HOW TO INITIATE THE SERVICE MODE

Refer to HOW TO INITIATE THE SERVICE MODE .

HOW TO TERMINATE THE SERVICE MODE

Refer to HOW TO TERMINATE THE SERVICE MODE .

Note. While the hands free module is in diagnosis mode, connection with the Bluetooth® device is shut down. While the hands free module is in diagnosis mode, the sound input to the microphone unit is output directly through the speaker.

Scheme 772

Scheme 773

1. Select "hands free module" on "Service" screen.
2. "Hands Free Module" screen is displayed.

DISPLAY BUTTON AND FUNCTION

DISPLAY BUTTON AND FUNCTION CHART

SOFTWARE UPDATE (S/W Update)

The software of the hands free module can be updated.

Note. "S/W Update" is displayed when an USB that contains files to update the hands free module is connected. When the software update cannot continue because of improper removal of the USB during the update or of an incorrect update code, the display returns to the "Hands Free Module" screen. At this time, warning is not displayed.

Scheme 774

Scheme 775

Scheme 776

Scheme 777

Scheme 778

Scheme 779

1. Press "S/W Update."
2. Select "Yes." (When "No" is selected, the display returns to the "Hands Free Module" screen.)
3. Input the 4-digit code for update. ("Enter" is displayed in gray until the 4-digit code is input.)
4. Update starts if the 4-digit code is normal. NOTE: When the input code is normal, the speaker will not output the sound input to the microphone unit until the display returns to the "Hands Free Module" screen. When the data rewriting operation is failed, the error screen is displayed.
5. The "Reboot" screen is displayed when the update is completed successfully.
6. After the hands free module is rebooted, the "Update successfully." screen is displayed. When "OK" is selected, the display returns to the "Hands Free Module" screen.

ERROR CODE

The error code is displayed to show the internal state of the module.

Note. This code shows the internal state of the hands free module. Do not determine that the module is defective even when an error code is displayed. Be sure to diagnose the module before replacing it.

Scheme 780

1. Press "Error Code." NOTE: "Error Code" is displayed when the "HFM Self Check" is "NG."
2. When "Back" is selected, the display returns to the "Hands Free Module" screen.

UNLOCK

Forcibly unlocks the 4-digit passcode that was set by the security function.

Note. When the module is not locked by passcode, the "Unlock" button is displayed in gray.

Scheme 781

Scheme 782

1. Press "Unlock." NOTE: "Error Code" is displayed when the "HFM Self Check" is "NG."
2. When "Yes" is selected, "Lock mode canceled" will be displayed and the passcode lock will be unlocked. NOTE: When "No" is selected, the display returns to the "Hands Free Module" screen.
3. The display returns to the "Hands Free Module" screen after 4 seconds.

PROBABLE CAUSES

1. The hands free module may be defective.
2. The multivision display may be defective.
3. Damaged harness wires and connectors

METHODS FOR PAIRING AND PAIRING DELETION WITH BLUETOOTH® DEVICE USING STEERING WHEEL VOICE CONTROL SWITCH

Note. Some bluetooth® devices (mobile phone or music player) may not be compatible with the hands free module. A maximum of seven bluetooth® devices can be registered. This system can not be used when a battery of bluetooth® devices was exhausted.

Scheme 783

1. Shift the shift lever to N (neutral) position and pull the parking brake lever.
2. Turn the ignition switch to "ACC" or "ON" position.
3. Press the "Speech" switch.
4. Say "Setup."
5. Say "Pairing options."
6. The voice guide will say "Select one of the following: pair, edit, delete, or list?"
7. Say "Pair."
8. The voice guide will say "Please say a 4-digit pairing code."
9. Say a 4 digit number. The 4 digit number will be registered as a pairing code for the device. When the confirmation function is on, the system will confirm whether the number said is acceptable. Answer "Yes" to go Step 10. Say "No" to return to pairing code selection. NOTE: The pairing code entered here is only used for the Bluetooth® connection certification. It is any 4-digit number the user would like to select. Remember the pairing code as it needs to be keyed into the device later in the pairing process. Depending on the connection settings of the bluetooth® device, this code may have to be entered each time you connect the bluetooth® device to the hands free module. For the default connection settings, refer to the instructions for the device.
10. The voice guide will say "Start pairing procedure on device. See pairing device owner's manual for instructions." Refer to the owner's manual for your device and enter into the device the pairing code that was registered in Step 9 .
11. When this system finds a Bluetooth® device, the voice guide will say "Please say the name of the device after the beep."
12. After you hear the beep, name the device by saying a name of your preference. NOTE: When the confirmation function is on, after repeating the device tag you have said, the voice guide will ask "Is this correct?" Answer "Yes". To change the device tag, answer "No" and then say the device tag again.
13. The voice guide will say "Pairing complete," after which a beep will be played and the pairing process will end.

