System readiness

The system allows the position to be changed if at least one of the following requirements is fulfilled

1. Term. 15 is switched on or
2. The driver's door is opened

Operational readiness is maintained for an after-running time of 60 s after the key has been removed or the door has been closed. If the position is changed during the after-running time, then the after-running time is started again. If the position is not changed during the after-running time, then the system switches to inactive state, thus reducing power consumption.

Information

Term. 15 must be switched on for communication with the PST 2.

System components

The system consists of the following components

1. Lumbar support
2. Motor for lumbar support (lumbar pump)
3. Switch for seat adjustment
4. Electric motor for seat adjustment
5. Electric motor for front height adjustment
6. Electric motor for rear height adjustment
7. Electric motor for backrest adjustment
8. Control module for memory seat adjustment
9. Switch for memory seat adjustment
10. Switch for rearview mirrors (door mirrors)
11. Changeover switch for rearview mirrors (door mirrors)
12. Right and left rearview mirrors (door mirrors)

The system enables the following system components to be adjusted individually

1. Front seat height
2. Rear seat height
3. Backrest angle
4. Left rearview mirror
5. Right rearview mirror
6. Lumbar support
7. Fore-and-aft adjustment

Storing the positions

1. Adjust the rearview mirrors, seat height, backrest angle and lumbar support to the desired positions.
2. Hold down switch M and push one of the switches for memory seat adjustment (1, 2 or 3) at the same time.

The positions are now stored under the number selected.

The following components are monitored by the system

1. Lumbar pressure sensor (regulating switch)
2. Potentiometer voltage of both rearview mirrors
3. Hall-effect sensor for backrest adjustment
4. Hall-effect sensor for fore-and-aft adjustment
5. Hall-effect sensor for height adjustment
6. Functioning of the control module (EPROM, A/D converter, main relay)
7. Switch for memory seat adjustment and switch for seat adjustment

When the switch for memory seat adjustment or the switch for seat adjustment are actuated, the faulty component is stored in the fault memory. In this case the word present also appears on the screen, for example

"Open circuit present in Hall-effect sensor for fore-and-aft adjustment"

If the cause of the fault is eliminated, then the switch for memory seat adjustment or the switch for seat adjustment must be actuated again. If the cause of the fault has really been eliminated, the text in the fault memory changes from present to not present .

Note. The fault memory must always be read out and any faults which may have been stored must always be deleted after diagnosis.

Tools

The following equipment is required for troubleshooting

Scheme 15

Scheme 16

1. Porsche System Tester 2
2. Commercially available digital multimeter

Scheme 17

Function of individual components

1. Parking aid When reverse gear is engaged, the corresponding rearview mirror (right-hand drive or left-hand drive according to coding) is lowered by the angle stored. Manual adjustment of the seat motors is carried out parallel to the lowering of the rearview mirror. Automatic adjustment interrupts the lowering procedure. If reverse gear is still engaged after automatic adjustment is complete, the rearview mirror is lowered again.
2. Rearview mirrors Manual adjustment of both rearview mirrors is carried out with the switches for rearview mirrors or changeover switch for rearview mirrors. When the desired positions have been set and stored by means of the switches for memory seat adjustment , automatic adjustment of the rearview mirrors is carried out by actuating the corresponding switch (1, 2 or 3).
3. Support with gear unit The support with gear unit consists of the following components: Two electric motors with a potentiometer Gear unit
4. Front seat The following are the possibilities for adjusting the front seat: Backrest Front height Rear height Longitudinal direction Upper lumbar Lower lumbar When the desired positions have been found and stored by means of the switches for memory seat adjustment , they can be called up at the push of a button when required.
5. Control module The control module is fastened under the front seat (driver's side) with two screws. There is a total of 10 connection points on the control module.
6. Switches for memory seat adjustment These switches [M, 1, 2, 3] can be used to store or call up the optimum positions once they have been found. The systems enables adjustment values for three persons to be stored.

Lumbar support

The lumbar support consists of two cushions which are inflated by means of a motor for lumbar support. The cushions are inflated or deflated to the required pressure one after the other beginning with the upper cushion. The pressure in the cushions is measured using a pressure sensor (regulating switch). The pressure sensor is located at the same height as the headrest and is integrated into the lumbar adjustment. Automatic adjustment of the lumbar support is carried out by actuating the switch for memory seat adjustment. The motor for lumbar adjustment is (Scheme 18)together with both lumbar cushions. Automatic adjustment of the lumbar support is divided into two phases.

