Parking Assistant: Other Porsche Boxster 986 рестайлинг

Collision/avoidance 3 illustrations ~1263 words

CLEANING ULTRASONIC SENSORS

Sensors can be de-iced and cleaned using a steam-jet cleaner. Always maintain a sufficient distance to prevent damaging sensors and paint.

MODIFYING CODING

  1. Connect Porsche System Tester 2 to diagnostic socket. (Scheme 8)
  2. Turn on System Tester 2. Allow about 1 minute for Tester to come on-line.
  3. Turn ignition on.
  4. Select vehicle type and start diagnosis by pressing the "2.14" button. Computer will list all control modules on vehicle and will list non-existent (example: Tiptronic module on a vehicle with manual transmission) in gray.
  5. Select "Park Assistant" control module.
  6. Select "Modify Coding" Menu.
  7. Select vehicle type and press F8 to confirm.

PREPARING PORSCHE SYSTEM TESTER 2

  1. Connect Porsche System Tester 2 to diagnostic socket. (Scheme 8)
  2. Turn on System Tester 2. Allow about 1 minute for Tester to come on-line.
  3. Turn ignition on.
  4. Select vehicle type and start diagnosis by pressing the "2.14" button. Computer will list all control modules on vehicle and will list non-existent (example: Tiptronic module on a vehicle with manual transmission) in gray.

Scheme 8

Scheme 8
Scheme 8

Accessing Fault Memory

  1. Connect Porsche System Tester 2 to diagnostic socket (located under left side of dashboard).
  2. Switch on ignition and System Tester. Allow about 1 minute for Tester to come on-line.
  3. Press F8 key to retrieve fault memory. Save with F4 key.

CONNECTOR ASSIGNMENT

(Scheme 9)for control module connector assignment.

Scheme 9

Scheme 9: CONNECTOR ASSIGNMENT
Scheme 9: CONNECTOR ASSIGNMENT

Possible Causes

  1. Short circuit to B+ voltage in supply lead to outside right sensor.
  2. Short circuit to ground in supply lead to outside right sensor.
  3. Open circuit in supply lead to outside right sensor.
  4. Faulty outside right sensor.

Elimination

Clear fault memory, disengage reverse gear and turn ignition OFF. Turn ignition ON. Engage reverse gear and read out fault memory. If fault appears again, check electrical plug on sensor for open circuit.

If no open circuit, check for continuity between sensor connector, between pin 1 and pin 4. Check continuity between sensor connector, pin 1 and pin 2 also. In both cases, no continuity should exist.

If no faulty wiring is found, replace sensor.

  1. Short circuit to B+ voltage in supply lead to inner right sensor.
  2. Short circuit to ground in supply lead to inner right sensor.
  3. Open circuit in supply lead to inner right sensor.
  4. Faulty inner right sensor.

Clear fault memory, disengage reverse gear and turn ignition OFF. Turn ignition ON. Engage reverse gear and read out fault memory. If fault appears again, check electrical plug on sensor for open circuit.

If no open circuit, check for continuity between sensor connector, between pin 1 and pin 4. Check continuity between sensor connector, pin 1 and pin 2 also. In both cases, no continuity should exist.

If no faulty wiring is found, replace sensor.

  1. Short circuit to B+ voltage in supply lead to inner left sensor.
  2. Short circuit to ground in supply lead to inner left sensor.
  3. Open circuit in supply lead to inner left sensor.
  4. Faulty inner left sensor.

Clear fault memory, disengage reverse gear and turn ignition OFF. Turn ignition ON. Engage reverse gear and read out fault memory. If fault appears again, check electrical plug on sensor for open circuit.

If no open circuit, check for continuity between sensor connector, between pin 1 and pin 4. Check continuity between sensor connector, pin 1 and pin 2 also. In both cases, no continuity should exist.

If no faulty wiring is found, replace sensor.

  1. Short circuit to B+ voltage in supply lead to outside left sensor.
  2. Short circuit to ground in supply lead to outside left sensor.
  3. Open circuit in supply lead to outside left sensor.
  4. Faulty outside left sensor.

Clear fault memory, disengage reverse gear and turn ignition OFF. Turn ignition ON. Engage reverse gear and read out fault memory. If fault appears again, check electrical plug on sensor for open circuit.

