SPECIAL TOOLS

6756 - Receiver, Ball Joint (Originally Shipped In Kit Number(s) 6745, 6809.) 6960 - Tools, Trac-Lok Axle (Originally Shipped In Kit Number(s) 6947, 6949, 6966.) 8249 - Compressor, Spring (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC, 9975.) 8250 - Compressor, Spring (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC, 9975.) 8251 - Compressor, Spring (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC, 9975.) 8252 - Installer (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC, 9975.) 8253 - Installer, Seal (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC, 9975.) 8254 - Installer, Grommet (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC, 9975.) 8257 - Support, Transmission (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC, 9975.) 8259 - Adapter, Pressure Test (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC, 9975.) 8260A - Fixture, Input Clutch (Originally Shipped In Kit Number(s) 8260A.) 8261 - Plate, Alignment (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC, 9975.) 8266-1 - Spline Tool, RFE Input 8266-17 - Spline Tool, RFE Output (Originally Shipped In Kit Number(s) 8283, 8527, 8575.) 8266B - End Play Socket Set (Originally Shipped In Kit Number(s) 8283, 8527, 8575, 8575CC.) 8285 - Compressor, Spring (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC, 9975.) 8321 - Wrench, Oil Filter (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC, 9975.) 8349-1 - Installer Crank Seal (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC.) 8504 - Installer (Originally Shipped In Kit Number(s) 8283, 8283CC, 8527, 8527CC, 8575, 8575CC, 9975.) 9045 - Installer, Plug (Originally Shipped In Kit Number(s) 8847, 8850, 8850CC, 8853, 8854, 8854CC.) 9955 - Installer, Front Cover (Originally Shipped In Kit Number(s) 9955.) C-3293-SP - Gauge, Pressure 0-300 P.S.I. C-3339A - Set, Dial Indicator (Originally Shipped In Kit Number(s) 9202.) C-3860-A - Installer, Seal (Originally Shipped In Kit Number(s) 9695.) C-3972-A - Installer, Seal (Originally Shipped In Kit Number(s) 9975.) C-4171 - Driver Handle, Universal (Originally Shipped In Kit Number(s) 9202, 9202A-CAN, 9202CC, 9299, 9299CC, 9299CC, 9300A-CAN.) C-4755 - Trim Stick (Originally Shipped In Kit Number(s) 9299, 9299CC, 9299CC, 9300A-CAN.)

Scheme 121

Scheme 121: SPECIAL TOOLS

Scheme 122

Scheme 123

Scheme 124

Scheme 125

Scheme 126

Scheme 127

Scheme 128

Scheme 129

Scheme 130

Scheme 131

Scheme 132

Scheme 133

Scheme 134

Scheme 135

Scheme 136

Scheme 137

Scheme 138

Scheme 138: DESCRIPTION

1 - THRUST BEARING NUMBER 3	10 - SNAP-RING (SELECT)
2 - OD HUB/SHAFT	11 - PLATE
3 - SNAP-RING (WAVE)	12 - DISC
4 - REV/OD REACTION PLATE	13 - OD CLUTCH
5 - THRUST BEARING NUMBER 4	14 - SNAP-RING (TAPERED)
6 - SNAP-RING (FLAT)	15 - UD/OD REACTION PLATE
7 - REVERSE HUB/SHAFT	16 - SNAP-RING (FLAT)
8 - REVERSE CLUTCH	17 - UD HUB/SHAFT
9 - REVERSE REACTION PLATE	18 - THRUST BEARING NUMBER 2

Three hydraulically applied input clutches are used to drive planetary components. The underdrive, overdrive, and reverse clutches are considered input clutches and are contained within the input clutch assembly. (Scheme 121)

The input clutch assembly also contains

Input shaft
Input hub
Clutch retainer
Underdrive piston
Overdrive/reverse piston
Overdrive hub
Underdrive hub
