STANDARD FLOW OF DIAGNOSTIC TROUBLESHOOTING

Refer to TROUBLESHOOTING CONTENTS .

HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)

Required Special Tools

1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system) CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958.

Scheme 739

1. Ensure that the ignition switch is at the "LOCK" (OFF) position.
2. Start up the personal computer.
3. Connect special tool MB991827 to special tool MB991824 and the personal computer.
4. Connect special tool MB991910 to special tool MB991824.
5. Connect special tool MB991910 to the data link connector.
6. Turn the power switch of special tool MB991824 to the "ON" position. NOTE: When special tool MB991824 is energized, special tool MB991824 indicator light will be illuminated in a green color.
7. Start the M.U.T.-III system on the personal computer. NOTE: Disconnecting scan tool MB991958 is the reverse of the connecting sequence, making sure that the ignition switch is at the "LOCK" (OFF) position.

DIAGNOSIS MODE < VEHICLES WITH RADIO AND CD PLAYER >

Enter the diagnosis mode according to the following steps

Scheme 740

1. Turn the Ignition switch to the "ACC" or "ON" position and switch off the radio and CD player.
2. Press the following buttons in that order within sixty seconds from step (1). [CH1] button. Rewind button. Fast-forward button. [CH4] button. NOTE: When the "Power" button of the radio and CD player is pressed during the diagnosis mode, the diagnosis mode will be cancelled, thus switching off the radio and CD player. However, if the "Power" button is pressed while the hands free module is being updated, the update will not be cancelled. When the "Mode change" button (FM/AM, CD) is pressed during diagnosis mode except the hands free module update, the diagnosis mode will be cancelled and relevant operation will be carried out. When an invalid button is pressed during diagnosis mode except the hands free module update, the diagnosis mode will be cancelled, thus switching off the radio and CD player. During the diagnosis mode, voice which is input through the microphone unit is played through a relevant loudspeaker.
3. "HFM DIAG" is displayed.

Scheme 741

RADIO AND CD PLAYER REFERENCE CHART

DIAGNOSIS MODE < VEHICLES WITH MMCS >

As a diagnosis mode for the hands free module, version information of the hands free module and diagnostic results of the hands free module and the microphone unit can be displayed by the service mode of the multivision display.

TROUBLE SYMPTOM CHART

Note. Some Bluetooth® devices may not be compatible with the hands free module

TROUBLE SYMPTOM CHART

Inspection Procedure 1: Check The Hands Free Module Power Supply Circuit

Scheme 742

Scheme 743

Scheme 744

Scheme 745

TROUBLESHOOTING HINTS

1. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector
2. The hands free module may be defective
3. The radio and CD player may be defective. < Vehicles with radio and CD player >
4. The multivision display may be defective. < Vehicles with MMCS >

