans in the ventilated seats are controlled manually with pushbuttons in the ACC panel. The LEDs in the buttons show fan speed. The preconditions are that the engine is running and that the cabin fan knob is not in the OFF position.

The fan speed in the driver's seat and passenger seat is controlled by a voltage

Step 1: low speed approx. 9.3 volts

Step 2 : high speed approx. 11 volts

The ACC unit's K1 pin 2 is connected to the driver's seat fan and is grounded via G14 and K1 pin 11 to the passenger seat's fan that is grounded via G24.

StepIndication in buttonCurrent consumption (A)
0None0
11 LEDApprox. 1.3
22 LEDsApprox. 2

REFERENCE CHART

Scheme 312

Scheme 312: Button and control illumination

Scheme 313

Scheme 313: Motor, Ventilation Fan (36)

Scheme 314

Scheme 314: Motor, Air Recirculation Flap (38)

Scheme 315

Scheme 315: K6

K40

Scheme 316

Scheme 316

Scheme 317

Scheme 317: Mixed Air Temperature Sensor, LH (217LH)

Scheme 318

Scheme 318: Mixed Air Temperature Sensor, RH (217RH)

Scheme 319

Scheme 319: Cabin Temperature Sensor (218)

Scheme 320

Scheme 320: Ventilation Fan Control (220)

Scheme 321

Scheme 321: Motor, Air Distribution Damper, Defroster/Panel/Floor (221a)

Scheme 322

Scheme 322: Air Mixing Flap Motor, LH (222LH)

Scheme 323

Scheme 323: Air Mixing Flap Motor, RH (222RH)

Scheme 324

Scheme 324: Solar Sensor (223)

Scheme 325

Scheme 325: Relay, Parking Heater (409a)

Scheme 326

Scheme 326: Relay, Auxiliary Heater (409b)

Scheme 327

Scheme 327: Motor, Coolant Circulation Pump (453)

Scheme 328

Scheme 328: Solenoid Valve, Heat Exchanger (581)

Scheme 329

Scheme 329: LHD

Scheme 330

Scheme 330: RHD

Scheme 331

Scheme 331: Connector H8-7

Scheme 332

Scheme 332: Connector H10-5

Scheme 333

Scheme 333: Connector H10-6

Scheme 334

Scheme 334: Connector H10-8

Scheme 335

Scheme 335: Connector H33-1

Scheme 336

Scheme 336: Connector H80-1

Scheme 337

Scheme 337: Crimp Connection J45, Instrument Harness

Scheme 338

Scheme 338: Crimp Connection J62, Instrument Harness

Scheme 339

Scheme 339: Crimp Connection J63, Instrument Harness

Scheme 340

Scheme 340: Crimp Connection J65, Instrument Harness

Scheme 341

Scheme 341: Crimp J66, Instrument Harness

Scheme 342

Scheme 342: Crimp Connection J142, Instrument Harness

Scheme 343

Scheme 343: Crimp J199, Instrument Harness

Scheme 344

Scheme 344: Grounding Point, G41P

Scheme 345

Scheme 345
