AV COMMUNICATION SYSTEM

1. Do not apply voltage of 7.0 V or higher to the measurement terminals.
2. Use the tester with its open terminal voltage being 7.0 V or less.
3. Be sure to turn ignition switch OFF and disconnect the battery cable from the negative terminal before checking the circuit.

Scheme 173

Scheme 174

1. Solder the repaired parts, and wrap with tape. [Frays of twisted line must be within 110 mm (4.33 in).]
2. Do not perform bypass wire connections for the repair parts. (The spliced wire will become separated and the characteristics of twisted line will be lost.)

Commercial Service Tools

Tool Description Power tool Loosening screws

Scheme 175

Scheme 176

Scheme 177

1. The AV control unit is equipped with the following parts. It is the master unit integrated with functions and controls the multi-AV system. Units equipped AM/FM electronic tuner CD/DVD drive USB interface Camera controller
2. Signals necessary for the vehicle information display function are received from ECM and the combination meter via CAN communication.
3. Signals necessary for vehicle setting functions are sent and received with BCM via CAN communication.
4. It inputs the signal for driving status recognition (vehicle speed signal, reverse signal, and parking brake signal).
5. A predictive course line is generated on the camera image from the rear view camera, and it is shown on the front display.
6. It inputs the signals for driving status recognition (vehicle speed, reverse and parking brake).

Note. For details of each functions, refer to " MULTI AV SYSTEM: SYSTEM DESCRIPTION ".

AM/FM Electronic Tuner

The adoption of the PLL frequency synthesizer system enables the signal outputting with accurate frequencies.

CD/DVD drive

1. It is CD-R/CD-RW compliant and enables MP3 and WMA files to play music.
2. It displays the artist name, album title or song title recorded to the file by the ID3 tag/WMA tag display function.
3. DVD playback function is equipped.

USB Interface

1. Music can be played by connecting an iPod® or USB memory.

Camera Controller

1. Warning message, width/distance guiding line and predictive course line are generated on the image from the rear view camera.
2. The predictive course line is drawn based on the steering signal received from the steering sensor via CAN communication.

Speaker

12 speakers system is adopted.

Scheme 178

1. ø 15.0 x 23.0 cm (6 x 9 in) speaker is installed to the bottom of the front door.
2. Sound signal is input from the BOSE amp. to output low range sounds. Rated input: 13.6 W Maximum input: 40.5 W Impedance: 2 ohms

Scheme 179

1. ø 6.5 cm (2 in) squawker is installed to the side of instrument panel.
2. Sound signal is input from the BOSE amp. to output high and mid range sounds. Rated input: 4.8 W Maximum input: 14 W Impedance: 3.6 ohms

Scheme 180

1. ø 8 cm (3 in) squawker is installed to the center of instrument panel.
2. Sound signal is input from the BOSE amp. to output high and mid range sounds. Rated input: 7.6 W Maximum input: 22.5 W Impedance: 3.6 ohms

Scheme 181

1. ø 8 cm (3 in) squawker is located at the lower part of the front of the slide door.
2. Sound signal is input from the BOSE amp. to output high and mid range sounds. Rated input: 7.6 W Maximum input: 22.5 W Impedance: 3.6 ohms

Scheme 182

1. ø 16 cm speaker is located at the lower part of the back of the slide door.
2. Sound signal is input from the BOSE amp. to output high, mid, and low range sounds. Rated input: 12.9 W Maximum input: 38.5 W Impedance: 2.1 ohms

Scheme 183

1. ø 8 cm (3 in) squawker is installed to the side of luggage room.
2. Sound signal is input from the BOSE amp. to output high and mid range sounds. Rated input: 7.6 W Maximum input: 22.5 W Impedance: 3.6 ohms

Scheme 184

1. Woofer integral with the enclosure is located in the luggage floor box to improve the sound-field characteristics of the bass range.
2. Composed of two woofers and a woofer amp.
3. The woofer is activated when receiving a woofer amp. ON signal from the BOSE amp.

Scheme 185

1. Inputs the TEL voice signal from TEL antenna and outputs it to the AV control unit.
2. It is connected with the AV control unit via AV communication and controlled with the AV control unit.

TEL Antenna

Receives the TEL voice signal from cellular phone and outputs it to the TEL adapter unit.

Scheme 186

Scheme 187

1. The voice control/TEL microphone is installed on the left side of the map lamp assembly.
2. The power is supplied from the TEL adapter unit to the microphone, transmitting sound signals to the TEL adapter unit at the voice control or during hands-free phone communication.

Scheme 188

1. USB connector is installed to the console box.
2. iPod® and USB memory can be connected to the AV control unit.

Scheme 189

1. Installed to the rear of center console.
2. Sound signals and image signals from the external equipment are transmitted to the AV control unit.

Rear View Camera

1. The rear view camera is installed to the back door finisher.
2. Super-small CCD camera (color) using CCD* for the image pickup element is adopted.
3. With the mirror processing function, a mirror image is sent as if it is viewed by a rear view mirror.
4. Power for the camera is supplied from the AV control unit, and the image at the rear of the vehicle is sent to the AV control unit.

Note. *: Abbreviation of Charge Coupled Device. CCD can turn incident light from the lens into electrons and memorize the image like a photo.

Scheme 190

SATELLITE RADIO ANTENNA

1. Satellite radio antenna is installed to the rear center of the roof.
2. Receives satellite radio waves and outputs it to satellite radio tuner.