DIAGNOSIS

Required Special Tools

1. MB991223: Harness Set
2. MB992006: Extra Fine Probe

Scheme 746

Scheme 747

Scheme 748

1. STEP 1. Check hands free module connector C-11 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: IS hands free module connector C-11 in good condition? YES: Go to Step 2. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-592584-S02750277482014011000000) .
2. STEP 2. Check the ground circuit to the hands free module. Measure the resistance at hands free module connector C-11. Disconnect hands free module connector C-11, and measure at the wiring harness side. Measure resistance between terminal 17 and ground. OK: The resistance should be 2 ohms or less. Q: Is the measured resistance 2 ohms or less? YES: Go to Step 4 . NO: Go to Step 3.
3. STEP 3. Check the wiring harness between hands free module connector C-11 (terminal 17) and ground. Check the body ground wires for open circuit. Q: Is the wiring harness between hands free module connector C-11 (terminal 17) and ground in good condition? YES: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(ref-592586-S21436341472014011000000) ). NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary.
4. STEP 4. Check the power supply circuit to the hands free module. Measure the voltage at hands free module connector C-11. Disconnect hands free module connector C-11, and measure the voltage available at the wiring harness side of the connector. Measure the voltage between terminal 1 and ground. OK: The voltage should measure approximately 12 volts (battery positive voltage). Q: Is the measured voltage approximately 12 volts (battery positive voltage)? YES: Go to Step 6 . NO: Go to Step 5.
5. STEP 5. Check the wiring harness between hands free module connector C-11 (terminal 1) and fusible link (36). Check the power supply line for open circuit and short circuit. NOTE: Also check ETACS-ECU connector C-307, C-317 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If ETACS-ECU connector C-307, C-317 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(ref-592584-S02750277482014011000000) . Q: Is the wiring harness between hands free module connector C-11 (terminal 1) and fusible link (36) in good condition? YES: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(ref-592586-S21436341472014011000000) ). NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary.
6. STEP 6. Check the power supply circuit to the hands free module. Measure the voltage at hands free module connector C-11. Disconnect hands free module connector C-11, and measure the voltage available at the wiring harness side of the connector. Turn the ignition switch to "ACC" position. Measure the voltage between terminal 15 and ground. OK: 1 voltage or less. Q: Is the measured voltage approximately 12 volts (battery positive voltage)? YES: Replace the hands free module. NO: Go to Step 7.
7. STEP 7. Check radio and CD player connector C-109 < Vehicles with radio and CD player > or multivision display connector C-09 < Vehicles with MMCS > for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is radio and CD player connector C-109 < Vehicles with radio and CD player > or multivision display connector C-09 < Vehicles with MMCS > in good condition? YES: Go to Step 8. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-592584-S02750277482014011000000) .
8. STEP 8. Check the wiring harness between hands free module connector C-11 terminal (terminal 15) and radio and CD player connector C-109 terminal (terminal 17) < vehicles with radio and CD player > or multivision display connector C-09 terminal (terminal 72) < vehicles with MMCS >. Check the signal line for open circuit and short circuit. NOTE: Also check intermediate connector C-110 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector C-110 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(ref-592584-S02750277482014011000000) . < Vehicles with MMCS > Q: Is the check result normal? YES: Replace the radio and CD player or multivision display NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary.

Inspection Procedure 2: The USB Adapter Data Cannot Be Replayed < Vehicles With Radio And CD Player >

Scheme 749

Scheme 750

1. The radio and CD player may be defective.
2. The hands free module may be defective.
3. The USB adapter may be defective.
4. The USB cable may be defective.
5. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector

Required Special Tools

1. MB991223: Harness Set
2. MB992006: Extra Fine Probe

1. STEP 1. Check the radio and CD player operation. Check if the radio and CD player work normally and the sound is output. Q: Is the check result normal? YES: Go to Step 2. NO: Troubleshoot the radio and CD player (Refer to «RADIO AND CD PLAYER - LANCER EVOLUTION»(ref-592601) ).
2. STEP 2. Check the diagnosis mode Check if the hands free module can be switched to the diagnosis mode. (Refer to «DIAGNOSIS MODE < VEHICLES WITH RADIO AND CD PLAYER >»(ref-592655-S40668600972014011000000) .) Q: Is the check result normal? YES: Go to Step 3. NO: Perform Inspection Procedure 5 "DIAGNOSIS MODE cannot be made an entry." (Refer to «INSPECTION PROCEDURE 5: DIAGNOSIS MODE CANNOT BE MADE AN ENTRY. < VEHICLES WITH RADIO AND CD PLAYER >»(ref-592655-S22277711072014011000000) .)
3. STEP 3. Check the USB adapter. Check that the continuity exists between the front side terminals of USB adapter and rear side terminals of USB adapter. (Refer to «USB ADAPTER INSPECTION»(ref-592655-S32501523312014011000000) ) Q: Is the check result normal? YES: Go to Step 4. NO: Replace the USB adapter.
4. STEP 4. Check the USB cable. Check that the USB cable is connected to the USB adapter or hands free module normally. Or check the USB cable for damage such as bend. Q: Is the check result normal? YES: Go to Step 5. NO: Replace or repair the USB cable.
5. STEP 5. Check hands free module connector C-11 and radio and CD player C-109 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Are hands free module connector C-11 and radio and CD player C-109 in good condition? YES: Go to Step 6. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-592584-S02750277482014011000000) .
6. STEP 6. Check the wiring harness between hands free module connector C-11 (terminal 22, 8) and radio and CD player connector C-109 (terminal 3, 12). Check the signal lines for open circuit and short circuit. Q: Is the wiring harness between hands free module connector C-11 (terminal 22, 8) and radio and CD player C-109 (terminal 3, 12) in good condition? YES: Go to Step 7. NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary.
7. STEP 7. Replace the hands free module temporarily, and check the trouble symptom. Replace the hands free module temporarily, and check that the sound is output from the speaker. Q: Is the check result normal? YES: Replace the hands free module. NO: Replace the radio and CD player.

