Replace Telephone System Microphone (Retrofit Kit) Opel Meriva A

Remove

1. 1. Remove glove compartment (1) • Unscrew 4x bolt (2) • Disconnect glove compartment lighting wiring harness plug • Detach glove box cooling air duct

Note. Only in vehicles with AC.

2. 2. Remove upper A-pillar inner panelling
3. 3. Disconnect microphone wiring harness and partially remove • Disconnect wiring harness plug (1) • Separate cable ties (2) • Remove wiring harness

4. 4. Remove microphone • Remove microphone from headlining in direction of arrow

Install

5. 5. Install microphone • Insert microphone in headlining
6. 6. Partially route microphone wiring harness and connect • Route wiring harness • Fit cable ties • Connect wiring harness plug
7. 7. Install upper A-pillar inner panelling
8. 8. Fit glove compartment • Connect glove compartment lighting wiring harness plug • Attach glove compartment cooling air duct • Insert glove compartment • Tighten 4x screw

Note. Only in vehicles with AC.
