Automatic Transaxle: Overhaul Nissan Altima L31

DISASSEMBLY

Disassemble upper, inter and lower bodies.

Bolt length, number and location

Scheme 509

Scheme 510

Scheme 511

Scheme 512

Scheme 513

Scheme 514

Scheme 515

Scheme 516

Scheme 517

Scheme 518

Scheme 519

Scheme 520

1. Remove bolts a , d and nut f and remove oil strainer from control valve assembly.
2. Remove solenoid valve assembly and line pressure solenoid valve from control valve assembly.
3. Remove O-rings from solenoid valves and terminal body.
4. Place upper body facedown, and remove bolts b, c and nut f .
5. Remove inter body from lower body.
6. Turn over lower body, and remove accumulator support plate.
7. Remove bolts e , separating plate and separating gasket from lower body.
8. Remove check balls and oil cooler relief valve springs from lower body. Be careful not to lose check balls and oil cooler relief valve springs.
9. Remove inter body from upper body.
10. Check to see that steel balls are properly positioned in inter body and then remove them. Be careful not to lose steel balls.
11. Check to see that steel balls are properly positioned in upper body and then remove them. Be careful not to lose steel balls.

Scheme 521

Scheme 522

1. Check to see that retainer plates are properly positioned in lower body.
2. Check to see that retainer plates are properly positioned in upper body.
3. Be careful not to lose these parts.
