Installing dashboard bracket Porsche Cayenne I

Linings, Insulation 19 illustrations ~739 words

Installing dashboard bracket

Installation Location

Scheme 140

Scheme 140: Installing dashboard bracket

Scheme 141

Scheme 141

1. Insert bracket.

1.1. Insert bracket -31- over center tunnel -Arrow A-. (Scheme 142)

1.2. Insert bracket -31- over parking brake mechanism -Arrow B-. (Scheme 141)

1.3. Insert bracket -31- into guide in the firewall -Arrow C-. When doing so, insert the strut -35- over the bolts -36- -Arrow D-. (Scheme 142)

Scheme 142

Scheme 142

Scheme 143

Scheme 143

2. Screw bracket to A-pillar, left and right.

2.1. Align bracket -31- with the markings previously made -Arrows E-. (Scheme 143)

2.2. Screw in -32- fastening screws. (Scheme 143)

Scheme 144

Scheme 144

3. Screw on bracket at center tunnel.

3.1. Screw in -34- fastening screws. (Scheme 144)

Scheme 145

Scheme 145

4. Screw parking brake to bracket.

4.1. Screw in fastening screws -30a and 30b- and tighten to the specified torque. --> Tightening torque: 23 (17 ftlb.) Nm --> Tightening torque: 23 (17 ftlb.) Nm. (Scheme 145)

Scheme 146

Scheme 146

5. Screw bracket to firewall.

5.1. Screw in fastening screw -29- and tighten to the specified torque. --> Tightening torque: 23 (17 ftlb.) Nm +/-3 (2 ftlb.) Nm. (Scheme 146)

5.2. Press in -28- cover cap -Arrow F-. (Scheme 146)

Scheme 147

Scheme 147

6. Screw on ground straps.

6.1. Connect ground straps -18- together with cage -17- -Arrow M-. (Scheme 147)

6.2. Screw in nuts -19- and tighten to the specified torque. --> Tightening torque: 9 (6.5 ftlb.) Nm +/-1 (0.5 ftlb.) Nm. (Scheme 147)

Scheme 148

Scheme 148

7. Clip in wire harness for instrument cluster to bracket.

7.1. Clip in wire harness for instrument cluster -21- at the fixing clips -20- -Arrow H-. (Scheme 148)

Scheme 149

Scheme 149

8. Clip in wire harness for PCM to bracket.

8.1. Clip in wire harness for PCM -22- at the fixing clips -24- -Arrow K-. (Scheme 149)

8.2. Clip in wire harness for PCM -22- at the fixing clips -23- -Arrow I-. (Scheme 149)

Scheme 150

Scheme 150

9. Clip in PCM antenna lines to bracket.

9.1. Clip in antenna lines for PCM -25- at the fixing clips -26- and -27- -Arrows L-. (Scheme 150), (Scheme 151).

Scheme 151

Scheme 151

Scheme 152

Scheme 152

10. Install fuse box.

10.1. Insert fuse box on driver's and front passenger's side -1- ( -Arrow M- ). (Scheme 152)

10.2. Screw in fastening screw -2-. (Scheme 152)

10.3. Screw in fastening screw -2- just enough for the fastening screws -32- still to be accessible. (Scheme 152)

Scheme 153

Scheme 153

11. Mount control unit for tire pressure monitoring system.

11.1. Insert control unit for tire pressure monitoring system -5- -Arrow N-. (Scheme 153)

11.2. Screw in -4- fastening screws. (Scheme 153)

12. Connect plug and clip in wire harness for parking brake contact switch.

Scheme 154

Scheme 154

12.1. Push on the plug -8- until the locking tabs engage audibly -arrow O-. (Scheme 154)

Scheme 155

Scheme 155

12.2. Clip in wire harness -6- on fastening clip -7- -arrow P-. (Scheme 155)

Scheme 156

Scheme 156

13. Install control unit carrier.

13.1. Insert control unit carrier -10- and support -11- on bracket -Arrow R- and pull downward -Arrow S-. (Scheme 156)

13.2. Screw in nut -9- and tighten to the specified torque. --> Tightening torque: 8 (6.5 ftlb.) Nm +/-1 (0.5 ftlb.) Nm. (Scheme 156)

Scheme 157

Scheme 157

14. Screw air-conditioning unit on bracket.

14.1. Screw in fastening screws -13- and tighten to the specified torque. --> Tightening torque: 10 (7.5 ftlb.) Nm +/-0.5 (0.5 ftlb.) Nm. (Scheme 157)

Scheme 158

Scheme 158

15. Fasten bracket strut for pedals.

15.1. Swivel strut -16- upward -Arrow T-. (Scheme 158)

15.2. Push bolts -15- into place -Arrow U-. (Scheme 158)

15.3. Press circlip -14- down until it can be heard to engage -Arrow W-. (Scheme 158)

1. Install relay carrier. Refer to 97 90 19 Removing and installing relay carrier, plenum chamber E-box - as of MY 2003 (All Models) .

2. Install cowl panel cover. Refer to 66 44 19 Removing and installing cowl panel cover - as of MY 2003 (All Models) .

3. Screw in steering column at dashboard bracket. Refer to 48 15 19 Removing and installing steering column - as of MY 2003 (Cayenne S TIP, Cayenne S MAN, Cayenne Turbo) . Refer to 48 15 19 Removing and installing steering column - as of MY 2003 (Cayenne TIP, Cayenne MAN) . Refer to 48 15 19 Removing and installing steering column - as of MY 2003 (Cayenne Turbo S, Cayenne S TIO Titan) .

4. Install dashboard. > 701819 Removing and installing dashboard - "Installing" .