Inspection Procedure 2: The USB Adapter Data Cannot Be Replayed < Vehicles With MMCS >

Scheme 751

Scheme 752

1. The multivision display may be defective.
2. The hands free module may be defective.
3. The USB adapter may be defective.
4. The USB cable may be defective.
5. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector

Required Special Tools

1. MB991223: Harness Set
2. MB992006: Extra Fine Probe

1. STEP 1. Check the multivision display operation. Check if the multivision display work normally and the sound is output. Q: Is the check result normal? YES: Go to Step 2. NO: Troubleshoot the MMCS (Refer to «TROUBLE SYMPTOM CHART»(ref-592603-S42769495692014011000000) ).
2. STEP 2. Check the multivision display operation. Display the INFOR screen, and check that the "Mobile Phone" item is displayed. Q: Is the check result normal? YES: Go to Step 3. NO: Perform Inspection Procedure 6: "DIAGNOSIS MODE cannot be made an entry. Mobile Phone item is not displayed on the INFOR screen of MMCS." (Refer to «INSPECTION PROCEDURE 6: DIAGNOSIS MODE CANNOT BE MADE AN ENTRY. MOBILE PHONE ITEM IS NOT DISPLAYED ON THE INFOR SCREEN OF MMCS. < VEHICLES WITH MMCS >»(ref-592655-S02162925672014011000000) .)
3. STEP 3. Check the USB adapter. Check that the continuity exists between the front side terminals of USB adapter and rear side terminals of USB adapter. (Refer to «USB ADAPTER INSPECTION»(ref-592655-S32501523312014011000000) ) Q: Is the check result normal? YES: Go to Step 4. NO: Replace the USB adapter.
4. STEP 4. Check the USB cable. Check that the USB cable is connected to the USB adapter or hands free module normally. Or check the USB cable for damage such as bend. Q: Is the check result normal? YES: Go to Step 5. NO: Replace or repair the USB cable.
5. STEP 5. Check hands free module connector C-11 and multivision display C-10 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Are hands free module connector C-11 and multivision display connector C-10 in good condition? YES: Go to Step 6. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-592584-S02750277482014011000000) .
6. STEP 6. Check the wiring harness between hands free module connector C-11 (terminal 22, 8) and multivision display connector C-10 (terminal 35, 51). Check the signal lines for open circuit and short circuit. NOTE: Also check intermediate connector C-110 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector C-110 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(ref-592584-S02750277482014011000000) . Q: Is the wiring harness between hands free module connector C-11 (terminal 22, 8) and multivision display connector C-10 (terminal 35, 51) in good condition? YES: Go to Step 7. NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary.
7. STEP 7. Replace the hands free module temporarily, and check the trouble symptom. Replace the hands free module temporarily, and check that the sound is output from the speaker. Q: Is the check result normal? YES: Replace the hands free module. NO: Replace the multivision display.

