Engine Compartment Survey (16 LZ2)
- Coolant temperature sensor
- Injection valve
- Throttle valve potentiometer
- Crankshaft pulse pick-up
- Intake manifold pressure sensor
- Idle speed stepper motor
- High voltage distributor
Home/Opel/Vectra/Opel Vectra B (1996-2001)/Repair manual/OHC Petrol Engine/Engine Compartment Survey (16 LZ2)
Contents
Wiring diagrams Section: OHC Petrol Engine- How to Check and Measure the Cylinder Head and Attaching Parts (Survey)
- How to Check the Cylinder Head Height
- How to Check for Plane Surface the Cylinder Head
- How to Measure the Valve
- How to Check the Inner Diameter of Valve Guide
- Valve Stem Play, Determine
- How to Check the Installation Height of Valves
- Correction of Engine Oil Filling Quantities
- Oil Pump Gasket Leaks
- How to Check the Installation Height of Valve Guide
- Engines with Two-Part Oil Pans (Alum. Upper Part, Sheet Metal Lower)
- New Quality Designation for Engine Oils According to Acea
- Battery / Starter, Petrol (Current Measurement)
- Battery / Starter (Voltage Measurement)
- How to Overhaul the Cylinder Head
- Cylinder Head, Attach to Assembly Tool Set KM-6215
- Cylinder Head, Disassemble
- How to Remove the Valves
- Compression 4-cylinder, Unsynchronised
- Valve Seat, Cut (In Cylinder Head)
- Valve Guide, Ream
- Crankshaft Impulse Sensor, Petrol and Z19DT
- Valve, Grind
- Valve, Grind In
- How to Replace the Valve Stem Seals
- How to Assemble the Cylinder Head
- Cylinder Head Machining Special Tools
- Exhaust Gas Recirculation Valve, Multec S and Motronic (MY 2000)
- Engine Identification
- Notes on Octane Number Information
- Ignition, Secondary
- Injector (Multi-Point Fuel Injection), All Except Z22YH
- Injector (Single-Point Fuel Injection)
- Vectra-B Engine Data, Performance Data, Fuel Consumption Data
- Intake Manifold Absolute Pressure (MAP) Sensor
- Knock Sensor
- Oxygen Sensor, Multec-F
- Engine and Performance Values - Vectra-B
- Vectra-B All Vehicles - Engine, Engine Att. Parts
- Engine Identification Plate
- Information on Octane No. Specifications
- Engine Data, Performance Figures, Fuel Consumption Figures, Vectra-B
- Throttle Valve Potentiometer, Multec (MY 2000)
- Engine Values and Performance Values Vectra-B
- New Legislation for Fuel Consumption Measurement
- Engine Designation
- Octane Rating Instructions
- Allocation - Engine No. to Engine Type
- Allocation - Engine Identification
- Survey of Engines and Engine Management Systems
- New Features - X 16 SZR OHC Petrol Eng
- Engine-Specific Charact.data X 16 SZR
- Introduction
- New Features - 16 LZ2 and 20 Nej OHC Petrol Engines
- Engine-Specific Charact. Data 16 LZ2
- Engine-Specific Charact.data 20 Nej
- New Features - Oil Pan
- New Features - Engine Suspension Torque Support
- New Features - Engine Suspension Engine Damping Blocks
- Loss of Oil from Oil Pump Seal and Exhaust Pipe Becoming Detached
- Cracks in Intake Manifold Gasket
- Engine - Spark Plugs Wet
- How to Measure the Engine Oil Temperature
- How to Check (X 16 SZR) the Timing
- How to Check (16 LZ2 and 20 Nej) Nej) the Timing
- How to Remove and Install (X 16 SZR) the Toothed Belt
- How to Remove and Install (16 LZ2 and 20 Nej) the Toothed Belt
- How to Remove and Install (X 16 SZR) the Toothed Belt Tension Roller
- How to Replace (X 16 SZR) the Camshaft Housing Seal Ring - Cylinder Head - Rear
- How to Replace (16 LZ2) the Seal Ring - Rear Camshaft Housing
- How to Replace (20 Nej) the Gasket - Rear Camshaft Housing
- Toothed Belt Diagnosis - Possible Causes and Remedys
