Starter Motor Replacement
| Callout | Component Name |
|---|
| Preliminary Procedures Disconnect the negative battery cable. Refer to Battery Negative Cable Disconnection and Connection . Remove the intake manifold. Refer to Intake Manifold Replacement . |
| 1 | Starter Solenoid Terminal Nut Caution: Refer to Fastener Caution in the Preface section. Tighten 10 N·m (89 lb in) |
| 2 | Positive Battery Cable Terminal |
| 3 | Starter Solenoid "S" Terminal Nut Tighten 3 N·m (27 lb in) |
| 4 | Engine Harness Terminal |
| 5 | Engine Harness Terminal |
| 6 | Starter Motor Bolt (Qty: 2) Tighten 40 N·m (30 lb ft) |
| 7 | Starter Bolt |
