Scheme 52

Scheme 53

OUTLINE

1. BCM (Body Control Module) controls the various electrical components. It inputs the information required to the control from CAN communication and the signal received from each switch and sensor.
2. BCM has combination switch reading function for reading the operation status of combination switches (light, turn signal, wiper and washer) in addition to a function for controlling the operation of various electrical components. It also has the signal transmission function as the passed point of signal and the power saving control function that reduces the power consumption with the ignition switch OFF.
3. BCM is equipped with the diagnosis function that performs the diagnosis with CONSULT and various settings.

BCM CONTROL FUNCTION LIST

Scheme 54

1. BCM reads the status of the combination switch (light, turn signal, wiper and washer) and recognizes the status of each switch.
2. BCM has a combination of 5 output terminals (OUTPUT 1 - 5) and 5 input terminals (INPUT 1 - 5). It reads a maximum of 20 switch states.

Scheme 55

COMBINATION SWITCH INPUT-OUTPUT SYSTEM LIST

COMBINATION SWITCH READING FUNCTION

Description

Scheme 56

Scheme 57

1. BCM reads the status of the combination switch at 10 ms intervals normally. NOTE: BCM reads the status of the combination switch at 60 ms intervals when BCM is controlled at low power consumption control mode.
2. BCM operates as follows and judges the status of the combination switch. It operates the transistor on OUTPUT side in the following order: OUTPUT 1 --> 2 --> 3 --> 4 --> 5, and outputs voltage waveform. The voltage waveform of OUTPUT corresponding to the formed circuit is input into the interface on INPUT side if any (1 or more) switches are ON. It reads this change of the voltage as the status signal of the combination switch.

Operation Example

In the following operation example, the combination of the status signals of the combination switch is replaced as follows: INPUT 1 - 5 to "1 - 5" and OUTPUT 1 - 5 to "A - E".

Example 1: When a switch (TAIL LAMP) is turned ON

Scheme 58

1. The circuit between OUTPUT 4 and INPUT 5 is formed when the TAIL LAMP switch is turned ON.
2. BCM detects the combination switch status signal "5D" when the signal of OUTPUT 4 is input to INPUT 5.
3. BCM judges that the TAIL LAMP switch is ON when the signal "5D" is detected.

Example 2: When some switches (TURN RH, TAIL LAMP) are turned ON

Scheme 59

1. The circuits between OUTPUT 1 and INPUT 5 and between OUTPUT 4 and INPUT 5 are formed when the TURN RH switch and TAIL LAMP switch are turned ON.
2. BCM detects the combination switch status signal "5AD" when the signals of OUTPUT 1 and OUTPUT 4 are input to INPUT 5.
3. BCM judges that the TURN RH switch and TAIL LAMP switch are ON when the signal "5AD" is detected.

WIPER INTERMITTENT DIAL POSITION

BCM judges the wiper intermittent dial 1 - 7 by the status of INT VOLUME 1, 2 and 3 switches.

Note. For details of wiper intermittent dial position, refer to " FRONT WIPER AND WASHER SYSTEM: SYSTEM DESCRIPTION ".

Scheme 60

BCM has the signal transmission function that outputs/transmits each input/received signal to each unit.

SIGNAL TRANSMISSION FUNCTION LIST

Scheme 61

1. BCM incorporates a power saving control function that reduces the power consumption according to the vehicle status.
2. BCM switches the status (control mode) by itself with the power saving control function. It performs the sleep request to each unit (IPDM E/R and combination meter) that operates with the ignition switch OFF.

Normal mode (wake-up)

1. CAN communication is normally performed with other units
2. Each control with BCM is operating properly

CAN communication sleep mode (CAN sleep)

1. CAN transmission is stopped
2. Control with BCM only is operating

Low power consumption mode (BCM sleep)

1. Low power consumption control is active
2. CAN transmission is stopped

LOW POWER CONSUMPTION CONTROL WITH BCM

BCM reduces the power consumption with the following operation in the low power consumption mode.

1. The reading interval of each switch changes from 10 ms interval to 60 ms interval.

Sleep mode activation

1. BCM receives the sleep-ready signal (ready) from IPDM E/R and combination meter via CAN communication.
2. BCM transmits the sleep wake up signal (sleep) to each unit when all of the CAN sleep conditions are fulfilled.
3. Each unit stops the transmission of CAN communication with the sleep wakeup signal. BCM is in CAN communication sleep mode.
4. BCM is in the low power consumption mode and performs the low power consumption control when all of the BCM sleep conditions are fulfilled with CAN sleep condition.

