Audio, Visual & Navigation System (Display Audio): Other Nissan Quest IV

Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT PRE-TENSIONER"

The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted. Information necessary to service the system safely is included in the SRS AIRBAG and SEAT BELTS of this Service Information.

PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS

Scheme 231

1. When removing the 12V battery terminal, turn OFF the ignition switch and wait at least 30 seconds. NOTE: ECU may be active for several tens of seconds after the ignition switch is turned OFF. If the battery terminal is removed before ECU stops, then a DTC detection error or ECU data corruption may occur.
2. For vehicles with the 2-batteries, be sure to connect the main battery and the sub battery before turning ON the ignition switch. NOTE: If the ignition switch is turned ON with any one of the terminals of main battery and sub battery disconnected, then DTC may be detected.
3. After installing the 12V battery, always check "Self Diagnosis Result" of all ECUs and erase DTC. NOTE: The removal of 12V battery may cause a DTC detection error.

AV COMMUNICATION SYSTEM

1. Do not apply voltage of 7.0 V or higher to the measurement terminals.
2. Use the tester with its open terminal voltage being 7.0 V or less.
3. Be sure to turn ignition switch OFF and disconnect the battery cable from the negative terminal before checking the circuit.

Scheme 232

Scheme 233

1. Solder the repaired parts, and wrap with tape. [Frays of twisted line must be within 110 mm (4.33 in).]
2. Do not perform bypass wire connections for the repair parts. (The spliced wire will become separated and the characteristics of twisted line will be lost.)

Commercial Service Tools

Tool Description Power tool Loosening screws

Scheme 234

Scheme 235

Scheme 236

1. AM/FM electronic tuner radio, satellite radio tuner, CD drive, auxiliary input jack, and camera controller are integrated into the audio unit.
2. The display can show audio status and rear view monitor images.
3. Music files stored in iPod®*/USB memory can be played by using the separate USB connector.
4. Audio played back by external audio equipment is outputted from the vehicle speakers via the auxiliary input jack installed to the audio fascia. *: iPod® is a trademark of Apple inc., registered in the U.S. and other countries.

Speaker

6 speakers system is adopted.

Scheme 237

1. ø 15.0 x 23.0 cm (6 x 9 in) speaker is installed to the bottom of the front door.
2. Sound signal is input from the audio unit to output low range sounds. Rated input: 20 W Maximum input: 40 W Impedance: 2 ohms

Scheme 238

1. ø 6.5 cm (2 in) squawker is installed to the side of instrument panel.
2. Sound signal is input from the audio unit to output high and mid range sounds. Rated input: 7 W Maximum input: 40 W Impedance: 4 ohms

Scheme 239

1. ø 16cm (6.5 in) speaker is located at the lower part of the back of the slide door.
2. Sound signal is input from the audio unit to output high, mid, and low range sounds. Rated input: 20 W Maximum input: 40 W Impedance: 2 ohms

Scheme 240

1. Inputs the TEL voice signal from TEL antenna and outputs it to the audio unit
2. It is connected with the audio unit via AV communication and controlled with the audio unit.

TEL Antenna

Receives the TEL voice signal from cellular phone and outputs it to the TEL adapter unit.

Scheme 241

Scheme 242

1. The voice control/TEL microphone is installed on the left side of the map lamp assembly.
2. The power is supplied from the TEL adapter unit to the microphone, transmitting sound signals to the TEL adapter unit at the voice control or during hands-free phone communication.

Scheme 243

1. USB connector is installed to the console box.
2. iPod® and USB memory can be connected to the audio unit.

Scheme 244

1. Operations for audio and hands-free phone, etc. are possible.
2. This switch is connected to the TEL adapter unit, and the switch operation signal is transmitted to the TEL adapter unit via voltage multiplex communication.