Scheme 191

1. The adoption of the wireless headphone allows the independent audio listening on the rear seat.
2. Sound signals are received from the rear display unit via infrared communication.

Scheme 192

1. The adoption of the infrared remote controller allows audio operation and other operations on the rear seat.
2. The light-receptive spot is included in the rear display unit.

Scheme 193

Note. The name MULTIFUNCTION SWITCH indicates the integration of PRESET SWITCH and MULTIFUNCTION SWITCH virtually.

CAN COMMUNICATION

AV CONTROL UNIT INPUT SIGNAL DESCRIPTION

COMMUNICATION SIGNAL

1. AV control unit function by transmitting/receiving data one by one with each unit (slave unit) that configures them completely as a master unit by connecting between units that configure MULTI AV system with two AV communication lines (H, L).
2. Two AV communication lines (H, L) adopt a twisted pair line that is resistant to noise.
3. AV control unit is connected with front display unit and serial communication, and it transmits the required signal of display and display control and receives the response signal from front display unit.
4. AV control unit controls satellite radio tuner by serial communication.

1. AV control unit is connected by CAN communication, and it receives data signal from ECM and combination meter. It computes and displays fuel economy information value with the obtained information.
2. The AV control unit, which has the vehicle setting function, transmits and receives data on vehicle setting condition via CAN communication with the BCM.
3. AV control unit receives steering angle signal from steering angle sensor via CAN communication and performs control of predictive course line in rear view monitor image.

AUDIO FUNCTION

The audio system is equipped with the following functions.

Operating Signal

Audio system operation can be performed with multifunction switch, preset switch, or steering switch.

1. Operating signal is transmitted to AV control unit with AV communication when it is operated by multifunction switch or preset switch.
2. The disk eject signal is transmitted to AV control unit by hardwire, when disk eject switch is operated.
3. Operating signal is transmitted to AV control unit with steering switch signal when it is operated by steering switch.
4. Operation status of audio is indicated at front display by RGB image signal, RGB area signal, and RGB image synchronizing signal.

AM/FM Radio Function

1. AM/FM radio tuner is built into AV control unit.
2. AM/FM radio wave is received by radio antenna, next it is amplified by antenna amp., and finally it is input to AV control unit.
3. FM radio wave is received by FM sub antenna, and it is transmitted to the AV control unit directly.
4. Audio signal is input to BOSE amp. and BOSE amp. outputs to woofer and each speaker.

Satellite Radio Mode

1. Satellite radio tuner is controlled by communication signal and request signal with AV control unit.
2. Sound signal (satellite radio) is received by satellite radio antenna and transmitted to AV control unit via satellite radio tuner.
3. AV control unit outputs audio signal (satellite radio) to BOSE amp. The signal is also outputted from BOSE amp. to woofer and each speaker.

CD Mode

1. CD function is built into AV control unit.
2. AV control unit outputs audio signal to BOSE amp. The signal is also outputted from BOSE amp. to woofer and each speaker when CD is inserted to AV control unit.
3. For further information about CD function specifications, refer to " «AV CONTROL UNIT»(ref-672661-S18722904532014112400000) ".

USB Connection Function

1. Connecting iPod® or USB memory allows the driver to play iPod® music files or USB memory-stored music files.
2. Sound signals of music files stored in iPod® or USB memory is transmitted from the USB connector to the AV control unit.
3. AV control unit outputs sound signal to BOSE amp. The signal is also outputted from BOSE amp. to woofer and each speaker.
4. iPod® is recharged when connected to USB connector.
5. Compliant USB memory and data recorded are limited. USB memory USB1.1 File system FAT16 FAT32
6. Only files that meet the following conditions will be played. Music file File format "MP3", "WMA" File extension ".mp3", ".wma" Maximum file size 2 GB

Note. iPod® is a trademark of Apple inc., registered in the U.S. and other countries. Image signals cannot be received from iPod® or USB memory. Use the enclosed USB harness when connecting iPod® to USB connector.

DVD PLAYBACK FUNCTION

1. DVD is played by inserting DVD into the AV control unit.
2. DVD image signals are transmitted to the front display unit, and DVD sound signals are transmitted to woofer and each speaker via BOSE amp.
3. DVD image signals and sound signals are transmitted to the rear display unit. The rear display unit transmits the sound signals to the headphone via infrared communication.
4. For further information about DVD function specifications, refer to " «AV CONTROL UNIT»(ref-672661-S18722904532014112400000) ".

MOBILE ENTERTAINMENT SYSTEM

Image and sound (DVD, USB memory-stored video data, and auxiliary input) played by AV control unit can be enjoyed in rear seat using rear display unit and headphone.

Operating Signal

1. The mobile entertainment system can be controlled by one of the remote controller.
2. It receives the operation signal of the remote controller by the remote control receiver built into rear display unit, and then transmits it to the AV control unit.

Headphone Sound

Headphone sound signals are transmitted to infrared communication between rear display unit and headphone.

Screen rear display

1. Image signal output from AV control unit is transmitted to the rear display unit.
2. The rear display unit receives the composite image signal (DVD, USB memory-stored video data, and auxiliary input) from the AV control unit.
3. The rear display unit switches composite images through the communications with the AV control unit via AV communication.