SLEEP CONDITION DESCRIPTION

Wake-up operation

1. BCM changes from the low power consumption mode to the CAN communication sleep mode when the any of the BCM wake-up conditions are fulfilled. Only the control with BCM is activated.
2. BCM transmits the sleep wake up signal (wake up) to each unit when any of the CAN wake-up conditions are fulfilled. It changes from the low power consumption mode or the CAN communication sleep mode to the normal mode.
3. Each unit starts the transmission of CAN communication with the sleep wake up signal. In addition, the combination meter transmits the wake up signal to BCM via CAN communication to report the CAN communication start. BCM wake-up condition CAN wake-up condition Door lock assembly LH (key cylinder switch): Lock or unlock Door lock switch: OFF-->ON Door unlock switch: OFF-->ON Remote keyless entry receiver: Receiving valid keyfob Receiving the sleep-ready signal (Not-ready) from any units Push-button ignition switch (push switch): OFF-->ON Hazard switch: OFF-->ON PASSING switch: OFF-->ON, ON-->OFF TAIL LAMP switch: OFF-->ON Driver door switch: OFF-->ON, ON-->OFF Passenger door switch: OFF --> ON, ON --> OFF Driver door request switch: OFF-->ON Passenger door request switch: OFF-->ON Stop lamp switch 2 signal: ON Remote keyless entry receiver: Receiving valid keyfob

DATA MONITOR

WORK SUPPORT

CONFIGURATION

Refer to " DESCRIPTION ".

CAN DIAG SUPPORT MNTR

Refer to " CAN DIAGNOSTIC SUPPORT MONITOR ".

AIR PRESSURE MONITOR: CONSULT Function (BCM - AIR PRESSURE MONITOR)

Note. The Signal Tech II Tool (J-50190) can be used to perform the following functions. Refer to the Signal Tech II User Guide for additional information. Activate and display TPMS transmitter IDs Display tire pressure reported by the TPMS transmitter Read TPMS DTCs Register TPMS transmitter IDs Check Intelligent Key relative signal strength Confirm vehicle Intelligent Key antenna signal strength

Reference Value

Note. The Signal Tech II Tool (J-50190) can be used to perform the following functions. Refer to the Signal Tech II User Guide for additional information. Activate and display TPMS transmitter IDs Display tire pressure reported by the TPMS transmitter Read TPMS DTCs Register TPMS transmitter IDs Check Intelligent Key relative signal strength Confirm vehicle Intelligent Key antenna signal strength

