Intake manifold
The intake manifold on LEV cars is manufactured in one piece without intermediate piece. There is an air strainer fitted under the throttle body that distributes air as evenly as possible to the different cylinders to attain an even combustion.
Identifying Mass Air Flow Sensor (B204i). Scheme 54
The mass air flow sensor, which is of hot film type, is mounted between the air cleaner and the intake manifold.
For further information on the mass air flow sensor, see TRIONIC ENGINE MANAGEMENT SYSTEM .
Identifying Mass Air Flow Sensor (B235R, B205L/R). Scheme 55
The mass air flow sensor, which is of hot film type, is mounted between the air cleaner and the intake manifold.
For more information on mass air flow sensor, see TRIONIC ENGINE MANAGEMENT SYSTEM .
Identifying Charge Air Temperature Sensor (B204E) Components. Scheme 56
The temperature sensor is mounted between the air cleaner and intake manifold.
For more information on the temperature sensor, see TRIONIC ENGINE MANAGEMENT SYSTEM .
Identifying Charge Air Temperature Sensor (B235R, B205L/R) Components. Scheme 57
The temperature sensor is mounted between the air cleaner and intake manifold.
For more information on temperature sensor, see TRIONIC ENGINE MANAGEMENT SYSTEM .
