Replace Telephone System Microphone Opel Meriva A

Communication / Navigation 1 illustration

Remove

1. Remove front interior lamp with frame
2. Remove interior lamp bracket • Remove 2x screw (1)
3. Disconnect microphone and remove • Unclip compact plug (2) • Disconnect wiring harness plug (3

Replace Telephone System Microphone

Install

4. Connect microphone • Connect compact plug • Clip in compact plug
5. Install interior lamp bracket • Tighten 2x bolts
6. Install front interior lamp with frame
