Parking Assistant: Removal & Installation Porsche Boxster 986 рестайлинг

Removal & Installation

To remove rear bumper, first remove rear spoiler. See REAR SPOILER. For further removal procedures (Scheme 1) For installation procedure (Scheme 2) Check gap dimensions of tailpipe, and adjust as necessary. (Scheme 3)

Scheme 1

Scheme 2

Scheme 3

For removal and installation procedures on vehicles produced up to 2002 (Scheme 4) For removal and installation procedures on vehicles produced from 2003 and on (Scheme 5)

Scheme 4

Scheme 5

Removal

1. Remove rear spoiler (bumper cover). See «REAR BUMPER»(ref-153149-S31988477552003032000000).
2. Disconnect electrical plug. Bend holding peg SLIGHTLY on sensor housing and push out sensor. Retaining plate remains in bumper cover. (Scheme 6)
3. Remove insulating ring.

Scheme 6

Installation

1. Fit insulating ring BEFORE fitting sensor. Push sensor into housing and engage.
2. Engage electrical plug.
3. Install rear spoiler (bumper cover). See «REAR BUMPER»(ref-153149-S31988477552003032000000) .
