Occupant Restraint Controller (Orc) - Electrical Diagnostics: Diagnosis RAM Pickup 2500

DIAGNOSTIC CODE INDEX

DIAGNOSTIC CODE INDEX

Scheme 76

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

Diagnostic Test

1. VERIFY ACTIVE DTC Turn the ignition ON. With the scan tool, read ORC DTCs. Does the scan tool display active B0090-49-LEFT FRONTAL RESTRAINTS SENSOR - INTERNAL ELECTRONIC FAILURE DTC or did the DTC set the Stored history setting? Yes WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Replace the Left Front Impact Sensor in accordance with the Service Information. Refer to «SENSOR, Impact , Removal»(ref-457806-S34746421292012030200000) . Perform the RESTRAINT SYSTEM VERIFICATION TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) . No (Did not set a active or stored DTC B0090-49- LEFT FRONTAL SENSOR - INTERNAL ELECTRONIC FAILURE) Perform the RESTRAINTS SYSTEM INTERMITTENT TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) .

1. VERIFY ACTIVE DTC Turn the ignition on. With the scan tool, read ORC DTCs. Does the scan tool display an active B0095-49-RIGHT FRONTAL ACCELERATION SENSOR - INTERNAL ELECTRONIC FAILURE DTC or shows a setting history in stored? Yes WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Replace the Right Front Impact Sensor in accordance with the Service Information. Refer to «SENSOR, Impact , Removal»(ref-457806-S34746421292012030200000) . Perform the RESTRAINT SYSTEM VERIFICATION TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) . No (Did not set a active or stored DTC B0095-49- RIGHT FRONTAL SENSOR - INTERNAL ELECTRONIC FAILURE) Perform the RESTRAINTS SYSTEM INTERMITTENT TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) .

Scheme 77

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

1. VERIFY ACTIVE DTC Turn the ignition on. With the scan tool, read ORC DTCs. Does the scan tool display active B0091-49-LEFT SIDE ACCELERATION SENSOR 1 - INTERNAL ELECTRONIC FAILURE DTC or shows a setting history in stored? Yes WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Replace the Left Side Impact Sensor 1 in accordance with the Service Information. Refer to «SENSOR, Impact , Removal»(ref-457806-S34746421292012030200000) . Perform the RESTRAINT SYSTEM VERIFICATION TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) . No (Did not set a active or stored DTC B0091-49- LEFT SIDE SATELLITE SENSOR 1- INTERNAL ELECTRONIC FAILURE) Perform the RESTRAINTS SYSTEM INTERMITTENT TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) .

1. VERIFY ACTIVE DTC Turn the ignition on. With the scan tool, read ORC DTCs. Does the scan tool display an active B0092-49-LEFT SIDE ACCELERATION SENSOR 2 - INTERNAL ELECTRONIC FAILURE DTC or shows a setting history in stored? Yes WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Replace the Left Side Impact Sensor 2 in accordance with the Service Information. Refer to «SENSOR, Impact , Removal»(ref-457806-S34746421292012030200000) . Perform the RESTRAINT SYSTEM VERIFICATION TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) . No (Did not set a active or stored DTC B0092-49- LEFT SIDE SATELLITE SENSOR 2- INTERNAL ELECTRONIC FAILURE) Perform the RESTRAINT SYSTEM INTERMITTENT TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) .

Scheme 78

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

1. VERIFY ACTIVE DTC Turn the ignition on. With the scan tool, read ORC DTCs. Does the scan tool display active B009A-49-LEFT SIDE SATELLITE SENSOR 4 - INTERNAL ELECTRONIC FAILURE DTC or shows a setting history in stored? Yes WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Replace the Left Side Impact Pressure Sensor in accordance with the Service Information. Refer to «SENSOR, Impact , Removal»(ref-457806-S34746421292012030200000) . Perform the RESTRAINT SYSTEM VERIFICATION TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) . No (Did not set a active or stored DTC B009A-49-LEFT SIDE SATELLITE SENSOR 4- INTERNAL ELECTRONIC FAILURE). Perform the RESTRAINT SYSTEM INTERMITTENT TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) .

