Restraints - Service Information: Other RAM Pickup 2500

WARNING

ACTIVE RESTRAINTS

The active restraints for this vehicle include

1. Child Restraint Anchors - All standard cab vehicles are equipped with two, fixed-position, child seat upper tether anchors that are integral to the upper cab back panel reinforcement and concealed behind individual trim cover and bezel units that are integral to the cab back trim panel. All vehicles with rear seats are equipped with three child seat upper tether anchor straps that are secured to the upper cab back panel reinforcement, behind the upright rear seat back. Two lower anchors are also provided for each rear outboard seating position on quad or crew cabs. Mega cabs have lower anchors provided for all three rear seating positions. These lower anchors are accessed from the front of the seat where the seat back meets the seat cushion. Child seat upper tether and lower anchors for the front seat are unavailable on quad or crew cab and mega cab vehicles. Likewise, lower anchors for the front seat are not available on standard cab vehicles.
2. Front Seat Belts - Both outboard front seating positions are equipped with three-point seat belt systems employing a lower B-pillar mounted inertia latch-type Emergency Locking Retractor (ELR), a height-adjustable upper B-pillar mounted turning loop, a fixed lower seat belt anchor secured to the lower B-pillar (standard cab) or floor panel adjacent to the B-pillar (quad or crew cab), and a traveling end-release seat belt buckle secured to the inboard seat track. Except for the driver side front seat, the retractors for all vehicles are also switchable from an ELR to an Automatic Locking Retractor (ALR) for compatibility with child seats. The front seat belt buckle for the driver side of all vehicles includes an integral seat belt switch that detects whether its seat belt has been fastened. The center front seating position for standard cabs is also equipped with a three-point seat belt employing a floor panel mounted inertia latch-type ELR, a routing bracket and bezel near the top of the cab back panel, and two fixed end-release buckles secured to the center seat cushion frame. One of the center buckles is specially keyed to serve as the center seat belt lower anchor. The center front seating position for quad or crew cab vehicles with a split bench front seat is equipped with a fixed lap belt and an end-release buckle secured to the center seat cushion frame.
3. Rear Seat Belts - On all vehicles equipped with rear seats, each rear seating position is equipped with a three-point seat belt system. Each outboard rear seating position seat belt employs a lower C-pillar mounted inertia latch-type Emergency Locking Retractor (ELR), a fixed position upper C-pillar mounted turning loop, and a fixed lower seat belt anchor secured to the lower C-pillar. The quad or crew cab rear seat center seating position has a rear floor panel mounted inertia latch-type ELR and a routing bracket and bezel on the top of the cab back panel, while the mega cab rear seat center position retractor and a routing bracket and bezel are mounted to the rear seat back panel. A fixed end-release buckle unit for the quad or crew cab right outboard seating position is integral to the right side of the center retractor mounting bracket on the rear floor panel. The end-release buckle units for the quad or crew cab center and left outboard seating positions are individually secured to the rear floor panel on vehicles with the standard equipment rear bench seat, or secured with the rear seat mounting hardware on vehicles with the optional split rear bench seat. The fixed end-release buckle units for all mega cab rear seating positions are secured to the seat cushion frame mounting hardware. The rear seat retractors for all vehicles are also switchable from an ELR to an Automatic Locking Retractor (ALR) for compatibility with child seats.

Scheme 35

The passive restraints available for this vehicle include the following

1. Dual Front Airbags - Multistage driver and front passenger airbags are used in this vehicle. This airbag system consists of passive, inflatable, Supplemental Restraint System (SRS) components and vehicles with this equipment can be readily identified by the SRS - AIRBAG logo molded into the driver airbag trim cover in the center of the steering wheel and also into the passenger airbag door on the top of the instrument panel trim cover above the upper glove box or storage bin opening. Vehicles with the airbag system can also be identified by the airbag indicator, which will illuminate in the ElectroMechanical Instrument Cluster (EMIC) (also known as the Cab Compartment Node/CCN) from four to six seconds as a bulb test each time the ignition switch is turned to the ON position. A pyrotechnic-type seat belt tensioner is also integral to the front outboard seat belt retractors to work in conjunction with the dual front airbags.
2. Side Curtain Airbags - Side curtain airbags are standard equipment for this vehicle when it is also equipped with dual front airbags. This airbag system consists of passive, inflatable, SRS components and vehicles with this equipment can be readily identified by a molded identification trim button with the SRS - AIRBAG logo located at the top of each B-pillar trim (all models) and C-pillar trim (quad or crew cab and mega cab only) near the headliner.

Scheme 36

The SRS includes the following major components, which are described in further detail elsewhere in this service information

1. Airbag Indicator - The airbag indicator is integral to the ElectroMechanical Instrument Cluster (EMIC) (also known as the Cab Compartment Node/CCN), which is located on the instrument panel in front of the driver.
2. Clockspring - The clockspring is located near the top of the steering column, directly beneath the steering wheel.
3. Driver Airbag (3) - The driver airbag is located in the center of the steering wheel horn pad, beneath the driver airbag trim cover.
4. Driver Knee Blocker - The driver knee blocker is a structural unit secured to the back side of and integral to the instrument panel steering column opening cover.
5. Front Impact Sensor (1) - Two front impact sensors are used, one left side and one right side. One sensor is located on the back side of each end of the lower radiator support cross member on each side of the cooling module and below the inboard side of each front lamp unit.
6. Occupant Restraint Controller (5) - The Occupant Restraint Controller (ORC) is located on a mounting bracket on the floor panel transmission tunnel below the center section of the front seat, or under the center floor console, as the vehicle is equipped.
7. Passenger Airbag (2) - The passenger airbag is located in the instrument panel, beneath the passenger airbag door integral to the top of the instrument panel trim cover just forward of the upper glove box or storage bin on the passenger side of the vehicle.
8. Passenger Knee Blocker - The passenger knee blocker is a structural reinforcement that is integral to and concealed within the lower glove box door.
9. Seat Belt Tensioner (6) - A seat belt tensioner is integral to both front outboard seat belt retractor units. The seat belt retractor tensioner units are secured to the right and left inner B-pillars and concealed beneath the lower B-pillar trim.
10. Side Curtain Airbag (8) - A side curtain airbag is secured to each inside roof side rail above the headliner, and extends from the A-pillar to near the cab back.
11. Side Impact Sensor - Up to six side impact sensors are used on vehicles with side curtain airbags, up to three on each side of the vehicle. One pressure-type sensor (4) is located on each right and left front door module carrier behind the front door trim panel on some vehicles. In addition, an acceleration-type sensor (7) is located on each inner B-pillar behind the lower B-pillar trim on all models, while quad or crew cab and mega cab models also have one acceleration-type sensor on each inner C-pillar behind the lower C-pillar trim.

The ORC and the EMIC each contain a microprocessor and programming that allow them to communicate with each other using the Controller Area Network (CAN) data bus. This method of communication is used by the ORC for control of the airbag indicator in the EMIC. Refer to COMMUNICATION , Description .

Hard wired circuitry connects the SRS components to each other through the electrical system of the vehicle. These hard wired circuits are integral to several wire harnesses, which are routed throughout the vehicle and retained by many different methods. These circuits may be connected to each other, to the vehicle electrical system, and to the SRS components through the use of a combination of soldered splices, splice block connectors, and many different types of wire harness terminal connectors and insulators. Refer to the appropriate wiring information. The wiring information includes wiring diagrams, proper wire and connector repair procedures, further details on wire harness routing and retention, as well as pin-out and location views for the various wire harness connectors, splices and grounds.

The primary passenger restraints in this or any other vehicle are the standard equipment factory-installed seat belts and child restraint anchors. Seat belts and child restraint anchors are referred to as an active restraint because the vehicle occupants are required to physically fasten and properly adjust these restraints in order to benefit from them.

PASSIVE RESTRAINTS

The passive restraints are referred to as a Supplemental Restraint System (SRS) because they were designed and are intended to enhance the protection for the occupants of the vehicle only when used in conjunction with the seat belts. They are referred to as passive restraints because the vehicle occupants are not required to do anything to make them operate; however, the vehicle occupants must be wearing their seat belts in order to obtain the maximum safety benefit from the factory-installed SRS components.

The SRS electrical circuits are continuously monitored and controlled by a microprocessor and software contained within the Occupant Restraint Controller (ORC). An airbag indicator in the ElectroMechanical Instrument Cluster (EMIC) (also known as the Cab Compartment Node/CCN) illuminates from four to six seconds as a bulb test each time the ignition switch is turned to the ON or START positions. Following the bulb test, the airbag indicator is turned ON or OFF by the ORC to indicate the status of the SRS. If the airbag indicator comes ON at any time other than during the bulb test, it indicates that there is a problem in the SRS electrical circuits. Such a problem may cause airbags not to deploy when required, or to deploy when not required.

Deployment of the SRS components depends upon the angle and severity of an impact. Deployment is not based upon vehicle speed; rather, deployment is based upon the rate of deceleration as measured by the forces of gravity (G force) upon the acceleration-type impact sensors, or by a pressure wave within a front door as measured by the pressure-type impact sensor. When an impact is severe enough, the microprocessor in the ORC signals the inflator of the appropriate airbag units to deploy their airbag cushions. The outboard front seat belt retractor tensioners are provided with a deployment signal by the ORC in conjunction with the front airbags. The side curtain airbags are provided with a deployment signal individually by the ORC based upon a side impact sensor input for the same side of the vehicle.