Inspection Procedure 3: When The Speech Switch Is Pressed, The Voice Information Is Output, But The Voice Recognition Is Not Performed

Scheme 753

Scheme 754

1. The hands free module may be defective.
2. The microphone unit may be defective.
3. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector

Required Special Tools

1. MB991223: Harness Set
2. MB992006: Extra Fine Probe

1. STEP 1. Check the diagnosis mode Check if the microphone check result "MIC OK" is displayed on the diagnosis mode of hands free module. (Refer to «DIAGNOSIS MODE < VEHICLES WITH RADIO AND CD PLAYER >»(ref-592655-S40668600972014011000000) .) < Vehicles with radio and CD player > Display the "Hands Free Module" screen on the diagnosis mode of hands free module and check if the items of "HFM Self Check" and "HFM MIC Check" are shown "OK." (Refer to «DIAGNOSIS MODE < VEHICLES WITH MMCS >»(ref-592655-S06563619622014011000000) .) < Vehicles with MMCS > Q: Is the check result normal? YES: Go to Step 4 . NO: Go to Step 2.
2. STEP 2. Check hands free module connector C-11 and microphone unit D-04 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Are hands free module connector C-11 and microphone unit connector D-04 in good condition? YES: Go to Step 3. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-592584-S02750277482014011000000) .
3. STEP 3. Check the wiring harness between hands free module connector C-11 (terminal 14, 28) and microphone unit connector D-04 (terminal 2, 1). Check the signal lines for open circuit and short circuit. NOTE: Also check intermediate connector C-133 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector C-133 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(ref-592584-S02750277482014011000000) . Q: Is the wiring harness between hands free module connector C-11 (terminal 14, 28) and microphone unit connector D-04 (terminal 2, 1) in good condition? YES: Go to Step 4. NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary.
4. STEP 4. Replace the microphone unit temporarily, and check the trouble symptom. Q: Is the check result normal? YES: Replace the microphone unit. NO: Go to Step 5.
5. STEP 5. Replace the hands free module temporarily, and check the trouble symptom. Q: Is the check result normal? YES: Replace the hands free module. NO: The trouble can be an intermittent malfunction (Refer to «HOW TO USE TROUBLESHOOTING/INSPECTION SERVICE POINTS»(ref-592586-S39671804762014011000000) ).

Inspection Procedure 4: When The Speech Switch Is Pressed, The Voice Information Is Not Output < Vehicles With Radio And CD Player >

Scheme 755

Scheme 756

1. The radio and CD player may be defective.
2. The steering wheel audio remote control switch may be defective.
3. The steering wheel voice control switch may be defective.
4. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector

Required Special Tools

1. MB991223: Harness Set
2. MB992006: Extra Fine Probe

1. STEP 1. Check the diagnosis mode Check if the hands free module can be switched to the diagnosis mode. (Refer to «DIAGNOSIS MODE < VEHICLES WITH RADIO AND CD PLAYER >»(ref-592655-S40668600972014011000000) .) Q: Is the check result normal? YES: Go to Step 2. NO: Perform Inspection Procedure 5 "DIAGNOSIS MODE cannot be made an entry." (Refer to «INSPECTION PROCEDURE 5: DIAGNOSIS MODE CANNOT BE MADE AN ENTRY. < VEHICLES WITH RADIO AND CD PLAYER >»(ref-592655-S22277711072014011000000) .)
2. STEP 2. Operation check of the steering wheel audio remote control switch Check that the radio and CD player can be operated by the steering wheel audio remote control switch. Q: Is the check result normal? YES: Go to Step 3. NO: Troubleshoot the steering wheel audio remote control switch. (Refer to «STEERING WHEEL AUDIO REMOTE CONTROL SWITCH - LANCER EVOLUTION»(ref-592656) )
3. STEP 3. Check the steering wheel voice control switch. Check the continuity of the steering wheel voice control switch. (Refer to «STEERING WHEEL VOICE CONTROL SWITCH INSPECTION.»(ref-592655-S42865055782014011000000) ) Q: Is the check result normal? YES: Go to Step 4. NO: Replace the steering wheel voice control switch.
4. STEP 4. Check the steering wheel audio remote control switch. Check the continuity of the steering wheel audio remote control switch. (Refer to «STEERING WHEEL AUDIO REMOTE CONTROL SWITCH INSPECTION»(ref-592655-S42865055782014011000000) .) Q: Is the check result normal? YES: Go to Step 5. NO: Replace the steering wheel audio remote control switch.
5. STEP 5. Check the wiring harness between steering wheel audio remote control switch connector C-213 (terminal 3) and steering wheel voice control switch connector C-206 (terminal 3). Check the communication lines for open circuit and short circuit. Q: Is the wiring harness between steering wheel audio remote control switch connector C-213 (terminal 3) and steering wheel voice control switch connector C-206 (terminal 3) in good condition? YES: Go to Step 6. NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary.
6. STEP 6. Check clock spring connector C-202 for loose, corroded or damaged terminals, or terminals pushed back in the connector Q: Is clock spring connector C-202 in good condition? YES: Go to Step 7. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-592584-S02750277482014011000000) .
7. STEP 7. Check the harness wire between clock spring connector C-202 (terminal 4) and steering wheel voice control switch connector C-206 (terminal 2). Check the communication lines for open circuit and short circuit. Q: Is the wiring harness between clock spring connector C-202 (terminal 4) and steering wheel voice control switch connector C-206 (terminal 2) in good condition? YES: Go to Step 8. NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary.
8. STEP 8. Temporarily replace the steering wheel voice control switch, and check the trouble symptom. Q: Is the check result normal? YES: Replace the steering wheel voice control switch. NO: Replace the radio and CD player.