Scheme 79

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

1. VERIFY ACTIVE DTC Turn the ignition on. With the scan tool, read ORC DTCs. Does the scan tool display active B0096-49-RIGHT SIDE ACCELERATION SENSOR 1 - INTERNAL ELECTRONIC FAILURE DTC or shows a setting history in stored? Yes WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Replace the Right Side Impact Sensor 1 in accordance with the Service Information. Refer to «SENSOR, Impact , Removal»(ref-457806-S34746421292012030200000) . Perform the RESTRAINT SYSTEM VERIFICATION TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) . No (Did not set a active or stored DTC B0096-49-RIGHT SIDE SATELLITE SENSOR 1- INTERNAL ELECTRONIC FAILURE) Perform the RESTRAINTS SYSTEM INTERMITTENT TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) .

1. VERIFY ACTIVE DTC Turn the ignition on. With the scan tool, read ORC DTCs. Does the scan tool display active B0097-49-RIGHT SIDE ACCELERATION SENSOR 2 - INTERNAL ELECTRONIC FAILURE DTC or shows a setting history in stored? Yes WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Replace the Right Side Impact Sensor 2 in accordance with the Service Information. Refer to «SENSOR, Impact , Removal»(ref-457806-S34746421292012030200000) . Perform the RESTRAINT SYSTEM VERIFICATION TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) . No (Did not set a active or stored DTC B0097-49-RIGHT SIDE SATELLITE SENSOR 2- INTERNAL ELECTRONIC FAILURE). Perform the RESTRAINT SYSTEM INTERMITTENT TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) .

Scheme 80

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

1. VERIFY ACTIVE DTC Turn the ignition on. With the scan tool, read ORC DTCs. Does the scan tool display active B009D-49-RIGHT SIDE SATELLITE SENSOR 4 - INTERNAL ELECTRONIC FAILURE DTC or shows a setting history in stored? Yes WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Replace the Right Side Impact Pressure Sensor in accordance with the Service Information. Refer to «SENSOR, Impact , Removal»(ref-457806-S34746421292012030200000) . Perform the RESTRAINT SYSTEM VERIFICATION TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) . No (Did not set a active or stored DTC B009D-49-RIGHT SIDE SATELLITE SENSOR 4- INTERNAL ELECTRONIC FAILURE) Perform the RESTRAINT SYSTEM INTERMITTENT TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) .

1. VERIFY ACTIVE DTC NOTE: Ensure the battery is fully charged. Turn the ignition on. With the scan tool, read ORC DTCs. Does the scan tool display active B1BA5-00-AIRBAG SQUIB CONFIGURATION MISMATCH - DTC? Yes Go To 2 . No Perform the RESTRAINTS SYSTEM INTERMITTENT TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) .
2. VERIFY ORC PART NUMBER With the scan tool, read the ORC part number. Is the part number correct for the vehicle? Yes Go To 3 . No WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: If the Occupant Restraint Controller (ORC) is dropped at any time, it must be replaced. Failure to follow these instructions may result in possible serious or fatal injury. Replace the ORC in accordance with Service Information. Perform the RESTRAINTS SYSTEM VERIFICATION TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) .
3. CHECK THE VIN WITH THE SCAN TOOL With the scan tool, read the VIN. Compare the vehicle VIN to the ORC VIN. Is the correct VIN displayed? Yes Go To 4 . No Replace the PCM in accordance with Service Information. Perform the POWERTRAIN VERIFICATION TEST. Refer to «STANDARD PROCEDURE»(ref-457810-S22630084262012030200000) .
4. VERIFY TIPM CONFIGURATION With the scan tool, read the TIPM configuration. Does the TIPM configuration match the vehicle equipment? Yes WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: If the Occupant Restraint Controller (ORC) is dropped at any time, it must be replaced. Failure to follow these instructions may result in possible serious or fatal injury. Replace the ORC in accordance with Service Information. Perform the RESTRAINTS SYSTEM VERIFICATION TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) . No Re-configure or replace the TIPM in accordance with Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .

1. VERIFY ACTIVE DTC Turn the ignition ON. With the scan tool, read ORC active DTCs. Does the scan tool display an active B1BC7-00-DEPLOYMENT DATA RECORD FULL - DTC? Yes WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: If the Occupant Restraint Controller (ORC) is dropped at any time, it must be replaced. Failure to follow these instructions may result in possible serious or fatal injury. Replace the ORC in accordance with the service information. Perform the RESTRAINTS SYSTEM VERIFICATION TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) . No Perform the RESTRAINTS SYSTEM VERIFICATION TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) .

Scheme 81

For a complete wiring diagram, refer to Wiring Information .

1. CHECK PCM FOR CHARGING SYSTEM DTC Turn the ignition on. With the scan tool, read Powertrain Control Module (PCM) DTCs. Are there any Charging System DTCs set in the PCM? Yes Refer to appropriate Electrical Diagnostic Information for Charging System diagnostic procedures . No Go To 2 .
2. VERIFY ACTIVE DTC Turn the ignition on. With the scan tool, read all ORC DTCs. Does the scan tool display active B2199-17-BATTERY VOLTAGE - CIRCUIT VOLTAGE ABOVE THRESHOLD DTC? Yes WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Replace the ORC in accordance with Service Information. Perform the RESTRAINTS SYSTEM VERIFICATION TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) . No Perform the RESTRAINTS SYSTEM INTERMITTENT TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) .

Scheme 82

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

1. VERIFY ACTIVE DTC NOTE: Make sure the battery is fully charged. Turn the ignition on. With the scan tool, read ORC DTCs. Does the scan tool display active B210F-00-LOSS OF BATTERY VOLTAGE - DTC? Yes Go To 2 . No Perform the RESTRAINTS SYSTEM INTERMITTENT TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) .
2. CHECK FOR ACTIVE RUN RELAY DTC With the scan tool, read TIPM DTCs. Does the scan tool display any active TIPM Run Relay related DTCs? Yes Refer to appropriate Electrical Diagnostic Information and perform the appropriate diagnostic procedure . No Go To 3 .
3. INSPECT TIPM FUSE M32 Turn the Ignition OFF. Remove and inspect the TIPM Fuse M32. NOTE: Check connectors - Clean and repair as necessary. Is the TIPM Fuse M32 open? Yes Go To 4 . No Go To 5 .
4. CHECK (F100) FUSED IGNITION RUN CONTROL OUTPUT CIRCUIT RESISTANCE WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Measure the resistance of the (F100) Fused Ignition Run Control Output circuit between the TIPM Fuse M32 output terminal TIPM C6 cavity 38 and ground. Is the resistance below 100 Ohms? Yes Go To 5 . No Using the wiring diagram/schematic as a guide, inspect the related wiring and connectors. Look for chafed, pierced, pinched, or partially broken wires and broken, bent, pushed out, spread, corroded, or contaminated terminals. Replace TIPM Fuse M32. Perform the RESTRAINTS SYSTEM VERIFICATION TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) .
5. CHECK (F100) FUSED IGNITION RUN CONTROL OUTPUT CIRCUIT WITH ORC DISCONNECTED WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Disconnect the ORC harness connectors. NOTE: Check connectors - Clean and repair as necessary. Connect the SRS Load Tool Adaptor (special tool #8443-24, 32-Way Adapter) to the ORC C2 harness connector. Measure the resistance of the (F100) Fused Ignition Run Control Output circuit between appropriate terminal of the SRS Load Tool Adaptor (special tool #8443-24, 32-Way Adapter) cavity 24 and ground. Is the resistance below 100 Ohms? Yes Repair the (F100) Fused Ignition Run Control Output circuit for a short to ground. Replace the TIPM Fuse M32. Perform the RESTRAINTS SYSTEM VERIFICATION TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) . No WARNING: If the Occupant Restraint Controller (ORC) is dropped at any time, it must be replaced. Failure to follow these instructions may result in possible serious or fatal injury. Replace the ORC in accordance with the Service Information. Replace the TIPM Fuse M32. Perform the RESTRAINTS SYSTEM VERIFICATION TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) .

1. REPLACE OCCUPANT RESTRAINT CONTROLLER (ORC) NOTE: When this DTC is set, the module self test has discovered an internal fault that cannot be repaired and the module must be replaced regardless of DTC status. When this code is set do not clear codes, view repair. Repair WARNING: If the Occupant Restraint Controller (ORC) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental airbag deployment. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Replace the ORC in accordance with Service Information. Perform the RESTRAINTS SYSTEM VERIFICATION TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) .

