68RFE Automatic Transmission - Service Information: Component Locations RAM Pickup 2500

Automatic Trans 18 illustrations ~480 words

SPECIAL TOOLS

10020 - Installer, Seal (Originally Shipped In Kit Number(s) 10019.) 10065 - Plate, Alignment (Originally Shipped In Kit Number(s) 10065.) 6756 - Receiver, Ball Joint (Originally Shipped In Kit Number(s) 6745, 6809.) 6960 - Tools, Trac-Lok Axle (Originally Shipped In Kit Number(s) 6947, 6949, 6966.) 8154 - Installer, Seal (Originally Shipped In Kit Number(s) 8163, 8163CC, 8164, 8164CC.) 8249 - Compressor, Spring (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC, 9975.) 8250 - Compressor, Spring (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC, 9975.) 8251 - Compressor, Spring (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC, 9975.) 8252 - Installer (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC, 9975.) 8253 - Installer, Seal (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC, 9975.) 8254 - Installer, Grommet (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC, 9975.) 8257 - Support, Transmission (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC, 9975.) 8259 - Adapter, Pressure Test (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC, 9975.) 8260A - Fixture, Input Clutch (Originally Shipped In Kit Number(s) 8260A.) 8266-17 - Spline Tool, RFE Output (Originally Shipped In Kit Number(s) 8283, 8527, 8575.) 8266-20 - Spline Tool, AS68RC Output (Originally Shipped In Kit Number(s) 9978.) 8266B - End Play Socket Set (Originally Shipped In Kit Number(s) 8283, 8527, 8575, 8575CC.) 8285 - Compressor, Spring (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC, 9975.) 8321 - Wrench, Oil Filter (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC, 9975.) 8349-1 - Installer Crank Seal (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC.) 8504-1 - Piston Installer (Outer) (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC, 9975.) 8896 - Installer, Seal (Originally Shipped In Kit Number(s) 8887, 8887CC.) 9045 - Installer, Plug (Originally Shipped In Kit Number(s) 8847, 8850, 8850CC, 8853, 8854, 8854CC.) 9546 - Disconnect Tool (Originally Shipped In Kit Number(s) 9590.) 9955 - Installer, Front Cover (Originally Shipped In Kit Number(s) 9955.) C-3293-SP - Gauge, Pressure 0-300 P.S.I. C-3339A - Set, Dial Indicator (Originally Shipped In Kit Number(s) 9202.) C-4171 - Driver Handle, Universal (Originally Shipped In Kit Number(s) 9202, 9202A-CAN, 9202CC, 9299, 9299CC, 9299CC, 9300A-CAN.)

Scheme 288

Scheme 288: SPECIAL TOOLS
Scheme 288: SPECIAL TOOLS

Scheme 289

Scheme 289
Scheme 289

Scheme 290

Scheme 290
Scheme 290

Scheme 291

Scheme 291
Scheme 291

Scheme 292

Scheme 292
Scheme 292

Scheme 293

Scheme 293
Scheme 293

Scheme 294

Scheme 294
Scheme 294

Scheme 295

Scheme 295
Scheme 295

Scheme 296

Scheme 296
Scheme 296

Scheme 297

Scheme 297
Scheme 297

Scheme 298

Scheme 298
Scheme 298

Scheme 299

Scheme 299
Scheme 299

Scheme 300

Scheme 300
Scheme 300

Scheme 301

Scheme 301
Scheme 301

Scheme 302

Scheme 302
Scheme 302

Scheme 303

Scheme 303
Scheme 303

Scheme 304

Scheme 304: DESCRIPTION
Scheme 304: DESCRIPTION
1 - INPUT CLUTCH HUB11 - UD CLUTCH
2 - O-RING SEALS12 - UD OUTER DISC
3 - SEAL13 - INPUT CLUTCH RETAINER
4 - SNAP-RING14 - SEAL
5 - SNAP-RING15 - OD/REV PISTON
6 - UD BALANCE PISTON16 - BELLEVILLE SPRING
7 - SNAP-RING17 - SNAP-RING
8 - UD PISTON18 - SEAL RINGS
9 - UD SPRING PACK19 - INPUT SHAFT
10 - UD INNER DISC20 - LUBRICATION CHECK VALVE AND SNAP-RING

Scheme 305

Scheme 305
Scheme 305
1 - THRUST BEARING NUMBER 310 - SNAP-RING (SELECT)
2 - OD HUB/SHAFT11 - OD OUTER DISC
3 - SNAP-RING (WAVE)12 - OD INNER DISC
4 - REV/OD PRESSURE PLATE13 - OD CLUTCH
5 - THRUST BEARING NUMBER 414 - SNAP-RING (TAPERED)
6 - SNAP-RING (FLAT)15 - UD/OD REACTION PLATE
7 - REVERSE HUB/SHAFT16 - SNAP-RING (FLAT)
8 - REVERSE CLUTCH17 - UD HUB/SHAFT
9 - REVERSE REACTION PLATE18 - THRUST BEARING NUMBER 2

Three hydraulically applied input clutches are used to drive planetary components. The underdrive, overdrive, and reverse clutches are considered input clutches and are contained within the input clutch assembly.

The input clutch assembly also contains

  1. Input shaft
  2. Input hub
  3. Clutch retainer
  4. Underdrive piston
  5. Overdrive/reverse piston
  6. Overdrive hub
  7. Underdrive hub

More articles — 68RFE Automatic Transmission - Service Information
