Automatic Climate Control: Adjustments Saab 9-5 I рестайлинг 2

Manual Calibration, ACC

Manual calibration must be performed if the stepping motor is replaced, removed or if the position of the flaps is changed. Calibration must also be performed when the battery has been disconnected. Perform calibration as follows.

Scheme 346

1. Start the engine.
2. Press in the AUTO and REC buttons until the message "ACC: CALIBR. STARTED" is shown on the main instrument unit display. Calibration takes approximately 20 seconds.

Scheme 347

Scheme 348

1. Remove the Recirculation motor. See «Recirculation Flap»(ref-278647-S25832169592008013000000) .
2. Remove the motor bolts.
3. Bend apart the mounting from the motor using a screwdriver.
4. Lift off the arm.

Scheme 349

Scheme 350

1. Fit the arm on the mounting.
2. Fit the mounting to the motor.
3. Fit the recirculation motor. See «Recirculation Flap»(ref-278647-S25832169592008013000000) .

Scheme 351

Scheme 352

Scheme 353

Adjustment

The ACC unit can be adjusted using the diagnostic tool as follows

Scheme 354

1. the air-blending flap continuously remains in full heat position.
2. select another fan current.

With the diagnostics tool, the ACC unit can be adjusted to delay fan engagement if there is a risk of mist forming on the inside of the windscreen. This occurs if the engine has been turned off for more than 1 minute and the outside temperature is between 0°C and 15°C.

The delay period can be set to between 0 and 30 s.

Using the diagnostic tool, the ACC unit can be adjusted to always start with the air recirculation flap in recirculation. The flap immediately adopts this position. Fresh air can only be selected manually on the panel

The ACC unit can be adjusted using the diagnostic tool to raise or lower the temperature in the left and right-hand temperature zones compared with what was set on the steering wheel control.

Note. The cabin temperature is always regulated so that the perceived temperature is equivalent to the setting. This means that a thermometer normally shows a value different from the setting.

Scheme 355

The system is set in accordance with the following

1. fan speed 6 steps
2. AC ON
3. air distribution in defrost position, 100% is shown on the diagnostic tool
4. temperature control
5. air recirculation in off position
6. electrically heated rear window on
7. the LED in the AUTO button goes out

Scheme 356

The system is set in accordance with the following

1. air distribution in defrost/floor position, 70% is shown on the diagnostic tool
2. the button LEDs for defrost/floor come on
3. the LED in the AUTO button goes out

Scheme 357

The system is set in accordance with the following

1. air distribution in floor position, 50% is shown on the diagnostic tool
2. the button LED for floor comes on
3. the LED in the AUTO button goes out

Scheme 358

The system is set in accordance with the following

1. air distribution in floor/panel position, 25% is shown on the diagnostic tool
2. the button LEDs for floor/panel come on
3. the LED in the AUTO button goes out

Scheme 359

The system is set in accordance with the following

1. air distribution in panel position, 4.5% is shown on the diagnostic tool
2. the button indicator lamp for panel comes on
3. the indicator lamp in the AUTO button goes out

Scheme 360

The button can be switched manually between air recirculation and fresh air. To return to automatic control AUTO must be depressed. Note that the AUTO button LED also comes on during manual air recirculation.

Air recirculation is affected in the following cases

1. OFF, if the defroster button is activated
2. ON if LO temperature and AC ON have been selected

The system is set in accordance with the following with recirculation on

1. air recirculation in ON position
2. the LED in the air recirculation button comes on

Scheme 361

Adjust heated seat offset temperature with the diagnostic tool.

Adjusting heated seat offset temperature with the diagnostic tool.