1. REPLACE OCCUPANT RESTRAINT CONTROLLER (ORC) NOTE: When this DTC is set, the module self test has discovered an internal fault that cannot be repaired and the module must be replaced regardless of DTC status. When this code is set do not clear codes, view repair. Repair WARNING: If the Occupant Restraint Controller (ORC) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental airbag deployment. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Replace the ORC in accordance with Service Information. Perform the RESTRAINTS SYSTEM VERIFICATION TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) .

1. REPLACE OCCUPANT RESTRAINT CONTROLLER (ORC) NOTE: When this DTC is set, the module self test has discovered an internal fault that cannot be repaired and the module must be replaced regardless of DTC status. When this code is set do not clear codes, view repair. Repair WARNING: If the Occupant Restraint Controller (ORC) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental airbag deployment. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Replace the ORC in accordance with Service Information. Perform the RESTRAINTS SYSTEM VERIFICATION TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) .

1. REPLACE OCCUPANT RESTRAINT CONTROLLER (ORC) NOTE: When this DTC is set, the module self test has discovered an internal fault that cannot be repaired and the module must be replaced regardless of DTC status. When this code is set do not clear codes, view repair. Repair WARNING: If the Occupant Restraint Controller (ORC) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental airbag deployment. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Replace the ORC in accordance with Service Information. Perform the RESTRAINTS SYSTEM VERIFICATION TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) .

1. REPLACE OCCUPANT RESTRAINT CONTROLLER (ORC) NOTE: When this DTC is set, the module self test has discovered an internal fault that cannot be repaired and the module must be replaced regardless of DTC status. When this code is set do not clear codes, view repair. Repair WARNING: If the Occupant Restraint Controller (ORC) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental airbag deployment. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Replace the ORC in accordance with Service Information. Perform the RESTRAINTS SYSTEM VERIFICATION TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) .

Scheme 83

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

1. VERIFY ACTIVE ORC DTC NOTE: Ensure the battery is fully charged. Turn the ignition on. Wait 12 seconds, with the scan tool, read all ORC DTCs. Does the scan tool display active B223B-00-VEHICLE CONFIGURATION MISMATCH - DTC? Yes Go To 2 . No Perform the RESTRAINTS SYSTEM INTERMITTENT TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) .
2. VERIFY ORC PART NUMBER With the scan tool, read the ORC part number. Is the part number correct for the vehicle? Yes Go To 3 . No WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: If the Occupant Restraint Controller (ORC) is dropped at any time, it must be replaced. Failure to follow these instructions may result in possible serious or fatal injury. Replace the ORC in accordance with Service Information. Perform the RESTRAINTS SYSTEM VERIFICATION TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) .
3. CHECK THE TIPM CONFIGURATION With the scan tool, check for Side Airbags and PAD Switch configuration. Does the Vehicle Configuration in the TIPM match the Vehicle Configuration in the ORC? Yes WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: If the Occupant Restraint Controller (ORC) is dropped at any time, it must be replaced. Failure to follow these instructions may result in possible serious or fatal injury. Replace the ORC in accordance with Service Information. Perform the RESTRAINTS SYSTEM VERIFICATION TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) . No With the scan tool enter program network configuration and program the TIPM to the vehicle configuration. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .

1. REPLACE OCCUPANT RESTRAINT CONTROLLER (ORC) Turn the ignition on. With the scan tool, read ORC DTCs. Does the scan tool display active B222A-00-VEHICLE LINE MISMATCH - DTC? Yes WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: If the Occupant Restraint Controller (ORC) is dropped at any time, it must be replaced. Failure to follow these instructions may result in possible serious or fatal injury. Replace the Occupant Restraint Controller (ORC) in accordance with the Service Information. Perform the RESTRAINTS SYSTEM VERIFICATION TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) . No Perform the RESTRAINTS SYSTEM INTERMITTENT TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) .