During a frontal vehicle impact, the knee blockers work in concert with properly fastened and adjusted seat belts to restrain both the driver and the right front seat passenger in the proper position for an airbag deployment. The knee blockers also absorb and distribute the crash energy from the driver and the right front seat passenger to the structure of the instrument panel. The seat belt tensioners remove the slack from the outboard front seat belts to provide further assurance that the driver and right front seat passenger are properly positioned and restrained for an airbag deployment.

Typically, the vehicle occupants recall more about the events preceding and following a collision than they do of an airbag deployment itself. This is because the airbag deployment and deflation occur very rapidly. In a typical 48 kilometer-per-hour (30 mile-per-hour) barrier impact, from the moment of impact until the airbags are fully inflated takes about 40 milliseconds. Within one to two seconds from the moment of impact, the airbags are almost entirely deflated. The times cited for these events are approximations, which apply only to a barrier impact at the given speed. Actual times will vary somewhat, depending upon the vehicle speed, impact angle, severity of the impact, and the type of collision.

When the ORC monitors a problem in any of the SRS circuits or components, including the seat belt tensioners, it stores a fault code or Diagnostic Trouble Code (DTC) in its memory circuit and sends an electronic message to the EMIC to turn ON the airbag indicator. The hard wired circuits between components related to the SRS may be diagnosed using conventional diagnostic tools and procedures. Refer to the appropriate wiring information. The wiring information includes wiring diagrams, proper wire and connector repair procedures, details of wire harness routing and retention, connector pin-out information and location views for the various wire harness connectors, splices and grounds.

However, conventional diagnostic methods will not prove conclusive in the diagnosis of the SRS or the electronic controls or communication between other modules and devices that provide features of the SRS. The most reliable, efficient, and accurate means to diagnose the SRS or the electronic controls and communication related to SRS operation, as well as the retrieval or erasure of a DTC requires the use of a diagnostic scan tool. Refer to the appropriate diagnostic information.

HANDLING NON-DEPLOYED SUPPLEMENTAL RESTRAINTS

At no time should any source of electricity be permitted near the inflator on the back of a non-deployed airbag or seat belt tensioner. When carrying a non-deployed airbag, the trim cover or airbag cushion side of the unit should be pointed away from the body to minimize injury in the event of an accidental deployment. If the airbag unit is placed on a bench or any other surface, the trim cover or airbag cushion side of the unit should be face up to minimize movement in the event of an accidental deployment.

When handling a non-deployed seat belt tensioner, take proper care to keep fingers out from under the retractor or buckle cover and away from the seat belt webbing or cable where it exits from the retractor or buckle cover. In addition, the Supplemental Restraint System (SRS) should be disarmed whenever any steering wheel, steering column, seat belt tensioner, airbag, impact sensor, or instrument panel components require diagnosis or service. Failure to observe this warning could result in accidental airbag deployment and possible personal injury.

All damaged, ineffective or non-deployed airbags and seat belt tensioners which are replaced on vehicles are to be handled and disposed of properly. If an airbag or seat belt tensioner unit is ineffective or damaged and non-deployed, refer to the Hazardous Substance Control System for information regarding the potentially hazardous properties of the subject component and the proper safe handling procedures. Then dispose of all non-deployed and deployed airbags and seat belt tensioners in a manner consistent with state, provincial, local and federal regulations.

SUPPLEMENTAL RESTRAINT STORAGE

Airbags and seat belt tensioners must be stored in their original, special container until they are used for service. Also, they must be stored in a clean, dry environment; away from sources of extreme heat, sparks and high electrical energy. Always place or store any airbag on a surface with its trim cover or airbag cushion side facing up, to minimize movement in case of an accidental deployment.

SERVICE AFTER A SUPPLEMENTAL RESTRAINT DEPLOYMENT

Any vehicle which is to be returned to use following a Supplemental Restraint System (SRS) component deployment must have the deployed restraints replaced. In addition, the following guidelines MUST be observed.

1. Following ANY major vehicle impact damage in the vicinity of an impact sensor or the ORC - It is critical that the mounting surfaces and mounting brackets for the Occupant Restraint Controller (ORC), front impact sensors and side impact sensors located within the proximity of the impact damage be closely inspected and restored to their original conditions. Because the ORC and each impact sensor are used by the SRS to monitor or confirm the direction and severity of a vehicle impact, improper orientation or insecure fastening of these components may cause airbags not to deploy when required, or to deploy when not required.
2. If the driver airbag is deployed - If the driver airbag has been deployed, the clockspring and the steering column must be replaced.
3. If the passenger airbag is deployed - If the passenger airbag has been deployed, the instrument panel trim cover must also be replaced.
4. If a seat belt tensioner is deployed - The seat belt tensioners are deployed in conjunction with the front airbags, but can also be deployed with side curtain airbags. The seat belt tensioners must be replaced if either front airbag has been deployed, and must be inspected if either side curtain airbag has been deployed.
5. If a side curtain airbag is deployed - If a side curtain airbag has been deployed, the headliner as well as the upper A, B and C-pillar trim on the same side of the vehicle as the deployed airbag must also be replaced. On vehicles with an optional sunroof, the sunroof drain tubes and hoses must be closely inspected following a side curtain airbag deployment.

The components identified with the deployed SRS components in the preceding list are not intended for reuse and will be damaged or weakened as a result of an airbag deployment, which may or may not be obvious during a visual inspection. All other vehicle components should be closely inspected following any SRS component deployment, but are to be replaced only as required by the extent of the visible damage incurred.

AIRBAG SQUIB STATUS

Multistage airbags with multiple initiators (squibs) must be checked to determine that all squibs were used during the deployment event. The driver and passenger airbags in this vehicle are deployed by electrical signals generated by the Occupant Restraint Controller (ORC) through the driver or passenger squib 1 and squib 2 circuits to the two initiators in the airbag inflators. Typically, both initiators are used and all potentially hazardous chemicals are burned during an airbag deployment event. However, it is possible for only one initiator to be used; therefore, it is always necessary to confirm that both initiators have been used in order to avoid the improper handling or disposal of potentially live pyrotechnic or hazardous materials. The following procedure should be performed using a diagnostic scan tool to verify the status of both airbag squibs before either deployed airbag is removed from the vehicle for disposal.

1. Be certain that the diagnostic scan tool contains the latest version of the proper diagnostic software. Connect the scan tool to the 16-way Data Link Connector (DLC). The DLC is located on the driver side lower edge of the instrument panel, outboard of the steering column.
2. Turn the ignition switch to the ON position.
3. Using the scan tool, read and record the active (current) Diagnostic Trouble Code (DTC) data.

Using the active DTC information, refer to the Airbag Squib Status table to determine the status of both driver and passenger airbag squibs.

Note. If none of the Driver or Passenger Squib 1 or 2 open are active codes, the status of the airbag squibs is unknown. In this case the airbag should be handled and disposed of as if the squibs were both live.

Scheme 37

Following a Supplemental Restraint System (SRS) component deployment, the vehicle interior will contain a powdery residue. This residue consists primarily of harmless particulate by-products of the small pyrotechnic charge that initiates the propellant used to deploy a SRS component. However, this residue may also contain traces of sodium hydroxide powder, a chemical by-product of the propellant material that is used to generate the inert gas that inflates the airbag. Since sodium hydroxide powder can irritate the skin, eyes, nose, or throat, be certain to wear safety glasses, rubber gloves, and a long-sleeved shirt during cleanup.

Scheme 38

1. Begin the cleanup by using a vacuum cleaner to remove any residual powder from the vehicle interior. Clean from outside the vehicle and work your way inside, so that you avoid kneeling or sitting on a non-cleaned area.
2. Be certain to vacuum the heater and air conditioning outlets as well. Run the heater and air conditioner blower on the lowest speed setting and vacuum any powder expelled from the outlets. CAUTION: Deployed front airbags having two initiators (squibs) in the airbag inflator may or may not have live pyrotechnic material within the inflator. Do not dispose of these airbags unless you are certain of complete deployment. Refer to the «AIRBAG SQUIB STATUS»(ref-457806-S36821126102012030200000) heading within this information. All damaged, ineffective, or non-deployed Supplemental Restraint System (SRS) components which are replaced on vehicles are to be handled and disposed of properly. If an airbag or seat belt tensioner unit is ineffective or damaged and non-deployed, refer to the Hazardous Substance Control System for information regarding the potentially hazardous properties of the subject component and the proper safe handling procedures. Then dispose of all non-deployed and deployed airbags and seat belt tensioners in a manner consistent with state, provincial, local and federal regulations.
3. Next, remove the deployed SRS components from the vehicle. Refer to the appropriate service removal procedures.
4. You may need to vacuum the interior of the vehicle a second time to recover all of the powder.

