Remove
Battery Ground Cable, Disconnect
Instrument assembly – see operation "Instrument Assembly, Remove and Install or Replace".
Mixed Air Nozzle Casing – see operation "Mixed Air Nozzle Casing – Driver's Side, Remove and Install" in group "D".
Release ground cable behind instrument assembly and light switch control wiring harness plug from mixed air nozzle casing.
Remove storage compartment. Unlock fuse box below (2) and unscrew above – 2 screws.
Guide attaching strap (5) up over the metal frame first.
Pull fuse box carefully out of instrument panel. Disconnect relays (1) designated in illustration.
Release wiring harness plug (4) and disconnect; remove locking pin (3); remove multi-timer sideways from fuse box.
Install
Multi-timer into fuse box.
Locking pin, wiring harness plug, relay.
Carefully introduce fuse box,
Guide attaching strap up over the metal frame first.
Fasten fuse box. Storage compartment,
Light switch control wiring harness plug, mixed air nozzle casing,
Ground cable, instrument assembly,
Battery ground cable, connect.