Scheme 245

1. AM/FM radio main antenna is located on the right rear side window glass and FM radio sub antenna on the left rear side window glass.
2. The AM/FM radio main antenna path has an antenna amp. to obtain sufficient reception power. CAUTION: Affixing any mirror-type window films or metallic items (e.g. commercial antenna) on the rear side window glass causes a reduction in the radio receiver sensitivity.

Scheme 246

"tringle": Indicates that the part is connected at points with same symbol in actual vehicle.

SATELLITE RADIO ANTENNA

1. Satellite radio antenna is installed to the rear center of the roof.
2. Receives satellite radio waves and outputs it to audio unit.

Scheme 247

"tringle": Indicates that the part is connected at points with same symbol in actual vehicle.

Scheme 248

1. The rear view camera is installed to the back door finisher.
2. Super-small CCD camera (color) using CCD* for the image pickup element is adopted.
3. With the mirror processing function, a mirror image is sent as if it is viewed by a rear view mirror.
4. Power for the camera is supplied from the audio unit, and the image at the rear of the vehicle is sent to the audio unit. NOTE: *: Abbreviation of Charge Coupled Device. CCD can turn incident light from the lens into electrons and memorize the image like a photo.

COMMUNICATION SIGNAL

1. Audio unit function by transmitting/receiving data one by one with TEL adapter unit (slave unit) that configures them completely as a master unit by connecting between units that configure display audio system with two AV communication lines (H, L).
2. Two AV communication lines (H, L) adopt a twisted pair line that is resistant to noise.

AUDIO FUNCTION

1. The audio unit has a 4.3-inch liquid crystal color display.
2. The adoption of CD drive, USB connector, and auxiliary input jack (stereo mini jack) enables the playback of various kinds of media.
3. The MP3/WMA/AAC playback function enables music to play for a long time: the user need not change the CD during a long trip. The text display function is also adopted so that the title name and artist name of the ID3 tag/WMA/AAC tag can be displayed. NOTE: MP3 stands for MPEG AUDIO LAYER3. It is the compression standard defined by "MPEG", a joint activity organization of ISO and IEC (the international standardization groups). WMA stands for Windows Media® Audio. It is the sound data compression standard formulated by Micros oft Corporation. AAC is abbreviation of Advanced Audio Coding. It is the sound data compression method standardized in an animation compression standard (MPEG).
4. The audio system is equipped with the following functions.

AM/FM Radio

1. AM/FM radio tuner is built into audio unit.
2. AM/FM radio wave is received by radio antenna, next it is amplified by antenna amp., and finally it is input to audio unit.
3. FM radio wave is received by FM sub antenna, and it is transmitted to the audio unit directly.
4. Audio unit outputs the sound signal to each speaker.

Satellite Radio

1. Radio signal is received by satellite radio antenna and transmitted to audio unit.
2. Audio unit outputs the sound signal to each speaker.

CD

1. CD function is built into audio unit.
2. Audio unit outputs sound signal to each speaker when CD is inserted to audio unit.
3. For further information about CD function specifications, refer to " «AUDIO UNIT»(ref-672666-S17957299562014112400000) ".

Auxiliary input

1. Auxiliary input jack (stereo mini jack) installed to the audio fascia.
2. Audio played back by external equipment (e.g. iPod® and portable audio) is outputted from the vehicle speakers via the auxiliary input jack installed to the audio fascia.
3. In auxiliary input mode, only sound volume and sound quality can be operated with the audio unit.

USB Connection

1. iPod® or music files in USB memory can be played.
2. iPod® sound signals are transmitted from USB connector to each speaker via audio unit.
3. iPod® is recharged when connected to USB connector.
4. Compliant USB memory and data recorded are limited. USB memory USB2.0 File system FAT16 FAT32
5. Only files that meet the following conditions will be played. Music file File format "MP3", "WMA" File extension ".mp3", ".wma" Maximum file size 800 MB

iPod® is a trademark of Apple inc., registered in the U.S. and other countries.