BLUETOOTH® HANDS-FREE PHONE FUNCTION

1. TEL adapter unit is controlled with AV communication from AV control unit.
2. When the cellular phone is connected to the TEL adapter unit via TEL antenna in Bluetooth® communication, hands-free phone communication can be performed.
3. Simply operating the steering switch without releasing hands from the steering wheel allows the driver to make a phone call or receive a phone call.
4. When a Bluetooth® communication compliant phone is registered to the TEL adapter unit, hands-free phone communication can be performed. Five units of Bluetooth® communication devices can be registered to the TEL adapter unit.
5. The content of the memory (telephone book) of the cellular phone can be recorded in the TEL adapter unit.
6. TEL adapter unit has the on board self-diagnosis function. Refer to " «ON BOARD DIAGNOSIS FUNCTION»(ref-672661-S00971628332014112400000) ".

When A Call Is Originated

1. Spoken voice sound output from the microphone (microphone signal) is input to TEL adapter unit.
2. TEL adapter unit outputs to cellular phone with Bluetooth® communication as a TEL voice signal.
3. Voice sound is then heard at the other party.

When Receiving A Call

1. Voice sound is input to own cellular phone from the other party.
2. TEL voice signal is input to TEL adapter unit by establishing Bluetooth® communication from cellular phone, and the signal is output to front speaker via BOSE amp.

AUXILIARY INPUT FUNCTION

1. Image and sound can be output from an external device by connecting a device with front auxiliary input jacks.
2. AUX image signals are transmitted to front and rear display unit via AV control unit
3. AUX sound signals are transmitted to each unit as follows: To each speaker via AV control unit and BOSE amp. To the rear display unit via AV control unit, and headphone sound signals are transmitted to infrared communication between rear display unit and headphone.

REAR VIEW MONITOR FUNCTION

Operation Description

1. When the selector lever is shifted to the reverse position, the rear view monitor image is displayed.
2. When the selector lever is shifted to any position other than the reverse position, the original image (the image displayed before the rear view monitor image) is displayed.

Camera Image Operation Principle

1. The AV control unit that receives the reverse signal input supplies power to the rear view camera and gives input of image signal.
2. The AV control unit outputs the rear view camera image to the front display when the reverse signal is inputted.
3. The AV control unit generates the warning message, side distance guiding lines and the predictive course lines on the image from the rear view camera, and transmits the rear view camera image signal to the front display unit.

Side Distance Guide Lines and Predictive Course Lines Display Function at Rear View Monitor Display

Scheme 194

1. The side distance guide lines and the predictive course line that indicate the vehicle route according to the steering angle are displayed at the rear view monitor display to allow the driver to more easily judge distances between the vehicle and objects and help the driver back into a parking space.
2. The AV control unit receives the steering angle signal from the steering angle sensor via CAN communication and draws a predictive course line according to the steering angle signal.
3. When the predictive course line are displayed, the side distance guide lines are displayed translucently.
4. The predictive course line are not displayed when the steering is in the neutral position.
5. The predictive course line can be displayed/not displayed by selecting "Settings" - "Others" - "Camera" - "Predictive Course Lines"

Precautions for Side Distance Guide Lines and predictive course line Display on the Rear View Monitor Display Side distance guide lines and predictive course line on the display may be different from actual lines depending on vehicle conditions and road conditions.

Precautions for road conditions

Scheme 195

1. Since guide lines and predictive course line are drawn based on the road, a different distance may be displayed if a protruding block is present nearby.

Precautions for block

Scheme 196

1. Since guide lines and predictive course line are drawn based on the road, a different distance may be displayed if a protruding block is present nearby.

VEHICLE INFORMATION FUNCTION

1. Status of audio, climate control system, fuel economy, maintenance and navigation are displayed.
2. AV control unit displays the fuel consumption status while receiving data signal through CAN communication from ECM and combination meter.

Vehicle Setting Function

The AV control unit transmits and receives data signals via CAN communication with the BCM, allowing the following vehicle settings.

1. To turn on the automatic interior room lamp (ON/OFF) when the door is unlocked
2. To adjust the auto light sensitivity (+/-)
3. To operate the intermittent wiper linked with the vehicle speed (ON/OFF)
4. Vehicle setting initialization

Note. The setting items vary depending on the vehicle specification

Vehicle Signals

A comparison check can be made of each actual vehicle signal and the signals recognized by the system.

Scheme 197

Climate Control

Refer to HEATER & AIR CONDITIONING CONTROL SYSTEM (AUTOMATIC AIR CONDITIONING) or HEATER & AIR CONDITIONING CONTROL SYSTEM (MANUAL AIR CONDITIONING) for details.

Error History

The self-diagnosis results are judged depending on whether any error occurs from when "Self-diagnosis" is selected until the self-diagnosis results are displayed.

However, the diagnosis results are judged normal if an error has occurred before the ignition switch is turned ON and then no error has occurred until the self-diagnosis start. Check the "Error Record" to detect any error that may have occurred before the self-diagnosis start because of this situation.

The frequency of occurrence is displayed in a count up manner. The actual count up method differs depending on the error item.

Count up method A

1. The counter resets to 0 if an error occurs when ignition switch is turned ON. The counter increases by 1 if the condition is normal at a next ignition ON cycle.
2. The counter upper limit is 39. Any counts exceeding 39 are ignored. "The counter can be reset (no error record display) with the "Delete log" switch or CONSULT.

Count up method B

1. The counter increases by 1 if an error occurs when ignition switch is ON. The counter will not decrease even if the condition is normal at the next ignition ON cycle.
2. The counter upper limit is 50. Any counts exceeding 50 are ignored. "The counter can be reset (no error record display) with the "Delete log" switch or CONSULT.

