Automatic Transaxle: Diagnosis Nissan Altima L31

Precautions for On Board Diagnostic (OBD) System of A/T and Engine

The ECM has an on board diagnostic system. It will light up the malfunction indicator lamp (MIL) to warn the driver of a malfunction causing emission deterioration.

Scheme 264

Scheme 265

Scheme 266

Scheme 267

1. Before connecting or disconnecting the TCM harness connector, turn ignition switch OFF and disconnect negative battery terminal. Failure to do so may damage the TCM. Because battery voltage is applied to TCM even if ignition switch is turned off.
2. When connecting or disconnecting pin connectors into or from TCM, take care not to damage pin terminals (bend or break). Make sure that there are not any bends or breaks on TCM pin terminal, when connecting pin connectors.
3. Before replacing TCM, perform TCM input/output signal inspection and make sure whether TCM functions properly or not. Refer to «INPUT/OUTPUT SIGNAL OF TCM»(ref-206576-S16887597082005112500000) .
4. After performing each TROUBLE DIAGNOSIS, perform DTC (Diagnostic Trouble Code) CONFIRMATION PROCEDURE. The DTC should not be displayed in the DTC CONFIRMATION PROCEDURE if the repair is completed.
5. Before proceeding with disassembly, thoroughly clean the outside of the transaxle. It is important to prevent the internal parts from becoming contaminated by dirt or other foreign matter.
6. Disassembly should be done in a clean work area.
7. Use lint-free cloth or towels for wiping parts clean. Common shop rags can leave fibers that could interfere with the operation of the transaxle.
8. Place disassembled parts in order for easier and proper assembly.
9. All parts should be carefully cleaned with a general purpose, non-flammable solvent before inspection or reassembly.
10. Gaskets, seals and O-rings should be replaced any time the transaxle is disassembled.
11. It is very important to perform functional tests whenever they are indicated.
12. The valve body contains precision parts and requires extreme care when parts are removed and serviced. Place disassembled valve body parts in order for easier and proper assembly. Care will also prevent springs and small parts from becoming scattered or lost.
13. Properly installed valves, sleeves, plugs, etc. will slide along bores in valve body under their own weight.
14. Before assembly, apply a coat of recommended ATF to all parts. Apply petroleum jelly to protect O-rings and seals, or hold bearings and washers in place during assembly. Do not use grease.
15. Extreme care should be taken to avoid damage to O-rings, seals and gaskets when assembling.
16. Replace ATF cooler if excessive foreign material is found in oil pan or clogging strainer. Refer to «ATF COOLER SERVICE»(ref-206576-S15530625732005112500000) .
17. After overhaul, refill the transaxle with new ATF.
18. When the A/T drain plug is removed, only some of the fluid is drained. Old A/T fluid will remain in torque converter and ATF cooling system. Always follow the procedures when changing A/T fluid. Refer to «SERVICING - A/T»(ref-142978) article .

OBD-II SELF-DIAGNOSIS

1. A/T self-diagnosis is performed by the TCM in combination with the ECM. The results can be read through the blinking pattern of the A/T check (position) indicator or the malfunction indicator lamp (MIL). Refer to «SELF-DIAGNOSTIC RESULT TEST MODE»(ref-206576-S42429752142005112500000) for the indicator used to display each self-diagnostic result.
2. The self-diagnostic results indicated by the MIL are automatically stored in both the ECM and TCM memories.
3. Always perform the procedure HOW TO ERASE DTC to complete the repair and avoid unnecessary blinking of the MIL.
4. The following self-diagnostic items can be detected using ECM self-diagnostic results mode* only when the A/T check (position) indicator lamp does not indicate any malfunctions. park/neutral position (PNP) switch

1. A/T 1st, 2nd, 3rd, or 4th gear function
2. A/T TCC S/V function (lock-up). *: For details of OBD-II, refer to «SELF-DIAGNOSTICS - ALTIMA»(ref-135505) article.

1. Certain systems and components, especially those related to OBD, may use a new style slide-locking type harness connector.

For description and how to disconnect, refer to HOW TO CHECK TERMINAL . .

Wiring Diagrams and Trouble Diagnosis

When you read wiring diagrams, refer to the following

1. «HOW TO READ WIRING DIAGRAMS»(ref-177331-S13148762022006041300000)
2. «POWER DISTRIBUTION»(ref-151282-S09691687642002121200000) When you perform trouble diagnosis, refer to the following
3. «HOW TO FOLLOW TEST GROUPS IN TROUBLE DIAGNOSE»(ref-177331-S36300051462006041300000)
4. «HOW TO PERFORM EFFICIENT DIAGNOSIS FOR AN ELECTRICAL INCIDENT»(ref-177331-S14523163872005052600000)

HOW TO READ DTC AND 1ST TRIP DTC

DTC and 1st trip DTC can be read by the following methods.

(With CONSULT-II or GST) CONSULT-II or GST (Generic Scan Tool) Examples: P0705, P0710, P0720, P0725, etc.

These DTCs are prescribed by SAE J2012.

(CONSULT-II also displays the malfunctioning component or system.)

1. 1st trip DTC No. is the same as DTC No.
2. Output of the diagnostic trouble code indicates that the indicated circuit has a malfunction. However, in case of the Mode II and GST they do not indicate whether the malfunction is still occurring or occurred in the past and returned to normal. CONSULT-II can identify them as shown below. Therefore, using CONSULT-II (if available) is recommended.

A sample of CONSULT-II display for DTC and 1st trip DTC is shown in the following page. DTC or 1st trip DTC of a malfunction is displayed in SELF DIAGNOSIS mode for ENGINE with CONSULT-II. Time data indicates how many times the vehicle was driven after the last detection of a DTC.

Scheme 268

If the DTC is being detected currently, the time data will be 0.

Scheme 269

If a 1st trip DTC is stored in the ECM, the time data will be 1t.

Scheme 270

HOW TO ERASE DTC

The diagnostic trouble code can be erased by CONSULT-II, GST or ECM DIAGNOSTIC TEST MODE as described following.

1. If the battery terminal is disconnected, the diagnostic trouble code will be lost within 24 hours.
2. When you erase the DTC, using CONSULT-II or GST is easier and quicker than switching the mode selector on the ECM.

The following emission-related diagnostic information is cleared from the ECM memory when erasing DTC related to OBD-II. For details, refer to SELF-DIAGNOSTICS - ALTIMA article.