1. CHECK FOR ADDITIONAL ACTIVE ORC DTCS NOTE: Make sure the battery is fully charged. Turn the ignition on. With the scan tool, read the active ORC DTC. Is B2722-00-ORC UNLOCKED-ALL DEPLOYMENT DISABLED the only active DTC? Yes Go To 2 . No Select the appropriate diagnostic procedure from the appropriate Diagnostic Information. Refer to «Diagnosis and Testing»(ref-457871-S00283187372012030200000) .
2. INITIALIZE ORC With the scan tool, select Initialize ORC. The scan tool will display the current Deployment Disable Status (CURRENT STATUS) Select the CURRENT STATUS displayed on the scan tool. CURRENT STATUS LOCKED The ORC is in a full state of readiness. Perform the RESTRAINTS SYSTEM VERIFICATION TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) . CURRENT STATUS UNLOCKED Go To 3 . CURRENT STATUS ORC is Responding with incorrect Data With the scan tool, select MISC. FUNCTION and then Initialize ORC. After the ORC Initialization is complete: Restart this test at step 1. Go To 1 .
3. CHANGE ORC STATUS Follow the instruction on the screen to change the status to LOCKED. The scan tool will display the result of the initialization. Does the scan tool display: ORC LOCK Successful? Yes CURRENT STATUS is ORC LOCK Successful Perform the RESTRAINTS SYSTEM VERIFICATION TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) . No Go To 4 .
4. INCOMPLETE OR FAILED ORC INITIALIZATION Does the scan tool display: ORC Initialization Failed? Yes CURRENT STATUS is ORC Initialization Failed WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: If the Occupant Restraint Controller (ORC) is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental airbag deployment. Failure to follow these instructions may result in possible serious or fatal injury. Replace the ORC in accordance with service information. Perform the RESTRAINTS SYSTEM VERIFICATION TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) . No CURRENT STATUS is Current and original VIN have not been learned by ORC With the scan tool, select and rerun Initialize ORC. After the Initialize ORC Procedure is complete: Restart this test at step 1. Go To 1 .

1. VERIFY ACTIVE DTC NOTE: Make sure the IOD fuse is installed and battery Voltage is between 10 and 16 Volts before proceeding. Turn the ignition on. With the scan tool, read ORC DTCs. Does the scan tool display active U0001-00-CAN C BUS - DTC? Yes Refer to «U0001-CAN C BUS»(ref-457926-S37851162552012030200000) for 1500, 2500 & 3500 or «U0001-CAN C BUS CIRCUIT»(ref-457927-S12132305092012030200000) for 3500 CAB & CHASSIS, 4500 & 5500, and perform the U0001-Can C Bus diagnostic procedure. . No Perform the «STORED LOST COMMUNICATION DTCS»(ref-457934-S05707347042012030200000) for 1500, 2500 &3500, or «STORED LOST COMMUNICATION DTCS»(ref-457935-S26988435972012030200000) for 3500 Cab & Chassis, 4500 &5500, diagnostic procedure .

1. VERIFY THE DTC IS ACTIVE NOTE: For vehicle communication problems, use the scan tool to refer to the Network Review Screen. The screen depicts a high level view of the vehicle network. Fault and problem areas appear in red. Selecting any of the network components allows access to the source of the problem. Turn the ignition on. With a scan tool, read DTCs. Is the DTC active at this time? Yes Diagnose the U0002-00 CAN C BUS OFF PERFORMANCE as the U0001 CAN C BUS CIRCUIT test. and perform the U0001-Can C Bus diagnostic procedure. Refer to «U0001-CAN C BUS»(ref-457926-S37851162552012030200000) for 1500, 2500 & 3500 or «U0001-CAN C BUS CIRCUIT»(ref-457927-S12132305092012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 . No Perform the «STORED LOST COMMUNICATION DTCS»(ref-457934-S05707347042012030200000) for 1500, 2500 and 3500, or «STORED LOST COMMUNICATION DTCS»(ref-457935-S26988435972012030200000) for 3500 Cab & Chassis, 4500 and 5500, diagnostic procedure .