- How to Replace the Seal Ring - Rear Crankshaft
- How to Check the Crankshaft, Check; Crankshaft End Play
- How to Check the Oil Pump
- How to Remove and Install Reinstallation the Safety Valve
- How to Remove and Install (Without Air Conditioning) the Radiator
- How to Remove and Install (16 LZ2 and 20 Nej) the Thermostat
- How to Remove and Install Reinstallation the Dis Ignition Module
- Toothbelt - Service Intervall Overview
- How to Remove and Install the Fuel Pressure Regulator
- How to Remove and Install the Hot Film Mass Air Flow Meter
- How to Check the Fuel Pressure
- Engine - Broken Timing Chain
- How to Remove and Install the Throttle Valve Injection Housing
- How to Remove and Install the Throttle Valve Injection Housing, Upper Part
- How to Remove and Install (16 LZ2) the Ignition Module
- Spark Plug Damages - Possible Causes and Failure Modes
- Engine Number
- How to Check the Checking and Adjustment Operations - Ribbed V-Belt Tension
- How to Check the Compression
- How to Check the Pressure Loss
- How to Check the Oil Pressure
- How to Measure the Oil Consumption
- How to Adjust (X 16 SZR) the Timing
- How to Adjust (16 LZ2 and 20 Nej) Nej) the Timing
- How to Check (X 16 SZR) Szr) the Toothed Belt Tension
- How to Adjust (X 16 SZR) Szr) the Toothed Belt Tension
- How to Check (16 LZ2 and 20 Nej) the Toothed Belt Tension
- How to Adjust (16 LZ2 and 20 Nej) the Toothed Belt Tension
- Air Cleaner Housing, Air Ducts (Illustration (X 16 SZR))
- Air Cleaner Housing, Air Ducts (Illustration (16 Lz 2))
- Air Cleaner Housing, Air Ducts (Illustration (20 Nej))
- How to Remove and Install the Ribbed V-Belt - Engine Timing Side
- How to Remove and Install (X 16 SZR Without AC) Air Conditioning) the Ribbed V-Belt Tension Roller
- How to Remove and Install (X 16 SZR with AC the Ribbed V-Belt Tension Roller (16 LZ2 and 20 Nej) 20 Nej))
- How to Remove and Install (X 16 SZR) the Front Toothed Belt Cover
- How to Remove and Install (16 LZ2 and 20 Nej) the Front Toothed Belt Cover
- How to Remove and Install (16 LZ2 and 20 Nej) the Toothed Belt Tension Roller
- How to Replace the Seal Ring - Front Camshaft Housing
- How to Remove and Install (X 16 SZR) the Rear Toothed Belt Cover
- How to Remove and Install (16 LZ2 and 20 Nej) the Rear Toothed Belt Cover
- How to Remove and Install Reinstallation the Exhaust Manifold
- How to Remove and Install (X 16 SZR) the Intake Manifold
- How to Remove and Install (16 LZ2) the Intake Manifold
- How to Remove and Install (20 Nej) the Intake Manifold
- How to Remove and Install Reinstallation the Heat Shields
- How to Remove and Install (Cylinder Head Installed) the Camshaft and Cam Follower
- How to Replace (Cylinder Head Installed) the Valve Stem Seals
- How to Replace (Cylinder Head Installed) the Hydraulic Valve Lifter
- How to Remove and Install (Cylinder Head Removed) the Camshaft
- How to Check for Plane Surface the Camshaft Housing
- How to Replace the Camshaft Housing
- How to Remove and Install (X 16 SZR) the Cylinder Head
- How to Remove and Install (16 LZ2 and 20 Nej) the Cylinder Head
- How to Remove and Install the Drive Disc
- How to Remove and Install the Crank Drive, Cylinder Block Flywheel
- How to Replace the Starter Ring Gear
- How to Remove and Install Reinstallation the Piston with Con-Rod
- How to Remove and Install the Piston Rings
- How to Replace the Con-Rod Bearing
- How to Check (Determine Bearing Clearance with Plastigage) the Con-Rod Bearing Clearance
- How to Check (Determine Bearing Clearance with Micrometer and Inside Micrometer) the Con-Rod Bearing Clearance