1. Diagnostic trouble codes (DTC)
2. 1st trip diagnostic trouble codes (1st trip DTC)
3. Freeze frame data
4. 1st trip freeze frame data
5. System readiness test (SRT) codes
6. Test values

HOW TO ERASE DTC (WITH CONSULT-II)

1. If a DTC is displayed for both ECM and TCM, it needs to be erased for both ECM and TCM.

Scheme 271

1. If the ignition switch stays ON after repair work, be sure to turn ignition switch OFF once. Wait at least 10 seconds and then turn it ON (engine stopped) again.
2. Turn CONSULT-II ON and touch A/T.
3. Touch SELF-DIAG RESULTS.
4. Touch ERASE. (The DTC in the TCM will be erased.) Then touch BACK twice.
5. Touch ENGINE.
6. Touch SELF DIAGNOSIS.
7. Touch ERASE. (The DTC in the ECM will be erased.)

HOW TO ERASE DTC (WITH GST)

1. If the ignition switch stays ON after repair work, be sure to turn ignition switch OFF once. Wait at least 10 seconds and then turn it ON (engine stopped) again.
2. Perform OBD-II SELF-DIAGNOSTIC PROCEDURE (No Tools). Refer to «OBD-II SELF-DIAGNOSTIC PROCEDURE (NO TOOLS)»(ref-206576-S38209305822005112500000) . (The engine warm-up step can be skipped when performing the diagnosis only to erase the DTC.)
3. Select Mode 4 with Generic Scan Tool (GST). For details, refer to «SELF-DIAGNOSTICS - ALTIMA»(ref-135505) article.

HOW TO ERASE DTC (NO TOOLS)

1. If the ignition switch stays ON after repair work, be sure to turn ignition switch OFF once. Wait at least 10 seconds and then turn it ON (engine stopped) again.
2. Perform TCM SELF-DIAGNOSTIC PROCEDURE (NO TOOLS). Refer to «TCM SELF-DIAGNOSTIC PROCEDURE (NO TOOLS)»(ref-206576-S39240413392005112500000) . (The engine warm-up step can be skipped when performing the diagnosis only to erase the DTC.)

Scheme 272

1. The malfunction indicator lamp will light up when the ignition switch is turned ON without the engine running. This is for checking the lamp. If the malfunction indicator lamp does not light up, refer to «GAUGES & INSTRUMENT PANELS»(ref-152591) article. [Or see «SELF-DIAGNOSTICS - ALTIMA»(ref-135505) article.
2. When the engine is started, the malfunction indicator lamp should go off. If the lamp remains on, the on board diagnostic system has detected an emission-related (OBD-II) malfunction. For details, refer to «SELF-DIAGNOSTICS - ALTIMA»(ref-135505) article.

OBD-II SELF-DIAGNOSTIC PROCEDURE (WITH GST)

Refer to SELF-DIAGNOSTICS - ALTIMA article.

OBD-II SELF-DIAGNOSTIC PROCEDURE (NO TOOLS)

Refer to SELF-DIAGNOSTICS - ALTIMA article.

Scheme 273

Scheme 274

Scheme 275

Scheme 276

Scheme 277

Scheme 278

1. CHECK A/T CHECK (POSITION) INDICATOR LAMP Move selector lever to P position. Start engine and warm it up to normal engine operating temperature. Turn ignition switch to OFF position. Wait 5 seconds. Turn ignition switch to ON position. (Do not start engine.) Does A/T check (position) indicator lamp come on for about 2 seconds? Yes or No Yes: GO TO 2. No: Stop procedure. Perform «1. A/T Check (Position) Indicator Lamp Does Not Come On»(ref-206576-S21109005872005112500000) before proceeding.
2. JUDGEMENT PROCEDURE STEP 1 Turn ignition switch to OFF position. Turn ignition switch to ON position. (Do not start engine.) Depress the brake pedal, then move gear selector lever from P to D position. Wait 3 seconds. Move selector lever to 2 position. Release brake pedal. : GO TO 3.
3. JUDGEMENT PROCEDURE STEP 2 Move selector lever to 1 position. Depress brake pedal. Depress accelerator pedal fully and release it. The A/T check (position) indicator lamp will begin to flash. : GO TO 4.
4. CHECK SELF-DIAGNOSTIC CODE Check A/T check (position) indicator lamp. Refer to «JUDGEMENT OF SELF-DIAGNOSIS CODE»(ref-206576-S16337766912005112500000) . : DIAGNOSIS END

Scheme 279

Scheme 280

Scheme 281

HOW TO PERFORM TROUBLE DIAGNOSES FOR QUICK AND ACCURATE REPAIR

A good understanding of the malfunction conditions can make troubleshooting faster and more accurate. In general, each customer feels differently about a problem. It is important to fully understand the symptoms or conditions for a customer complaint.

Make good use of the two sheets provided, INFORMATION FROM CUSTOMER and DIAGNOSTIC WORKSHEET , to perform the best troubleshooting possible.

Scheme 282

Scheme 283

Scheme 284

1. Clean area suspected of leaking.-For example, mating surface of converter housing and transmission case.
2. Start engine, apply foot brake, place selector lever in D position and wait a few minutes.
3. Stop engine.
4. Check for fresh leakage.

Scheme 285

Scheme 286

JUDGEMENT OF STALL TEST

The test result and possible damaged components relating to each result are shown in the illustrations on next page.

In order to pinpoint the possible damaged components, refer to WORK FLOW CHART .

Note. Stall revolution is too high in D, 2 or 1 position: Slippage occurs in 1st gear but not in 2nd and 3rd gears..... Low one-way clutch slippage Slippage occurs in the following gears: 1st through 3rd gears in 3 position and engine brake functions. 1st and 2nd gears in 2 position and engine brake functions with accelerator pedal released (fully closed throttle)..... Forward clutch or forward one-way clutch slippage

LINE PRESSURE TEST PORTS

Location of line pressure test ports are shown in the illustration.

Scheme 287

1. Always replace pressure plugs as they are self-sealing bolts.

Scheme 288

Scheme 289

Scheme 290

Scheme 291

1. Check A/T fluid and engine oil levels. If necessary, add fluid and oil.
2. Drive vehicle for approximately 10 minutes or until fluid and oil reach operating temperature. ATF operating temperature: 50 - 80°C (122 - 176°F)
3. Install pressure gauge to corresponding line pressure port.
4. Set parking brake and block wheels. Continue to depress brake pedal fully while line pressure test is being performed at stall speed.
5. Start engine and measure line pressure at idle and stall speed. When measuring line pressure at stall speed, follow the stall test procedure. See Line Pressure Test «LINE PRESSURE TEST PROCEDURE»(ref-206576-S25610828072005112500000) and refer to SDS, «LINE PRESSURE»(ref-206576-S10112921102005112500000) .