1. VERIFY THE DTC IS ACTIVE NOTE: Make sure the IOD fuse is installed and the battery is fully charged before proceeding. Turn the ignition on. With the scan tool, read active DTCs. Is the DTC active at this time? Yes Perform the U0141-Lost Communication with IPM (FCM/TIPM) diagnostic procedure. Refer to appropriate Electrical Diagnostic Information . . No Perform the Stored Lost Communication DTCs diagnostic procedure. Refer to «STORED LOST COMMUNICATION DTCS»(ref-457934-S05707347042012030200000) for 1500, 2500 and 3500, or «STORED LOST COMMUNICATION DTCS»(ref-457935-S26988435972012030200000) for 3500 Cab & Chassis, 4500 and 5500 .

1. VERIFY ACTIVE ORC DTC NOTE: Ensure the battery is fully charged. Turn the ignition on. With the scan tool, read ORC DTCs. Does the scan tool display an active U1414-00-IMPLAUSIBLE/MISSING ECU NETWORK CONFIGURATION DATA - DTC? Yes Go To 2 . No Repair complete. Perform the RESTRAINTS SYSTEM VERIFICATION TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) .
2. VERIFY ACTIVE TIPM DTC With the scan tool, read TIPM DTCs. Does the scan tool display any active TIPM DTCs? Yes Perform the appropriate TIPM diagnostic procedures. Refer to the appropriate Electrical Diagnostic Information . No Replace the Totally Integrated Power Module (TIPM) in accordance with Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .

1. VERIFY ACTIVE ORC DTC NOTE: Ensure the battery is fully charged. Turn the ignition on. With the scan tool, read ORC DTCs. Does the scan tool display an active U1415-00-IMPLAUSIBLE/MISSING VEHICLE CONFIGURATION DATA - DTC? Yes Go To 2 . No Repair complete. Perform the RESTRAINTS SYSTEM VERIFICATION TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) .
2. VERIFY ACTIVE TIPM DTC With the scan tool, read TIPM DTCs. Does the scan tool display any active TIPM DTCs? Yes Perform the appropriate TIPM diagnostic procedures. Refer to appropriate Electrical Diagnostic Information . No Replace the Totally Integrated Power Module (TIPM) in accordance with Service Information. Perform the BODY VERIFICATION TEST. Refer to «BODY VERIFICATION TEST»(ref-457926-S40044966262012030200000) for 1500, 2500 & 3500, or «BODY VERIFICATION TEST»(ref-457927-S20352278932012030200000) for 3500 CAB & CHASSIS, 4500 & 5500 .

RESTRAINTS SYSTEM INTERMITTENT TEST

For a complete wiring diagram, refer to appropriate SYSTEM WIRING DIAGRAMS article .

1. RECORD AND ERASE ALL RESTRAINT SYSTEM DTCS With the scan tool, record and erase all DTCs from all restraints system modules. Monitor for any active codes as you work through the following steps. Review the code monitored and set conditions for any DTCs that are stored and attempt to reproduce the conditions listed. Wiggle the wiring harness and connectors of the related airbag circuit, sensor, or component. If codes are related to the Driver Airbag circuits, rotate the steering wheel from stop to stop. Turn the ignition off. Refer to any Technical Service Bulletins (TSBs) that may apply. Was the source of the customer complaint found or did any DTCs appear and stay active? Yes Make the appropriate repairs and either perform the RESTRAINTS SYSTEM VERIFICATION TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) . Select the DTC procedure from the appropriate Diagnostic Information. Refer to «Diagnosis and Testing»(ref-457871-S00283187372012030200000) . No Go To 2 .
2. ATTEMPT TO REPRODUCE THE CONDITION In the event the customer complaint cannot be duplicated due to an intermittent condition in the restraints system, the following may aid in attempting to reproduce the condition. WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors related to the stored code or component in question. Look for chafed, pierced, pinched, or partially broken wires and broken, bent, pushed out, spread, corroded, or contaminated terminals. Reconnect any disconnected components and harness connectors and ensure they are properly seated. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If numerous trouble codes were set, use a schematic and inspect any common ground or supply circuits. Was the source of the intermittent condition located? Yes Make the appropriate repairs and perform the RESTRAINTS SYSTEM VERIFICATION TEST. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) . No The problem cannot be found at this time.