Note. The audio unit does not support the display of static images and videos. Use the enclosed USB harness when connecting iPod® to USB connector.

Speed Sensitive Volume

1. Volume level of this system gone up and down automatically in proportion to the vehicle speed.
2. The control level can be selected by the customer.

HANDS-FREE PHONE FUNCTION

1. TEL adapter unit is controlled with AV communication from audio unit.
2. When the cellular phone is connected to the TEL adapter unit via TEL antenna in Bluetooth® communication, hands-free phone communication can be performed.
3. Simply operating the steering switch without releasing hands from the steering wheel allows the driver to make a phone call or receive a phone call.
4. When a Bluetooth® communication compliant phone is registered to the TEL adapter unit, hands-free phone communication can be performed. Five units of Bluetooth® communication devices can be registered to the TEL adapter unit.
5. The content of the memory (telephone book) of the cellular phone can be recorded in the TEL adapter unit.
6. TEL adapter unit has the on board self-diagnosis function. Refer to " «ON BOARD DIAGNOSIS FUNCTION»(ref-672666-S37882950912014112400000) ". Bluetooth® compliant profile HFP1.5 Core specification 2.0 + EDR

When A Call Is Originated

1. Spoken voice sound output from the microphone (microphone signal) is input to TEL adapter unit.
2. TEL adapter unit outputs to cellular phone with Bluetooth® communication as a TEL voice signal.
3. Voice sound is then heard at the other party.

When Receiving A Call

1. Voice sound is input to own cellular phone from the other party.
2. TEL voice signal is input to TEL adapter unit by establishing Bluetooth® communication from cellular phone, and the signal is output to front speaker.

REAR VIEW MONITOR FUNCTION

Operation Description

1. When the selector lever is shifted to the reverse position, the rear view monitor image is displayed.
2. When the selector lever is shifted to any position other than the reverse position, the original image (the image displayed before the rear view monitor image) is displayed.

Camera Image Operation Principle

Scheme 249

Scheme 250

Scheme 251

1. The audio unit supplies power to the rear view camera when receiving a reverse signal.
2. The rear view camera transmits camera images to the audio unit when power is supplied from the audio unit.
3. The audio unit combines a warning message and fixed guide lines with an image received from the rear view camera to display a rear view camera image on the screen. Vehicle Width and Distance Guide Lines Display Function at Rear View Monitor Display
4. The vehicle width and distance guide lines are displayed at the rear view monitor display to allow the driver to more easily judge distances between the vehicle and objects and help the driver back into a parking space. Side Distance Guide Lines and Possible Route Lines Display Function at Rear View Monitor Display Precautions for Side Distance Guide Lines and predictive course line Display on the Rear View Monitor Display Side distance guide lines and predictive course line on the display may be different from actual lines depending on vehicle conditions and road conditions. Precautions for road conditions
5. Since guide lines are drawn based on the road, a different distance may be displayed if a protruding block is present nearby. Precautions for block
6. Since guide lines are drawn based on the road, a different distance may be displayed if a protruding block is present nearby.

Scheme 252

Vehicle Signals

A comparison check can be made of each actual vehicle signal and the signals recognized by the system.

Scheme 253

Error History

The self-diagnosis results are judged depending on whether any error occurs from when "Self-diagnosis" is selected until the self-diagnosis results are displayed.

However, the diagnosis results are judged normal if an error has occurred before the ignition switch is turned ON and then no error has occurred until the self-diagnosis start. Check the "Error Record" to detect any error that may have occurred before the self-diagnosis start because of this situation.

The frequency of occurrence is displayed in a count up manner. The actual count up method differs depending on the error item.

Count up method A

1. The counter is set to 40 if an error occurs. 1 is subtracted from the counter if the condition is normal at a next ignition ON cycle.
2. The counter lower limit is 1. The counter can be reset (no error record display) with the "Delete log" switch.

