Multitimer
The multitimer is integrated into the fuse body; its design, function and position is identical to the unit in the Vectra-B.
Block Diagram
| 15 | Ignition ON (terminal 15) |
|---|---|
| 30 | Battery positive (terminal 30) |
| 31 | Ground (terminal 31) |
| 58D | Illumination |
| A11 | Multitimer |
| A12 | Control unit, central locking unlock/lock |
| A13 | Control unit, anti-theft warning system |
| B24 | Odometer signal |
| E16 | Interior lamp |
| E17.4 | Switch, heated rear screen |
| E31.7 | Switch, heated rear screen |
| H1.14 | Telltale, trailer turn signal |
For more detailed information on the identification of new units, see section 6.1.
6.4.1 Block Diagram
| K3 | Relay, heated rear screen |
|---|---|
| K4 | Relay, front fog lamps |
| K5 | Relay, rear fog lamp |
| K6 | Relay, rear screen wiper |
| K7 | Relay, mirror heating |
| K8 | Relay, left turn signal |
| K9 | Relay, right turn signal |
| K10 | Relay, windscreen wiper |
| S1/W | Ignition lock |
| S2 | Light switch centre |
| Dimming | |
| Interior lamp | |
| Front fog lamps | |
| Rear fog lamp | |
| Parking lamp, low beam | |
| S5 | Turn signal switch |
| Turn signal, left and right | |
| S6 | Hazard warning lamps switch |
| S22 | Switch assembly, wiper system |
| Windscreen wiper interval | |
| Rear screen wiper interval | |
| Windscreen/rear screen washer | |
| S38 | Door contact switch, driver's door |
| S39 | Door contact switch, co-driver's door |
| S40 | Door contact switch, rear left |
| S41 | Door contact switch, rear right |
For more detailed information on the identification of new units, see section 6.1.