Scheme 292

Symptom Chart

Numbers are arranged in order of inspection.

Perform inspections starting with number one and work up.

Scheme 293

Scheme 294

Scheme 295

Scheme 296

Scheme 297

Scheme 298

Scheme 299

Scheme 300

Scheme 301

Scheme 302

Scheme 303

Scheme 304

1. Measure voltage between each terminal and terminal 25 or 48 by following TCM INSPECTION TABLE.

Scheme 305

TCM INSPECTION TABLE

(Data are reference values.)

Scheme 306

Scheme 307

Scheme 308

On Board Diagnosis Logic

Diagnostic trouble code PNP SW/CIRC with CONSULT-II or P0705 without CONSULT-II is detected when TCM does not receive the correct voltage signal from the switch based on the gear position.

Diagnostic Trouble Code (DTC) Confirmation Procedure

Note. If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 309

Scheme 310

1. Turn ignition switch ON.
2. Select DATA MONITOR mode for ENGINE with CONSULT-II.
3. Start engine and maintain the following conditions for at least 5 consecutive seconds.
4. VHCL SPEED SE: 10 km/h (6 MPH) or more
5. THRTL POS SEN: More than 1.3V
6. Selector lever: 3 or D position

Diagnostic trouble code ATF TEMP SEN/CIRC with CONSULT-II or P0710 without CONSULT-II is detected when TCM receives an excessively low or high voltage from the sensor.

Note. If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 311

Scheme 312

1. Turn ignition switch ON and select DATA MONITOR mode for ENGINE with CONSULT-II.
2. Start engine and maintain the following conditions for at least 10 minutes (Total). (It is not necessary to maintain continuously.) CMPS. RPM (REF): 450 RPM or more VHCL SPEED SE: 10 km/h (6 MPH) or more THRTL POS SEN: More than 1.2V Selector lever: D position

Diagnostic Procedure

1. INSPECTION START Do you have CONSULT-II? Yes or No Yes: GO TO 2. No: GO TO 3 .
2. CHECK INPUT SIGNAL OF A/T FLUID TEMPERATURE SENSOR (WITH CONSULT-II) With CONSULT-II

1. Start engine.
2. Select TCM INPUT SIGNALS in DATA MONITOR mode for A/T with CONSULT-II.
3. Read out the value of FLUID TEMP SE. Voltage: Cold [20°C (68°F)] --> Hot [80°C (176°F)] : Approximately 1.5V --> 0.5V OK or NG

Scheme 313

Scheme 314

Scheme 315

Scheme 316

Scheme 317

Scheme 318

Scheme 319

1. OK: GO TO 4 .
2. NG: GO TO 3.
3. CHECK A/T FLUID TEMPERATURE SENSOR WITH TERMINAL CORD ASSEMBLY Turn ignition switch to OFF position. Disconnect terminal cord assembly connector in engine compartment. Check resistance between terminal cord F30 terminals 6 and 7 (component side) when A/T is cold. Reinstall any part removed. OK or NG OK: GO TO 4. NG: GO TO 3 .
4. DETECT MALFUNCTIONING ITEM Check the following items: Harness for short to ground or short to power or open between TCM, ECM and terminal cord assembly (Main harness) Ground circuit for ECM. Refer to «POWER DISTRIBUTION»(ref-151282-S09691687642002121200000) . OK or NG OK: GO TO 4 . NG: Repair or replace damaged parts. DETECT MALFUNCTIONING ITEM Remove oil pan. Check the following items: A/T fluid temperature sensor Check resistance between two terminals while changing temperature as shown in figure. Harness of terminal cord assembly for short or open OK or NG OK: GO TO 4 . NG: Repair or replace damaged parts. CHECK INPUT SIGNAL OF A/T FLUID TEMPERATURE SENSOR (WITHOUT CONSULT-II) Without CONSULT-II Start engine. Check voltage between TCM terminal 47 (BR) and ground while warming up A/T. OK or NG OK: GO TO 7. NG: GO TO c . CHECK DTC Perform «Diagnostic Trouble Code (DTC) Confirmation Procedure»(ref-206576-S39114183902005112500000) . OK or NG OK: INSPECTION END NG: GO TO 8. CHECK TCM INSPECTION Perform TCM input/output signal inspection. If NG, recheck TCM pin terminals for damage or loose connection with harness connector. OK or NG OK: INSPECTION END NG: Repair or replace damaged parts.

Diagnostic trouble code VEH SPD SEN/CIR AT with CONSULT-II or P0720 without CONSULT-II is detected when TCM does not receive the proper voltage signal from the sensor.

Note. If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 320

Scheme 321

Scheme 322

Scheme 323

1. Turn ignition switch ON and select DATA MONITOR mode for A/T with CONSULT-II.
2. Drive vehicle and check for an increase of VHCL/S SE. MTR value. If the check result is NG, go to «DIAGNOSTIC PROCEDURE»(ref-206576-S38580451452005112500000) . If the check result is OK, go to following step.
3. Select DATA MONITOR mode for ENGINE with CONSULT-II.
4. Start engine and maintain the following conditions for at least 5 consecutive seconds. VHCL SPEED SE: 30 km/h (19 MPH) or more THRTL POS SEN: More than 1.2V Selector lever: D position Driving location: Driving the vehicle uphill (increased engine load) will help maintain the driving conditions required for this test . If the check result is NG, go to «DIAGNOSTIC PROCEDURE»(ref-206576-S38580451452005112500000) . If the check result is OK, go to following step.
5. Maintain the following conditions for at least 5 consecutive seconds. CMPS. RPM (REF): 3,500 RPM or more THRTL POS SEN: More than 1.2V Selector lever: D position Driving location: Driving the vehicle uphill (increased engine load) will help maintain the driving conditions required for this test .

Diagnostic trouble code ENGINE SPEED SIG with CONSULT-II or P0725 without CONSULT-II is detected when TCM does not receive the proper voltage signal from ECM.

Note. If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 324

Scheme 325

1. Turn ignition switch ON and select DATA MONITOR mode for ENGINE with CONSULT-II.
2. Start engine and maintain the following conditions for at least 10 consecutive seconds. VHCL SPEED SE: 10 km/h (6 MPH) or more THRTL POS SEN: More than 1.2V Selector lever: D position

This diagnosis monitors actual gear position by checking the torque converter slip ratio calculated by TCM as follows

Torque converter slip ratio = A x C/B

A: Output shaft revolution signal from revolution sensor

B: Engine speed signal from ECM

C: Gear ratio determined as gear position which TCM supposes

If the actual gear position is higher than the position (1st) supposed by TCM, the slip ratio will be more than normal. In case the ratio exceeds the specified value, TCM judges this diagnosis malfunction.