Scheme 18

Scheme 19

1. If the seat motors have not yet reached their required position, adjustment of the lumbar support is interrupted by releasing the switch for memory seat adjustment.
2. If the seat motors have reached their required position, adjustment of the lumbar support is completed after the switch for memory seat adjustment is released.

Plug 1, 5-pole

PLUG 1, 5-POLE CONNECTOR - PIN NO. DESIGNATION

Plug 2, 5-pole

PLUG 2, 5-POLE CONNECTOR - PIN NO. DESIGNATION

Plug 3, 5-pole

PLUG 3, 5-POLE CONNECTOR - PIN NO. DESIGNATION

Plug 4, 5-pole

PLUG 4, 5-POLE CONNECTOR - PIN NO. DESIGNATION

Plug 5, 9-pole

PLUG 5, 9-POLE CONNECTOR - PIN NO. DESIGNATION

Plug 6, 8-pole

PLUG 6, 8-POLE CONNECTOR - PIN NO. DESIGNATION

PLUG 6, 8-POLE CONNECTOR - PIN NO. DESIGNATION

PLUG 6, 8-POLE CONNECTOR - PIN NO. DESIGNATION

Plug 7, 26-pole

PLUG 7, 26-POLE CONNECTOR - PIN NO. DESIGNATION

Plug Nos. 1 to 4

The plugs each consist of two individual plugs which are clipped together (Scheme 20) The 2-pole plug is intended for the load circuit (motor). The 3-pole plug is the signal circuit connection (Hall-effect sensor). When they are clipped together, plug nos. 1 to 4 each have 5 poles.

Scheme 20

Plug No. 5

The plug consists of three individual plugs which are clipped together (Scheme 21) Each individual plug has 3 poles. When it is clipped together, plug no. 5 has 9 poles.

Sequence of the individual plugs

The sequence of the individual plugs from left to right is as follows

SEQUENCE OF INDIVIDUAL PLUGS

Scheme 21

See the 3-pole plug in (Scheme 22) for pin assignment. The pin numbers are printed on the side of the plugs.

Plug No. 6

The plug consists of three individual plugs which are clipped together (Scheme 21) Two individual plugs have 3 poles each, the third has 2 poles. When it is clipped together, plug no. 6 has 8 poles.

Scheme 22

The sequence of the individual plugs from left to right is as follows

SEQUENCE OF INDIVIDUAL PLUGS

Plug No. 7

Plug No. 7 has 26 poles. The pin assignment is (Scheme 23)

Scheme 23

Plug Nos. 8 to 10

See Plug Nos. 1 to 4

Fault code 1

Control module faulty, Main relay does not drop out

Possible causes, elimination, notes

This fault is stored in the following cases

1. The control module is faulty
2. Temporary system error

Elimination

1. Clear fault memory.
2. Read out fault memory.
3. If the fault is no longer present , check that all system components such as seat adjustment, mirror adjustment, memory function, etc. are functioning correctly.

If the fault is still present , replace the control module.

Fault code 2

Control module faulty, Main relay does not pick up

This fault is stored in the following cases

1. The control module is faulty
2. Temporary system error

Elimination

1. Clear fault memory.
2. Read out fault memory.
3. If the fault is no longer present , check that all system components such as seat adjustment, mirror adjustment, memory function, etc. are functioning correctly.

If the fault is still present , replace the control module.

Fault code 3

A/D converter faulty

This fault is stored in the following cases

1. The control module is faulty
2. Temporary system error.

Elimination

1. Clear fault memory.
2. Read out fault memory.
3. If the fault is no longer present , check that all system components such as seat adjustment, mirror adjustment, memory function, etc. are functioning correctly.

If the fault is still present , replace the control module.

Fault code 4

EEPROM fault (Checksum)

This fault is stored in the following case: The control module is faulty.

Elimination

1. Replace the control module.

Fault code 5

Required position 1 (Checksum)

This fault is stored in the following case: The control module is faulty.

Elimination

1. Replace the control module.

Fault code 6

Required position 2 (Checksum)

This fault is stored in the following case: The control module is faulty.

Elimination

1. Replace the control module.

Fault code 7

Required position 3 (Checksum)

This fault is stored in the following case: The control module is faulty.