If no open circuit, check for continuity between sensor connector, between pin 1 and pin 4. Check continuity between sensor connector, pin 1 and pin 2 also. In both cases, no continuity should exist.

If no faulty wiring is found, replace sensor.

  1. Low vehicle voltage.
  2. Faulty generator.

Check voltage from battery and generator and replace any faulty components. Using Porsche System Tester 2, select "Actual values" menu Select "Control module supply voltage" and "Sensor supply voltage" menus and check values with reverse gear engaged and engine running. Supply to control module should be approximately 12 volts and supply to sensor(s) should be approximately 8 volts.

After checking actual values, clear fault memory, disengage reverse gear and turn ignition OFF. Turn ignition ON again, engage reverse gear and read out fault memory.

  1. Low vehicle voltage.
  2. Short circuit in supply leads to control module.

Check voltage from battery and generator and replace any faulty components. Using Porsche System Tester 2, select "Actual values" menu Select "Control module supply voltage" and "Sensor supply voltage" menus and check values with reverse gear engaged and engine running. Supply to control module should be approximately 12 volts and supply to sensor(s) should be approximately 8 volts.

After checking actual values, pull out license plate light and check continuity between plug (sleeve side) pin 4 toward pin 3.

  1. Low vehicle voltage.
  2. Short circuit in supply leads.
  3. Faulty sensor.
  4. Faulty control module.

Check voltage from battery and generator and replace any faulty components. Using Porsche System Tester 2, select "Actual values" menu Select "Control module supply voltage" and "Sensor supply voltage" menus and check values with reverse gear engaged and engine running. Supply to control module should be approximately 12 volts and supply to sensor(s) should be approximately 8 volts.

After checking actual values, clear fault memory, disengage reverse gear and turn ignition OFF. Turn ignition ON again, engage reverse gear and read out fault memory. If fault appears again, replace sensors detected as faulty.

  1. Control module not coded correctly.
  2. Faulty control module.

Clear fault memory, disengage reverse gear and turn ignition OFF. Turn ignition ON again, engage reverse gear and read out fault memory. If fault appears again, check coding. See MODIFYING CODING . If coding is correct and fault still appears, replace control module.

  1. Control module not coded correctly.
  2. Faulty control module.

Clear fault memory, disengage reverse gear and turn ignition OFF. Turn ignition ON again, engage reverse gear and read out fault memory. If fault appears again, check coding. See MODIFYING CODING . If coding is correct and fault still appears, replace control module.

Corroded ground points.

Inspect ground points for corrosion and replace any damaged points. Clear fault memory and repeat.

  1. Remove driver-side front seat. See «FRONT SEAT»(ref-153149-S05949686002003032000000).
  2. Remove both fastening screws from cover of control module. (Scheme 10)
  3. Turn cover over and disconnect both electrical plugs. (Scheme 10)
  4. Unscrew control module from cover.
  5. To install, follow reverse order of removal. Ensure that wires are not pinched when reconnecting harness.

Scheme 10

Scheme 10
Scheme 10

FRONT SEAT

Pull seat rail cover forward on front end of right and left seat rails. Move seat fully rearward. Remove front Torx screws from right and left seat rails. Move seat fully forward. Remove rear Torx screws from left and right seat rails. Disconnect electrical connectors. Remove seat. To install, reverse removal procedure. Tighten seat rail Torx bolts to 48 ft. lbs. (65 N.m).

REAR BUMPER

CAUTIONWhen installing rear spoiler, exhaust heat shields MUST NOT be installed if bent, distorted, damaged or if there is separation between metal sheets (pressed metal layers). If damaged heat shields are installed, damage WILL occur to bumper cover.

1998-99

Parking assistant wiring for 1998-99 Boxster models is identical. See 1999 SYSTEM WIRING DIAGRAMS .

2000

See 2000 SYSTEM WIRING DIAGRAMS .

2001-02

Parking assistant wiring for 2001-02 Boxster models is identical. See 2002 SYSTEM WIRING DIAGRAMS .

2003

For 2003 parking assistant wiring see 2003 SYSTEM WIRING DIAGRAMS .

2004

For 2004 parking assistant wiring see 2004 SYSTEM WIRING DIAGRAMS .
