TORQUE CONVERTER SERVICE

The torque converter should be replaced under any of the following conditions

  1. External leaks in the hub weld area.
  2. Converter hub is scored or damaged.
  3. Converter pilot is broken, damaged or fits poorly into crankshaft.
  4. Steel particles are found after flushing the cooler and cooler lines.
  5. Pump is damaged or steel particles are found in the converter.
  6. Vehicle has TCC shudder and/or no TCC apply. Replace only after all hydraulic and electrical diagnoses have been made. (Converter clutch material may be glazed.)
  7. Converter is contaminated with engine coolant containing antifreeze.
  8. Internal failure of stator roller clutch.
  9. Heavy clutch debris due to overheating (blue converter).
  10. Steel particles or clutch lining material found in fluid filter or on magnet when no internal parts in unit are worn or damaged-indicates that lining material came from converter.
  11. The torque converter should not be replaced if
  12. The fluid has an odor, is discolored, and there is no evidence of metal or clutch facing particles.
  13. The threads in one or more of the converter bolt holes are damaged.
  14. Transaxle failure did not display evidence of damaged or worn internal parts, steel particles or clutch plate lining material in unit and inside the fluid filter.
  15. Vehicle has been exposed to high mileage (only). The exception may be where the torque converter clutch dampener plate lining has seen excess wear by vehicles operated in heavy and/or constant traffic, such as taxi, delivery or police use.

Torque Converter Clutch Solenoid Valve Control

The torque converter clutch solenoid valve is controlled by the TCM. The plunger closes the drain circuit during the OFF period, and opens the circuit during the ON period. If the percentage of OFF-time increases in one cycle, the pilot pressure drain time is reduced and pilot pressure remains high.

Scheme 98

Scheme 98: Torque Converter Clutch Solenoid Valve Control

The torque converter clutch piston is designed to slip to adjust the ratio of ON-OFF, thereby reducing lock-up shock.

OFF-time INCREASING

Amount of drain DECREASING

Pilot pressure HIGH

Lock-up RELEASING

Scheme 99

Scheme 99

Scheme 100

Scheme 100: Torque Converter Clutch Control Valve Operation

Stall revolution within specifications

  1. Vehicle does not achieve speed of more than 80 km/h (50 MPH)..... One-way clutch seizure in torque converter housing
CAUTIONBe careful since automatic fluid temperature increases abnormally. Slippage occurs in 3rd and 4th gears in D position..... High clutch slippage Slippage occurs in 2nd and 4th gear in D position..... Brake band slippage Engine brake does not function in 2nd and 3rd gears in D position, 2nd gear in 2 position, and 1st gear in 1 position.

Stall revolution less than specifications

Scheme 101

Scheme 101
  1. Poor acceleration during starts..... One-way clutch seizure in torque converter

General Specifications

EngineQR25DEVQ35DE
Automatic transaxle modelRE4F04B
Automatic transaxle assemblyModel code number85X2188X02
Transaxle gear ratio1st2.785
2nd1.545
3rd1.000
4th0.694
Reverse2.272
Final drive4.0873.789
Recommended fluidNissan Matic "D" (Continental U.S. and Alaska) or Canada Nissan Automatic Transmission Fluid (1)
Fluid capacity l (US qt, lmp qt)9.2 (9.75, 8.125)
(1) Refer to SERVICING - A/T article.
(1)Refer to SERVICING - A/T article.

General Specifications

Scheme 102

Scheme 102: VEHICLE SPEED WHEN SHIFTING GEARS THROTTLE POSITION - QR25DE MODEL

Scheme 103

Scheme 103: VEHICLE SPEED WHEN PERFORMING AND RELEASING LOCK-UP-QR25DE MODEL

Note. Lock-up vehicle speed indicates the speed in D 4 position. Perform lock-up inspection after warming up engine. Lock-up vehicle speed may vary depending on the driving conditions and circumstances.

Scheme 104

Scheme 104: VEHICLE SPEED WHEN SHIFTING GEARS THROTTLE POSITION - VQ35DE MODEL

Scheme 105

Scheme 105

Scheme 106

Scheme 106: VEHICLE SPEED WHEN PERFORMING AND RELEASING LOCK-UP - VQ35DE MODEL

Note. Lock-up vehicle speed indicates the speed in D 4 position. Perform lock-up inspection after warming up engine. Lock-up vehicle speed may vary depending on the driving conditions and circumstances.

Scheme 107

Scheme 107: Stall Revolution

Scheme 108

Scheme 108: Line Pressure

Scheme 109

Scheme 109: CONTROL VALVE AND PLUG RETURN SPRINGS

Scheme 110

Scheme 110

Scheme 111

Scheme 111: O-RING

Scheme 112

Scheme 112: RETURN SPRING

Scheme 113

Scheme 113: REVERSE CLUTCH

Scheme 114

Scheme 114: HIGH CLUTCH - QR25DE MODEL

Scheme 115

Scheme 115: HIGH CLUTCH - VQ35DE MODEL

Scheme 116

Scheme 116: FORWARD CLUTCH

Scheme 117

Scheme 117

Scheme 118

Scheme 118: OVERRUN CLUTCH

Scheme 119

Scheme 119: LOW & REVERSE BRAKE

Scheme 120

Scheme 120: CLUTCH AND BRAKE RETURN SPRINGS

Scheme 121

Scheme 121

Scheme 122

Scheme 122: BRAKE BAND

Scheme 123

Scheme 123: DIFFERENTIAL SIDE GEAR CLEARANCE

Scheme 124

Scheme 124: DIFFERENTIAL SIDE GEAR THRUST WASHERS

Scheme 125

Scheme 125: DIFFERENTIAL SIDE BEARING PRELOAD ADJUSTING SHIMS

Scheme 126

Scheme 126: BEARING PRELOAD

Scheme 127

Scheme 127: TURNING TORQUE

Scheme 128

Scheme 128: PLANETARY CARRIER

Scheme 129

Scheme 129: OIL PUMP

Scheme 130

Scheme 130

Scheme 131

Scheme 131: SEAL RING CLEARANCE

Scheme 132

Scheme 132: SEAL RING

Scheme 133

Scheme 133: TURNING TORQUE

Scheme 134

Scheme 134: REDUCTION PINION GEAR BEARING ADJUSTING SHIMS

Scheme 135

Scheme 135

Scheme 136

Scheme 136: RETURN SPRING

Scheme 137

Scheme 137: SEAL RING CLEARANCE

Scheme 138

Scheme 138: SEAL RING

Scheme 139

Scheme 139: END PLAY

Scheme 140

Scheme 140: OUTPUT SHAFT ADJUSTING SHIMS

Scheme 141

Scheme 141: SEAL RING CLEARANCE

Scheme 142

Scheme 142: Total End Play

Scheme 143

Scheme 143: BEARING RACE FOR ADJUSTING TOTAL END PLAY

Scheme 144

Scheme 144: Reverse Clutch End Play

Scheme 145

Scheme 145: THRUST WASHERS FOR ADJUSTING REVERSE CLUTCH DRUM END PLAY

Scheme 146

Scheme 146: Removal and Installation

Scheme 147

Scheme 147: Shift Solenoid Valves

Scheme 148

Scheme 148: Solenoid Valves

Scheme 149

Scheme 149