Inspection Procedure 4: When The Speech Switch Is Pressed, The Voice Information Is Not Output < Vehicles With MMCS >

Scheme 757

Scheme 758

1. The multivision display may be defective.
2. The steering wheel audio remote control switch may be defective.
3. The steering wheel voice control switch may be defective.
4. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector

Required Special Tools

1. MB991223: Harness Set
2. MB992006: Extra Fine Probe

1. STEP 1. Check the multivision display operation. Display the INFOR screen, and check that the "Mobile Phone" item is displayed. Q: Is the check result normal? YES: Go to Step 2. NO: Perform Inspection Procedure 6: "DIAGNOSIS MODE cannot be made an entry. Mobile Phone item is not displayed on the INFOR screen of MMCS." of the troubleshooting (Refer to «INSPECTION PROCEDURE 6: DIAGNOSIS MODE CANNOT BE MADE AN ENTRY. MOBILE PHONE ITEM IS NOT DISPLAYED ON THE INFOR SCREEN OF MMCS. < VEHICLES WITH MMCS >»(ref-592655-S02162925672014011000000) ).
2. STEP 2. Operation check of the steering wheel audio remote control switch Check that the multivision display can be operated by the steering wheel audio remote control switch. Q: Is the check result normal? YES: Go to Step 3. NO: Troubleshoot the steering wheel audio remote control switch. (Refer to «STEERING WHEEL AUDIO REMOTE CONTROL SWITCH - LANCER EVOLUTION»(ref-592656) .)
3. STEP 3. Check the steering wheel voice control switch. Check the continuity of the steering wheel voice control switch. (Refer to «STEERING WHEEL VOICE CONTROL SWITCH INSPECTION.»(ref-592655-S42865055782014011000000) ) Q: Is the check result normal? YES: Go to Step 4. NO: Replace the steering wheel voice control switch.
4. STEP 4. Check the steering wheel audio remote control switch. Check the continuity of the steering wheel audio remote control switch. (Refer to «STEERING WHEEL AUDIO REMOTE CONTROL SWITCH INSPECTION»(ref-592655-S42865055782014011000000) .) Q: Is the check result normal? YES: Go to Step 5. NO: Replace the steering wheel audio remote control switch.
5. STEP 5. Check the wiring harness between steering wheel audio remote control switch connector C-213 (terminal 3) and steering wheel voice control switch connector C-206 (terminal 3). Check the communication lines for open circuit and short circuit. Q: Is the wiring harness between steering wheel audio remote control switch connector C-213 (terminal 3) and steering wheel voice control switch connector C-206 (terminal 3) in good condition? YES: Go to Step 6. NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary.
6. STEP 6. Check clock spring connector C-202 for loose, corroded or damaged terminals, or terminals pushed back in the connector Q: Is clock spring connector C-202 in good condition? YES: Go to Step 7. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-592584-S02750277482014011000000) .
7. STEP 7. Check the harness wire between clock spring connector C-202 (terminal 4) and steering wheel voice control switch connector C-206 (terminal 2). Check the communication lines for open circuit and short circuit. Q: Is the wiring harness between clock spring connector C-202 (terminal 4) and steering wheel voice control switch connector C-206 (terminal 2) in good condition? YES: Go to Step 8. NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary.
8. STEP 8. Temporarily replace the steering wheel voice control switch, and check the trouble symptom. Q: Is the check result normal? YES: Replace the steering wheel voice control switch. NO: Replace the multivision display.