REPAIR PROCEDURE

Scheme 39

Scheme 40

Scheme 41

Scheme 42

1. Remove 13 millimeters (0.50 inch) of insulation from each wire that needs to be spliced.
2. Place a piece of adhesive sealant-lined heat shrink tubing (Part Number 04778570 or equivalent) over the wire on one side of the splice. Be certain the length of tubing will be sufficient to cover and seal the entire repair area.
3. Place the strands of the wires being spliced so that they are overlapping each other within the splice band (1).
4. Using a crimping tool (1) (MOPAR® Part Number 05019912AA, Miller Special Tool Number (special tool #10042, Crimper, Wire/Terminal) or equivalent) crimp the splice band and wires together securely. CAUTION: Never use acid core solder for electrical wiring repairs.
5. Using rosin core type solder (1) only and a suitable soldering iron (3), solder the wire and splice band connection (2) together.
6. Center the heat shrink tubing (2) over the splice joint repair and heat using a suitable heat gun. Heat the joint until the tubing is tightly sealed and sealant (1) begins to ooze out of both ends of the tubing.

FRONT CENTER AND CENTER ANCHOR

Note. A fixed position front center seat belt buckle is located on the left side of the front center seat section (20 percent) used on all vehicles with a split bench front seat. Standard cab vehicles have a unique, fixed position, black, keyed, lower anchor buckle for the three-point center seat belt lower anchor located on the right side of the front center seat section. Quad or crew cab and mega cab vehicles have a fixed position front center seat lap belt located on the right side of the front center seat section. The following procedure applies to the front center seating position belt buckle, the lap belt or the anchor buckle. The three-point front center seat belt and retractor unit is only used on standard cab vehicles. Refer to RETRACTOR, Seat Belt , Removal .

Scheme 43

1. Move the adjacent right or left front outboard seat section (40 percent) to its most forward position and tilt the seat back forward for easiest access to the lower anchor of the front center seat belt buckle, lap belt or anchor buckle (1).
2. On standard cab vehicles only, if equipped, remove the stowage tray from the rear floor panel behind the seat. Refer to «BIN, Storage , Removal»(ref-457777-S00271888692012030200000) .
3. From behind the front seat, remove the screw (5) that secures the lower anchor of the front center seat belt buckle, lap belt or anchor buckle to the center seat support bracket (3).
4. From the front of the front seat, reach between the side of the center seat cushion (6) and the adjacent right or left front outboard seat cushion to access and remove the seat belt buckle, lap belt or anchor buckle through the elastic strap (2) on the side of the center seat cushion.
5. Remove the front center seat belt buckle, lap belt or anchor buckle unit from the front seat.

FRONT OUTBOARD

Note. A traveling front outboard seat belt buckle is located on the inboard side of each front outboard split bench seat section (40 percent) or bucket seat used on all vehicles. The seat belt buckle on the driver side front seat for all vehicles also includes a seat belt switch.

Scheme 44

1. Move the right or left front outboard split bench seat section or bucket seat to its most rearward position and tilt the seat back forward for easiest access to the front outboard seat belt buckle lower anchor.
2. On standard cab vehicles only equipped with a split bench seat, also move the outboard seat section opposite the side from which the buckle is to be removed to its most forward position and tilt the seat back forward.
3. On standard cab vehicles only, if equipped, remove the stowage tray from the rear floor panel behind the seat. Refer to «BIN, Storage , Removal»(ref-457777-S00271888692012030200000) .
4. On the driver side only, from behind the front seat disconnect the seat belt switch pigtail wire connector (4) from the seat wire harness take out and connector located on the lower inboard side of the seat cushion frame just forward of the buckle lower anchor.
5. From behind the front seat, remove the screw (3) that secures the buckle (1) lower anchor to the lower inboard side of the seat cushion frame.
6. From the front of the front seat, reach between the center seat cushion (2) or center floor console and the right or left front outboard seat cushion to access and remove the front outboard seat belt buckle from the seat.

REAR CENTER ANCHOR AND RIGHT OUTBOARD - MEGA CAB

Note. The rear seat right outboard occupant buckle is serviced as a unit with an anchor bracket. The lower anchor of the rear center seat belt and retractor is also secured to the anchor bracket with a screw so that it can be removed from the anchor bracket and serviced separately from the buckle. Refer to RETRACTOR, Seat Belt , Removal .

Scheme 45

Scheme 46

1. Fold the 60 percent section of the rear seat back (2) down onto the seat cushion in the cargo storage position, then lift and prop open the seat back filler panel (3) as necessary for easiest access to the rear center seat belt lower anchor and right outboard buckle anchor bracket.
2. Remove the screw (7) that secures the center seat belt lower anchor to the anchor bracket (3) and temporarily secure the belt lower anchor to keep it from being pulled from between the seat back (1) and the seat cushion (2) by the retractor.
3. Remove and discard the screw (6) that secures the buckle anchor bracket and the rear seat rear mounting bracket (5) to the rear floor panel.
4. Remove the nut (4) that secures the buckle anchor bracket to the stud on the rear seat rear mounting bracket.
5. Disengage the buckle from between the seat cushion and the seat back, then remove the anchor bracket and buckle from behind the rear seat as a unit.

REAR CENTER AND LEFT OUTBOARD - MEGA CAB

Scheme 47

1. Fold both the 40 percent section and the 60 percent section of the rear seat back (1 and 2) down onto the seat cushion in the cargo storage position, then lift and prop open the seat back filler panels (3 and 4) as necessary for easiest access to the rear center and left outboard seat belt buckle anchor bracket.
2. Remove the four screws (2) that secure the stabilizer bracket (4) to the two inboard seat hinge brackets.
3. Remove the stabilizer bracket from between the seat hinge brackets.
4. Remove and discard the screw (3) that secures the buckle anchor bracket (5) and the rear seat rear mounting bracket to the rear floor panel.
5. Remove the nut (1) that secures the buckle anchor bracket to the stud on the rear seat rear mounting bracket.
6. Disengage the buckles from between the seat cushion and the seat back, then remove the anchor bracket and buckles from between the rear seat sections as a unit.

REAR - QUAD OR CREW CAB

Note. The following removal procedure covers service of the rear seat center and left outboard seat belt buckle units. The rear seat right outboard seat belt buckle is serviced as a unit with the rear seat center seat belt and retractor assembly. Refer to RETRACTOR, Seat Belt , Removal .

Scheme 48

1. Lift up the rear seat cushion into its stowed position against the rear seat back.
2. Remove the screw (2) that secures either the center (4) or the left outboard (3) occupant buckle unit to the rear floor panel near the base of the cab back panel (1). On vehicles with the optional 60/40 split rear bench, the screw that secures the buckle unit also secures one of the rear seat mounting brackets to the rear floor panel.
3. Remove the center or left outboard occupant buckle unit from the rear floor panel or from the rear seat mounting bracket.

Note. A fixed position front center seat belt buckle is located on the left side of the front center seat section (20 percent) used on all vehicles with a split bench front seat. Standard cab vehicles have a unique, fixed position, black, keyed, lower anchor buckle for the three-point center seat belt lower anchor located on the right side of the front center seat section. Quad or crew cab and mega cab vehicles have a fixed position front center seat lap belt located on the right side of the front center seat section. The following procedure applies to the front center seating position belt buckle, the lap belt or the anchor buckle. The three-point front center seat belt and retractor unit is only used on standard cab vehicles. Refer to RETRACTOR, Seat Belt , Installation .

Scheme 49

1. From the front of the front seat, position the front center seat belt buckle, lap belt or anchor buckle unit (1) through the elastic strap (2) on the side of the center seat cushion (6).
2. From the front of the front seat, reach between the side of the center seat cushion and the adjacent right or left front outboard seat cushion to route the lower anchor of the seat belt buckle, lap belt or anchor buckle unit down between the side of the center seat cushion and the adjacent right or left front outboard seat cushion. Be certain that the belt webbing is not twisted.
3. From behind the front seat, position the lower anchor of the seat belt buckle, lap belt or anchor buckle to the center seat support bracket (3). Be certain to engage the anti-rotation tab on the lower anchor into the corresponding hole in the center seat support bracket.
4. Install and tighten the screw (5) that secures the lower anchor of the seat belt buckle, lap belt or anchor buckle to the center seat support bracket. Tighten the screw to 39 N.m (29 ft. lbs.).
5. On standard cab vehicles only, if equipped, reinstall the stowage tray onto the rear floor panel behind the seat. Refer to «BIN, Storage , Installation»(ref-457777-S37567961132012030200000) .

Note. A traveling front outboard seat belt buckle is located on the inboard side of each front outboard split bench seat section (40 percent) or bucket seat used on all vehicles. The seat belt buckle on the driver side front seat for all vehicles also includes a seat belt switch.

1. From the front of the front seat, reach between the center seat cushion (2) or center floor console and the right or left front outboard seat cushion to position the front outboard seat belt buckle to the seat.
2. From behind the front seat, position the front outboard seat belt buckle lower anchor to the lower inboard side of the seat cushion frame. Be certain to engage the anti-rotation tab on the lower anchor into the corresponding hole in the seat cushion frame.
3. Install and tighten the screw (3) that secures the front outboard seat belt buckle lower anchor to the seat cushion frame. Tighten the screw to 25 N.m (18 ft. lbs.).
4. On the driver side only, reconnect the seat belt switch pigtail wire connector (4) to the seat wire harness take out and connector located on the lower inboard side of the seat cushion frame just forward of the buckle lower anchor.
5. On standard cab vehicles only, if equipped, reinstall the stowage tray onto the rear floor panel behind the seat. Refer to «BIN, Storage , Installation»(ref-457777-S37567961132012030200000) .