1. Before attempting to repair any restraint system, technicians should be familiar with and fully understand the system operation. Refer to Restraints System Description and Operation for complete details. Refer to «Operation»(ref-457806-S16005739082012030200000) . Refer to «Description»(ref-457806-S14336261192012030200000) . The following should be used as a checklist to be completed in its entirety prior to referencing specific Restraints Diagnostic Procedures. FOLLOW THE BASIC OUTLINE SET FORTH IN THE SIX-STEP TROUBLESHOOTING PROCEDURE Verification of complaint. Verification of any related symptoms. Symptom analysis. Problem isolation. Repair of isolated problem. Verification of proper operation. TAKE INTO ACCOUNT CURRENT VEHICLE CONDITION, REPAIR HISTORY, AND TECHNICAL SERVICE BULLETINS (TSBs) Verify that there are no outward signs of vehicle damage or effects from a collision that could impact the proper operation of the Restraints system. Check for aftermarket vehicle accessories that may have been installed improperly or could interfere with the system. Check the vehicle repair history for repairs that may relate to the current condition. Check for current Technical Service Bulletins (TSBs) for the Restraints system related to the customer concern. If a TSB applies, follow the procedure outlined in the TSB. DIAGNOSE ONLY THOSE FAILURES THAT ARE ACTIVE AND CAN BE REPRODUCED Check the control module central to the subsystem that is exhibiting the condition for active DTCs. For an intermittent failure that is not active at the time of vehicle inspection, perform the RESTRAINTS SYSTEM INTERMITTENT TEST and document the event on the repair order. Refer to «Standard Procedure»(ref-457871-S26700628122012030200000) . ADDRESS ACTIVE DIAGNOSTIC TROUBLE CODES (DTCs) IN THE CORRECT ORDER Low/High Voltage and Serial Data Loss of Communication Codes. Module Internal Failure and Configuration Mismatch Codes. Circuit specific DTC failures. Should the malfunction still be present after conducting this Pre-diagnostic Procedure, technicians should continue to the appropriate DTC procedure. Refer to «Diagnosis and Testing»(ref-457871-S00283187372012030200000) . Was the Pre-Test reviewed and is the DTC still present? Yes Perform the appropriate DTC procedure. Refer to «Diagnosis and Testing»(ref-457871-S00283187372012030200000) . No Test Complete.

1. PERFORM THE RESTRAINTS SYSTEM VERIFICATION TEST NOTE: If the ORC has been replaced, the ORC Initialization Procedure must be performed to clear the ORC Unlocked DTC and bring the module to a full state of readiness. Refer to the DTC list. Refer to «Diagnosis and Testing»(ref-457871-S00283187372012030200000) . Please perform all steps in the sequence presented following exactly the steps to successfully complete the procedures. WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Remove any special tools or jumper wires and reconnect all previously disconnected components - except the Battery. If equipped with the keyless ignition, use this ignition on warning. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the ORC fuses, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the ORC fuses. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the standard key ignition, use this ignition on warning. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. Connect the scan tool to the Data Link Connector - use the most current software available. With the scan tool, erase stored DTCs in all airbag system modules. Perform module reset. NOTE: If equipped with an Airbag On - Off switch, read the DTCs in all switch positions. Exercise the Restraints System to duplicate the appropriate monitor conditions for any DTCs that were set. Wait one minute, and read active codes, if there are none present, read the stored codes. If the scan tool shows any active or stored codes, return to the DTC Index and follow the path specified for that trouble code. If no active or stored codes are present, the repair is complete. Are any DTCs present or, is the original condition still present? Yes Refer to «Diagnosis and Testing»(ref-457871-S00283187372012030200000) and perform the appropriate diagnostic procedure. No WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If the battery was disconnected for any reason, you must perform the Battery Reconnection procedure in the 8F-Engine Systems article of the Service Information. NOTE: Please follow the ignition on warnings for either the standard key ignition or keyless ignition for reintroducing battery voltage to the restraint airbag system. WARNING: Disconnect the 12-volt battery wait two minutes before proceeding, remove the ORC fuses, connect the 12-volt battery, wait two minutes before proceeding. Cycle the ignition to the On position, then reconnect the ORC fuses. Wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. WARNING: Turn the ignition on, then reconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury. If equipped with the keyless ignition, use this ignition on warning. If equipped with the standard key ignition, use this ignition on warning. Repair is complete.