Inspection Procedure 5: DIAGNOSIS MODE Cannot Be Made An Entry < Vehicles With Radio And CD Player >

Scheme 759

1. The hands free module may be defective.
2. The radio and CD player may be defective.
3. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector.

Required Special Tools

1. MB991223: Harness Set
2. MB992006: Extra Fine Probe

1. STEP 1. Check the radio and CD player operation. Check if the radio and CD player work normally and the sound is output. Q: Is the check result normal? YES: Go to Step 2. NO: Troubleshoot the radio and CD player. (Refer to «RADIO AND CD PLAYER - LANCER EVOLUTION»(ref-592601) .)
2. STEP 2. Check hands free module connector C-11 and radio and CD player connector C-109 for loose, corroded or damaged terminals, or terminals pushed back in the connector Q: Are hands free module connector C-11 and radio and CD player connector C-109 in good condition? YES: Go to Step 3. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-592584-S02750277482014011000000) .
3. STEP 3. Check the wiring harness between hands free module connector C-11 (terminal 2, 16) and radio and CD player connector C-109 (terminal 1, 10). Check the signal lines for open circuit and short circuit. Q: Is the wiring harness between hands free module connector C-11 (terminal 2, 16) and radio and CD player connector C-109 (terminal 1, 10) in good condition? YES: Go to step 4. NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary.
4. STEP 4. Check if the power supply circuit of hands free ECU have a problem. Perform the inspection Procedure 1 "Check the hands free module power supply circuit." of the troubleshooting. (Refer to «INSPECTION PROCEDURE 1: CHECK THE HANDS FREE MODULE POWER SUPPLY CIRCUIT.»(ref-592655-S17271141632014011000000) .) Q: Is the check result normal? YES: Go to step 5. NO: Repair according to the troubleshooting for reference.
5. STEP 5. Replace the hands free module temporarily, and check the trouble symptom. Q: Is the check result normal? YES: Replace the hands free module. NO: Replace the radio and CD player.

Inspection Procedure 6: DIAGNOSIS MODE Cannot Be Made An Entry - Mobile Phone Item Is Not Displayed On The INFOR Screen Of MMCS < Vehicles With MMCS >

Scheme 760

Scheme 761

1. The hands free module may be defective.
2. The multivision display may be defective.
3. Damaged harness wires and connectors

Required Special Tools

1. MB991223: Harness Set
2. MB992006: Extra Fine Probe

1. STEP 1. Check the multivision display operation. Check if the multivision display work normally and the sound is output. Q: Is the check result normal? YES: Go to Step 2. NO: Troubleshoot the MMCS. (Refer to «TROUBLE SYMPTOM CHART»(ref-592603-S42769495692014011000000) .)
2. STEP 2. Check hands free module connector C-11 and multivision display connector C-09 for loose, corroded or damaged terminals, or terminals pushed back in the connector Q: Are hands free module connector C-11 and multivision display connector C-09 in good condition? YES: Go to Step 3. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-592584-S02750277482014011000000) .
3. STEP 3. Check the wiring harness between hands free module connector C-11 (terminal 16, 2) and multivision display connector C-09 (terminal 74, 73). Check the signal lines for open circuit and short circuit. NOTE: Also check intermediate connector C-110 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector C-110 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(ref-592584-S02750277482014011000000) . Q: Is the wiring harness between hands free module connector C-11 (terminal 16, 2) and multivision display connector C-09 (terminal 74, 73) in good condition? YES: Go to Step 4. NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary.
4. STEP 4. Check if the power supply circuit of hands free ECU have a problem. Perform the inspection Procedure 1 "Check the hands free module power supply circuit." of the troubleshooting. (Refer to «INSPECTION PROCEDURE 1: CHECK THE HANDS FREE MODULE POWER SUPPLY CIRCUIT.»(ref-592655-S17271141632014011000000) .) Q: Is the check result normal? YES: Go to Step 5. NO: Repair according to the troubleshooting for reference.
5. STEP 5. Replace the hands free module temporarily, and check the trouble symptom. Q: Is the check result normal? YES: Replace the hands free module. NO: Replace the multivision display.

