Installing lining for lid Porsche Cayenne I

Linings, Insulation 10 illustrations ~147 words

Installing lining for lid

Installation Location

Scheme 487

Scheme 487: Installing lining for lid
Scheme 487: Installing lining for lid

Scheme 488

Scheme 488
Scheme 488

1. Check clips for deformation; replace if necessary.

Scheme 489

Scheme 489
Scheme 489

2. Clip the rear lid lining -1- onto the rear lid at the marked positions. (Scheme 489)

Scheme 490

Scheme 490
Scheme 490

Scheme 491

Scheme 491
Scheme 491

3. Insert handle liner -9- into the rear lid lining -1-. (Scheme 491)

4. Screw in fastening screw -10-. (Scheme 491)

Scheme 492

Scheme 492
Scheme 492

5. Clip lock cover -8- into the rear lid lining -1-. (Scheme 492)

Scheme 493

Scheme 493
Scheme 493

6. Engage plug connection on the side lights -arrow-. (Scheme 493)

Scheme 494

Scheme 494
Scheme 494

7. Insert side lights -6, 7- into the rear lid lining and clip into place. (Scheme 494)

Scheme 495

Scheme 495
Scheme 495

8. Check sheetmetal retaining clips for deformation; replace if necessary. (Scheme 495)

Scheme 496

Scheme 496
Scheme 496

9. Clip cover for rear wiper motor -11- onto the rear lid at the marked positions. (Scheme 496)