Scheme 198

Error item

Some error items may be displayed simultaneously according to the cause. If some error items are displayed simultaneously, the detection of the cause can be performed by the combination of display items

Camera Cont.

The two functions of "Correct Draw Line of Rear view Cam", "Confirm Configuration" are available.

Scheme 199

Adjust Offset of Rear view Camera

Scheme 200

1. Use this mode to adjust the guide line display position of the rear view monitor if necessary after removing the rear view monitor camera. CAUTION: After the adjustment, never perform other operations for one minute.

Factory Configuration Confirmation

Scheme 201

1. Configuration stored in the AV control unit can be checked.

Delete Unit Connection Log

Deletes any unit connection records and error records from the AV control unit memory. (Clear the records of the unit that has been removed.)

Scheme 202

Initialize Settings

"User Data Initialization" and "Accessory Number Initialization" are possible.

Scheme 203

AV Communication

When "AV communication" of "CAN Diag Support Monitor" is selected, the following function will be performed.

DATA MONITOR

Note. The following table includes information (items) inapplicable to this vehicle. For information (items) applicable to this vehicle, refer to CONSULT display items.

ALL SIGNALS

1. Displays the status of the following vehicle signals inputted into the AV control unit.
2. For each signal, actual signal can be compared with the condition recognized on the system.

SELECTION FROM MENU

Allows the technician to select which vehicle signals should be displayed and displays the status of the selected vehicle signals.

WORK SUPPORT

Adjusts the neutral position of the steering angle sensor.

CONFIGURATION

Configuration includes functions as follows.

The Details of Error Count

The error count guides "0" when the error occurs. The next time it counts up "1" if it is normal with the ignition switch ON. It continues the count up unless the initialization of hands-free phone system is performed.