This malfunction will be caused when either shift solenoid valve A is stuck open or shift solenoid valve B is stuck open.

Gear positions supposed by TCM are as follows.

In case of gear position with no malfunctions: 1, 2, 3 and 4 positions

In case of gear position with shift solenoid valve A stuck open: 2* , 2, 3 and 3 positions

In case of gear position with shift solenoid valve B stuck open: 4* , 3, 3 and 4 positions to each gear position above

*: P0731 is detected.

Diagnostic trouble code A/T 1ST GR FNCTN with CONSULT-II or P0731 without CONSULT-II is detected when A/T cannot be shifted to the 1st gear position even if electrical circuit is good.

Note. If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at least 10 seconds before conducting the next test.

TESTING CONDITION

Always drive vehicle on a level road to improve the accuracy of test

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 326

Scheme 327

Scheme 328

Scheme 329

1. Start engine and select DATA MONITOR mode for A/T with CONSULT-II.
2. Make sure that output voltage of A/T fluid temperature sensor is within the range below. FLUID TEMP SEN: 0.4 - 1.5V If out of range, drive the vehicle to decrease the voltage (warm up the fluid) or stop engine to increase the voltage (cool down the fluid).
3. Select 1ST GR FNCTN P0731 of DTC WORK SUPPORT mode for A/T with CONSULT-II and touch START.
4. Accelerate vehicle to 20 to 25 km/h (12 to 16 MPH) under the following condition and release the accelerator pedal completely. THROTTLE POSI: Less than 1.0/8 (at all times during step 4) Selector lever: D position Check that GEAR shows 2 after releasing pedal .
5. Depress accelerator pedal to WOT (more than 7.0/8 of THROTTLE POSI ) quickly from a speed of 20 to 25 km/h (12 to 16 MPH) until TESTING changes to STOP VEHICLE or COMPLETED. (It will take approximately 3 seconds.) If the check result NG appears on CONSULT-II screen, go to «DIAGNOSTIC PROCEDURE»(ref-206576-S41717644152005112500000) . If STOP VEHICLE appears on CONSULT-II screen, go to the following step. Check that GEAR shows 1 when depressing accelerator pedal to WOT . If TESTING does not appear on CONSULT-II for a long time, select SELF-DIAG RESULTS for ENGINE. In case a 1st trip DTC other than P0731 is shown, refer to TROUBLE DIAGNOSIS FOR DTC. .
6. Stop vehicle.
7. Follow the instruction displayed. (Check for normal shifting referring to the table below.)
8. Make sure that OK is displayed. (If NG is displayed, refer to DIAGNOSTIC PROCEDURE.) Refer to «DIAGNOSTIC PROCEDURE»(ref-206576-S41717644152005112500000) . Refer to «SHIFT SCHEDULE»(ref-206576-S24864084732005112500000) .

This diagnosis monitors actual gear position by checking the torque converter slip ratio calculated by TCM as follows

Torque converter slip ratio = A x C/B

A: Output shaft revolution signal from revolution sensor

B: Engine speed signal from ECM

C: Gear ratio determined as gear position which TCM supposes

If the actual gear position is higher than the position (2nd) supposed by TCM, the slip ratio will be more than normal. In case the ratio exceeds the specified value, TCM judges this diagnosis malfunction.

This malfunction will be caused when shift solenoid valve B is stuck open.

Gear positions supposed by TCM are as follows.

In case of gear position with no malfunctions: 1,2,3 and 4 positions

In case of gear position with shift solenoid valve B stuck open: 4, 3*, 3 and 4 positions to each gear position above

*: P0732 is detected.

Diagnostic trouble code A/T 2ND GR FNCTN with CONSULT-II or P0732 without CONSULT-II is detected when A/T cannot be shifted to the 2nd gear position even if electrical circuit is good.

Note. If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at least 10 seconds before conducting the next test.

Always drive vehicle on a level road to improve the accuracy of test

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 330

Scheme 331

Scheme 332

Scheme 333

1. Start engine and select DATA MONITOR mode for A/T with CONSULT-II.
2. Make sure that output voltage of A/T fluid temperature sensor is within the range below. FLUID TEMP SEN: 0.4 - 1.5V If out of range, drive the vehicle to decrease the voltage (warm up the fluid) or stop engine to increase the voltage (cool down the fluid).
3. Select 2ND GR FNCTN P0732 of DTC WORK SUPPORT mode for A/T with CONSULT-II and touch START.
4. Accelerate vehicle to 45 to 50 km/h (28 to 31 MPH) under the following condition and release the accelerator pedal completely. THROTTLE POSI: Less than 1.0/8 Selector lever: D position Check that GEAR shows 3 or 4 after releasing pedal.
5. Depress accelerator pedal to WOT (more than 7.0/8 of THROTTLE POSI ) quickly from a speed of 45 to 50 km/h (28 to 31 MPH) until TESTING changes to STOP VEHICLE or COMPLETE. (It will take approximately 3 seconds.) If the check result NG appears on CONSULT-II screen, go to «DIAGNOSTIC PROCEDURE»(ref-206576-S27398079602005112500000) . If STOP VEHICLE appears on CONSULT-II screen, go to following step. Check that GEAR shows 2 when depressing accelerator pedal to WOT . If TESTING does not appear on CONSULT-II for a long time, select SELF-DIAG RESULTS for ENGINE. In case a 1st trip DTC other than P0732 is shown, refer to TROUBLE DIAGNOSIS FOR DTC .
6. Stop vehicle.
7. Follow the instruction displayed. (Check for normal shifting referring to the table below.)
8. Make sure that OK is displayed. (If NG is displayed, refer to DIAGNOSTIC PROCEDURE.) Refer to «DIAGNOSTIC PROCEDURE»(ref-206576-S27398079602005112500000) . Refer to «SHIFT SCHEDULE»(ref-206576-S24864084732005112500000) .

This diagnosis monitors actual gear position by checking the torque converter slip ratio calculated by TCM as follows

Torque converter slip ratio = A x C/B

A: Output shaft revolution signal from revolution sensor

B: Engine speed signal from ECM

C: Gear ratio determined as gear position which TCM supposes

If the actual gear position is higher than the position (3rd) supposed by TCM, the slip ratio will be more than normal. In case the ratio exceeds the specified value, TCM judges this diagnosis malfunction.

This malfunction will be caused when shift solenoid valve A is stuck closed.

Gear positions supposed by TCM are as follows.