Elimination

1. Replace the control module.

Fault code 8

Hall-effect sensor fore-and-aft adjustment, open circuit

This fault is stored in the following cases

1. There is an open circuit in the wire to the Hall-effect sensor fore-and-aft adjustment.
2. The Hall-effect sensor is faulty.
3. The control module is faulty.

Elimination

1. Check plug on control module for contact and damage.
2. Check wire to sensor for damage.

Once the cause of the fault has been found and eliminated, actuate the fore-and-aft adjustment switch. The text in the fault memory changes from present to not present if the cause of the fault has really been eliminated.

1. If no fault is detected in the wire on the sensor, replace the electric motor for seat adjustment.
2. If the fault is still present , replace control module.

Fault code 9

Hall-effect sensor fore-and-aft adjustment, short circuit

This fault is stored in the following cases

1. There is a short circuit in the wires to the Hall-effect sensor.
2. The Hall-effect sensor is faulty.
3. The control module is faulty.

Elimination

1. Disconnect plug from control module, check for continuity with ohmmeter on Pin 2 and Pin 3.

If a short circuit is found, check the sensor wires first. If no fault is detected in the wire, replace the electric motor for seat adjustment. Once the cause of the fault has been found and eliminated, actuate the fore-and-aft adjustment switch. The text in the fault memory changes from present to not present if the cause of the fault has really been eliminated.

1. If the fault is still present , replace control module.

Fault code 10

Hall-effect sensor backrest adjustment, open circuit

This fault is stored in the following cases

1. There is an open circuit in the wire to the Hall-effect sensor for backrest adjustment.
2. The Hall-effect sensor is faulty.
3. The control module is faulty.

Elimination

1. Check plug on control module for contact and damage.
2. Check wire to sensor for damage.

Once the cause of the fault has been found and eliminated, actuate the fore-and-aft adjustment switch. The text in the fault memory changes from present to not present if the cause of the fault has really been eliminated.

1. If no fault is detected in the wire, replace the electric motor for seat adjustment.
2. If the fault is still present , replace control module.

Fault code 11

Hall-effect sensor backrest adjustment, short circuit

This fault is stored in the following cases

1. There is a short circuit in the wires to the Hall-effect sensor.
2. The Hall-effect sensor is faulty.
3. The control module is faulty.

Elimination

1. Disconnect plug from control module, check for continuity with ohmmeter on Pin 2 and Pin 3.

If a short circuit is found, check the sensor wires first.

1. If no fault is detected in the wire, replace the electric motor for backrest adjustment.
2. Once the cause of the fault has been found and eliminated, actuate the fore-and-aft adjustment switch. The text in the fault memory changes from present to not present if the cause of the fault has really been eliminated.
3. If the fault is still present , replace control module.

Fault code 12

Hall-effect sensor height adjustment, open circuit

This fault is stored in the following cases

1. There is an open circuit in the wire to the Hall-effect sensor fore-and-aft adjustment.
2. The Hall-effect sensor is faulty.
3. The control module is faulty.

Elimination

1. Check plug on control module for contact and damage.
2. Check wire to sensor for damage.
3. Once the cause of the fault has been found and eliminated, actuate the height adjustment switch. The text in the fault memory changes from present to not present if the cause of the fault has really been eliminated.
4. If no fault is detected in the wire on the sensor, replace the electric motor for height adjustment.
5. If the fault is still present , replace control module.

Fault code 13

Hall-effect sensor front height adjustment, short circuit

This fault is stored in the following cases

1. There is a short circuit in the wires to the Hall-effect sensor.
2. The Hall-effect sensor is faulty.
3. The control module is faulty.

Elimination

1. Disconnect plug from control module, check for continuity with ohmmeter on Pin 2 and Pin 3.

If a short circuit is found, check the sensor wires first.

1. If no fault is detected in the wire, replace sensor. Once the cause of the fault has been found and eliminated, actuate the fore-and-aft adjustment switch. The text in the fault memory changes from present to not present if the cause of the fault has really been eliminated.
2. If the fault is still present , replace control module.

Fault code 14

Hall-effect sensor rear height adjustment, open circuit

This fault is stored in the following cases

1. There is an open circuit in the wire to the Hall-effect sensor fore-and-aft adjustment.
2. The Hall-effect sensor is faulty.
3. The control module is faulty.