Scheme 204

PHYSICAL VALUES

Terminal (Wire color) Description Condition Standard Reference value (Approx.) + - Signal name Input/Output 6 (L) 15 (GR) Steering switch signal A Input Ignition switch ON Keep pressing SOURCE switch. 0 - 3.3 V 0 V Keep pressing SEEK UP switch. 0.7 V Keep pressing SEEK DOWN switch. 1.3 V Keep pressing switch 2.0 V Except for above. 3.3 V 7 (O) 20 (B) ACC power supply Input Ignition switch ACC - 9.0 - 16.0 V Battery voltage 9 (O) 20 (B) Dimmer signal Input Ignition switch ON Either of the following conditions Lighting switch is OFF Lighting switch is 1st or 2nd, and the area around the vehicle is bright (shine a light on the optical sensor) 3.0 V or less 0 V Lighting switch is 1st or 2nd, and the area around the vehicle is dark (block the light from the optical sensor) 7.0 - 16.0 V 12.0 V 16 (P) 15 (GR) Steering switch signal B Input Ignition switch ON Keep pressing VOL DOWN switch. 0 - 3.3 V 0 V Keep pressing VOL UP switch. 0.7 V Keep pressing switch. 1.3 V Except for above. 3.3 V 19 (SB) 20 (B) Battery power supply Input Ignition switch OFF - 9.0 - 16.0 V Battery voltage 36 (P) 37 (Y) Signal VCC Output Ignition switch ACC - 8.0 - 9.5 V 8.8 V 38 (G) 20 (B) Horizontal synchronizing (HP) signal Input Ignition switch ON - Waveform of 1.0 V - 5.5 V is input. 39 (R) 20 (B) Communication signal (DISP-->CONT) Input Ignition switch ON When adjusting display brightness. Waveform of 0.5 V or less - 3.5 V or more is input. 40 (B) 20 (B) RGB area (YS) signal Output Ignition switch ON At RGB image is displayed. 5.5 V or less 5.0 V At AUX image is displayed. Waveform of 0.8 V - 5.5 V is Output. 41 - Shield - - - - - 42 (W) 20 (B) RGB synchronizing signal Output Ignition switch ON - Waveform of 0.8 V - 5.5 V is Output. 43 (R) 20 (B) RGB image signal (R: red) Output Ignition switch ON Start Confirmation/Adjustment mode, and then display color bar by selecting "Color Spectrum Bar" on Display Diagnosis screen. Outputs waveform synchronized with RGB image. 44 (W) 20 (B) RGB image signal (G: green) Output Ignition switch ON Start Confirmation/Adjustment mode, and then display color bar by selecting "Color Spectrum Bar" on Display Diagnosis screen. Outputs waveform synchronized with RGB image. 45 (B) 20 (B) RGB image signal (B: blue) Output Ignition switch ON Start Confirmation/Adjustment mode, and then display color bar by selecting "Color Spectrum Bar" on Display Diagnosis screen. Outputs waveform synchronized with RGB image. 47 (B) 46 (W) Composite image signal (for front display unit) Output Ignition switch ON When DVD or AUX image is displayed on front display unit. Outputs waveform synchronized with composite image. 48 (BR) 49 (SB) Inverter VCC Output Ignition switch ACC - 8.0 - 9.5 V 8.8 V 50 (R) 20 (B) Vertical synchronizing (VP) signal Input Ignition switch ON - Waveform of 1.0 V - 5.5 V is Input. 51 (G) 20 (B) Communication signal (CONT-->DISP) Output Ignition switch ON When adjusting display brightness. Waveform of 0.4 V - 5.3 V is Output. 52 - Shield - - - - - 57 - Shield - - - - - 58 - Shield - - - - - 61 (BR) 69 (Y) AUX image signal Output Ignition switch ON When AUX image is displayed on front or rear display unit. Outputs waveform synchronized with AUX image. 62 (B) 20 (B) Camera image signal input Ignition switch ON When camera image is displayed. Outputs waveform synchronized with camera image. 65 - Shield - - - - - 67 (W) 66 (B) Composite image signal (for rear display unit) Output Ignition switch ON When DVD or AUX image is displayed on rear display unit Outputs waveform synchronized with composite image. 70 - Shield - - - - - 71 - Shield - - - - - 73 (R) 72 (R) Camera power supply Output Ignition switch ON When camera image is displayed. 5.9 - 6.5 V 6.2 V 76 (LG) - AV communication signal (L) Input/Output - - - - 77 (V) - AV communication signal (H) Input/Output - - - - 78 (LG) - AV communication signal (L) Input/Output - - - - 79 (SB) - AV communication signal (H) Input/Output - - - - 80 (P) - CAN-L Input/Output - - - - 81 (L) - CAN-H Input/Output - - - - 96 (BR) 82 (W) Disk eject signal Input Ignition switch ON Keep pressing disk eject switch. - 0 V Except for above. - 3.3 V 87 (R) 88 (W) Sound signal (TEL voice, voice guidance) Output Ignition switch ON During voice guide output with the switch pressed. Outputs waveform synchronized with sound. 90 (BR) 91 (Y) Headphone sound signal RH Output Ignition switch ON Headphone sound output. Outputs waveform synchronized with sound. 92 (Y) 20 (B) Vehicle speed signal (8-pulse) Input Ignition switch ON When vehicle speed is approx. 40 km/h (25 MPH) Waveform according to vehicle speed is input. NOTE: The maximum voltage varies depending on the specification (destination unit). 93 (W) 20 (B) Parking brake signal Input Ignition switch ON Parking brake is applied. 1.5 V or less 0 V Parking brake is released. 3.5 V or more 4.5 V 94 (BR) 20 (B) Reverse signal Input Ignition switch ON Selector lever is in "R" position. 7.0 - 16.0 V 12.0 V Selector lever is in other than "R" position. - 0 V 95 (G) 20 (B) Ignition signal Input Ignition switch ON - 9.0 - 16.0 V Battery voltage 103 (B) 102 (W) AUX sound signal LH Input Ignition switch ON When AUX mode is selected on front or rear display unit. Outputs waveform synchronized with sound. 104 (R) 102 (W) AUX sound signal RH Input Ignition switch ON When AUX mode is selected on front or rear display unit. Outputs waveform synchronized with sound. 105 (GR) - Shield - - - - - 106 (P) 107 (L) Headphone sound signal LH Output Ignition switch ON Headphone sound output. Outputs waveform synchronized with sound. 108 (BR) 114 (Y) Sound signal rear RH Input Ignition switch ON Sound output Outputs waveform synchronized with sound. 109 (W) 115 (B) Sound signal front RH Input Ignition switch ON Sound output Outputs waveform synchronized with sound. 110 (LG) 20 (B) BOSE amp. ON signal Output Ignition switch ACC - 7.0 - 16.0 V 12.0 V 111 (GR) - Shield - - - - - 112 (B) 118 (W) Sound signal rear LH Input Ignition switch ON Sound output Outputs waveform synchronized with sound. 113 (R) 119 (G) Sound signal front LH Input Ignition switch ON Sound output Outputs waveform synchronized with sound. 120 (R) 124 (B) Satellite radio sound signal LH Input Ignition switch ON When satellite radio mode is selected. Outputs waveform synchronized with sound. 121 (W) 125 (G) Satellite radio sound signal RH Output Ignition switch ON When satellite radio mode is selected. Outputs waveform synchronized with sound. 122 (R/W) 20 (B) Communication signal (CONT-->SAT) Output Ignition switch ON When satellite radio mode is selected. Waveform of 1.5 - 6.0 V is input. 126 - Shield - - - - - 127 - Shield - - - - - 129 (R/L) Ground Request signal (SAT-->CONT) Input Ignition switch ON When satellite radio mode is selected. Waveform of 1.1 V or less - 7.181 V or more is Input. 130 (B) Ground Communication signal (SAT-->CONT) Input Ignition switch ON When satellite radio mode is selected. Waveform of 1.1 V or less - 7.181 V or more is Input. 132 (G) - USB ground - - - - - 133 (W) - USB D- signal - - - - - 134 (R) - V BUS signal - - - 4.75 - 5.25 V - 135 (B) - USB D+ signal - - - - - 136 - Shield - - - - - 150 20 (B) Antenna amp. ON signal Input Ignition switch ACC - 7.0 - 16.0 V 12.0 V 151 - AM-FM main Input - - - - 152 - FM sub Input

