CAN COMMUNICATION SYSTEM: CAN Communication Control Circuit
CAN communication control circuit is incorporated into the control unit and transmits/receives CAN communication signals.
Scheme 29
Scheme 29: CAN COMMUNICATION SYSTEM: CAN Communication Control Circuit
| Component | System description |
|---|
| CAN controller | It controls CAN communication signal transmission and reception, error detection, etc. |
| Transceiver IC | It converts digital signal into CAN communication signal, and CAN communication signal into digital signal. |
| Noise filter | It eliminates noise of CAN communication signal. |
| Termination circuit (1) (Resistance of approx. 120 ohms) | Generates a potential difference between CAN-H and CAN-L. |
| (1) These are the only control units wired with both ends of CAN communication system. |
| (1) | These are the only control units wired with both ends of CAN communication system. |
CAN COMMUNICATION SYSTEM: CAN Communication Signal Chart
Refer to " HOW TO USE CAN COMMUNICATION SIGNAL CHART " for how to use CAN communication signal chart.
Note. Refer to " ABBREVIATION LIST " for the abbreviations of the connecting units. The air bag diagnosis sensor unit and AV control unit uses CAN communication only for communicating with the diagnostic tool (not with other connected control units).
Scheme 30
Scheme 30: CAN COMMUNICATION SYSTEM: CAN Communication Signal Chart
Scheme 31
Scheme 32
Scheme 33
Scheme 33: Wiring Diagram
Scheme 34
Scheme 34: Connector End Views
Scheme 35
Scheme 36
Scheme 37
Scheme 38
Interview Sheet
Note. Refer to " TROUBLE DIAGNOSIS PROCEDURE " for how to use interview sheet.
Scheme 39
Scheme 39: Interview Sheet
Main Line
| Malfunction area | Reference |
|---|
| Main line between IPDM E/R and data link connector | " DIAGNOSIS PROCEDURE " |
| Main line between IPDM E/R and around view monitor control unit | " DIAGNOSIS PROCEDURE " |
| Main line between around view monitor control unit and data link connector | " DIAGNOSIS PROCEDURE " |
Branch Line
| Malfunction area | Reference |
|---|
| ECM branch line circuit | " DIAGNOSIS PROCEDURE " |
| ABS actuator and electric unit (control unit) branch line circuit | " DIAGNOSIS PROCEDURE " |
| IPDM E/R branch line circuit | " DIAGNOSIS PROCEDURE " |
| TCM branch line circuit | " DIAGNOSIS PROCEDURE " |
| Around view monitor control unit branch line circuit | " DIAGNOSIS PROCEDURE " |
| Air bag diagnosis sensor unit branch line circuit | " DIAGNOSIS PROCEDURE " |
| AV control unit branch line circuit | " DIAGNOSIS PROCEDURE " |
| Data link connector branch line circuit | " DIAGNOSIS PROCEDURE " |
| EPS control unit branch line circuit | " DIAGNOSIS PROCEDURE " |
| Combination meter branch line circuit | " DIAGNOSIS PROCEDURE " |
| Steering angle sensor branch line circuit | " DIAGNOSIS PROCEDURE " |
| BCM branch line circuit | " DIAGNOSIS PROCEDURE " |
Short Circuit
| Malfunction area | Reference |
|---|
| CAN communication circuit | " DIAGNOSIS PROCEDURE " |
