Installing front armrest
Installation Location
Scheme 327
1. Prepare frame section for installation.
1.1. Shorten mounting dome with a parting grinder.
(Only if replacing the frame section)
2. Prepare armrest for installation.
2.1. Shorten mounting dome with a parting grinder.
Scheme 328
(Only if replacing the armrest)
2.2. Drill out any remaining plastic material in the center of the mounting dome using a drill bit (4 mm).
Scheme 329
(Only if re-installing the armrest)
Scheme 330
3. Position frame section.
Scheme 331
4. Place armrest in position.
Scheme 332
5. Screw in screws.
5.1. Tighten screws hand-tight in the sequence shown -A to D-. (Scheme 332)
Scheme 333
6. Install door handle.
6.1. Place door handle -5- in position and screw fastening screw -4- in hand-tight. (Scheme 333)
Scheme 334
7. Install air duct.
7.1. Place air duct -2- in position -arrows A and B- and screw fastening screw -3- in hand-tight. (Scheme 334)