Scheme 205

Scheme 206

Scheme 207

Scheme 208

Scheme 209

Scheme 210

Terminal (Wire color) Description Condition Standard Reference value (Approx.) + - Signal name Input/Output 2 (BR) 13 (SB) Inverter VCC Input Ignition switch ACC - 8.0 - 9.5 V 8.8 V 3 (P) 14 (Y) Signal VCC Output Ignition switch ACC - 8.0 - 9.5 V 8.8 V 5 - Shield - - - - - 6 (W) 1 (B) RGB image signal (G: green) Input Ignition switch ON Start Confirmation/Adjustment mode, and then display color bar by selecting "Color Spectrum Bar" on Display Diagnosis screen. Outputs waveform synchronized with RGB image. 7 - Shield - - - - - 8 (G) 1 (B) Horizontal synchronizing (HP) signal Output Ignition switch ON - Waveform of 1.0 V - 5.5 V is output. 9 (B) 1 (B) RGB area (YS) signal Input Ignition switch ON At RGB image is displayed. 5.5 V or less 5.0 V At AUX image is displayed. Waveform of 0.8 V - 5.5 V is input. 11 (G) 1 (B) Communication signal (CONT-->DISP) Input Ignition switch ON When adjusting display brightness. Waveform of 0.4 V - 5.3 V is input. 15 (B) 4 (W) Composite image signal Input Ignition switch ON When DVD or AUX image is displayed. Outputs waveform synchronized with composite image. 17 (R) 1 (B) RGB image signal (R: red) Input Ignition switch ON Start Confirmation/Adjustment mode, and then display color bar by selecting "Color Spectrum Bar" on Display Diagnosis screen. Outputs waveform synchronized with RGB image. 18 (B) 1 (B) RGB image signal (B: blue) Input Ignition switch ON Start Confirmation/Adjustment mode, and then display color bar by selecting "Color Spectrum Bar" on Display Diagnosis screen. Outputs waveform synchronized with RGB image. 19 (W) 1 (B) RGB synchronizing signal Input Ignition switch ON - Waveform of 0.8 V - 5.5 V is input. 20 (R) 1 (B) Vertical synchronizing (VP) signal Output Ignition switch ON - Waveform of 1.0 V - 5.5 V is output. 21 - Shield - - - - - 22 (R) 1 (B) Communication signal (DISP-->CONT) Output Ignition switch ON When adjusting display brightness. Waveform of 0.5 V or less - 3.5 V or more is output. 23 - Shield

Scheme 211

Terminal (Wire color) Description Condition Standard Reference value (Approx.) + - Signal name Input/Output 2 (L/O) 1 (W/L) Headphone sound signal RH Input Ignition switch ON Headphone sound output. Waveform according to headphone sound is input. 4 (BR) 3 (Y) Headphone sound signal LH Input Ignition switch ON Headphone sound output. Waveform according to headphone sound is input. 5 - Shield - - - - - 6 - Shield - - - - - 7 (L/G) 8 (L/R) Composite image signal Input Ignition switch ON When DVD, USB or AUX image is displayed. Waveform according to composite image is input. 18 - Shield - - - - - 19 (R) - AV communication signal (L) Input/Output - - - - 20 (Y) - AV communication signal (L) Input/Output - - - - 21 (G) - AV communication signal (H) Input/Output - - - - 22 (BR) - AV communication signal (H) Input/Output - - - - 26 (LG) 31 (B) 32 (B) Ignition signal Input Ignition switch ON - 3.0 V - battery voltage Battery voltage 27 (SB) 31 (B) 32 (B) Illumination signal Input Ignition switch ON Lighting switch is 1st or 2nd. - 12.0 V Lighting switch is OFF. - 0 V 28 (V) 31 (B) 32 (B) ACC power supply Input Ignition switch ACC - 7.6 V - battery voltage Battery voltage 29 (P) 31 (B) 32 (B) Battery power supply Input Ignition switch ON - 9.0 - 16.0 V Battery voltage 30 (P) 31 (B) 32 (B) Battery power supply Input Ignition switch ON - 9.0 - 16.0 V Battery voltage

Scheme 212

Terminal (Wire color) Description Condition Standard Reference value (Approx.) + - Signal name Input/Output 1 (W) 2 (B) Sound signal front squawker LH Output Ignition switch ON Sound output Outputs waveform synchronized with sound. 4 (BR) 3 (Y) Sound signal front squawker RH Output Ignition switch ON Sound output Outputs waveform synchronized with sound. 10 (SB) 7 (B) 12 (B) Battery power supply Input Ignition switch OFF - 9.0 - 16.0 V Battery power supply 11 (G) 7 (B) 12 (B) Battery power supply Input Ignition switch OFF - 9.0 - 16.0 V Battery power supply 13 (R) 8 (G) Sound signal woofer Output Ignition switch ON Sound output Outputs waveform synchronized with sound. 14 (L) 9 (P) Sound signal slide door speaker RH Output Ignition switch ON Sound output Outputs waveform synchronized with sound. 16 (Y) 17 (BR) Sound signal luggage squawker Output Ignition switch ON Sound output Outputs waveform synchronized with sound. 18 (BR) 19 (G) Sound signal front door woofer LH Output Ignition switch ON Sound output Outputs waveform synchronized with sound. 20 (LG) 7 (B) 12 (B) Amp. ON signal Input Ignition switch ACC - 6.5 V or more 12.0 V 24 (R) 23 (L) Sound signal rear LH Input Ignition switch ON Sound output Waveform according to sound signal is input. 26 (BR) 25 (Y) Sound signal rear RH Input Ignition switch ON Sound output Waveform according to sound signal is input. 28 (L) 15 (R) Sound signal slide door speaker LH Output Ignition switch ON Sound output Outputs waveform synchronized with sound. 29 (V) 30 (P) Sound signal center squawker Output Ignition switch ON Sound output Outputs waveform synchronized with sound. 31 (L) 32 (R) Sound signal front door woofer RH Output Ignition switch ON Sound output Outputs waveform synchronized with sound. 33 (V) 34 (G) Sound signal front RH Input Ignition switch ON Sound output Waveform according to sound signal is input. 35 (W) 36 (B) Sound signal front LH Input Ignition switch ON Sound output Waveform according to sound signal is input

