Special Service Tools Opel Astra G

OHC Petrol Engine 8 illustrations
KM-135Adapter
To measure engine oil pressure in conjunction with KM-498-B
KM-194-ESpark Plug Key
To remove and install spark plugs, A/F 16 mm
KM-301Gauge Bar
To check piston projection
KM-352Installer
To install valve stem sealing
KM-412Engine Overhaul Stand
To hold the removed engine
KM-412-10Adapter
To hold engine in conjunction with KM-412
KM-417Assembly Sleeves
To press crankshaft seal ring into oil pump housing
KM-421-AAdjusting Wrench – A/F 41 mm
To adjust toothed belt tension
KM-422Installer
To press seal ring in camshaft housing
KM-427Remover / Installer
To install guide pins into engine block
KM-470-BAngular Torque Wrench
To tighten cylinder head bolts
KM-471Adapter
To check pressurised cooling system in conjunction with cooling system tester
KM-498-BOil Pressure Manometer
To check engine oil pressure in conjunction with KM-135
KM-565-ARemover/Installer
To remove and install rocker arms and valve play compensator
MKM-571-BDial Gauge
To measure piston projection
MKM-588-APressure Gauge
To check fuel pressure
MKM-596-ATemperature Gauge
To measure oil temperature, exhaust gas special test (German AU)
MKM-604-DTorx Bit and Socket Set
To remove/install Torx bolts
KM-609Electronic Kit I
Diagnosis of electric and electronic systems
MKM-610Torque Wrench, 1/2"
Range 30 – 130 Nm / 22 – 96 lbf. ft.
MKM-611Torque Wrench, 3/8"
Range 10 – 60 Nm / 7 – 44 lbf. ft.
KM-634Remover/Installer
To remove/install piston pin
KM-652Flywheel Locking Device
To lock flywheel/drive disc
KM-658Installer
To install rear crankshaft seal ring
MKM-667Pressure and Vacuum Pump
To check for leaks in vacuum unit
MKM-669Torque Wrench, 1/2"
Range 50 – 300 Nm / 37 – 221 lbf. ft.
KM-726-AOil Filter Wrench
To remove/install the oil filter
KM-796-ADismantler
To open quick fittings for fuel lines
KM-834-ARemover/Installer
To remove and install heat sleeves
KM-840Remover
To remove valve stem seal
MKM-889Automatic Valve Spring Lever
To remove/install the valve stem seals (cylinder head installed)
MKM-891Valve Lifter Depressor
To remove/install camshaft (cylinder head installed)
KM-904Base Frame
To remove and install various vehicle components with additional adapters
KM-911Flywheel Locking Device
To lock flywheel/drive disc
KM-2355Socket Wrench T55
To loosen/tighten cylinder head bolts
KM-6000Centring Tool
To remove and install front axle in conjunction with KM-904
KM-6001-AEngine Mount
To align engine to body in conjunction with KM-6173
KM-6173Engine Mount
To support engine on front axle body in conjunction with KM-6001-A
KM-6179Remover/Installer
To remove and install oxygen sensor
KM-6283Adjusting Wrench – A/F 39 mm
To adjust toothed belt tension
KM-J-34730-91Pressure Tester
To check fuel pressure