Elimination

1. Check plug on control module for contact and damage.
2. Check wire to sensor for damage.
3. Once the cause of the fault has been found and eliminated, actuate the height adjustment switch. The text in the fault memory changes from present to not present if the cause of the fault has really been eliminated.
4. If the fault is still present , replace control module.

Fault code 15

Hall-effect sensor rear height adjustment, short circuit

This fault is stored in the following cases

1. There is a short circuit in the wires to the Hall-effect sensor.
2. The Hall-effect sensor is faulty.
3. The control module is faulty.

Elimination

1. Disconnect plug from control module, check for continuity with ohmmeter on Pin 2 and Pin 3.

If a short circuit is found, check the sensor wires first.

1. If no fault is detected in the wire, replace the electric motor for height adjustment.
2. Once the cause of the fault has been found and eliminated, actuate the height adjustment switch. The text in the fault memory changes from present to not present if the cause of the fault has really been eliminated.
3. If the fault is still present , replace control module.

Fault code 18

Lumbar pressure sensor open circuit

This fault is stored in the following cases

1. There is an open circuit in the wire to the lumbar pressure sensor.
2. The pressure sensor is faulty.
3. The control module is faulty.

Elimination

1. Check plug on control module for contact and damage.
2. Check wire to sensor for damage.
3. If no fault is detected in the wire, replace lumbar adjustment.
4. Once the cause of the fault has been found and eliminated, actuate the lumbar adjustment switch. The text in the fault memory changes from present to not present if the cause of the fault has really been eliminated.
5. If the fault is still present , replace control module.

Fault code 19

Lumbar pressure sensor short circuit

This fault is stored in the following cases

1. There is a short circuit in the wires to the pressure sensor.
2. The pressure sensor is faulty.
3. The control module is faulty.

Elimination

1. Disconnect plug from control module, check for continuity with ohmmeter on Pin 2 and Pin 3, and on Pin 1 and Pin 3. If a short circuit is found, check the sensor wires first.
2. If no fault is detected in the wire, replace lumbar adjustment.
3. Once the cause of the fault has been found and eliminated, actuate the lumbar adjustment switch. The text in the fault memory changes from present to not present if the cause of the fault has really been eliminated.
4. If the fault is still present , replace control module.

Fault code 20

Potentiometer, mirror right horizontal open circuit

This fault is stored in the following cases

1. There is an open circuit in the wire to the pot. right rearview mirror.
2. The potentiometer is faulty.
3. The control module is faulty.

Elimination

1. Replace support with gear unit.
2. Actuate switch for memory seat adjustment.

The text in the fault memory changes from present to not present if the cause of the fault has really been eliminated.

1. If the fault is no longer present , erase the fault memory.
2. If the fault is still present , there is a fault in the wire.

For a fault in the wire, proceed as described below

1. Disconnect mirror plug from the control module.
2. Disconnect plug at support with gear unit.
3. Use an ohmmeter to check for open circuit on the support plug Pin 5 and the mirror plug on the control module Pin 11. Ohmmeter display < 5ohm
4. Use an ohmmeter to check for open circuit on the support plug Pin 7 and the mirror plug on the control module Pin 4. Ohmmeter display < 5ohm
5. Use an ohmmeter to check for continuity on the support plug Pin 3 and Pin 5.
6. If no fault is detected in the wire, replace the control module.

Fault code 21

Potentiometer, mirror right horizontal short circuit

This fault is stored in the following cases

1. There is a short circuit in the wire to the pot. right rearview mirror.
2. The potentiometer is faulty.
3. The control module is faulty.

Elimination

1. Replace support with gear unit.
2. Actuate switch for memory seat adjustment.

The text in the fault memory changes from present to not present if the cause of the fault has really been eliminated.

1. If the fault is still present , there is a fault in the wire. For a fault in the wire, proceed as described below
2. Disconnect plug at support with gear unit.
3. Disconnect mirror plug from the control module.
4. Use an ohmmeter to check for short circuit on the support plug Pin 5, wire colour yellow, and Pin 7, wire colour pink.

If no short circuit is detected

1. Use an ohmmeter to check for open circuit on the support plug Pin 3 and the mirror plug on the control module Pin 5 Ohmmeter display < 5ohm
2. If the fault is still present , replace control module.

Fault code 22

Potentiometer, mirror right vertical open circuit

This fault is stored in the following cases

1. There is an open circuit in the wire to the pot. right rearview mirror.
2. The potentiometer is faulty.
3. The control module is faulty.