In case of gear position with no malfunctions: 1,2, 3 and 4 positions

In case of gear position with shift solenoid valve A stuck closed: 1, 1, 4* and 4 positions to each gear position above

*: P0733 is detected.

Diagnostic trouble code A/T 3RD GR FNCTN with CONSULT-II or P0733 without CONSULT-II is detected when A/T cannot be shifted to the 3rd gear position even if electrical circuit is good.

Note. If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at least 10 seconds before conducting the next test.

Always drive vehicle on a level road to improve the accuracy of test

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 334

Scheme 335

Scheme 336

Scheme 337

1. Start engine and select DATA MONITOR mode for A/T with CONSULT-II.
2. Make sure that output voltage of A/T fluid temperature sensor is within the range below. FLUID TEMP SEN: 0.4 - 1.5V If out of range, drive the vehicle to decrease the voltage (warm up the fluid) or stop engine to increase the voltage (cool down the fluid).
3. Select 3RD GR FNCTN P0733 of DTC WORK SUPPORT mode for A/T with CONSULT-II and touch START.
4. Accelerate vehicle to 60 to 75 km/h (37 to 47 MPH) under the following condition and release the accelerator pedal completely. THROTTLE POSI: Less than 1.0/8 (at all times during step 4) Selector lever: D position Check that GEAR shows 4 after releasing pedal .
5. Depress accelerator pedal steadily with 3.5/8 - 4.5/8 of THROTTLE POSI from a speed of 60 to 75 km/h (37 to 47 MPH) until TESTING changes to STOP VEHICLE or COMPLETED. (It will take approximately 3 seconds.) If the check result NG appears on CONSULT-II screen, go to «DIAGNOSTIC PROCEDURE»(ref-206576-S07507253192005112500000) . If STOP VEHICLE appears on CONSULT-II screen, go to following step. Check that GEAR shows 3 when depressing accelerator pedal with 3.5/8 - 4.5/8 of THROTTLE POSI. If TESTING does not appear on CONSULT-II for a long time, select SELF-DIAG RESULTS for ENGINE. In case a 1st trip DTC other than P0733 is shown, refer to TROUBLE DIAGNOSIS FOR DTC .
6. Stop vehicle.
7. Follow the instruction displayed. (Check for normal shifting referring to the table below.)
8. Make sure that OK is displayed. (If NG is displayed, refer to DIAGNOSTIC PROCEDURE.) Refer to «DIAGNOSTIC PROCEDURE»(ref-206576-S07507253192005112500000) . Refer to «SHIFT SCHEDULE»(ref-206576-S24864084732005112500000) .

This diagnosis monitors actual gear position by checking the torque converter slip ratio calculated by TCM as follows

Torque converter slip ratio = A x C/B

A: Output shaft revolution signal from revolution sensor

B: Engine speed signal from ECM

C: Gear ratio determined as gear position which TCM supposes

If the actual gear position is much lower than the position (4th) supposed by TCM, the slip ratio will be much less than normal. In case the ratio does not reach the specified value, TCM judges this diagnosis malfunction.

This malfunction will be caused when shift solenoid valve B is stuck closed.

Gear positions supposed by TCM are as follows.

In case of gear position with no malfunctions: 1, 2, 3 and 4 positions

In case of gear position with shift solenoid valve B stuck closed: 1, 2, 2 and 1* positions to each gear position above

*: P0734 is detected.

Diagnostic trouble code A/T 4TH GR FNCTN with CONSULT-II or P0734 without CONSULT-II is detected when A/T cannot be shifted to the 4th gear position even if electrical circuit is good.

Note. If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at least 10 seconds before conducting the next test.

Always drive vehicle on a level road to improve the accuracy of test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 338

Scheme 339

Scheme 340

Scheme 341

1. Start engine and select DATA MONITOR mode for A/T with CONSULT-II.
2. Make sure that output voltage of A/T fluid temperature sensor is within the range below. FLUID TEMP SEN: 0.4 - 1.5V If out of range, drive the vehicle to decrease the voltage (warm up the fluid) or stop engine to increase the voltage (cool down the fluid).
3. Select 4TH GR FNCTN P0734 of DTC WORK SUPPORT mode for A/T with CONSULT-II and touch START.
4. Accelerate vehicle to 55 to 65 km/h (34 to 40 MPH) under the following condition and release the accelerator pedal completely. THROTTLE POSI: Less than 5.5/8 (at all times during step 4) Selector lever: D position Check that GEAR shows 3 after releasing pedal.
5. Depress accelerator pedal steadily with 1.0/8 - 2.0/8 of THROTTLE POSI from a speed of 55 to 65 km/h (34 to 40 MPH) until TESTING has turned to STOP VEHICLE or COMPLETED. (It will take approximately 3 seconds.) If the check result NG appears on CONSULT-II screen, go to Diagnostic Procedure. If STOP VEHICLE appears on CONSULT-II screen, go to following step. Check that GEAR shows 4 when depressing accelerator pedal with 1.0/8 - 2.0/8 of THROTTLE POSI. If TESTING does not appear on CONSULT-II for a long time, select SELF-DIAG RESULTS for ENGINE. In case a 1st trip DTC other than P0734 is shown, refer to applicable TROUBLE DIAGNOSIS FOR DTC.
6. Stop vehicle.
7. Follow the instruction displayed. (Check for normal shifting referring to the table below.)
8. Make sure that OK is displayed. (If NG is displayed, refer to DIAGNOSTIC PROCEDURE.) Refer to «DIAGNOSTIC PROCEDURE»(ref-206576-S13032222912005112500000) . Refer to «SHIFT SCHEDULE»(ref-206576-S24864084732005112500000) .

Diagnostic trouble code TCC SOLENOID/CIRC with CONSULT-II or P0740 without CONSULT-II is detected when TCM detects an improper voltage drop when it tries to operate the solenoid valve.

Note. If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 342

Scheme 343

1. Turn ignition switch ON.
2. Select DATA MONITOR mode for ENGINE with CONSULT-II and wait at least 1 second.

This diagnosis monitors actual gear position by checking the torque converter slip ratio calculated by TCM as follows

Torque converter slip ratio = A x C/B

A: Output shaft revolution signal from revolution sensor

B: Engine speed signal from ECM

C: Gear ratio determined as gear position which TCM supposes

If the actual gear position is much lower than the position (4th) supposed by TCM, the slip ratio will be much less than normal. In case the ratio does not reach the specified value, TCM judges this diagnosis malfunction

This malfunction will be caused when shift solenoid valve B is stuck closed.

Gear positions supposed by TCM are as follows.

In case of gear position with no malfunctions: 1, 2, 3 and 4 positions

In case of gear position with shift solenoid valve B stuck closed: 1, 2, 2 and 1* position to each gear position above

* P0744 is detected.