- How to Replace the Piston
- How to Remove and Install the Crankshaft
- How to Check the Crankshaft, Check; Crankshaft Radial Runout
- How to Check (Determine Bearing Play with Plastigage) the Crankshaft, Check; Crankshaft Bearing Play
- How to Check the Crankshaft, Check; Crankshaft Bearing Play ((Determine Bearing Play Using External and Internal Micrometer) Inside Micrometer))
- How to Check for Plane Surface Inspection the Cylinder Block
- How to Check the Piston Projection
- How to Replace the Oil Filter - Oil Circuit
- How to Replace the Bypass Valve
- How to Replace the Seal Ring - Front Crankshaft
- How to Remove and Install (X 16 SZR with AC) the Oil Pan
- How to Remove and Install (X 16 SZR Without AC) the Oil Pan
- How to Remove and Install (16 LZ2) LZ2) the Oil Pan
- How to Remove (20 Nej) Nej) the Lower Part of Oil Pan
- How to Remove and Install (20 Nej) the Upper Part of Oil Pan
- How to Remove and Install (20 Nej) the Sensor, Dynamic Oil Level Control
- How to Remove and Install (X 16 SZR) the Oil Pump
- How to Remove and Install (16 LZ2) the Oil Pump
- How to Remove and Install (20 Nej) the Oil Pump
- How to Replace (16 LZ2 and 20 Nej) the Oil Short Circuit Valve
- How to Top Up and Bleed the Cooling System - Cooling System
- How to Check for Leaks the Cooling System
- How to Check for Leaks the Engine ((CO Content in Cooling System))
- How to Remove and Install the Fan Motor
- How to Remove and Install the Radiator (With Air Conditioning)
- How to Remove and Install (X 16 SZR) the Thermostat
- How to Replace (16 LZ2 and 20 Nej) Nej) the Seal Ring, Cylinder Head Thermostat Housing
- How to Remove and Install the Coolant Pump
- Engine Damping Blocks, Engine, Short- Block (Front Engine Damping Blocks, Remove and Install)
- How to Remove and Install the Rear Engine Damping Block
- How to Remove and Install (With Air Conditioning) the Auxiliary Component Bracket
- How to Remove and Install the Engine
- How to Repair Using Short-Block Engine the Engine
- Engine Management System Motronic M 1. 5.4 - Engine Compartment Survey (20 Nej)
- Wiring Harness Routing, Motronic M 1.5. 4
- How to Remove and Install the Throttle Valve Potentiometer
- How to Remove and Install the Throttle Body
- How to Remove and Install Reinstallation the Injectors
- How to Remove and Install the Crankshaft Pulse Pick-Up
- How to Remove and Install the Knock Sensor
- How to Remove and Install the Idle Speed Adjuster
- How to Remove and Install the Injection System Relay
- How to Remove and Install Reinstallation the Fuel Pump Relay
- How to Remove and Install the Intake Air Temperature Sensor
- How to Remove and Install the Coolant Temperature Sensor
- How to Remove and Install Reinstallation the Engine Control Unit
- How to Remove and Install Reinstallation the Tank Vent Valve
- Engine Management System Multec Central Fuel Injection - Engine Compartment Survey (X 16 SZR)
- Engine Compartment Survey (16 LZ2)
- Wiring Harness Routing, Multec Central Fuel Injection
- How to Check the Intake Air Pre-Heating
- How to Remove and Install (X 16 SZR) the Dis Ignition Module
- How to Remove and Install (16 LZ2) the High Voltage Distributor
- How to Remove and Install the Intake Manifold Pressure Sensor
- How to Remove and Install Reinstallation the Injection Valve
- How to Check (X 16 SZR) the Reference Gap Between Crankshaft Pulse Pickup and Increment Disc
- How to Remove and Install (X 16 SZR) the Knock Sensor
- How to Remove and Install the Fuel Pressure Regulator / Fuel Pressure Regulator Diaphragm