Note. The rear seat right outboard occupant buckle is serviced as a unit with a mounting bracket. The lower anchor of the rear center seat belt and retractor is also secured to the mounting bracket with a screw so that it can be removed from the mounting bracket and serviced separately from the buckle. Refer to RETRACTOR, Seat Belt , Removal .

1. Engage the buckle unit between the seat cushion (2) and the seat back (1), then position the anchor bracket (3) to the rear seat rear mounting bracket (5) behind the rear seat as a unit. Be certain to engage the anti-rotation tab on the anchor bracket into the clearance hole in the mounting bracket.
2. Install and tighten the nut (4) that secures the buckle anchor bracket to the stud on the rear seat rear mounting bracket. Tighten the nut to 23 N.m (17 ft. lbs.).
3. Install and tighten a new screw (6) to secure the buckle anchor bracket and the rear seat rear mounting bracket to the rear floor panel. Tighten the screw to 47 N.m (35 ft. lbs.).
4. Route the center seat belt lower anchor between the seat back and the seat cushion and position it to the anchor bracket. Be certain the belt webbing is not twisted between the retractor and the anchor bracket.
5. Install and tighten the screw (7) that secures the seat belt lower anchor to the anchor bracket. Tighten the screw to 40 N.m (30 ft. lbs.).
6. Restore the 60 percent seat back filler panel and the seat back to their previous positions.

1. Position the buckles and anchor bracket (5) between the inboard rear seat hinge brackets and engage the buckle units between the seat cushion and the seat back as a unit. Be certain to engage the anti-rotation tab on the anchor bracket into the clearance hole in the rear seat rear mounting bracket.
2. Install and tighten the nut (1) that secures the buckle anchor bracket to the stud on the rear seat rear mounting bracket. Tighten the nut to 23 N.m (17 ft. lbs.).
3. Install and tighten a new screw (3) to secure the buckle anchor bracket and the rear seat rear mounting bracket to the rear floor panel. Tighten the screw to 47 N.m (35 ft. lbs.).
4. Position the stabilizer bracket (4) between the two inboard rear seat hinge brackets.
5. Install and tighten the four screws (2) that secure the stabilizer bracket to the hinge brackets. Tighten the screws to 5 N.m (44 in. lbs.).
6. Restore both seat back filler panels and both seat backs to their previous positions.

Note. The following installation procedure covers service of the rear seat center and left outboard seat belt buckle units. The rear seat right outboard seat belt buckle is serviced as a unit with the rear seat center seat belt and retractor assembly. Refer to RETRACTOR, Seat Belt , Installation .

1. Position the center (4) or the left outboard (3) occupant buckle unit onto the rear floor panel or onto the rear seat mounting bracket near the base of the cab back panel (1). On vehicles with the optional 60/40 split rear bench, the screw that secures the buckle unit also secures one of the rear seat mounting brackets to the rear floor panel.
2. Install and tighten the screw (2) that secures the center or the left outboard occupant buckle unit to the rear floor panel. Tighten the screw to 39 N.m (29 ft. lbs.).
3. Restore the rear seat cushion to its seating position.

Scheme 50

The clockspring (5) for this vehicle is secured near the top of the steering column below the steering wheel. The clockspring also includes an integral, internal turn signal cancel cam, a Steering Angle Sensor (SAS) and, on vehicles equipped with the optional heated steering wheel, a set of internal slip rings. All of these components are serviced as a unit with the clockspring. The clockspring also supports the multi-function switch (1), the Steering Control Module (SCM) internal to the multi-function switch housing (2) and a blank filler (7) for, or the optional adjustable pedal switch, which are secured to the clockspring mounting bracket with integral keyways and latch feature provisions. The multi-function switch, adjustable pedal switch blank filler or the adjustable pedal switch are available for individual service replacement. When combined, these components are sometimes referred to as the Steering Column Control Module (SCCM).

The clockspring case includes integral tabs at the top and bottom for mounting the unit to the steering column housing with two screws, as well as integral provisions for mounting and supporting the multi-function switch, adjustable pedal switch, SAS and heated steering wheel slip rings. The SAS integral to the clockspring includes an electronic circuit board and a microprocessor, which allows it to communicate with other electronic modules in the vehicle over the Controller Area Network (CAN) data bus. The SAS circuitry is contained within a flat, molded plastic case that is secured to the lower surface of the clockspring case that hangs below the steering column.

Within the plastic clockspring case is a spool-like molded plastic rotor with a large exposed hub and an integral turn signal cancel cam. The upper surface of the rotor hub has a large center hole, an engagement dowel or drive pin, a single sleeve containing two short driver airbag squib pigtail wires with connectors, and a connector receptacle that faces toward the steering wheel. On vehicles equipped with the optional heated steering wheel, a third heated steering wheel pigtail wire and connector exits the upper surface of the rotor.

Service replacement clocksprings are shipped pre-centered and with a molded plastic locking pin (4) that snaps into a receptacle on the rotor. The locking pin secures the centered clockspring rotor to the clockspring case and the SAS during shipment and handling, but must be removed from the clockspring after it is installed on the steering column. The locking pin is a one time component and cannot be reinstalled once it has been removed. The clockspring must be replaced if proper centering has been compromised or the tape may be damaged and Diagnostic Trouble Codes (DTCs) or faults may be set within the SAS.

Scheme 51

The lower surface of the clockspring case (1) facing toward the instrument panel includes two receptacles on the left for mounting the multi-function switch (2) and the optional adjustable pedal switch (3). There are two integral connector receptacles (4) on the left lower corner of the clockspring case. Clocksprings with a SAS (5) also have a dedicated connector (6) near the right lower corner of that unit. Vehicles equipped with the optional heated steering wheel also have a dedicated connector (7) to the internal slip rings on the upper right corner of the clockspring case.

Within the plastic case and wound around the rotor spool is a long ribbon-like tape that consists of several thin copper wire leads sandwiched between two thin plastic membranes. The outer end of the tape terminates at the connector receptacles that face the instrument panel, while the inner end of the tape terminates at the driver airbag squib pigtail wires and connector receptacle on the hub of the clockspring rotor that face the steering wheel.

The clockspring cannot be repaired. If damaged, ineffective or if the driver airbag has been deployed, the clockspring must be replaced.

STANDARD PROCEDURE - CLOCKSPRING CENTERING

Like the clockspring in a timepiece, the clockspring tape has travel limits and can be damaged by being wound too tightly during full stop-to-stop steering wheel rotation. To prevent this from occurring, the clockspring is centered when it is installed on the steering column. Centering the clockspring indexes the clockspring tape and the SAS integral to the clockspring to the movable steering components so that the tape can operate within its designed travel limits and the SAS can accurately monitor and communicate steering wheel inputs. However, if the clockspring is removed from the steering column or if the steering shaft is disconnected from the steering gear, the clockspring spool and the SAS can change position relative to the movable steering components and relative to each other. The clockspring must be replaced if proper centering has been compromised or the tape may be damaged and Diagnostic Trouble Codes (DTC) or faults may be set within the SAS.

Service replacement clocksprings are shipped pre-centered and with a plastic locking pin installed. This locking pin should not be removed until the clockspring has been installed on the steering column. If the locking pin is removed before the clockspring is installed on a steering column, the clockspring must be replaced with a new unit. Proper clockspring installation must also be confirmed by viewing the SAS Menu Item, Data Display function using a diagnostic scan tool.

MODULE

Scheme 52

Scheme 53

1. Disconnect and isolate the battery negative cable. Wait two minutes for the system capacitor to discharge before further service.
2. Remove the protective cover from the Occupant Restraint Controller (ORC) (1). Refer to «CONTROLLER, Occupant Restraint , Removal»(ref-457806-S17044736412012030200000) .
3. Disconnect the instrument panel and body wire harness connectors (3) for the ORC from the ORC connector receptacles (2 and 4) located on the forward facing side of the module. To disconnect the connectors from the ORC: Slide the red Connector Position Assurance (CPA) lock on the top of the connector to the side. Depress the edge of the CPA lock closest to the ORC to release the connector latch tab and pull the connector straight away from the ORC connector receptacle.
4. Remove the three nuts (2) that secure the ORC (1) to the studs of the ORC mount (3) welded onto the top of the floor panel transmission tunnel.
5. Remove the ORC from the ORC mount.

COVER

Scheme 54

1. Disconnect and isolate the battery negative cable. Wait two minutes for the system capacitor to discharge before further service.
2. On vehicles equipped with front bucket seats, remove the front floor console from the vehicle. Refer to «CONSOLE, Floor , Removal»(ref-457777-S37024560332012030200000) . NOTE: The front bench seat assembly must be unfastened from the floor panel, but need not be removed from the vehicle for access to the Occupant Restraint Controller (ORC) cover for service.
3. On vehicles equipped with a front bench seat, detach the front seat from the floor panel. Refer to «SEAT, Front , Removal»(ref-457777-S40693473282012030200000) «SEAT, Front Center , Removal»(ref-457777-S38332699542012030200000) .
4. Using a trim stick or another suitable wide flat-bladed tool, gently pry the latch feature on either side of the ORC cover (1) away from the base of the ORC (2) far enough to disengage the cover from the module.
5. Remove the ORC cover from over the ORC.

