Generator Replacement
| Callout | Component Name |
|---|---|
| Preliminary Procedures Disconnect the negative battery cable. Refer to Battery Negative Cable Disconnection and Connection . Remove the air cleaner outlet duct. Refer to Air Cleaner Outlet Duct Replacement . Remove the drive belt. Refer to Drive Belt Replacement . | |
| 1 | Engine Harness Generator Connector |
| 2 | Engine Harness Ground Terminal Boot |
| 3 | Engine Harness Ground Terminal Nut Caution: Refer to Fastener Caution in the Preface section. Tighten 20 N·m (15 lb ft) |
| 4 | Engine Harness Ground Terminal |
| 5 | Generator Bolt (Qty: 3) Tighten 22 N·m (16 lb ft) |
| 6 | Generator |