PHYSICAL VALUES

Terminal No. (Wire color) Description Condition Value (Approx.) + - Signal name Input/Output 1 (GR) Ground Rear window defogger relay control Input Rear window defogger switch OFF Battery voltage ON 0 - 0.5 V 2 (BR) Ground INPUT 5 signal Input Combination switch OFF 0 V TURN RH HEADLAMP 1 HI BEAM TAIL LAMP 3 (Y) Ground INPUT 4 signal Input Combination switch OFF 0 V TURN LH PASSING HEADLAMP 2 FR FOG 4 (L) Ground INPUT 3 signal Input Combination switch OFF 0 V FR WIPER LO FR WIPER INT (any intermittent position) 5 (G) Ground INPUT 2 signal Input Combination switch OFF 0 V FR WASHER RR WASHER Wiper intermittent dial 1 Wiper intermittent dial 5 Wiper intermittent dial 6 RR WIPER ON 6 (R) Ground INPUT 1 signal Input Combination switch OFF 0 V FR WIPER HI Wiper intermittent dial 1 Wiper intermittent dial 2 Wiper intermittent dial 3 Wiper intermittent dial 6 Wiper intermittent dial 7 RR WIPER INT 7 (W) Ground Key cylinder unlock sw signal Input Key cylinder switch N position UNLOCK position 0 V 8 (GR) Ground Key cylinder lock sw signal Input Key cylinder switch N position LOCK position 0 V 9 (LG) Ground Stop lamp switch 1 Input Stop lamp switch OFF (Brake pedal released) 0 V ON (Brake pedal depressed) Battery voltage 12 (GR) Ground Central door lock sw signal Input Door lock and unlock switch NEUTRAL position LOCK position 0 V 13 (BR) Ground Central door unlock sw signal Input Door lock and unlock switch NEUTRAL position UNLOCK position 0 V 15 (G) Ground Rear defogger switch signal Input Rear window defogger switch Not pressed Pressed 0 V 18 (V) Ground Keyless tuner ground Input Push-button ignition switch ON 0 V 19 (LG) Ground Keyless tuner power supply Output Push-button ignition switch OFF Push-button ignition switch ACC or ON 5 V 20 (G) Ground Keyless tuner signal Input Push-button ignition switch OFF Waiting When operating either button on Intelligent Key 21 (P) Ground Immobilizer one way communication (CLOCK) signal Input/Output Intelligent Key battery is removed Brake pedal depressed NOTE: Waveform varies each time when brake pedal is depressed Brake pedal released Battery voltage 22 (W) Ground Keyless tuner RSSI signal Input Push-button ignition switch OFF Waiting When pressing and holding either button on Intelligent Key 23 (R/Y) Ground Security indicator output Output Security indicator lamp ON 0 - 0.5 V Blinking (push-button ignition switch OFF) OFF Battery voltage 24 (SB) Ground Dongle link (SERIAL) Input/Output Push-button ignition switch OFF 5 V 25 (LG) Ground Immobilizer two way communication signal Input/Output During waiting Brake pedal depressed NOTE: Waveform varies each time when brake pedal is depressed Brake pedal released Battery voltage 26 (O) Ground THERMO amp. signal Input Push-button ignition switch ON and blower fan switch ON A/C switch OFF Battery voltage A/C switch ON 0 V 27 (W) Ground Air con sw signal Input Push-button ignition switch ON and blower fan switch ON A/C switch OFF Battery voltage A/C switch ON 0 V 28 (SB) Ground Blower fan sw signal Input Fan switch OFF 0 V ON 29 (O) Ground Hazard sw signal Input Hazard switch OFF Battery voltage ON 0 - 1.5 V 31 (Y) Ground Driver door lock status Input Front door LH LOCK status UNLOCK status 0V 32 (P) Ground OUTPUT 5 Output Combination switch OFF FR FOG RR WIPER ON Wiper intermittent dial 1 Wiper intermittent dial 2 Wiper intermittent dial 6 Wiper intermittent dial 7 33 (V) Ground OUTPUT 4 Output Combination switch OFF TAIL LAMP Wiper intermittent dial 1 Wiper intermittent dial 5 Wiper intermittent dial 6 RR WIPER INT 34 (W) Ground OUTPUT 3 Output Combination switch OFF HI BEAM HEADLAMP 2 RR WASHER Wiper intermittent dial 1 Wiper intermittent dial 2 Wiper intermittent dial 3 35 (GR) Ground OUTPUT 2 Output Combination switch OFF HEADLAMP 1 PASSING FR WIPER HI FR WIPER INT (any intermittent position) 36 (LG) Ground OUTPUT 1 Output Combination switch OFF TURN RH TURN LH FR WIPER LO FR WASHER 37 (1) (R) Ground Park position switch signal Input Selector lever P (Park) position 0 - 1.5 V Any position other than P (Park) Battery voltage 37 (2) (GR) Ground Clutch pedal position switch signal Input Clutch pedal Depressed 0 - 1.5 V Released Battery voltage 38 (G) Ground Keyless intelligent tuner signal Input Push-button ignition switch OFF or ACC 0 - 0.5 V ON Battery voltage 39 (L) Ground CAN-H Input/Output - - 40 (P) Ground CAN-L Input/Output - - 43 (P) Ground Door switch (Back) signal Input Back door switch OFF (back door closed) ON (back door open) 0 V 44 (LG) Ground Rear wiper autostop switch Input Push-button ignition switch ON Rear wiper stop position Battery voltage Any position other than rear wiper stop position 0V 45 (O) Ground Door switch (AS) signal Input Front door switch RH OFF (front RH door closed) ON (front RH door open) 0 V 46 (BR) Ground Door switch (RR) signal Input Rear door switch RH OFF (rear RH door closed) ON (rear RH door open) 0 V 47 (SB) Ground Door switch (DR) signal Input Front door switch LH OFF (front LH door closed) ON (front LH door open) 0 V 48 (W) Ground Door switch (RL) signal Input Rear door switch LH OFF (rear LH door closed) ON (rear LH door open) 0 V 49 (L) Ground Cargo lamp control Output Back door is closed (cargo lamp turns OFF) Battery voltage Back door is opened (cargo lamp turns ON) 0 - 1 V 50 (G) Ground Door unlock output (back) Output Back door UNLOCK (Actuator is activated) Battery voltage Actuator is not activated 0 V 51 (W) Ground Request sw (back door) signal Input Back door request switch ON (Pressed) 0 - 1.5 V OFF (Not pressed) Battery voltage 54 (R) Ground Rear wiper output Output Rear wiper OFF (stopped) 0V ON (activated) Battery voltage 55 (G) Ground Door unlock output (RR, RL) Output Rear doors UNLOCK (Actuator is activated) Battery voltage Actuator is not activated 0 V 56 (W) Ground Battery saver output Output Interior room lamp battery saver timed out 0 V Except when interior room lamp battery saver timed