1. Position the Occupant Restraint Controller (ORC) (1) over the three studs of the ORC mount (3) welded onto the top of the floor panel transmission tunnel. When the ORC is correctly positioned, the arrow on the ORC label will be pointed forward in the vehicle.
2. Install and tighten the three nuts (2) that secure the ORC to the studs of the ORC mount that is welded onto the floor panel transmission tunnel. Tighten the nuts to 12 N.m (9 ft. lbs.).
3. Reconnect the instrument panel and body wire harness connectors (3) for the ORC (1) to the ORC connector receptacles (2 and 4) located on the forward facing side of the module. Be certain that the latches and the red Connector Position Assurance (CPA) locks on both connectors are each fully engaged.
4. Reinstall the ORC cover onto the ORC. Refer to «CONTROLLER, Occupant Restraint , Installation»(ref-457806-S02534790862012030200000) .
5. Do not reconnect the battery negative cable at this time. The Supplemental Restraint System (SRS) Verification Test procedure should be performed following service of any SRS component. Refer to «Standard Procedure»(ref-457806-S25050531802012030200000) .

1. Position the ORC cover (1) over the Occupant Restraint Controller (ORC) (2).
2. Align the latch feature on each side of the ORC cover with the notch in each side at the base of the ORC housing.
3. Using hand pressure, press firmly and evenly downward on the ORC cover until each latch feature is fully engaged with the ORC housing.
4. On vehicles equipped with a front bench seat, reinstall the front seat onto the floor panel. Refer to «SEAT, Front , Installation»(ref-457777-S41622774832012030200000) «SEAT, Front Center , Installation»(ref-457777-S08268480482012030200000) .
5. On vehicles equipped with front bucket seats, reinstall the front floor console into the vehicle. Refer to «CONSOLE, Floor , Installation»(ref-457777-S26995067582012030200000) .
6. Reconnect the battery negative cable.

Scheme 55

The seat belt retractors (1) used in all seating positions include an inertia-type, emergency locking mechanism as standard equipment. However, the retractor locking mechanisms for all seating positions except the driver side front position are mechanically switchable from an Emergency Locking Retractor (ELR) to an Automatic Locking Retractor (ALR). The primary function of this feature is to securely accommodate a child seat in any seating position of the vehicle without the need for a self-cinching seat belt tip half latch plate unit or another supplemental device that would be required to prevent the seat belt webbing from unwinding freely from the retractor spool of an inertia-type emergency locking retractor mechanism.

The emergency and automatic locking mechanisms are integral to the seat belt and retractor unit and are concealed beneath a molded plastic cover (2) located on one side of the retractor spool. These locking mechanisms cannot be adjusted or repaired and, if ineffective or damaged, the entire seat belt and retractor unit must be replaced.

CENTER - STANDARD CAB

Note. A front center three-point seat belt and retractor is used only on standard cab vehicles. Quad or crew cab and mega cab vehicles with a front bench seat have a two-point lap belt in the front center seating position. Refer to BUCKLE, Seat Belt , Removal .

Note. All seat belt retractors except the driver side front retractor include a switchable automatic locking mechanism. Refer to RETRACTOR, Seat Belt , Description .

Scheme 56

Scheme 57

1. Reach between the center of the front seat cushion and front seat back to access and unbuckle the front center seat belt lower anchor latch plate from the unique black, keyed lower anchor buckle. Use an ignition key or a small screwdriver to depress the small white release button on the anchor buckle.
2. Move the front seat to its most forward position for easiest access to the front center seat belt and retractor unit.
3. Remove the stowage tray from the rear floor panel behind the seat. Refer to «BIN, Storage , Removal»(ref-457777-S00271888692012030200000) .
4. Using a trim stick or another suitable wide flat-bladed tool, gently pry at each side of the front center seat belt bezel (5) on the cab back trim panel (1) to release the snap features that secure the bezel to the panel.
5. Remove the bezel from the webbing of the front center seat belt (4).
6. Remove the trim from the cab back panel. Refer to «PANEL, Cab Back Trim , Removal»(ref-457777-S15425953532012030200000) .
7. Remove the two screws (3) that secure the belt bracket (2) of the front center seat belt (7) to the body bracket (1) on the upper cab back panel (8) reinforcement.
8. Remove the belt bracket of the front center seat belt from the body bracket on the upper cab back panel reinforcement.
9. Remove the two screws (4) that secure the front center seat belt retractor bracket (5) to the floor panel (6) near the base of the cab back panel.
10. Remove the front center seat belt and retractor unit from the floor panel.

FRONT OUTBOARD - EXCEPT STANDARD CAB

Note. The following procedure is for replacement of an ineffective or damaged seat belt and retractor unit. The front outboard retractors also include a seat belt tensioner. If the front seat belt or retractor is ineffective or damaged, but the seat belt tensioner is not deployed, review the recommended procedures for Handling Non-Deployed Supplemental Restraints. Refer to Standard Procedure . If the seat belt tensioner has been deployed, review the recommended procedures for Service After A Supplemental Restraint Deployment before removing the unit from the vehicle. .

Note. All seat belt retractors except the driver side front retractor include a switchable automatic locking mechanism. Refer to RETRACTOR, Seat Belt , Description .

Scheme 58

Scheme 59

Scheme 60

Scheme 61

1. Adjust the front seat to its most forward position for easiest access to the front seat belt lower anchor (3) and the lower B-pillar trim.
2. Disconnect and isolate the battery negative cable. Wait two minutes for the system capacitor to discharge before further service.
3. On the passenger side only, remove the trim cover from the front seat riser as necessary to access the front seat belt lower anchor. Refer to «SEAT, Front , Removal»(ref-457777-S40693473282012030200000) «SEAT, Front Center , Removal»(ref-457777-S38332699542012030200000) .
4. Remove the screw (2) that secures the lower anchor (3) to the floor panel (4) near the base of the B-pillar (1).
5. Firmly grasp the top of the trim cover (3) for the front seat belt turning loop height adjuster (1) on the inside of the upper B-pillar and pull it away from the height adjuster far enough unsnap it, then disengage the lower snap features of the trim cover from the adjuster and discard. The trim cover is a one time component and is not intended for reuse.
6. Remove the screw (4) that secures the seat belt turning loop (5) to the height adjuster on the upper B-pillar.
7. Remove the seat belt turning loop from the height adjuster.
8. Remove the lower trim from the inside of the B-pillar. Refer to «PANEL, B-Pillar Trim, Lower , Removal»(ref-457777-S09741327532012030200000) .
9. Disengage the two clips that secure the belt web guide (2) to the B-pillar (1).
10. Remove the screw (3) that secures the upper retractor (6) bracket to the B-pillar.
11. Remove the screw (5) that secures the lower retractor bracket to the B-pillar.
12. Disengage the locating tab on the upper retractor bracket from the clearance hole in the inner B-pillar.
13. Disconnect the yellow connector (2) of the body wire harness (3) from the seat belt tensioner initiator on the retractor (1).
14. Remove the front outboard seat belt and retractor from the vehicle as a unit.

OUTBOARD - STANDARD CAB

Note. The following procedure is for replacement of an ineffective or damaged seat belt and retractor unit. The front outboard retractors also include a seat belt tensioner. If the front seat belt or retractor is ineffective or damaged, but the seat belt tensioner is not deployed, review the recommended procedures for Handling Non-Deployed Supplemental Restraints. Refer to Standard Procedure . If the seat belt tensioner has been deployed, review the recommended procedures for Service After A Supplemental Restraint Deployment before removing the unit from the vehicle. .

Scheme 62

Scheme 63

Scheme 64

1. Adjust the front seat to its most forward position for easiest access to the front seat belt lower anchor (4) and the lower B-pillar trim (2).
2. Disconnect and isolate the battery negative cable. Wait two minutes for the system capacitor to discharge before further service.
3. Remove the screw (3) that secures the lower anchor to the inner B-pillar (1).
4. Remove the lower trim from the inside of the B-pillar. Refer to «PANEL, B-Pillar Trim, Lower , Removal»(ref-457777-S09741327532012030200000) .
5. Grasp the upper edge of the lower anchor cover and pull upward to unsnap it from the front seat cushion outboard side shield.
6. Firmly grasp the top of the trim cover (3) for the front seat belt turning loop height adjuster (1) on the inside of the upper B-pillar and pull it away from the height adjuster far enough unsnap it, then disengage the lower snap features of the trim cover from the adjuster and discard. The trim cover is a one time component and is not intended for reuse.
7. Remove the screw (4) that secures the seat belt turning loop (5) to the height adjuster on the upper B-pillar.
8. Remove the seat belt turning loop from the height adjuster.
9. Disengage the two clips that secure the belt web guide (2) to the B-pillar (6).
10. Remove the screw (3) that secures the upper retractor (4) bracket to the B-pillar.
11. Remove the screw (5) that secures the lower retractor bracket to the B-pillar.
12. Disengage the locating tab on the upper retractor bracket from the clearance hole in the inner B-pillar.
13. Remove the front outboard seat belt and retractor from the B-pillar as a unit.
14. Disconnect the yellow connector (2) of the body wire harness (3) from the seat belt tensioner initiator on the retractor (1).
15. Remove the front outboard seat belt and retractor from the vehicle as a unit.

REAR CENTER - MEGA CAB

Note. All seat belt retractors except the driver side front retractor include a switchable automatic locking mechanism. Refer to RETRACTOR, Seat Belt , Description .