Scheme 213

Terminal (Wire color) Description Condition Standard Reference value (Approx.) + - Signal name Input/Output 2 (W) 1 (B) Satellite radio sound signal LH Output Ignition switch ON When satellite radio mode is selected. Outputs waveform synchronized with sound. 4 (G) 3 (R) Satellite radio sound signal RH Output Ignition switch ON When satellite radio mode is selected. Outputs waveform synchronized with sound. 5 - Shield - - - - - 6 - Shield - - - - - 8 (R/L) 15 (B) Request signal (SAT TO CONT) Output Ignition switch ON When satellite radio mode is selected. Waveform of 0.5 - 7.0 V is Output. 9 (B/R) 15 (B) Communication signal (SAT TO CONT) Output Ignition switch ON When satellite radio mode is selected. Waveform of 0.5 - 7.0 V is Output. 10 (R/B) 15 (B) Communication signal (CONT TO SAT) Input Ignition switch ON When satellite radio mode is selected. Waveform of 1.5 - 6.0 V is input. 12 (LG) 15 (B) Battery power supply Input Ignition switch OFF - 10.8 - 15.6 V Battery voltage 16 (O) 15 (B) ACC power supply Input Ignition switch ACC - 7.0 - 16.0 V Battery voltage 33 - Satellite radio antenna signal Input

Scheme 214

Terminal (Wire color) Description Condition Standard Reference value (Approx.) + - Signal name Input/Output 1 (Y) 4 (B/W) Battery power supply Input Ignition switch OFF - 9.0 - 16.0 V Battery voltage 2 (V) 4 (B/W) ACC power supply Input Ignition switch ACC - 7.0 - 16.0 V Battery voltage 3 (G) 4 (B/W) Ignition signal Input Ignition switch ON - 7.0 - 16.0 V Battery voltage 7 (W/L) 8 Microphone signal Input Ignition switch ON Give a voice. Waveform according to voice is input. 9 (B) 10 (W) Sound signal (TEL voice, voice guidance) Output Ignition switch ON During voice guide output with the switch pressed. Outputs waveform synchronized with sound. 20 (B/W) 4 (B/W) Control signal - Ignition switch ON - 3.1 V or less 0 V 27 (B/W) 4 (B/W) Control signal - Ignition switch ON - 3.1 V or less 0 V 28 (SB) 4 (B/W) Vehicle speed signal (8-pulse) Input Ignition switch ON When vehicle speed is approx. 40 km/h (25 MPH) Waveform according to vehicle speed is input. NOTE: The maximum voltage varies depending on the specification (destination unit). 29 (W/R) 8 Microphone VCC Output Ignition switch ON - 4.7 - 5.3 V 5.0 V 35 (SB) - AV communication signal (H) Input/Output - - - - 36 (LG) - AV communication signal (L) Input/Output - - - - 33 4 (B/W) TEL antenna signal Input/Output Ignition switch ON Not connected to TEL antenna connector. - 5.0 V 34 - Shield

DETAILED FLOW

1. INTERVIEW AND SYMPTOM CONFIRMATION Check the malfunction symptoms by performing the following items. Interview the customer to obtain the malfunction information (conditions and environment when the malfunction occurred). Check the symptom. Is the occurred symptom malfunction? YES: GO TO 2. NO: INSPECTION END
2. DIAGNOSIS WITH CONSULT Connect CONSULT and perform a self-diagnosis for "MULTI AV". Refer to " «CONSULT FUNCTION»(ref-672661-S28725969722014112400000) ". NOTE: Skip to step 4 of the diagnosis procedure if "MULTI AV" is not displayed. When DTC is detected, follow the instructions below: Record DTC and Freeze Frame Data. Is DTC displayed? YES: GO TO 3. NO: GO TO 4 .
3. TROUBLE DIAGNOSIS FOR DTC Check the DTC indicated in the self-diagnosis results. Perform the relevant diagnosis referring to the DTC Index. Refer to " «DTC INDEX»(ref-672661-S34801574542014112400000) ". : GO TO 5 .
4. TROUBLE DIAGNOSIS FOR SYMPTOMS Perform the relevant diagnosis referring to the diagnosis chart by symptom. Refer to " «SYMPTOM TABLE»(ref-672661-S07172794612014112400000) ". : GO TO 5.
5. ERROR PART REPAIR Repair or replace the identified malfunctioning parts. Perform a self-diagnosis for "MULTI AV" with CONSULT. NOTE: Erase the stored self-diagnosis results after repairing or replacing the relevant components if any DTC has been indicated in the self-diagnosis results. Check that the symptom does not occur. Does the symptom occur? YES: GO TO 1 . NO: INSPECTION END