DELETING A DEVICE

1. Turn the ignition switch to "ACC" or "ON" position.
2. Press the Speech switch.
3. Say "Setup."
4. Say "Pairing options"
5. The voice guide will say "Select one of the following: pair, edit, delete, or list".
6. Say "Delete."
7. After the voice guide says "Please say," the numbers of the devices and device tags of corresponding devices will be read out in order, starting with the device that has been most recently connected. After it completes reading all pairs, the voice guide will say "or all." Say the number of the device that you want to delete from the system. If you want to delete all paired devices from the system, say "All."
8. For confirmation purposes, the voice guide will say "Deleting (device tag) (number). Is this correct?" or "Deleting all devices, Is this correct?"
9. Answer "Yes" to delete the devices. Answer "No" the system will return to Step 4 .
10. The voice guide will say "Deleted", and then the system will end the device deletion process. If the device deletion process fails for some reason, the voice guide will say "Delete failed." and then the system will cancel deleting the device.

METHODS FOR PAIRING AND PAIRING DELETION WITH BLUETOOTH® DEVICE USING MULTIVISION DISPLAY

As for vehicles with MMCS, "pairing" registration of the Bluetooth® device and deletion of paired device from hands free module can be done by touch panel operation on the multivision display.

Note. Some Bluetooth® devices (cellular phone and music player) may not be compatible with the hands free module. A maximum of seven Bluetooth® devices can be registered. This system cannot be used when a battery of Bluetooth® devices was exhausted.

Scheme 784

Scheme 785

Scheme 786

Scheme 787

Scheme 788

1. When press the (1) in the illustration.
2. Display the INFOR screen, and select "Mobile Phone."
3. Select "1" in the illustration on the Mobile Phone screen.
4. Select "Pairing."
5. The pairing list screen is displayed.

Scheme 789

Scheme 790

Scheme 791

Scheme 792

1. Press the (1) in the illustration.
2. Display the A/V mode screen, and select "Bluetooth Audio." NOTE: When there are no active connections between the Bluetooth® Audio and the hands free module, "There are no active connections." is displayed.
3. Select "1" in the illustration on the Bluetooth Audio screen.
4. Select "Pairing."
5. The pairing list screen is displayed.

Scheme 793

Scheme 794

1. Shift the selector lever to P (parking) position < CVT > or shift lever to N (neutral) position < M/T or TC-SST > and pull the parking brake lever.
2. Display the pairing list screen, and select "New Device." NOTE: When the vehicle is being driven, or when the vehicle is driven during the pairing operation, "This function is disabled while driving." is displayed for 4 seconds, and the display returns to the pairing list screen.
3. Enter the 4-digit code on the Pin code screen, and select "Enter."
4. "Begin Pairing procedure on device. See device's owner's manual for instructions." is displayed on the screen.
5. Refer to the owner's manual for your device and enter into the device the pin code. NOTE: When "Cancel" is selected or the pairing is failed, the display returns to the pairing list screen.
6. When the pairing is completed, the display returns to the pairing list screen. NOTE: When 7 Bluetooth® devices are already paired to the hands free module, "Maximum device paired. Please delete a paired device before pairing a new device." is displayed.

Scheme 795

Scheme 796

Scheme 797

1. Display the pairing list screen, and select the "Bluetooth® device" to be deleted.
2. Select "Delete."
3. When "Yes" is selected, the Bluetooth® device is deleted and the display returns to the pairing list screen.

ERASE THE PASSWORD

The 4-digit password set by security function can be erased by the diagnosis mode. Perform the "UNLOCK" operation of the diagnosis mode. (Refer to DIAGNOSIS MODE < VEHICLES WITH RADIO AND CD PLAYER > < Vehicles with radio and CD player >, DIAGNOSIS MODE < VEHICLES WITH MMCS > < Vehicles with MMCS >.)

Scheme 798

Removal Steps

1. USB cable
2. Hands free module

Scheme 799

Removal steps

1. Front dome light assembly (Refer to «DOME LIGHT - LANCER EVOLUTION»(ref-592668) .)

>> A <<

1. Microphone unit

STEERING WHEEL VOICE-CONTROL SWITCH CONTINUITY CHECK

Use an ohmmeter to measure the resistance value between the terminal.

TERMINALS RESISTANCE VALUE CHART

Scheme 800

ILLUMINATION CHECK

Apply battery voltage of steering wheel voice control switch connector terminal No. 4 and 1, and check if the steering wheel audio remote control switch illuminates.

Note. Make sure that the polarity is correct.

Scheme 801

Scheme 802

1. Remove the USB adapter. (Refer to «USB ADAPTER REMOVAL AND INSTALLATION»(ref-592655-S30062472282014011000000) )
2. Check that the continuity exists between the front side terminals of USB adapter and rear side terminals of USB adapter. TERMINALS CONTINUITY REFERENCE CHART Front side terminal Rear side terminal Measurement value 1 1 Continuity exists (2 ohms or less) 2 2 3 3 4 4