out Battery voltage 57 (Y) Ground Battery power supply Input Push-button ignition switch OFF Battery voltage 59 (G) Ground Door unlock output (AS) Output Front RH door UNLOCK (Actuator is activated) Battery voltage Actuator is not activated 0 V 60 (V) Ground Flasher output (LEFT) Output Push-button ignition switch ON Turn signal switch OFF 0 V Turn signal switch LH 61 (W) Ground Flasher output (RIGHT) Output Push-button ignition switch ON Turn signal switch OFF 0 V Turn signal switch RH 63 (R) Ground Room lamp control Output Interior room lamp OFF Battery voltage ON 0 - 1.0 V 65 (SB) Ground Door lock output Output All doors LOCK (Actuator is activated) Battery voltage Actuator is not activated 0 V 66 (G) Ground Door unlock output (DR) Output Front LH door UNLOCK (Actuator is activated) Battery voltage Actuator is not activated 0 V 67 (B) Ground Ground Output Push-button ignition switch ON 0 V 68 (L) Ground Power window power supply (IGN) Output Push-button ignition switch ON Battery voltage 70 (G) Ground Battery power supply Input Push-button ignition switch OFF Battery voltage 72 (L) Ground A/C indicator Input - - 75 (GR) Ground Request sw (DR) signal Input Driver door request switch ON (Pressed) 0 - 1.5 V OFF (Not pressed) Battery voltage 76 (L) Ground Engine start sw Input Push-button ignition switch START pressed 0 - 1.5 V Not pressed Battery voltage 78 (P) Ground Door antenna (DR) + Output Push-button ignition switch ON Driver door request switch pressed Intelligent Key not in antenna detection area (Approx. 2 m) Intelligent Key in antenna detection area (80 cm or less) 79 (V) Ground Door antenna (DR) - Output Push-button ignition switch ON Driver door request switch pressed Intelligent Key not in antenna detection area (Approx. 2 m) Intelligent Key in antenna detection area (80 cm or less) 80 (LG) Ground Door antenna (AS) + Output Push-button ignition switch ON Passenger door request switch pressed Intelligent Key not in antenna detection area (Approx. 2 m) Intelligent Key in antenna detection area (80 cm or less) 81 (Y) Ground Door antenna (AS) - Output Push-button ignition switch ON Passenger door request switch pressed Intelligent Key not in antenna detection area (Approx. 2 m) Intelligent Key in antenna detection area (80 cm or less) 82 (W) Ground Outside key antenna (rear bumper) + Output Push-button ignition switch ON Trunk lid opener switch pressed Intelligent Key not in antenna detection area (Approx. 2 m) Intelligent Key in antenna detection area (80 cm or less) 83 (B) Ground Outside key antenna (rear bumper) - Output When the trunk lid opener switch is operated with push-button ignition switch ON Intelligent Key not in antenna detection area (Approx. 2 m) Intelligent Key in antenna detection area (80 cm or less) 84 (P) Ground Inside key antenna (instrument center) + Output Push-button ignition switch ON Intelligent Key not in antenna detection area (Approx. 2 m) Intelligent Key in antenna detection area (80 cm or less) 85 (L) Ground Inside key antenna (instrument center) - Output Push-button ignition switch ON Intelligent Key not in antenna detection area (Approx. 2 m) Intelligent Key in antenna detection area (80 cm or less) 86 (G) Ground Inside key antenna (console) + Output Push-button ignition switch ON Intelligent Key not in antenna detection area (Approx. 2 m) Intelligent Key in antenna detection area (80 cm or less) 87 (R) Ground Inside key antenna (console) - Output Push-button ignition switch ON Intelligent Key not in antenna detection area (Approx. 2 m) Intelligent Key in antenna detection area (80 cm or less) 88 (V) Ground Inside key antenna (trunk room) + Output Push-button ignition switch ON Intelligent Key not in antenna detection area (Approx. 2 m) Intelligent Key in antenna detection area (80 cm or less) 89 (LG) Ground Inside key antenna (trunk room) - Output Push-button ignition switch ON Intelligent Key not in antenna detection area (Approx. 2 m) Intelligent Key in antenna detection area (80 cm or less) 90 (W) Ground Push-button ignition switch illumination power supply Output Push-button ignition switch illumination ON Battery voltage OFF 0 - 1.5 V 91 (V) Ground ACC/ON indicator lamp Output Push-button ignition switch OFF Battery voltage ACC or ON 0 - 1.5 V 92 (B) Ground Push-button ignition switch illumination lamp Output Push-button ignition switch illumination ON 5.5 V OFF 0 - 1.5 V 93 (R) Ground Intelligent Key warning buzzer Output Intelligent Key warning buzzer Sounding 0 - 1.5 V Not sounding Battery voltage 96 (SB) Ground Accessory relay control Output Ignition Push-Button switch OFF 0 - 0.5 V ACC or ON Battery voltage 97 (R/Y) Ground Starter relay control Output Push-button ignition switch ON Selector lever in P (Park) or N (Neutral) position Battery voltage Selector lever not in P (Park) or N (Neutral) position 0 - 0.5 V 98 (O) Ground Ignition relay (IPDM E/R) control Output Push-button ignition switch OFF or ACC Battery voltage ON 0 - 0.5 V 99 (GR) Ground Ignition relay (F/B) control Output Push-button ignition switch OFF or ACC 0 - 0.5 V ON Battery voltage 100 (L) Ground Request sw (AS) signal Input Passenger door request switch ON (Pressed) 0 - 1.5 V OFF (Not pressed) Battery voltage 101 (V) Ground Clutch interlock switch Input Clutch interlock switch OFF (clutch pedal is not depressed) 0V ON (clutch pedal is depressed) Battery voltage 102 (BR) Ground P/N position Input Selector lever Selector lever in P (Park) or N (Neutral) position Battery voltage Selector lever not in P (Park) or N (Neutral) position 0 - 1.5 V 103 (LG) Ground Front defrost switch Input - - 104 (V) Ground CVT shift selector (park position switch) power supply Output Push-button ignition switch ON 9 - 16 V 105 (SB) Ground Stop lamp switch 2 Input Push-button ignition switch OFF Battery voltage 106 (Y) Ground Blower relay control Output Push-button ignition switch OFF or ACC 0 - 0.5 V ON Battery voltage (1) With CVT (2) With M/T

