Audio, Visual & Navigation System (Display Audio): Removal & Installation Nissan Quest IV

REMOVAL

1. Remove cluster lid D. Refer to " «REMOVAL AND INSTALLATION»(ref-672652-S11949434712014112400000) ".
2. Remove audio unit mounting screws.
3. Pull out audio unit, and then disconnect antenna feeder and harness connectors.
4. Remove audio unit and brackets as a single unit.
5. Remove brackets from audio unit.

INSTALLATION

Install in the reverse order of removal.

1. Remove front door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-672656-S07016970752014112400000) ".
2. Remove front door woofer screws and disconnect front door woofer connector.

Install in the reverse order of removal.

1. Remove speaker grille from instrument panel. Refer to " «REMOVAL AND INSTALLATION»(ref-672652-S11949434712014112400000) ".
2. Remove screws and disconnect connector, and remove the front squawker. WARNING: Never damage wind shield glass.

Install in the reverse order of removal.

1. Remove slide door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-672656-S21571296292014112400000) ".
2. Remove screws and disconnect connector, and remove slide door speaker.

Install in the reverse order of removal.

1. Remove back door finisher. Refer to " «REMOVAL AND INSTALLATION»(ref-672623-S33628633302014112400000) ".
2. Remove screws to remove rear view camera from back door finisher.

Install in the reverse order of removal.

Note. Adjust the guide line position if the guide line position is shifted after installing the rear view camera. Refer to " ADJUSTMENT ".

1. Remove center console upper finisher. Refer to " «DISASSEMBLY AND ASSEMBLY»(ref-672652-S04191511472014112400000) ".
2. Unhook pawl to remove USB connector from center console upper finisher.

Install in the reverse order of removal.

1. Remove cluster lid C. Refer to " «REMOVAL AND INSTALLATION»(ref-672652-S11949434712014112400000) ".
2. Remove TEL adapter unit mounting bracket screws.
3. Disconnect connector to remove TEL adapter unit, TEL antenna, and bracket as a single unit.
4. Remove bracket screws to remove TEL adapter unit from bracket.

Install in the reverse order of removal.

1. Remove cluster lid C. Refer to " «REMOVAL AND INSTALLATION»(ref-672652-S11949434712014112400000) ".
2. Remove TEL adapter unit mounting bracket screws.
3. Disconnect connector to remove TEL adapter unit, TEL antenna, and bracket as a single unit.
4. Disconnect connector and remove screws to TEL antenna.

Install in the reverse order of removal.

1. Remove map lamp assembly. Refer to " «REMOVAL AND INSTALLATION»(ref-672665-S03049040712014112400000) ".
2. Unhook pawls to remove microphone from map lamp assembly. CAUTION: Carefully handle the pawl fixing the microphone to prevent damage to the pawl.

Install in the reverse order of removal.

Note. After installing microphone, check that it is securely installed with no backlash.

Scheme 228

Scheme 229

1. Remove rear upper ventilator duct 2. Refer to " «EXPLODED VIEW»(ref-672613-S19314510802014112400000) ".
2. Disconnect antenna feeder connector.
3. Remove nut, and remove satellite radio antenna and the cover from the vehicle as a single unit.

Install in the reverse order of removal.

1. Remove rear pillar garnish RH. Refer to " «REAR PILLAR GARNISH: REMOVAL AND INSTALLATION»(ref-672656-S12526951132014112400000) ".
2. Remove screw and disconnect connector, and remove antenna amp.

Install in the reverse order of removal.

Scheme 230

"tringle": Indicates that the part is connected at points with same symbol in actual vehicle.