Scheme 65

Scheme 66

1. Fold the 60 percent section of the rear seat back (2) down onto the seat cushion in the cargo storage position, then lift and prop open the seat back filler panel (3) as necessary for easiest access to the rear center seat belt lower anchor and right outboard buckle anchor bracket.
2. Remove the screw (7) that secures the center seat belt lower anchor to the anchor bracket (3) and, from the front of the seat back, pull the belt lower anchor out from between the seat back (1) and the seat cushion (2).
3. Remove the two screws (3) that secure the bezel (2) to the top of the 60 percent section of the rear seat back (1).
4. Remove the bezel from the webbing of the rear center seat belt.
5. Remove the trim cover from the 60 percent section of the rear seat back. Refer to «COVER, Seat Back, Mega Cab Rear , Removal»(ref-457777-S37725689292012030200000) .
6. Remove the two screws (6) that secure the belt bracket (1) of the rear center seat belt to the top of the seat back frame (3).
7. Disengage the belt bracket of the rear center seat belt from the seat back frame.
8. Remove the screw (4) that secures the rear center seat belt retractor to the seat back frame.
9. Remove the seat belt and retractor from the rear seat back as a unit.

REAR CENTER - QUAD OR CREW CAB

Note. The rear center seat belt and retractor is secured to a mounting bracket that includes the right outboard occupant seat belt buckle. The rear right outboard occupant buckle is available for service only as a unit with the center seat belt and retractor.

Note. All seat belt retractors except the driver side front retractor include a switchable automatic locking mechanism. Refer to RETRACTOR, Seat Belt , Description .

Scheme 67

1. Lift up the rear seat cushion into its stowed position against the rear seat back.
2. Remove the screw (5) that secures the center seat belt lower anchor (7) and the left side of the seat belt retractor (6) mounting bracket to the rear floor panel (8).
3. Remove the rear seat from the vehicle. On vehicles with the optional 60/40 split rear bench, only the 60 percent section (right side) of the rear seat must be removed. Refer to «SEAT, Rear , Removal»(ref-457777-S40451389112012030200000) and «SEAT, Mega Cab Rear , Removal»(ref-457777-S34472900182012030200000) .
4. Lift upward on the forward edge of the rear center seat belt bezel (1) at the top of the cab back panel to release the snap features that secure the bezel to the belt bracket (3).
5. Remove the bezel from the webbing of the rear center seat belt.
6. Remove the two screws (2) that secure the belt bracket of the rear center seat belt to the body bracket (4) on the upper cab back panel reinforcement.
7. Remove the belt bracket of the rear center seat belt from the body bracket.
8. Remove the screw (10) that secures the right side of the seat belt retractor mounting bracket and the right outboard occupant buckle (9) unit to the rear floor panel near the base of the cab back panel.
9. Remove the rear center seat belt and retractor unit from the vehicle.

REAR OUTBOARD

Note. All seat belt retractors except the driver side front retractor include a switchable automatic locking mechanism. Refer to RETRACTOR, Seat Belt , Description .

Scheme 68

Scheme 69

1. Remove the rear seat from the vehicle. Refer to «SEAT, Rear , Removal»(ref-457777-S40451389112012030200000) and «SEAT, Mega Cab Rear , Removal»(ref-457777-S34472900182012030200000) .
2. Remove the screw (5) that secures the seat belt lower anchor (6) to the base of the inner C-pillar.
3. Unsnap the trim cover (3) from the front seat belt turning loop (2) and discard. The trim cover is a one time component and is not intended for reuse.
4. Remove the screw (4) that secures the seat belt turning loop to the upper C-pillar.
5. Remove the seat belt turning loop from the upper C-pillar.
6. Remove the upper trim (1) from the inside of the C-pillar. Refer to «PANEL, C-Pillar Trim, Upper , Removal»(ref-457777-S22028560802012030200000) .
7. Remove the lower trim (2) from the inside of the C-pillar. Refer to «PANEL, C-Pillar Trim, Lower , Removal»(ref-457777-S38153746222012030200000) .
8. Disengage the two clips that secure the belt web guide (5) to the inner C-pillar.
9. Remove the screw (3) that secures the lower bracket of the retractor (4) to the C-pillar.
10. Disengage the hooks on the upper retractor bracket from the slots in the C-pillar above the retractor mounting hole.
11. Remove the rear outboard seat belt and retractor from the C-pillar as a unit.

Note. A front center three-point seat belt and retractor is used only on standard cab vehicles. Quad or crew cab and mega cab vehicles with a front bench seat have a two-point lap belt in the front center seating position. Refer to BUCKLE, Seat Belt , Installation .

Note. All seat belt retractors except the driver side front retractor include a switchable automatic locking mechanism. Refer to RETRACTOR, Seat Belt , Description .

1. Position the front center seat belt and retractor unit (5) to the floor panel (6) at the base of the cab back panel (8) to the right of center.
2. Install and tighten the two screws (4) that secure the front center seat belt retractor bracket to the floor panel near the base of the cab back panel. Tighten the screws to 39 N.m (29 ft. lbs.).
3. Position the belt bracket (2) of the front center seat belt (7) to the body bracket (1) on the upper cab back panel reinforcement.
4. Install and tighten the two screws (3) that secure the belt bracket of the front center seat belt to the body bracket on the upper cab back panel reinforcement. Tighten the screws to 20 N.m (15 ft. lbs.).
5. Reinstall the trim (1) onto the cab back panel. Refer to «PANEL, Cab Back Trim , Installation»(ref-457777-S21863031712012030200000) .
6. Route the webbing of the front center seat belt (4) through the bezel (5) and position the bezel to the belt opening near the top of the cab back trim panel.
7. Using hand pressure, press firmly and evenly on each side of the front center seat belt bezel until it snaps into place on the cab back trim panel.
8. Reinstall the stowage tray onto the rear floor panel behind the seat. Refer to «BIN, Storage , Installation»(ref-457777-S37567961132012030200000) .
9. Reach between the center of the front seat cushion and front seat back to access and buckle the front center seat belt lower anchor latch plate to the unique black, keyed lower anchor buckle.

Note. The following procedure is for replacement of an ineffective or damaged seat belt and retractor unit. The front outboard retractors also include a seat belt tensioner. If the front seat belt or retractor is ineffective or damaged, but the seat belt tensioner is not deployed, review the recommended procedures for Handling Non-Deployed Supplemental Restraints. Refer to Standard Procedure . If the seat belt tensioner has been deployed, review the recommended procedures for Service After A Supplemental Restraint Deployment before removing the unit from the vehicle. .

Note. All seat belt retractors except the driver side front retractor include a switchable automatic locking mechanism. Refer to RETRACTOR, Seat Belt , Description .

1. Position the front outboard seat belt and retractor (1) into the vehicle.
2. Reconnect the yellow connector (2) of the body wire harness (3) to the seat belt tensioner initiator on the retractor.
3. Position the seat belt (7) and retractor (6) to the inner B-pillar (1) as a unit. Be certain to engage the locating tab on the upper retractor bracket into the clearance hole in the B-pillar.
4. Loosely install the screw (5) that secures the lower retractor bracket to the B-pillar.
5. Install and tighten the screw (3) that secures the upper retractor bracket to the B-pillar. Tighten the screw to 12 N.m (106 in. lbs.).
6. Tighten the screw that secures the lower retractor bracket to the B-pillar. Tighten the screw to 39 N.m (29 ft. lbs.).
7. Position the belt web guide (2) to the B-pillar and use hand pressure to press it firmly and evenly until the two clips that secure it snap into place. Be certain that the seat belt webbing between the retractor and the web guide is not twisted.
8. Reinstall the lower trim (4) onto the inside of the B-pillar. Refer to «PANEL, B-Pillar Trim, Lower , Installation»(ref-457777-S31614994752012030200000) .
9. Position the seat belt turning loop (5) onto the height adjuster (1) on the upper B-pillar. Be certain that the seat belt webbing between the web guide and the turning loop is not twisted.
10. Install and tighten the screw (4) that secures the turning loop to the height adjuster. Tighten the screw to 39 N.m (29 ft. lbs.).
11. Position a new trim cover (3) over the top of the turning loop, then snap it into place. Engage the lower snap features first, then the upper snap features. The trim cover is a one time component and is not intended for reuse.
12. Position the seat belt lower anchor (3) to the mounting hole in the floor panel (4) near the base of the B-pillar (1) cushion frame. Be certain that the seat belt webbing between the turning loop and the lower anchor is not twisted.
13. Install and tighten the screw (2) that secures the lower anchor to the floor panel. Tighten the screw to 39 N.m (29 ft. lbs.).
14. Do not reconnect the battery negative cable at this time. The Supplemental Restraint System (SRS) Verification Test procedure should be performed following service of any SRS component. Refer to «Standard Procedure»(ref-457806-S25050531802012030200000) .

Note. The following procedure is for replacement of an ineffective or damaged seat belt and retractor unit. The front outboard retractors also include a seat belt tensioner. If the front seat belt or retractor is ineffective or damaged, but the seat belt tensioner is not deployed, review the recommended procedures for Handling Non-Deployed Supplemental Restraints. Refer to Standard Procedure . If the seat belt tensioner has been deployed, review the recommended procedures for Service After A Supplemental Restraint Deployment before removing the unit from the vehicle. .