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Fail-safe

BCM performs fail-safe control when the following DTCs are detected.

Work Procedure

1. SAVING VEHICLE SPECIFICATION CONSULT Configuration Perform "READ CONFIGURATION" to save or print current vehicle specification. Refer to " «DESCRIPTION»(ref-675612-S22332073342014120500000) ". NOTE: If "READ CONFIGURATION" can not be used, use the "WRITE CONFIGURATION - Manual selection" after replacing BCM. : GO TO 2.
2. REPLACE BCM Replace BCM. Refer to " «REMOVAL AND INSTALLATION»(ref-675612-S22326735462014120500000) ". : GO TO 3.
3. WRITING VEHICLE SPECIFICATION CONSULT Configuration Perform "WRITE CONFIGURATION - Config file" or "WRITE CONFIGURATION - Manual selection" to write vehicle specification. Refer to " «WORK PROCEDURE»(ref-675612-S20105046772014120500000) ". : GO TO 4.
4. INITIALIZE BCM (NATS) (IF EQUIPPED) Perform BCM initialization. (NATS) : WORK END

1. WRITING MODE SELECTION CONSULT Configuration Select "CONFIGURATION" of BCM. When writing saved data: GO TO 2. When writing manually: GO TO 3 .
2. PERFORM "WRITE CONFIGURATION - CONFIG FILE" CONSULT Configuration Perform "WRITE CONFIGURATION - Config file". : WORK END
3. PERFORM "WRITE CONFIGURATION - MANUAL SELECTION" CONSULT Configuration Select "WRITE CONFIGURATION - Manual selection". Identify the correct model and configuration list. Refer to " «CONFIGURATION LIST»(ref-675612-S24412411362014120500000) ". Confirm and/or change setting value for each item. CAUTION: Thoroughly read and understand the vehicle specification. ECU control may not operate normally if the setting is not correct. NOTE: If items are not displayed, touch "SETTING". Refer to " «CONFIGURATION LIST»(ref-675612-S24412411362014120500000) " for written items and setting value. Select "SETTING". CAUTION: Make sure to select "SETTING" even if the indicated configuration of brand new BCM is same as the desirable configuration. If not, configuration which is set automatically by selecting vehicle model can not be memorized. When "COMMAND FINISHED", select "END". : GO TO 4.
4. OPERATION CHECK Confirm that each function controlled by BCM operates normally. : WORK END

Configuration List