Elimination

1. Replace support with gear unit.
2. Actuate switch for memory seat adjustment.

The text in the fault memory changes from present to not present if the cause of the fault has really been eliminated.

If the fault is no longer present , erase the fault memory.

If the fault is still present , there is a fault in the wire.

For a fault in the wire, proceed as described below

1. Disconnect mirror plug from the control module.
2. Disconnect plug at support with gear unit.
3. Use an ohmmeter to check for open circuit on the support plug Pin 5 and the mirror plug on the control module Pin 11 Ohmmeter display <5ohm
4. Use an ohmmeter to check for open circuit on the support plug Pin 7 and the mirror plug on the control module Pin 4. Ohmmeter display <5ohm
5. Use an ohmmeter to check for continuity on the support plug Pin 1 and Pin 3.
6. If no fault is detected in the wire, replace the control module.

Fault code 23

Potentiometer mirror right vertical short circuit

This fault is stored in the following cases

1. There is a short circuit in the wire to the pot. right rearview mirror.
2. The potentiometer is faulty.
3. The control module is faulty.

Elimination

1. Replace support with gear unit.
2. Actuate switch for memory seat adjustment.

The text in the fault memory changes from present to not present if the cause of the fault has really been eliminated.

If the fault is still present , there is a fault in the wire.

For a fault in the wire, proceed as described below

1. Disconnect plug at support with gear unit.
2. Disconnect mirror plug from the control module.
3. Use an ohmmeter to check for short circuit on the support plug Pin 1, wire colour grey, and Pin 7, wire colour pink. No continuity must be measured! If no short circuit is detected
4. Use an ohmmeter to check for open circuit on the support plug Pin 3 and the mirror plug on the control module Pin 5 Ohmmeter display <5ohm
5. Use an ohmmeter to check for continuity on the support plug Pin 1 and Pin 7.
6. If no fault is detected in the wire but the fault is still present , replace the control module.

Fault code 24

Potentiometer, mirror left horizontal open circuit

This fault is stored in the following cases

1. There is an open circuit in the wire to the pot. left rearview mirror.
2. The potentiometer is faulty.
3. The control module is faulty.

Elimination

1. Replace support with gear unit.
2. Actuate switch for memory seat adjustment.

The text in the fault memory changes from present to not present if the cause of the fault has really been eliminated.

1. If the fault is no longer present , erase the fault memory.
2. If the fault is still present , there is a fault in the wire.

For a fault in the wire, proceed as described below

1. Disconnect mirror plug from the control module.
2. Disconnect plug at support with gear unit.
3. Use an ohmmeter to check for open circuit on the support plug Pin 1 and the mirror plug on the control module Pin 10 Ohmmeter display < 5ohm
4. Use an ohmmeter to check for open circuit on the support plug Pin 7 and the mirror plug on the control module Pin 4. Ohmmeter display < 5ohm
5. Use an ohmmeter to check for continuity on the support plug Pin 1 and Pin 3.
6. If no fault is detected in the wire, replace the control module.

Fault code 25

Potentiometer, mirror left horizontal short circuit

This fault is stored in the following cases

1. There is a short circuit in the wire to the pot. left rearview mirror.
2. The potentiometer is faulty.
3. The control module is faulty.

Elimination

1. Replace support with gear unit.
2. Actuate switch for memory seat adjustment.

The text in the fault memory changes from present to not present if the cause of the fault has really been eliminated.

1. If the fault is no longer present , erase the fault memory.
2. If the fault is still present , there is a fault in the wire.

For a fault in the wire, proceed as described below

1. Disconnect plug at support with gear unit.
2. Disconnect mirror plug from the control module.
3. Use an ohmmeter to check for continuity on the support plug Pin 1 and Pin 7.
4. Use an ohmmeter to check for open circuit on the support plug Pin 3 and the mirror plug on the control module Pin 5 Ohmmeter display < 5ohm
5. If no fault is detected in the wire but the fault is still present , replace the control module.

Fault code 26

Potentiometer mirror left vertical open circuit.

This fault is stored in the following cases

1. There is an open circuit in the wire to the pot. left rearview mirror.
2. The potentiometer is faulty.
3. The control module is faulty.

Elimination

1. Replace support with gear unit.
2. Actuate switch for memory seat adjustment.

The text in the fault memory changes from present to not present if the cause of the fault has really been eliminated.

1. If the fault is no longer present , erase the fault memory.
2. If the fault is still present , there is a fault in the wire.