1. Position the front outboard seat belt and retractor (1) into the vehicle.
2. Reconnect the yellow connector (2) of the body wire harness (3) to the seat belt tensioner initiator on the retractor.
3. Position the seat belt and retractor (4) to the inner B-pillar (6) as a unit. Be certain to engage the locating tab on the upper retractor bracket into the clearance hole in the B-pillar.
4. Loosely install the screw (5) that secures the lower retractor bracket to the B-pillar.
5. Install and tighten the screw (3) that secures the upper retractor bracket to the B-pillar. Tighten the screw to 12 N.m (106 in. lbs.).
6. Tighten the screw that secures the lower retractor bracket to the B-pillar. Tighten the screw to 39 N.m (29 ft. lbs.).
7. Position the belt web guide (2) to the B-pillar and use hand pressure to press it firmly and evenly until the two clips that secure it snap into place. Be certain that the seat belt webbing between the retractor and the web guide is not twisted.
8. Reinstall the lower trim (3) onto the inside of the B-pillar. Refer to «PANEL, B-Pillar Trim, Lower , Installation»(ref-457777-S31614994752012030200000) .
9. Position the seat belt turning loop (5) onto the height adjuster (1) on the upper B-pillar. Be certain that the seat belt webbing between the web guide and the turning loop is not twisted.
10. Install and tighten the screw (4) that secures the turning loop to the height adjuster. Tighten the screw to 39 N.m (29 ft. lbs.).
11. Position a new trim cover (3) over the top of the turning loop, then snap it into place. Engage the lower snap features first, then the upper snap features. The trim cover is a one time component and is not intended for reuse.
12. Position the seat belt lower anchor (4) to the mounting hole near the base of the inner B-pillar (1). Be certain that the seat belt webbing between the turning loop and the lower anchor is not twisted.
13. Install and tighten the screw (3) that secures the lower anchor to the B-pillar. Tighten the screw to 39 N.m (29 ft. lbs.).
14. Do not reconnect the battery negative cable at this time. The Supplemental Restraint System (SRS) Verification Test procedure should be performed following service of any SRS component. Refer to «Standard Procedure»(ref-457806-S25050531802012030200000) .

Note. All seat belt retractors except the driver side front retractor include a switchable automatic locking mechanism. Refer to RETRACTOR, Seat Belt , Description .

1. Position the rear center seat belt and retractor unit into the 60 percent section of the rear seat back frame (3). Be certain the tab (5) on the retractor bracket is engaged in the slot in the frame.
2. Install and tighten the screw (4) that secures the rear center seat belt retractor to the seat back frame. Tighten the screw to 60 N.m (44 ft. lbs.).
3. Position the belt bracket (1) of the rear center seat belt onto the top of the seat back frame. Be certain the tab (2) on the bracket is engaged in the slot in the frame.
4. Install and tighten the two screws (6) that secure the belt bracket of the rear center seat belt to the seat back frame. Tighten the screws to 60 N.m (44 ft. lbs.).
5. Reinstall the trim cover onto the 60 percent section of the rear seat back frame. Refer to «COVER, Seat Back, Mega Cab Rear , Installation»(ref-457777-S19801212742012030200000) .
6. Engage the rear center seat belt bezel (2) over the webbing of the rear center seat belt.
7. Position the bezel over the belt bracket on the top of the rear seat back (1).
8. Install and tighten the two screws (3) that secure the bezel to the belt bracket on the top of the rear seat back frame. Tighten the screws to 5 N.m (44 in. lbs.).
9. Route the center seat belt lower anchor between the seat back (1) and the seat cushion (2) and position it to the anchor bracket (3). Be certain the belt webbing is not twisted between the retractor and the anchor bracket.
10. Install and tighten the screw (7) that secures the seat belt lower anchor to the anchor bracket. Tighten the screw to 40 N.m (30 ft. lbs.).
11. Restore the 60 percent seat back filler panel and the seat back to their previous positions.

Note. The rear center seat belt and retractor is secured to a mounting bracket that includes the right outboard occupant seat belt buckle. The rear right outboard occupant buckle is available for service only as a unit with the center seat belt and retractor.

Note. All seat belt retractors except the driver side front retractor include a switchable automatic locking mechanism. Refer to RETRACTOR, Seat Belt , Description .

1. Position the rear center seat belt retractor (6) and right outboard occupant buckle unit (9) onto the rear floor panel (8) near the base of the cab back panel.
2. Loosely install the screw (10) that secures the right side of the seat belt retractor mounting bracket and the right outboard occupant buckle unit to the rear floor panel near the base of the cab back panel.
3. Position the belt bracket (3) of the rear center seat belt onto the body bracket (4) on the upper cab back panel reinforcement.
4. Install and tighten the two screws (2) that secure the belt bracket to the body bracket. Tighten the screws to 20 N.m (15 ft. lbs.).
5. Lift the webbing of the rear center seat belt and slide the bezel (1) over the webbing to position it over the belt bracket at the top of the cab back panel. Engage the rearward snap features of the bezel with the belt bracket. Using hand pressure, press firmly and evenly downward on the front of the bezel until it snaps into place over the belt bracket.
6. Reinstall the rear seat into the vehicle. On vehicles with the optional 60/40 split rear bench, only the 60 percent section (right side) of the rear seat must be reinstalled. Refer to «SEAT, Rear , Installation»(ref-457777-S11645692232012030200000) and «SEAT, Mega Cab Rear , Installation»(ref-457777-S06869481442012030200000) .
7. Insert the rear center seat belt lower anchor (7) between the rear seat back and the seat cushion, and position the anchor to the left side of the seat belt retractor mounting bracket on the rear floor panel.
8. Install and tighten the screw (5) that secures the center seat belt lower anchor and the left side of the seat belt retractor mounting bracket to the rear floor panel. Tighten the screw to 39 N.m (29 ft. lbs.).
9. Tighten the screw that secures the right side of the seat belt retractor mounting bracket to the rear floor panel. Tighten the screw to 39 N.m (29 ft. lbs.).
10. Restore the rear seat cushion to its seating position.

Note. All seat belt retractors except the driver side front retractor include a switchable automatic locking mechanism. Refer to RETRACTOR, Seat Belt , Description .

1. Position the rear outboard seat belt and retractor (4) to the inner C-pillar as a unit. Be certain to engage the hooks on the upper retractor bracket into the mounting hole in the C-pillar.
2. Install and tighten the screw (3) that secures the lower retractor bracket to the C-pillar. Tighten the screw to 39 N.m (29 ft. lbs.).
3. Position the belt web guide (5) to the B-pillar and use hand pressure to press it firmly and evenly until the two clips that secure it snap into place. Be certain that the seat belt webbing between the retractor and the web guide is not twisted.
4. Reinstall the lower trim (2) onto the inside of the C-pillar. Refer to «PANEL, C-Pillar Trim, Lower , Installation»(ref-457777-S27223731662012030200000) .
5. Reinstall the upper trim (1) onto the inside of the C-pillar. Refer to «PANEL, C-Pillar Trim, Upper , Installation»(ref-457777-S29602986802012030200000) .
6. Position the seat belt turning loop (2) onto the upper C-pillar.
7. Install and tighten the screw (4) that secures the turning loop to the C-pillar. Tighten the screw to 39 N.m (29 ft. lbs.).
8. Engage the upper edge of a new trim cover (3) over the top of the turning loop. Then squeeze the lower end of the trim cover and the turning loop together firmly and evenly until the engagement tabs of the trim cover snap into the slots of the turning loop.
9. Position the seat belt lower anchor (6) to the mounting hole at the base of the C-pillar.
10. Install and tighten the screw (5) that secures the lower anchor to the C-pillar. Tighten the screw to 39 N.m (29 ft. lbs.).
11. Reinstall the rear seat into the vehicle. Refer to «SEAT, Rear , Installation»(ref-457777-S11645692232012030200000) and «SEAT, Mega Cab Rear , Installation»(ref-457777-S06869481442012030200000) .

ACCELERATION-TYPE

The acceleration-type impact sensors are electronic accelerometers that sense the rate of vehicle deceleration, which provides verification of the direction and severity of an impact. Each sensor also contains an electronic communication chip that allows the unit to communicate the sensor status as well as sensor fault information to the microprocessor in the Occupant Restraint Controller (ORC).

The ORC microprocessor continuously monitors all of the passive restraint system electrical circuits to determine the system readiness. If the ORC detects a monitored system fault, it sets a Diagnostic Trouble Code (DTC) and controls the airbag indicator operation accordingly. The impact sensors each receive battery current and ground through shared left and right sensor plus and minus circuits from the ORC. The impact sensors and the ORC communicate by modulating the voltage in the sensor plus circuit.

The hard wired circuits between the impact sensors and the ORC may be diagnosed using conventional diagnostic tools and procedures. Refer to the appropriate wiring information. However, conventional diagnostic methods will not prove conclusive in the diagnosis of the impact sensors or the electronic controls or communication between other modules and devices that provide some features of the Supplemental Restraint System (SRS). The most reliable, efficient, and accurate means to diagnose the acceleration-type impact sensors or the electronic controls and communication related to impact sensor operation requires the use of a diagnostic scan tool. Refer to the appropriate diagnostic information.

