NV271 Transfer Case - Service Information: Overview RAM Pickup 2500

Transfer Case 3 illustrations ~289 words

Scheme 65

Scheme 65: DESCRIPTION
1 - TRANSFER CASE
2 - MANUAL LEVER
3 - POSITION SENSOR

The NV271 transfer case (1) is a part-time transfer case with a low-range gear system. (Scheme 65) It provides three operating ranges plus a NEUTRAL position. The low range position provides a gear reduction ratio of 2.72:1 for increased low speed torque capability.

The gear cases and extension are all of aluminum. Drive sprockets and an interconnecting drive chain are used to transmit engine torque to the front/rear propeller shafts. The mainshaft, input gear and front output shaft are supported by ball and needle bearings.

Scheme 66

Scheme 66: IDENTIFICATION
1 - TRANSFER CASE
2 - IDENTIFICATION TAG

An identification tag (2) is attached to the rear case of every transfer case. (Scheme 66) The tag provides the transfer case model number, assembly number, serial number, and low range ratio.

The transfer case serial number also represents the date of build.

DESCRIPTION

The transfer case position sensor is an electronic device whose output can be interpreted to indicate the transfer case's current operating mode. The sensor consists of a five position, resistive multiplexed circuit which returns a specific resistance value to the Powertrain Control Module (PCM) for each transfer case operating mode. The sensor is located on the top of the transfer case, just left of the transfer case centerline and rides against the sector plate roostercomb. The PCM supplies 5VDC (+/- 0.5V) to the sensor and monitors the return voltage to determine the sector plate, and therefore the transfer case, position.

OPERATION

SENSOR POSITIONOPERATING MODESENSOR RESISTANCE (ohms)
12H1172-1195
24H677-691
3NEUTRAL406-415
44L208-213
5NOT USED60-61

Operating Mode Versus Resistance

Scheme 67

Scheme 67
1 - POSITION 1 - 10mm ±0.5mm
2 - POSITION 2 - 12mm ±0.5mm
3 - POSITION 3 - 14mm ±0.5mm
4 - POSITION 4 - 16mm ±0.5mm
5 - POSITION 5 - 18mm ±0.5mm
6 - POSITION 6 - 20mm±0.5mm - FULL EXTENSION

During normal vehicle operation, the Powertrain Control Module (PCM) monitors the transfer case position sensor return voltage to determine the operating mode of the transfer case. Refer to OPERATING MODE VERSUS RESISTANCE for the correct resistance for each position. see scheme 99