Work Procedure

1. SAVING VEHICLE SPECIFICATION CONSULT Configuration Perform "Before Replace ECU" to save or print current vehicle specification. Refer to " «DESCRIPTION»(ref-672661-S05105117702014112400000) ". NOTE: If "Before Replace ECU" can not be used, use the "Manual Configuration". : GO TO 2.
2. REPLACE AV CONTROL UNIT Replace AV control unit. Refer to " «REMOVAL AND INSTALLATION»(ref-672661-S38174634402014112400000) ". : GO TO 3.
3. WRITING VEHICLE SPECIFICATION CONSULT Configuration Perform "After Replace ECU" or "Manual Configuration" to write vehicle specification. Refer to " «WORK PROCEDURE»(ref-672661-S06914385572014112400000) ". : GO TO 4.
4. OPERATION CHECK Check that the operation of the AV control unit and camera images (fixed guide lines and predictive course lines) are normal. : WORK END

1. WRITE VEHICLE SPECIFICATION CONSULT Configuration Write vehicle specification into AV control unit. To write vehicle specification stored in CONSULT into the AV control unit: GO TO 2. To write vehicle specification into the AV control unit by hand: GO TO 3 .
2. WRITE STORED DATA CONSULT Configuration Select "After Replace ECU" in "Read/Write Configuration." Write data stored in CONSULT with the "Before Replace ECU" function into the AV control unit. : GO TO 4 .
3. MANUALLY WRITE VEHICLE SPECIFICATION CONSULT Configuration Perform "Manual Configuration". Refer to the Configuration List to write vehicle specification into the AV control unit. Refer to " «CONFIGURATION LIST»(ref-672661-S38263934702014112400000) ". NOTE: The following table includes information (items) inapplicable to this vehicle. For information (items) applicable to this vehicle, refer to CONSULT display items. : GO TO 4.
4. OPERATION CHECK Check that the operation of the AV control unit and camera images (fixed guide lines and predictive course lines) are normal. : WORK END

Configuration List

Note. The items shown in this list depend on vehicle specifications. The config list may not be displayed depending on vehicle specifications. This is not a malfunction.

RELATED TO HANDS-FREE PHONE

1. Before performing diagnosis, confirm that the cellular phone being used by the customer is compatible with the vehicle.
2. It is possible that a malfunction is occurring due to a version change of the phone even though the phone is a compatible type. This can be confirmed by changing the cellular phone to another compatible type, and checking that it operates normally. It is important to determine whether the cause of the malfunction is the vehicle or the cellular phone.

Check Compatibility

1. Make sure the customer's Bluetooth® related concern is understood.
2. Verify the customer's concern. NOTE: The customer's phone may be required, depending upon their concern.
3. Write down the customer's phone brand, model, and service provider. NOTE: It is necessary to know the service provider. On occasion, a given phone may be on the approved list with one provider, but may not be on the approved list with other providers.
4. Go to "www.nissanusa.com/bluetooth/". Using the website's search engine, find out if the customer's phone is on the approved list. If the customer's phone is NOT on the approved list: Stop diagnosis here. The customer needs to obtain a Bluetooth® phone that is on the approved list before any further action. If the feature related to the customer's concern shows as "N" (not compatible): Stop diagnosis here. If the customer still wants the feature to function, they will need to get an approved phone showing the feature as "Y" (compatible) in the "Basic Features" list. If the feature related to the customer's concern shows as "Y" (compatible)

Perform diagnosis as per the following table.

RELATED TO REAR VIEW MONITOR

RELATED TO RGB IMAGE

RELATED TO AUDIO

RELATED TO USB

Note. Check that there is no malfunction of USB equipment main body before performing a diagnosis.

iPod® is a trademark of Apple inc., registered in the U.S. and other countries.

RELATED TO DVD MODE

RELATED TO AUXILIARY INPUT

Note. Check that there is no malfunction of AUX equipment main body before performing a diagnosis.

RELATED TO REAR DISPLAY

Perform the diagnosis of the following items before starting diagnosis by symptom.

1. Self-diagnosis: Refer to " «CONSULT FUNCTION»(ref-672661-S28725969722014112400000) ".
2. Self-diagnosis mode: Refer to " «ON BOARD DIAGNOSIS FUNCTION»(ref-672661-S12266602812014112400000) ".
3. Power supply system: Refer to " «REAR DISPLAY UNIT: DIAGNOSIS PROCEDURE»(ref-672661-S29450499452014112400000) ".

Scheme 215

RELATED TO HEADPHONE

RELATED TO STEERING SWITCH

Related to Telephone

The system should respond correctly to all voice commands without difficulty. If problems are encountered, try the following solutions.

Where the solutions are listed by number, try each solution in turn, starting with number 1, until the problem is resolved.

1. The majority of the audio malfunctions are the result of outside causes (bad CD/cassette, electromagnetic interference, etc.). Check the symptoms below to diagnose the malfunction.
2. The vehicle itself can be a source of noise if noise prevention parts or electrical equipment is malfunctioning. Check if noise is caused and/or changed by engine speed, ignition switch turned to each position, and operation of each piece of electrical equipment, and then determine the cause.

Note. CD-R is not guaranteed to play because they can contain compressed audio (MP3, WMA) or could be incorrectly mastered by the customer on a computer. Check if the CDs carry the Compact Disc Logo. If not, the disc is not mastered to the "red book" Compact Disc Standard and may not play.

Noise resulting from variations in field strength, such as fading noise and multi-path noise, or external noise from trains and other sources, is not a malfunction.

Note. Fading noise: This noise occurs because of variations in the field strength in a narrow range due to mountains or buildings blocking the signal. Multi-path noise: This noise results from a time difference between the broadcast waves directly from the station arriving at the antenna and the waves reflected by mountains or buildings.

RELATED TO DVD

Feeder Layout