PRESSURE-TYPE

The pressure-type front door side impact sensors recognize a side impact in the front door area by monitoring changes in pressure within the front door cavity. A sudden pressure wave is created as the door collapses during an impact event. Each sensor also contains an electronic communication chip that allows the unit to communicate the sensor status as well as sensor fault information to the microprocessor in the Occupant Restraint Controller (ORC).

The ORC microprocessor continuously monitors all of the passive restraint system electrical circuits to determine the system readiness. If the ORC detects a monitored system fault, it sets a Diagnostic Trouble Code (DTC) and controls the airbag indicator operation accordingly. The impact sensors each receive battery current and ground through shared left and right sensor plus and minus circuits from the ORC. The impact sensors and the ORC communicate by modulating the current in the sensor plus circuit.

The hard wired circuits between the pressure-type front door side impact sensors and the ORC may be diagnosed using conventional diagnostic tools and procedures. Refer to the appropriate wiring information. However, conventional diagnostic methods will not prove conclusive in the diagnosis of the impact sensors or the electronic controls or communication between other modules and devices that provide features of the Supplemental Restraint System (SRS). The most reliable, efficient, and accurate means to diagnose the pressure-type impact sensors or the electronic controls and communication related to impact sensor operation requires the use of a diagnostic scan tool. Refer to the appropriate diagnostic information.

FRONT

Scheme 70

1. Disconnect and isolate the battery negative cable. Wait two minutes for the system capacitor to discharge before further service.
2. Disconnect the Front End Module (FEM) (1) wire harness connector (4) from the right or left front impact sensor (5) connector receptacle.
3. Remove the screw (2) that secures the front impact sensor to the back of the right or left end of the lower radiator crossmember (3).
4. Remove the right or left front impact sensor from the engine compartment.

SIDE

Scheme 71

Note. Two pressure-type front door side impact sensors are used on all standard cab versions of this vehicle as well as on early-build editions of other cab styles, one each for the left and right sides of the vehicle. Pressure-type impact sensors are NOT used on late-build editions of the club, crew or mega cab versions.

1. Disconnect and isolate the battery negative cable. Wait two minutes for the system capacitor to discharge before further service.
2. Remove the trim panel from the inside of the right or left front door. Refer to «PANEL, Door Trim , Removal»(ref-457777-S23683841882012030200000) .
3. Disconnect the front door module wire harness connector (3) from the side impact sensor (1) connector receptacle.
4. Remove the two screws (4) that secure the sensor to the front door module carrier panel (2).
5. Remove the side impact sensor from the front door.

Scheme 72

1. Adjust the driver or passenger side front seat to its most forward position for easiest access to the B-pillar trim.
2. Disconnect and isolate the battery negative cable. Wait two minutes for the system capacitor to discharge before further service.
3. Remove the trim from the inside of the lower B-pillar. Refer to «PANEL, B-Pillar Trim, Lower , Removal»(ref-457777-S09741327532012030200000) .
4. Disconnect the body wire harness connector (1) from the side impact sensor (2) connector receptacle.
5. Remove the screw (3) that secures the sensor to the inner B-pillar.
6. Remove the sensor from the inner B-pillar.

Scheme 73

1. Adjust the driver or passenger side front seat to its most forward position for easiest access to the B-pillar trim.
2. Disconnect and isolate the battery negative cable. Wait two minutes for the system capacitor to discharge before further service.
3. Remove the trim from the inside of the lower B-pillar. Refer to «PANEL, B-Pillar Trim, Lower , Removal»(ref-457777-S09741327532012030200000) .
4. Disconnect the body wire harness connector (1) from the side impact sensor (2) connector receptacle.
5. Remove the screw (3) that secures the sensor to the inner B-pillar.
6. Remove the sensor from the inner B-pillar.

Scheme 74

1. Disconnect and isolate the battery negative cable. Wait two minutes for the system capacitor to discharge before further service.
2. Remove the trim from the inside of the lower C-pillar. Refer to «PANEL, C-Pillar Trim, Lower , Removal»(ref-457777-S38153746222012030200000) .
3. Disconnect the body wire harness connector (1) from the side impact sensor (2) connector receptacle.
4. Remove the screw (3) that secures the sensor to the inner C-pillar.
5. Remove the sensor from the inner C-pillar.

1. Position the right or left front impact sensor (5) onto the back of the right or left end of the lower radiator cross member (3). Be certain that the anti-rotation pin on the back of the sensor is engaged in the clearance hole of the cross member.
2. Install and tighten the screw (2) that secures the sensor to the back of the cross member. Tighten the screw to 10 N.m (90 in. lbs.).
3. Reconnect the Front End Module (FEM) (1) wire harness connector (4) to the sensor connector receptacle.
4. Do not reconnect the battery negative cable at this time. The Supplemental Restraint System (SRS) Verification Test procedure should be performed following service of any SRS component. Refer to «Standard Procedure»(ref-457806-S25050531802012030200000) .

FRONT DOOR

Note. Two pressure-type front door side impact sensors are used on all standard cab versions of this vehicle as well as on early-build editions of other cab styles, one each for the left and right sides of the vehicle. Pressure-type impact sensors are NOT used on late-build editions of the club, crew or mega cab versions.

Note. Be certain that the gasket between the pressure-type side impact sensor and the front door module carrier panel is in good condition and positioned on the back of the sensor. There MUST be a good seal between the sensor and the module carrier panel for the sensor to operate properly. If the gasket is in poor condition, replace the sensor.

1. Position the side impact sensor (1) to the right or left front door module carrier panel (2). When the sensor is correctly positioned, the arrow on the sensor label will be pointed toward the bottom of the door.
2. Install and tighten the two screws (4) that secure the sensor to the carrier panel. Tighten the screws securely.
3. Reconnect the front door module wire harness connector (3) to the sensor connector receptacle.
4. Reinstall the trim panel onto the inside of the right or left front door. Refer to «PANEL, Door Trim , Installation»(ref-457777-S13542642742012030200000) .
5. Do not reconnect the battery negative cable at this time. The Supplemental Restraint System (SRS) Verification Test procedure should be performed following service of any SRS component. Refer to «Standard Procedure»(ref-457806-S25050531802012030200000) .

B-PILLAR - STANDARD CAB

1. Position the side impact sensor (2) to the inside of B-pillar. Be certain that the anti-rotation pin on the back of the sensor is engaged in the clearance hole of the B-pillar.
2. Install and tighten the screw (3) that secures the sensor to the inner B-pillar. Tighten the screw to 9 N.m (80 in. lbs.).
3. Reconnect the body wire harness connector (1) to the sensor connector receptacle.
4. Reinstall the trim onto the inside of the lower B-pillar. Refer to «PANEL, B-Pillar Trim, Lower , Installation»(ref-457777-S31614994752012030200000) .
5. Do not reconnect the battery negative cable at this time. The Supplemental Restraint System (SRS) Verification Test procedure should be performed following service of any SRS component. Refer to «Standard Procedure»(ref-457806-S25050531802012030200000) .

B-PILLAR - EXCEPT STANDARD CAB

1. Position the side impact sensor (2) to the inside of B-pillar. Be certain that the anti-rotation pin on the back of the sensor is engaged in the clearance hole of the B-pillar.
2. Install and tighten the screw (3) that secures the sensor to the inner B-pillar. Tighten the screw to 9 N.m (80 in. lbs.).
3. Reconnect the body wire harness connector (1) to the sensor connector receptacle.
4. Reinstall the trim onto the inside of the lower B-pillar. Refer to «PANEL, B-Pillar Trim, Lower , Installation»(ref-457777-S31614994752012030200000) .
5. Do not reconnect the battery negative cable at this time. The Supplemental Restraint System (SRS) Verification Test procedure should be performed following service of any SRS component. Refer to «Standard Procedure»(ref-457806-S25050531802012030200000) .

C-PILLAR

1. Position the side impact sensor (2) to the inside of C-pillar. Be certain that the anti-rotation pin on the back of the sensor is engaged in the clearance hole of the C-pillar.
2. Install and tighten the screw (3) that secures the sensor to the inner B-pillar. Tighten the screw to 9 N.m (80 in. lbs.).
3. Reconnect the body wire harness connector (1) to the sensor connector receptacle.
4. Reinstall the trim onto the inside of the lower C-pillar. Refer to «PANEL, C-Pillar Trim, Lower , Installation»(ref-457777-S27223731662012030200000) .
5. Do not reconnect the battery negative cable at this time. The Supplemental Restraint System (SRS) Verification Test procedure should be performed following service of any SRS component. Refer to «Standard Procedure»(ref-457806-S25050531802012030200000) .

Scheme 75

All vehicles are equipped with a driver side seat belt switch that is a small, normally open, single pole, single throw, leaf contact, momentary switch. The driver side seat belt switch is integral to the buckle (1) of the driver side front seat belt buckle, which is located within a molded plastic scabbard (2) and secured by a screw to the inboard side of the driver side front seat cushion frame.

The seat belt switch is connected to the vehicle electrical system through a two-lead pigtail wire and connector (3) on the seat belt buckle-half, which is connected to a wire harness connector and take out of the seat wire harness routed beneath the driver side front seat cushion in the passenger compartment.

The seat belt switch cannot be adjusted or repaired. If ineffective or damaged, the entire driver side front seat belt buckle-half unit must be replaced.