Diagnostic trouble code A/T TCC S/V FNCTN with CONSULT-II or P0744 without CONSULT-II is detected when A/T cannot perform lock-up even if electrical circuit is good.

Note. If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 344

Scheme 345

Scheme 346

1. Start engine and select DATA MONITOR mode for A/T with CONSULT-II.
2. Make sure that output voltage of A/T fluid temperature sensor is within the range below. FLUID TEMP SEN: 0.4 - 1.5V If out of range, drive vehicle to decrease voltage (warm up the fluid) or stop engine to increase voltage (cool down the fluid).
3. Select TCC S/V FNCTN P0744 of DTC WORK SUPPORT mode for A/T with CONSULT-II and touch START.
4. Accelerate vehicle to more than 80 km/h (50 MPH) and maintain the following condition continuously until TESTING has turned to COMPLETE. (It will take approximately 30 seconds after TESTING shows.) THROTTLE POSI: 1.0/8 - 2.0/8 (at all times during step 4) Selector lever: D position TCC S/V DUTY: More than 94% VHCL/S SE. A/T: Constant speed of more than 80 km/h (50 MPH) Check that GEAR shows 4. For shift schedule, refer to «Shift Schedule»(ref-206576-S24864084732005112500000) If TESTING does not appear on CONSULT-II for a long time, select SELF-DIAG RESULTS. In case a 1st trip DTC other than P0744 is shown, refer to TROUBLE DIAGNOSIS FOR DTC.
5. Make sure that OK is displayed. (If NG is displayed, refer to DIAGNOSTIC PROCEDURE.) Refer to «DIAGNOSTIC PROCEDURE»(ref-206576-S27411563752005112500000) Refer to «Shift Schedule»(ref-206576-S24864084732005112500000) .

Diagnostic trouble code L/PRESS SOL/CIRC with CONSULT-II or P0745 without CONSULT-II is detected when TCM detects an improper voltage drop when it tries to operate the solenoid valve.

Note. If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 347

Scheme 348

1. Turn ignition switch ON and select DATA MONITOR mode for ENGINE with CONSULT-II.
2. Depress accelerator pedal completely and wait at least 1 second.

Diagnostic trouble code SFT SOL A/CIRC with CONSULT-II or P0750 without CONSULT-II is detected when TCM detects an improper voltage drop when it tries to operate the solenoid valve.

Note. If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 349

Scheme 350

1. Turn ignition switch ON and select DATA MONITOR mode for ENGINE with CONSULT-II.
2. Start engine.
3. Drive vehicle in D position and allow the transmission to shift 1 --> 2 ( GEAR ).

Diagnostic trouble code SFT SOL B/CIRC with CONSULT-II or P0755 without CONSULT-II is detected when TCM detects an improper voltage drop when it tries to operate the solenoid valve.

Note. If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 351

Scheme 352

1. Turn ignition switch ON and select DATA MONITOR mode for ENGINE with CONSULT-II.
2. Start engine.
3. Drive vehicle in D position and allow the transmission to shift 1 --> 2 --> 3 ( GEAR ).

Diagnostic trouble code TP SEN/CIRC A/T or P1705 with CONSULT-II, or 3rd judgement flicker without CONSULT-II is detected when TCM receives an excessively low or high voltage from the ECM.

Note. If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 353

Scheme 354

Scheme 355

Scheme 356

Scheme 357

1. Turn ignition switch ON and select DATA MONITOR mode for A/T with CONSULT-II. If the check result is NG, go to «DIAGNOSTIC PROCEDURE»(ref-206576-S02484388422005112500000) . If the check result is OK, go to following step.
2. Turn ignition switch ON and select DATA MONITOR mode for ENGINE with CONSULT-II.
3. Start engine and maintain the following conditions for at least 3 consecutive seconds. Then release accelerator pedal completely. VHCL SPEED SE: 10 km/h (6 MPH) or more THRTL POS SEN: Approximately 3V or less Selector lever: D position If the check result is NG, go to «DIAGNOSTIC PROCEDURE»(ref-206576-S02484388422005112500000) . If the check result is OK, go to following step.
4. Maintain the following conditions for at least 3 consecutive seconds. Then release accelerator pedal completely. VHCL SPEED SE: 10 km/h (6 MPH) or more Accelerator pedal: Wide open throttle Selector lever: D position

Diagnostic trouble code O/R CLTCH SOL/CIRC with CONSULT-II or P1760 without CONSULT-II is detected when TCM detects an improper voltage drop when it tries to operate the solenoid valve.

Note. If DIAGNOSTIC TROUBLE CODE CONFIRMATION PROCEDURE has been previously conducted, always turn ignition switch OFF and wait at least 10 seconds before conducting the next test.

Always drive vehicle on a level road to improve accuracy of test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 358

Scheme 359

1. Turn ignition switch ON and select DATA MONITOR mode for ENGINE with CONSULT-II.
2. Start engine.
3. Accelerate vehicle to a speed of more than 10 km/h (6 MPH) with selector lever in D position.
4. Release accelerator pedal completely with selector lever in 3 position.

1. This is an OBD-II self-diagnostic item.
2. Diagnostic trouble code A/T COMM LINE or U1000 with CONSULT-II and 12th judgement flicker without CONSULT-II is detected when TCM cannot communicate to other control unit.

DTC Confirmation Procedure

Note. If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 360

1. Turn ignition switch to ON position. (Do not start engine.)
2. Select DATA MONITOR mode for ENGINE with CONSULT-II.
3. Start engine and wait for at least 6 seconds.
4. If DTC is detected, go to «DIAGNOSTIC PROCEDURE»(ref-206576-S05123149342005112500000) .

Diagnostic trouble code BATT/FLUID TEMP SEN with CONSULT-II or 8th judgement flicker without CONSULT-II is detected when TCM receives an excessively low or high voltage from the sensor.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 361

Scheme 362

1. Start engine.
2. Select DATA MONITOR mode for A/T with CONSULT-II.
3. Drive vehicle under the following conditions: Selector lever in D, vehicle speed higher than 20 km/h (12 MPH).

Scheme 363

1. Start engine.
2. Drive vehicle under the following conditions: Selector lever in D, vehicle speed higher than 20 km/h (12 MPH).
3. Perform self-diagnosis. Refer to «TCM SELF-DIAGNOSTIC PROCEDURE (NO TOOLS)»(ref-206576-S39240413392005112500000) .