For a fault in the wire, proceed as described below

1. Disconnect mirror plug from the control module.
2. Disconnect plug at support with gear unit.
3. Use an ohmmeter to check for open circuit on the support plug Pin 5 and the mirror plug on the control module Pin 11 Ohmmeter display <5ohm
4. Use an ohmmeter to check for open circuit on the support plug Pin 7 and the mirror plug on the control module Pin 4. Ohmmeter display <5ohm
5. Use an ohmmeter to check for continuity on the support plug Pin 3 and Pin 5.
6. If no fault is detected in the wire, replace the control module.

Fault code 27

Potentiometer, mirror left vertical short circuit

This fault is stored in the following cases

1. There is a short circuit in the wire to the pot. left rearview mirror.
2. The potentiometer is faulty.
3. The control module is faulty.

Elimination

1. Replace support with gear unit.
2. Actuate switch for memory seat adjustment.

The text in the fault memory changes from present to not present if the cause of the fault has really been eliminated.

1. If the fault is no longer present , erase the fault memory.
2. If the fault is still present , there is a fault in the wire.

For a fault in the wire, proceed as described below

1. Disconnect plug at support with gear unit.
2. Disconnect mirror plug from the control module.
3. Use an ohmmeter to check for continuity on the support plug Pin 5 and Pin 7.
4. Use an ohmmeter to check for open circuit on the support plug Pin 3 and the mirror plug on the control module Pin 5 Ohmmeter display <5ohm
5. If no fault is detected in the wire but the fault is still present , replace the control module.

Fault code 32

Button M, 1, 2, 3 or operating buttons actuated for longer than 60 sec.

This fault is stored in the following case

1. Switch for memory seat adjustment (1, 2, or 3), or switch for seat adjustment (for example, Fore-and-aft adjustment forward ) is continuously switched.

Elimination

1. Erase fault memory and read it out again after a waiting time of 60 seconds.

Proceed as described below if the fault is still present

1. Select menu item Input signals.

The following button positions can be read out in the menu item Input signals.

1. Button M
2. Button 1
3. Button 2
4. Button 3
5. Fore-and-aft adjustment forward
6. Fore-and-aft adjustment backward
7. Backrest forward
8. Backrest backward
9. Front height upward
10. Front height downward
11. Rear height upward
12. Rear height downward
13. Backrest forward
14. Backrest backward
15. Button up
16. Button down
17. Button backward
18. Button forward
19. Select a maximum of 8 button positions.
20. Search for the key on the screen that is continuously actuated. A comparison table can be found on «INPUT SIGNALS»(ref-199835-S05135665332005102000000) .
21. If a key is detected as faulty, replace the switch for memory seat adjustment or the switch for seat adjustment as appropriate.

Fault memory

Stored faults can be read out under the Fault memory menu item.

Clear the fault memory

Faults stored in the control module can be erased under the Erase fault memory menu item. Here, all stored faults are erased.

Actual values

In the Actual values menu item, the current values of the following parameters can be read out.

1. Voltage of terminal 30
2. Voltage of Hall-effect sensor for fore-and-aft adjustment
3. Voltage of Hall-effect sensor for backrest
4. Voltage of Hall-effect sensor for front height
5. Voltage of Hall-effect sensor for rear height
6. Voltage of pressure sensor
7. Voltage of right horizontal mirror potentiometer
8. Voltage of right vertical mirror potentiometer
9. Voltage of left horizontal mirror potentiometer
10. Voltage of left vertical mirror potentiometer

Input signals

This menu item enables input signals of the system to be read out by the Porsche System Tester 2.

This allows the function of the individual components to be assessed very quickly.