- How to Remove and Install (X 16 SZR) the Oxygen Sensor
- How to Remove and Install the Idle Speed Stepper Motor
- Octane Number Plug, Set Code (16 LZ2)
- How to Remove and Install (16 LZ2) the Program Memory
- How to Remove and Install (X 16 SZR) the Tank Vent Valve
- How to Remove and Install (16 LZ2) the Ignition Coil
- How to Remove and Install the Accelerator Pedal - Accelerator Pedal
- How to Remove and Install Install the Immobiliser with Immobiliser Control Unit Transponder
- How to Remove and Install (X16SZR) the Starter - Starter
- How to Remove and Install (16 LZ2 and 20 Nej) the Starter
- Special Service Tools (X16SZR, 16LZ2, 20NEJ)
- Technical Data - Sealants, Lubricants, and Locking Compounds (X16SZR, 16LZ2, 20NEJ)
- Technical Data - Oil Circuit (X16SZR, 16LZ2, 20NEJ)
- Technical Data - Cylinder Head (X16SZR, 16LZ2, 20NEJ)
- Technical Data - Crank Drive, Cylinder Block (X16SZR, 16LZ2, 20NEJ)
- Recommended Torque Values (X16SZR, 16LZ2, 20NEJ)
- Technical Data - Main Data (X16SZR, 16LZ2, 20NEJ)
- Technical Data - Checking and Adjustment Values (X16SZR, 16LZ2, 20NEJ)
- Technical Data - Drive Belts (X16SZR, 16LZ2, 20NEJ)
- Technical Data - Coolant Circuit (X16SZR, 16LZ2, 20NEJ)
- Technical Data - Engine Management (X16SZR, 16LZ2, 20NEJ)
- ABS
- ABS 415
- ABS 430
- ABS 5/TC, ABS 5.3/TC
- Accessories
- Additional Lighting
- Adhesive Foiles
- Air Conditioning
- Airbag
- Antenna
- Anti-Theft Warning System-M
- Automatic Transmission Front Wheel Drive
- Battery
- Body Equipment
- Brake Hydraulics, Brake Lines
- Brakes
- Car Level Control
- Central Door Locking System
- Central Locking with Atws (Electronic)
- Check Control
- Clutch
- Clutch and Transmission
- Communication / Navigation
- Connector pinouts
- Cooling System
- Corrosion Protection
- Diesel Engine
- DOHC Petrol Engine
- Ecc Electronic Climate Control
- Electrical Equipment and Instruments
- Electrical Window Winders
- Electronic Cruise Control
- Engine and Engine Aggregates
- Engine Electrics
- Exhaust System
- Fittings, Hinges, Locks
- Frame
- Front End
- Front Wheel Brake
- Front Wheel Suspension
- Front Wheel Suspension, Wheels and Tyres
- Fuel and Exhaust System
- Fuel Injection Systems
- Fuel System
- Fuse Box
- General Vehicle Information
- Glass, Window Guides, Window Winders
- Graphic Info Display
- Headlamps, Lamps and Horn
- Heating, Ventilation
- Heating, Ventilation, Air Conditioning (HVAC)
- Immobiliser
- Instruments, Telltales
- Maintenance, Body and Chassis Sheet Metal Parts, Frame
- Manual Transmission Front Wheel Drive
- Mid (Multi Info Display)
- Multitimer
- OHC Petrol Engine
- Other Accessories
- Outside Rear View Mirror
- Paint
- Painting Repair Operations
- Painting Repair System
- Parkpilot
- Power Steering
- Radiator Grille
- Radio
- Rear Axle and Rear Wheel Suspension
- Rear Axle Front Wheel Drive
- Rear End
- Rear Wheel Brake
- Roof Luggage Carrier (Railing)
- Seat Heating Systems
- Seats, Upholstery, Inner Trim Panels
- Secondary Air Injection
- Service Brake, Parking Brake
- Sheet Metal Parts (Bolted)
- Sheet Metal Parts (Cement and Seal)
- Sheet Metal Parts (Welded)
- Sliding Roof
- Steering
- Steering Gear
- Steering Linkage
- Steering Wheel - Steering Column
- Switches, Control Unit, Relays, Ignition Lock
- TID (Triple Info Display)
- Trailer Hitch
- Trim Panels, Radiator Grille, Spoiler
- Trim Strips, Lettering, Coverings
- Turbo-Charging
- Vehicle Side
- Wheels and Tyres
- Windscreen Wash/wipe System, Heated Screen
- Wiring Harnesses
- Xenon Control Unit (Headlamp Range Control)
