NV273 Transfer Case - Service Information: Component Locations RAM Pickup 2500

Transfer Case 7 illustrations ~445 words

SPECIAL TOOLS

6719A - Holder, Yoke (Originally Shipped In Kit Number(s) 6745, 6947, 6949, 9975.) 6953 - Remover/Installer, Bearing (Originally Shipped In Kit Number(s) 6945, 6947, 6949, 9975.) 7888 - Installer, Seal (Originally Shipped In Kit Number(s) 9975.) 8128 - Installer, Bearing (Originally Shipped In Kit Number(s) 8104, 9975.) 8148 - Cup (Originally Shipped In Kit Number(s) 8104, 9975.) 8151 - Installer, Bearing Cup (Originally Shipped In Kit Number(s) 8104.) 8152 - Installer, Seal (Originally Shipped In Kit Number(s) 8104, 9697, 9698.) 8891 - Installer, Seal (Originally Shipped In Kit Number(s) 8721, 8721CC, 8843, 9925, 9926.) 8992 - Remover, Pinion Flange (Originally Shipped In Kit Number(s) 8999, 8999CC, 9299, 9299CC, 9299CC, 9300A-CAN.) 9033 - Socket, Sector Support (Originally Shipped In Kit Number(s) 8848, 8849, 8849CC.) 9035 - Installer, Bearing (Originally Shipped In Kit Number(s) 8848, 8849, 8849CC.) 9036 - Installer, Seal (Originally Shipped In Kit Number(s) 8848, 8849, 8849CC.) 9037 - Installer, Dust Boot/Seal (Originally Shipped In Kit Number(s) 8848, 8849, 8849CC.) C-4171 - Driver Handle, Universal (Originally Shipped In Kit Number(s) 9202, 9202A-CAN, 9202CC, 9299, 9299CC, 9299CC, 9300A-CAN.) L-4454A - Remover, Bearing Cup (Originally Shipped In Kit Number(s) 9975.) MB-991168-A - Installer, Seal (Originally Shipped In Kit Number(s) 8847, 8853, 8854, 8854CC, 9975.)

Scheme 174

Scheme 174: SPECIAL TOOLS
Scheme 174: SPECIAL TOOLS

Scheme 175

Scheme 175
Scheme 175

Scheme 176

Scheme 176
Scheme 176

Scheme 177

Scheme 177
Scheme 177

Scheme 178

Scheme 178
Scheme 178

Scheme 179

Scheme 179: STANDARD PROCEDURE - FLUID DRAIN AND REFILL
Scheme 179: STANDARD PROCEDURE - FLUID DRAIN AND REFILL
1 - FILL HOLE
2 - DRAIN HOLE

The fill (1) and drain (2) plugs are both in the rear case. (Scheme 174)

  1. Raise vehicle.
  2. Position drain pan under transfer case. NOTE: It may be necessary to remove the exhaust y-pipe at the exhaust manifold to properly access the fill and drain plugs. Lowering the exhaust will allow the plugs to be accessed for torquing during installation. Refer to «PIPE, Exhaust , Removal»(ref-457794-S06798926572012030200000) .
  3. Remove drain and fill plugs and drain lubricant completely.
  4. Install drain plug. Tighten plug to 20-34 N.m (15-25 ft. lbs.).
  5. Remove drain pan.
  6. Fill transfer case to bottom edge of fill plug opening with Mopar® ATF +4, Automatic Transmission fluid.
  7. Install and tighten fill plug to 20-34 N.m (15-25 ft. lbs.).
  8. Install the exhaust y-pipe to the exhaust manifold, if removed. Refer to «PIPE, Exhaust , Installation»(ref-457794-S38991905122012030200000) .
  9. Wipe any excess fluid that may have spilled onto the exhaust.
  10. Lower vehicle.

Scheme 180

Scheme 180: DESCRIPTION
Scheme 180: DESCRIPTION
1 - TRANSFER CASE
2 - SHIFT MOTOR AND MODE SENSOR ASSEMBLY
3 - BOLT

The shift motor (2) consists of a permanent magnet D.C. motor with gear reduction to convert a high speed-low torque device into a low speed-high torque device. The output of the device is coupled to a shaft which internally moves the mode and range forks that change the transfer case operating ranges. The motor is rated at 25 amps maximum at 23° C (72° F) with 10 volts at the motor leads.