Diagnostic trouble code VHCL SPEED SEN. MTR with CONSULT-II or 2nd judgement flicker without CONSULT-II is detected when TCM does not receive the proper voltage signal from the sensor.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 364

Scheme 365

1. Turn ignition switch ON and select DATA MONITOR mode for A/T with CONSULT-II.
2. Start engine and accelerate vehicle from 0 to 25 km/h (0 to 16 MPH).

Scheme 366

1. Start engine.
2. Drive vehicle under the following conditions: Selector lever in D and vehicle speed higher than 25 km/h (16 MPH).
3. Perform self-diagnosis. Refer to «TCM SELF-DIAGNOSTIC PROCEDURE (NO TOOLS)»(ref-206576-S39240413392005112500000) .

After the repair, perform the following procedure to confirm the malfunction is eliminated.

With CONSULT-II

Scheme 367

1. Start engine.
2. Select DATA MONITOR mode for A/T with CONSULT-II.
3. Drive vehicle under the following conditions: Selector lever in D, vehicle speed higher than 40 km/h (25 MPH), engine speed higher than 1,500 RPM, throttle opening greater than 1.0/8 of the full throttle position and driving for more than 5 seconds.

Without CONSULT-II

Scheme 368

Scheme 369

1. Start engine.
2. Drive vehicle under the following conditions: Selector lever in D and vehicle speed higher than 40 km/h (25 MPH), engine speed higher than 1,500 RPM, throttle opening greater than 1/8 of the full throttle position and driving for more than 5 seconds.
3. Perform self-diagnosis. Refer to «TCM SELF-DIAGNOSTIC PROCEDURE (NO TOOLS)»(ref-206576-S39240413392005112500000)

Diagnostic trouble code CONTROL UNIT (RAM), CONTROL UNIT (ROM) with CONSULT-II is detected when TCM memory (RAM) or (ROM).

Note. If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at least 10 seconds before conducting the next test.

Scheme 370

Scheme 371

1. Turn ignition switch ON and select DATA MONITOR mode for A/T with CONSULT-II.
2. Start engine.
3. Run engine for at least 2 seconds at idle speed.

1. INSPECTION START WITH CONSULT-II Turn ignition switch ON and select SELF DIAGNOSIS mode for A/T with CONSULT-II. Touch ERASE. Perform Diagnostic Trouble Code (DTC) Confirmation Procedure. Is the CONTROL UNIT (RAM) or CONTROL UNIT (ROM) displayed again? Yes or No Yes: Replace TCM. No: INSPECTION END

Note. If DIAGNOSTIC TROUBLE CODE CONFIRMATION PROCEDURE has been previously conducted, always turn ignition switch OFF and wait at least 5 seconds before conducting the next test.

With CONSULT-II

Scheme 372

Scheme 373

1. Turn ignition switch ON and select DATA MONITOR mode for A/T with CONSULT-II.
2. Start engine.
3. Run engine for at least 2 seconds at idle speed.

1. CHECK DTC WITH CONSULT-II Turn ignition switch ON and select SELF DIAGNOSIS mode for A/T with CONSULT-II. Move selector lever to R position. Depress accelerator pedal (Full throttle position). Touch ERASE. Turn ignition switch OFF position for 10 seconds. Perform DIAGNOSTIC TROUBLE CODE (DTC) CONFIRMATION PROCEDURE. Is the CONT UNIT (EEPROM) displayed again? Yes: Replace TCM. No: INSPECTION END

21. TCM Self-diagnosis Does Not Activate (PNP & 3 Position Switches Circuit Checks), and Throttle Position Sensor [Accelerator Pedal Position (APP) Sensor] Circuit Check

SYMPTOM

A/T check (position) indicator lamp does not come on in TCM self-diagnostic procedure even if the lamp circuit is good.

Scheme 374

Scheme 375

Scheme 376

Note. The diagnostic procedure includes inspection for the 3 position switch circuit.

Scheme 377

Scheme 378

Scheme 379

Scheme 380

Scheme 381

Scheme 382

Scheme 383

Scheme 384

Scheme 385

1. CHECK PARK/NEUTRAL POSITION (PNP) SWITCH CIRCUIT (WITH CONSULT-II) With CONSULT-II Turn ignition switch to ON position. (Do not start engine.) Select TCM INPUT SIGNALS in DATA MONITOR mode for A/T with CONSULT-II. Read out P/N, R, D, 2 and 1 position switches moving selector lever to each position. Check that the signal of the selector lever position is indicated properly. OK or NG OK: GO TO 5 . NG: GO TO 2.
2. DETECT MALFUNCTIONING ITEM Check the following items: Park/neutral position (PNP) switch Check continuity between park/neutral position (PNP) switch F29 terminals 1 (G/R) and 2 (B) and between terminals 3 (G/Y) and 4 (PU/W), 5 (P/B), 6 (G), 7 (BR), 8 (G/W) and 9 (GY/R) while moving manual shaft through each position. If NG, check again with manual control cable disconnected from manual shaft of A/T assembly. Refer to «CONTROL CABLE ADJUSTMENT»(ref-206576-S16824758802005112500000) step a. If OK on step b, adjust manual control cable. Refer to «CONTROL CABLE ADJUSTMENT»(ref-206576-S16824758802005112500000) . If NG on step b, remove park/neutral position (PNP) switch from A/T and check continuity of park/neutral position (PNP) switch terminals. Refer to step a. See «PARK/NEUTRAL POSITION (PNP) SWITCH ADJUSTMENT»(ref-206576-S35411648552005112500000) . If OK on step d, adjust park/neutral position (PNP) switch. Refer to «PARK/NEUTRAL POSITION (PNP) SWITCH ADJUSTMENT»(ref-206576-S35411648552005112500000) . If NG on step d, replace park/neutral position (PNP) switch. Harness for short or open between ignition switch and park/neutral position (PNP) switch (Main harness) Harness for short or open between park/neutral position (PNP) switch and TCM (Main harness) OK or NG OK: GO TO 5 . NG: Repair or replace damaged parts.
3. CHECK PARK/NEUTRAL POSITION (PNP) SWITCH CIRCUIT (WITHOUT CONSULT-II) Without CONSULT-II Turn ignition switch to ON position. (Do not start engine.) Check voltage between TCM terminals 26 (PU/W), 27 (P/B), 34 (G), 35 (G/W), 36 (R/B) and ground while moving selector lever through each position. Voltage: B: Battery voltage 0: 0V OK or NG OK: GO TO 6 . NG: GO TO 4.
4. DETECT MALFUNCTIONING ITEM Check the following items: Park/neutral position (PNP) switch Check continuity between park/neutral position (PNP) switch F29 terminals 1 (G/R) and 2 (B) and between terminals 3 (G/Y) and 4 (PU/W), 5 (P/B), 6 (G), 7 (BR), 8 (G/W) and 9 (GY/R) while moving manual shaft through each position. If NG, check again with manual control cable disconnected from manual shaft of A/T assembly. Refer to step a. If OK on step b, adjust manual control cable. If NG on step b, remove park/neutral position (PNP) switch from A/T and check continuity of park/neutral position (PNP) switch terminals. Refer to step a. If OK on step d, adjust park/neutral position (PNP) switch. Refer «PARK/NEUTRAL POSITION (PNP) SWITCH ADJUSTMENT»(ref-206576-S35411648552005112500000) . If NG on step d, replace park/neutral position (PNP) switch. Harness for short or open between ignition switch and park/neutral position (PNP) switch (Main harness) Harness for short or open between park/neutral position (PNP) switch and TCM (Main harness) OK or NG OK: GO TO 7 . NG: Repair or replace damaged parts.
5. CHECK 3 POSITION SWITCH CIRCUIT (WITH CONSULT-II) : With CONSULT-II Turn ignition switch to ON position. (Do not start engine.) Select TCM INPUT SIGNALS in DATA MONITOR mode for A/T with CONSULT-II. Read out OVERDRIVE SW. Check the signal of the 3 position switch is indicated properly. (Overdrive switch ON displayed on CONSULT-II means overdrive OFF.) OK or NG OK: GO TO 7 . NG: GO TO 6.
6. DETECT MALFUNCTIONING ITEM Check the following items: 3 position switch M34. Check for continuity between terminals 1 (L/W) and 2 (B) with selector lever in 3 position. Harness for short or open between meter and 3 position switch (Main harness) Harness of ground circuit for 3 position switch (Main harness) for short or open OK or NG OK: GO TO 7. NG: Repair or replace damaged parts.
7. CHECK THROTTLE POSITION SENSOR [ACCELERATOR PEDAL POSITION (APP) SENSOR] Perform throttle position sensor [accelerator pedal position (APP) sensor] inspection. Refer to «DTC P1705 THROTTLE POSITION SENSOR [ACCELERATOR PEDAL POSITION (APP) SENSOR]»(ref-206576-S10484696542005112500000) . OK or NG OK: GO TO 8. NG: Repair or replace damaged parts.
8. CHECK TCM INSPECTION Perform TCM input/output inspection. Refer to «TCM INSPECTION TABLE»(ref-206576-S40256473462005112500000) OK or NG OK: INSPECTION END NG: Inspect TCM terminals and related wiring harnesses for damage or loose connections. Repair or replace damaged parts.

