Seats - Diagnosis: Adjustments Porsche Boxster 986 рестайлинг

Electric motor for backrest adjustment

The backrest is adjusted by an electric motor with gear unit. A Hall-effect sensor is integrated into the electric motor which measures the actual position.

Scheme 11

Switch for seat adjustment

Manual adjustment of the seat positions is carried out by actuating the three switches located on the driver's seat (front seat).

Scheme 12

1. 1, 2, 3. Fore-and-aft adjustment and height adjustment are carried out by actuating the switch in the positions (Scheme 12)
2. The seat backrest can be brought into desired position by actuating the switch.
3. The lumbar support is inflated or deflated by actuating the switch.

(Scheme 13) shows how the following system components are arranged under the front seat.

Scheme 13

1. Control module
2. Electric motor for front height adjustment
3. Electric motor for seat adjustment
4. Electric motor for rear height adjustment

Scheme 14
