Installing lid hinge trim
Installation Location
Scheme 515
1. Install wiring duct on rear window hinge.
Scheme 516
1.1. Guide wiring duct -7- over wire harness -(Arrow A)-. (Scheme 516)
1.2. Press in the cover -8- -(Arrow B)- until the locking tabs engage audibly -(Arrow C)-. see scheme 574, (Scheme 517).
Scheme 517
Scheme 518
1.3. Place the wiring duct -7- on the rear window hinge until the locking tabs engage audibly ( -(Arrow D)- ). (Scheme 518)
2. Install wiring duct on lid hinge.
Scheme 519
2.1. Guide wiring duct -5- over wire harness -(Arrow E)-. (Scheme 519)
2.2. Press in the cover -6- until the locking tabs engage audibly -(Arrow F)-. (Scheme 519)
Scheme 520
2.3. Connect wiring duct -5- to the rear window hinge -(Arrow G)-. (Scheme 520)
Scheme 521
3. Install hinge cover on inner lid.
3.1. Insert hinge cover -4- -(Arrow H)- and clip into place -(Arrows I)-. (Scheme 522), (Scheme 521).
Scheme 522
Scheme 523
4. Install hinge cover on outer lid.
4.1. Insert hinge cover on outer lid -2- -(Arrow K)-. (Scheme 523)
4.2. Screw in -3- fastening screws. (Scheme 523)
Scheme 524
5. Install hinge cover on body.
5.1. Position the hinge cover -1- and clip it into place -(Arrow L)-. (Scheme 524)