Count up method B

1. The counter increases by 1 if an error occurs when ignition switch is ON. The counter will not decrease even if the condition is normal at the next ignition ON cycle.
2. The counter upper limit is 50. Any counts exceeding 50 are ignored. The counter can be reset (no error record display) with the "Delete log" switch.

Scheme 254

Error item

Some error items may be displayed simultaneously according to the cause. If some error items are displayed simultaneously, the detection of the cause can be performed by the combination of display items

Camera System

Use this mode to adjust the guide line display position of the rear view monitor if necessary after removing the rear view camera.

Scheme 255

Scheme 256

1. Displays the communication status between audio unit (master unit) and each unit.
2. The error counter displays "OK" if any malfunction was not detected in the past and displays "0" if a malfunction is detected. It increases by 1 if the condition is normal at the next ignition switch ON cycle. The upper limit of the counter is 39.
3. The error counter is erased if "Reset" is pressed. Items Status (Current) Counter (Past) C Rx (BTHF-ITM) OK/??? OK/0 - 39 NOTE: "???" indicates UNKWN.

Initialize Settings

Deletes data stored from the audio unit.

Scheme 257

The Details of Error Count

The error count guides "0" when the error occurs. The next time it counts up "1" if it is normal with the ignition switch ON. It continues the count up unless the initialization of hands-free phone system is performed.

Scheme 258

Scheme 259

PHYSICAL VALUES

Terminal (Wire color) Description Condition Standard Reference value (Approx.) + - Signal name Input/Output 2 (R) 3 (G) Sound signal front speaker LH Output Ignition switch ON Sound output. Outputs waveform synchronized with sound. 4 (V) 5 (LG) Sound signal slide door speaker LH Output Ignition switch ON Sound output. Outputs waveform synchronized with sound. 6 (R) 15 (Y) Steering switch signal A Input Ignition switch ON Keep pressing SOURCE switch. 0 - 3.3 V 0 V Keep pressing SEEK UP switch. 0.7 V Keep pressing SEEK DOWN switch. 1.3 V Except for above. 3.3 V 7 (V) 20 (B) ACC power supply Input Ignition switch ACC - 9.0 - 16.0 V Battery voltage 9 (R/W) 8 (B/W) Illumination control signal Input Ignition switch ON Lighting switch 1ST When meter illumination is maximum Waveform of 0 - 15.6 V is input according to meter illumination step. Lighting switch 1ST When meter illumination is step 11 Lighting switch 1ST When meter illumination is minimum 0 V 11 (W) 12 (B) Sound signal front speaker RH Output Ignition switch ON Sound output. Outputs waveform synchronized with sound. 13 (P) 14 (L) Sound signal slide door speaker RH Output Ignition switch ON Sound output. Outputs waveform synchronized with sound. 16 (SB) 15 (Y) Steering switch signal B Input Ignition switch ON Keep pressing VOL DOWN switch. 0 - 3.3 V 0 V Keep pressing VOL UP switch. 0.7 V Except for above. 3.3 V 18 (SB) Ground Vehicle speed signal (8-pulse) Input Ignition switch ON When vehicle speed is approx. 40 km/h (25 MPH) Waveform according to vehicle speed is input. NOTE: The maximum voltage varies depending on the specification (destination unit). 19 (Y) 20 (B) Battery power supply Input Ignition switch OFF - 9.0 - 16.0 V Battery voltage 33 - Shield - - - - - 34 (B) 36 (W) Camera image signal Input Ignition switch ON At camera image is displayed. Waveform according to camera image is input. 35 (R) 36 (W) Camera power supply Output Ignition switch ON At camera image is displayed. 5.9 - 6.5 V 6.2 V 37 (LG) - AV communication signal (L) Input/Output - - - - 38 (SB) - AV communication signal (H) Input/Output - - - - 40 (LG) - AV communication signal (L) Input/Output - - - - 41 (SB) - AV communication signal (H) Input/Output - - - - 43 - Shield - - - - - 44 (B) 45 (W) Sound signal (TEL voice, voice guidance) Input Ignition switch ON During voice guide output with the switch pressed. Waveform according to sound is input. 51 (V) 20 (B) Reverse signal Input Ignition switch ON Shift position is in R. 7.0 - 16.0 V 12.0 V Shift position is in other than R. - 0 V 55 (B) - Control signal Input Ignition switch ON - - 0 V 57 (B) - Control signal Input Ignition switch ON - - 0 V 65 (G) - USB ground - - - - - 66 (W) - USB D- signal - - - - - 67 (R) - V BUS signal - - - 4.75 - 5.25 V - 68 (B) - USB D+ signal - - - - - 69 - Shield - - - - - 70 Ground Antenna amp. ON signal Output Ignition switch ACC - 7.0 - 16.0 V 12.0 V 71 - AM-FM main Input - - - - 72 - FM sub Input - - - - 73 - Satellite radio antenna signal Input