SHIFT LOCK CONTROL UNIT INSPECTION TABLE

Data are reference values.

Scheme 386

Scheme 387

Scheme 388

1. Check operation by applying battery voltage to A/T device connector. CAUTION: Be sure to apply the voltage of the correct polarity to the respective terminals. Otherwise, the part may be damaged.

Scheme 389

Scheme 390

1. Check continuity between terminals of the A/T device connector.

Scheme 391

Scheme 392

1. Check operation by applying battery voltage to key switch and key lock solenoid connector. CAUTION: Be careful not to cause burnout of the harness.

Scheme 393

Scheme 394

1. Check operation by applying battery voltage to key switch and key lock solenoid connector. CAUTION: Be careful not to cause burnout of the harness.

Scheme 395

Scheme 396

1. Check continuity between terminals of the key switch and key lock solenoid connector.

Scheme 397

Scheme 398

1. Check continuity between terminals of the stop lamp switch connector. Check stop lamp switch after adjusting brake pedal. Refer to «ADJUSTMENTS»(ref-138833-S41653648972002042400000) in BRAKE article .

Scheme 399

Scheme 400

Scheme 401

Scheme 402

Scheme 403

Scheme 404

Scheme 405

1. Drain ATF from transaxle.
2. Remove oil pan using power tools, and gasket. Do not reuse oil pan bolts.
3. Disconnect terminal cord assembly harness connector.
4. Remove stopper ring from terminal cord assembly harness terminal body.
5. Remove terminal cord assembly harness from transmission case by pushing on terminal body.
6. Remove control valve assembly by removing fixing bolts. Bolt length, number and location are shown in the illustration. Be careful not to drop manual valve and servo release accumulator return spring .
7. Disassemble and inspect control valve assembly if necessary. Refer to «CONTROL VALVE ASSEMBLY»(ref-206576-S35941667882005112500000) .
8. Remove servo release and N-D accumulators by applying compressed air if necessary. Hold each piston with a rag .

Scheme 406

1. Set manual shaft in Neutral, then align manual plate with groove in manual valve.
2. After installing control valve assembly, make sure that selector lever can be moved to all positions.

Scheme 407

1. Disconnect electrical connector.
2. Remove revolution sensor from A/T.
3. Reinstall any part removed. Always use new sealing parts .

Scheme 408

1. Disconnect electrical connector.
2. Remove bolt, and turbine revolution sensor from A/T.
3. Reinstall any part removed. Always use new sealing parts.

Scheme 409

Scheme 410

1. Remove control cable from manual shaft.
2. Set manual shaft in N position.
3. Loosen park/neutral position (PNP) switch fixing bolts.
4. Insert pin into adjustment holes in both park/neutral position (PNP) switch and manual shaft as near vertical as possible.
5. Reinstall any part removed.
6. Check continuity of park/neutral position (PNP) switch. Refer to «DIAGNOSTIC PROCEDURE»(ref-206576-S24575026692005112500000) .

INSPECTION

1. Check component parts for wear or damage. Replace if necessary.

Scheme 411

Scheme 412

Scheme 413

Scheme 414

Scheme 415

Scheme 416

1. Install manual shaft oil seal. Apply ATF to outer surface of oil seal.
2. Install manual shaft and manual plate.
3. Align groove of manual shaft and hole of transmission case.
4. Install manual shaft retaining pin up to bottom of hole.
5. Install parking rod to parking rod plate.
6. Set parking rod assembly onto manual shaft and drive retaining pin. Both ends of pin should protrude.
7. Drive manual plate retaining pin. Both ends of pin should protrude.
8. Install detent spring. Tighten detent spring bolts to the specified torque. Refer to «COMPONENTS»(ref-206576-S10300102012005112500000) .

Scheme 417

Scheme 418

Scheme 419

Scheme 420

Scheme 421

Scheme 422

1. Remove seal rings.
2. Loosen bolts in a crisscross pattern and remove oil pump cover.
3. Remove inner and outer gear from oil pump housing.
4. Remove O-ring from oil pump housing.
5. Remove oil pump housing oil seal.