Comparison table of input signals

In the comparison table, the following applies for the tester display

Boundary conditions

1. Terminal 15 switched on and reverse gear not engaged
2. Switch for memory seat adjustment not actuated
3. The system is in perfect condition INPUT SIGNALS TESTER DISPLAY - STATUS (1 OF 2) Tester display Status M Button M button not actuated Button 1 Button 1 not actuated Button 2 Button 2 not actuated Button 3 Button 3 not actuated Reverse gear engaged Reverse gear not engaged Door contact closed (door open) Depends on door position Supply voltage (terminal1 15) Terminal 15 signal present Cancel parking aid Cancel parking aid Fore-and-aft adjustment forward Switch sign "open" Fore-and-aft adjustment backward Switch sign "open" Front height upward Switch sign "open" Front height downward Switch sign "open" Rear height upward Switch sign "open" Rear height downward Switch sign "open" Backrest forward Switch sign "open" Backrest backward Switch sign "open" Lumbar pump Lumbar pump not active Fill upper valve Fill upper valve not active INPUT SIGNALS TESTER DISPLAY - STATUS (2 OF 2) Tester display Status Bleed upper valve Bleed upper valve not active Tester display Status Fill lower valve Fill lower valve not active Bleed lower valve Bleed lower valve not active Button up Button up open Button down Button down open Button backward Button backward open Button forward Button forward open Left mirror to right Left mirror to right not active Left mirror to left Left mirror to left not active Left mirror upward Left mirror upward not active Left mirror downward Left mirror downward not active Right mirror to right Right mirror to right not active Right mirror to left Right mirror to left not active Right mirror upward Right mirror upward not active Right mirror downward Right mirror downward not active

Drive links

The menu item Drive links enables the following system functions to be checked.

1. Fore-and-aft adjustment forward
2. Fore-and-aft adjustment backward
3. Backrest forward
4. Backrest backward
5. Front height upward
6. Front height downward
7. Rear height downward
8. Rear height upward
9. Left mirror to right
10. Left mirror to left
11. Left mirror upward
12. Left mirror downward
13. Right mirror to right
14. Right mirror to left
15. Right mirror upward
16. Right mirror downward
17. Fill upper valve
18. Bleed upper valve
19. Fill lower valve
20. Store position 1
21. Store position 2
22. Store position 3
23. Approach required position 1
24. Approach required position 2
25. Approach required position 3

Information

The drive links are not activated until the switch M is depressed continuously.

Modify coding

The following settings can be selected from the menu and encoded under the menu item Modify coding.

MODIFY CODING SETTINGS

Procedure

1. Select vehicle type.
2. Select Seat memory control module.
3. Select menu item Modify coding.
4. Select desired coding as described above and press the double arrow key.
5. Select the desired setting with the arrow keys and press the F8 key.

Information

The procedure for activating the parking aid is described in detail on ACTIVATING THE PARKING AID .

General

The automatic lowering of the rearview mirror aids the driver during parking manoeuvres. The rearview mirror is lowered by the set value as soon as reverse gear is engaged. If reverse gear is disengaged again or the rearview mirror switch touched with reverse gear still engaged, the rearview mirror returns to its stored position.

Information

This function is only available in vehicles with seat memory.

The following settings can be selected from the menu and encoded using the Porsche System Tester 2.

1. Parking aid (active or not active)
2. Parking aid with rearview mirror (right or left)
3. Lowering

The system function can be activated or deactivated under menu item Parking aid.

Either the right-hand or left-hand rearview mirror is selected and activated under the menu item Parking aid with rearview mirror.

The degree to which the rearview mirror is lowered is set under the menu item Lowering.

Activating the parking aid

1. Connect the PST 2 with the ignition off, then switch the ignition on.
2. Switch on the PST 2 and wait for the startup screen.
3. Press the ">>" key to go to the next level.
4. Select the vehicle type Boxster in the left-hand window using the "DOWN ARROW" key.
5. With the "DOWN ARROW" key, select the Seat memory control module and press the ">>" key to go to the next level.
6. With the "DOWN ARROW" key, select Modify coding and press the ">>" key to go to the next level.
7. The Parking aid menu item is already highlighted on your screen. Press the ">>" key to alter the coding.
8. Select the menu item active using the "DOWN ARROW" key.
9. Press key F8 (coding). The parking aid is now activated.
10. Press the "<<" key to switch between the right-hand or left-hand door mirror.
11. With the "DOWN ARROW" key, select Parking aid with rearview mirror and press the ">>" key to alter the coding.
12. Select the desired side right or left using key "DOWN ARROW" or "UP ARROW".
13. Press key F8 (coding). The selected rearview mirror is now activated.
14. Press the "<<" key to set the degree of lowering of the door mirror.
15. With the "DOWN ARROW" key, select Lowering and press the ">>" key to alter the coding.
16. Select the desired degree of lowering using key "DOWN ARROW" or "UP ARROW".
17. Press key F8 (coding). The selected degree of lowering has now been stored.
18. Press the [Esc] key 2x to quit this level. Setting of the system is now complete.

Poses Online