Scheme 260

Scheme 261

Scheme 262

Scheme 263

Terminal (Wire color) Description Condition Standard Reference value (Approx.) + - Signal name Input/Output 1 (Y) 4 (B/W) Battery power supply Input Ignition switch OFF - 9.0 - 16.0 V Battery voltage 2 (V) 4 (B/W) ACC power supply Input Ignition switch ACC - 7.0 - 16.0 V Battery voltage 3 (G) 4 (B/W) Ignition signal Input Ignition switch ON - 7.0 - 16.0 V Battery voltage 7 (W/L) 8 Microphone signal Input Ignition switch ON Give a voice. Outputs waveform synchronized with voice is input. 9 (B) 10 (W) Sound signal (TEL voice, voice guidance) Output Ignition switch ON During voice guide output with the switch pressed. Outputs waveform synchronized with sound. 12 (G) 14 (GR) Steering switch signal A Input Ignition switch ON Keep pressing SOURCE switch. 0 - 5.25 V 0 V Keep pressing SEEK UP switch. 1.3 V Keep pressing SEEK DOWN switch. 2.5 V Keep pressing switch. 3.4 V Except for above. 5.0 V 13 (V) 14 (GR) Steering switch signal B Input Ignition switch ON Keep pressing VOL DOWN switch. 0 - 5.25 V 0 V Keep pressing VOL UP switch. 1.3 V Keep pressing switch. 2.5 V Except for above. 5.0 V 17 (R) 19 (Y) Steering switch signal A Output Ignition switch ON Keep pressing SOURCE switch. 0 - 3.3 V 0 V Keep pressing SEEK UP switch. 0.9 V Keep pressing SEEK DOWN switch. 1.6 V Except for above. 3.3 V 18 (SB) 19 (Y) Steering switch signal B Output Ignition switch ON Keep pressing VOL DOWN switch. 0 - 3.3 V 0 V Keep pressing VOL UP switch. 0.9 V Except for above. 3.3 V 22 (B/W) 4 (B/W) Control signal - Ignition switch ON - 3.1 V or less 0 V 24 (B/W) 4 (B/W) Control signal - Ignition switch ON - 3.1 V or less 0 V 27 (B/W) 4 (B/W) Control signal - Ignition switch ON - 3.1 V or less 0 V 28 (SB) 4 (B/W) Vehicle speed signal (8-pulse) Input Ignition switch ON When vehicle speed is approx. 40 km/h (25 MPH) Waveform according to vehicle speed is input. NOTE: The maximum voltage varies depending on the specification (destination unit). 29 (W/R) 8 Microphone VCC Output Ignition switch ON - 4.7 - 5.3 V 5.0 V 35 (SB) - AV communication signal (H) Input/Output - - - - 36 (LG) - AV communication signal (L) Input/Output - - - - 33 4 (B/W) TEL antenna signal Input/Output Ignition switch ON Not connected to TEL antenna connector. - 5.0 V 34 - Shield

Scheme 264

Scheme 265

Scheme 266

Scheme 267

Scheme 268

Scheme 269

Scheme 270

Scheme 271

Scheme 272

Scheme 273

Scheme 274

Scheme 275

Scheme 276

Scheme 277

Scheme 278

Reference 1... Refer to " SYMPTOM TABLE " (audio system) or " SYMPTOM TABLE " (hands-free phone system).

