Installing the window frame trim
Installation Location
Scheme 497
1. Close rear lid. Open rear window -12-. (Scheme 497)
Scheme 498
2. Check sheetmetal retaining clips -5- for deformation; replace if necessary. (Scheme 498)
Scheme 499
3. Clip top window frame trim -4- at the places indicated ( -circle marks- ) on the rear lid. (Scheme 499), see scheme 554.
4. Move the rear lid to the intermediate position shown. see scheme 555
Scheme 500
Scheme 501
5. Clip the side window frame trim -3- onto the rear lid and the rear lid lining at the marked positions. (Scheme 500)
Scheme 502
Scheme 503
6. Clip center window frame trim -2- onto the rear lid at the marked positions. (Scheme 503)
Scheme 504
7. Close rear lid and rear window.
