Engine Damping Blocks, Engine, Short-Block
Engine Damping Blocks, Front, Remove and Install Engine Damping Blocks May Be Replace in Pairs Only.
Detach air intake hose.
Disconnect torque support from both torque support brackets.
In I: Remove lateral engine compartment cover.
Remove front axle body - see operation "Front Axle Body, Remove and Install" in group "E".
Lower complete drive unit using Engine Bridge MKM-883-1 until fastening nut (1) is accessible.
Disconnect engine damping block from engine damping block bracket and from transmission bracket - note installation position.
Connect engine damping block to engine damping block bracket and to transmission bracket - note installation position - tightening torque 45 Nm / 33.2 lbf. ft.
Install front axle body - see operation "Front Axle Body, Remove and Install" in group "E".
In I: Install lateral engine compartment cover.
Connect torque support to both torque support brackets - tightening torque 60 Nm / 44.2 lbf. ft.
It is only ensured that the intake system is free of leaks, thus ensuring operational safety of the engine, if the hose clamps are tightened correctly to the prescribed tightening torque.
Install air intake hose.