DETAILED FLOW

1. CHECK SYMPTOM Check the malfunction symptoms by performing the following items. Interview the customer to obtain the malfunction information (conditions and environment when the malfunction occurred). Check the symptom. : GO TO 2.
2. PERFORM DIAGNOSIS BY SYMPTOM Perform the relevant diagnosis referring to the diagnosis chart by symptom. Refer to " «SYMPTOM TABLE»(ref-672666-S04537519622014112400000) " (audio system) or " «SYMPTOM TABLE»(ref-672666-S17522763062014112400000) " (hands-free phone system). : GO TO 3.
3. REPAIR OR REPLACE MALFUNCTIONING PARTS Repair or replace the malfunctioning parts. : GO TO 4.
4. FINAL CHECK Perform the operation to check that the malfunction symptom is solved or any other symptoms are present. Is there any symptom? YES: GO TO 2 . NO: INSPECTION END

AUDIO SYSTEM

RELATED TO USB

Note. Check that there is no malfunction of USB equipment main body before performing a diagnosis.

RELATED TO CAMERA

RELATED TO STEERING SWITCH

RELATED TO HANDS-FREE PHONE

1. Before performing diagnosis, confirm that the cellular phone being used by the customer is compatible with the vehicle.
2. It is possible that a malfunction is occurring due to a version change of the phone even though the phone is a compatible type. This can be confirmed by changing the cellular phone to another compatible type, and checking that it operates normally. It is important to determine whether the cause of the malfunction is the vehicle or the cellular phone.

Check Compatibility

1. Make sure the customer's Bluetooth® related concern is understood.
2. Verify the customer's concern. NOTE: The customer's phone may be required, depending upon their concern.
3. Write down the customer's phone brand, model, and service provider. NOTE: It is necessary to know the service provider. On occasion, a given phone may be on the approved list with one provider, but may not be on the approved list with other providers.
4. Go to "www.nissanusa.com/bluetooth/". Using the website's search engine, find out if the customer's phone is on the approved list. If the customer's phone is NOT on the approved list: Stop diagnosis here. The customer needs to obtain a Bluetooth® phone that is on the approved list before any further action. If the feature related to the customer's concern shows as "N" (not compatible): Stop diagnosis here. If the customer still wants the feature to function, they will need to get an approved phone showing the feature as "Y" (compatible) in the "Basic Features" list. If the feature related to the customer's concern shows as "Y" (compatible): Perform diagnosis as per the following table.

RELATED TO AUDIO

1. The majority of the audio malfunctions are the result of outside causes (bad CD, electromagnetic interference, etc.). Check the symptoms below to diagnose the malfunction.
2. The vehicle itself can be a source of noise if noise prevention parts or electrical equipment is malfunctioning. Check that noise is caused and/or changed by engine speed, ignition switch turned to each position, and operation of each piece of electrical equipment. Then determine the cause.

Note. CD-R is not guaranteed to play because they can contain compressed audio (MP3, WMA) or could be incorrectly mastered by the customer on a computer. Check that the CDs carry the Compact Disc Logo. If not, the disc is not mastered to the red book Compact Disc Standard and may not play.

Noise resulting from variations in field strength, such as fading noise and multi-path noise, or external noise from trains and other sources, is not a malfunction.

Note. Fading noise: This noise occurs because of variations in the field strength in a narrow range due to mountains or buildings blocking the signal. Multi-path noise: This noise results from a time difference between the broadcast waves directly from the station arriving at the antenna and the waves reflected by mountains or buildings.

RELATED TO TELEPHONE