Inspection Procedure 7: Steering Wheel Voice Control Switch Illumination Does Not Come On

Scheme 762

Scheme 763

1. The steering wheel voice control switch may be defective.
2. The combination meter may be defective.
3. The clock spring may be defective.
4. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector

Required Special Tools

1. MB991223: Harness Set
2. MB992006: Extra Fine Probe

1. STEP 1. Check the combination meter. Check whether the illumination of combination meter works normally. Q: Does the combination meter operate normally? YES: Go to Step 2. NO: Diagnose the combination meter. (Refer to «COMBINATION METER - LANCER EVOLUTION»(ref-592598) .)
2. STEP 2. Check steering wheel voice control switch connector C-206 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is steering wheel voice control switch connector C-206 in good condition? YES: Go to Step 3. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-592584-S02750277482014011000000) .
3. STEP 3. Check the wiring harness between steering wheel voice control switch connector C-206 (terminal 1) and ground. Check the ground wire for open circuit. Q: Is the wiring harness between steering wheel voice control switch connector C-206 (terminal 1) and ground in good condition? YES: Go to Step 4. NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary.
4. STEP 4. Check clock spring connectors C-202 and C-205 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Are clock spring connectors C-202 and C-205 in good condition? YES: Go to Step 5. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-592584-S02750277482014011000000) .
5. STEP 5. Check the clock spring. Check whether the clock spring is in good condition (Refer to «DRIVER'S AIR BAG MODULE AND CLOCK SPRING»(ref-592595-S38953360042014011000000) ). Q: Is the check result normal? YES: Go to Step 6. NO: Replace the clock spring.
6. STEP 6. Check the wiring harness between steering wheel voice control switch connector C-206 (terminal 4) and clock spring connector C-202 (terminal 1). Check the power supply lines for open and short circuit. Q: Is the wiring harness between steering wheel voice control switch connector C-206 (terminal 4) and clock spring connector C-202 (terminal 1) in good condition? YES: Go to Step 7. NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary.
7. STEP 7. Check combination meter connector C-04 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is combination meter connector C-04 in good condition? YES: Go to Step 8. NO: Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-592584-S02750277482014011000000) .
8. STEP 8. Check the wiring harness between combination meter connector C-04 (terminal 23) and clock spring connector C-205 (terminal 6). Check the power supply lines for open and short circuit. Q: Is the wiring harness between combination meter connector C-04 (terminal 23) and clock spring connector C-205 (terminal 6) in good condition? YES: Go to Step 9. NO: The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary.
9. STEP 9. Retest the system Check whether the illumination of the steering wheel voice control switch comes on normally. Q: Doe the illumination of the steering wheel voice control switch comes on normally? YES: The trouble can be an intermittent malfunction (Refer to «HOW TO COPE WITH INTERMITTENT MALFUNCTIONS»(ref-592586-S21436341472014011000000) ). NO: Replace the steering wheel voice control switch.

Inspection Procedure 8: Voice Guide "Unable To Obtain Vehicle Speed - Please Try Again Or Contact Your Dealer For Service" Is Sent From The Speaker < Vehicles With Radio And CD Player >

1. The hands free module may be defective.
2. The radio and CD player may be defective.
3. Damaged harness wires and connectors

Required Special Tools

1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)

1. STEP 1. Check the combination meter. Check whether the speed meter works normally. (Refer to «SPEEDOMETER CHECK»(ref-592598-S13268979982014011000000) .) Q: Is the check result normal? YES: Go to Step 2. NO: Diagnose the combination meter (Refer to «COMBINATION METER - LANCER EVOLUTION»(ref-592598) ).
2. STEP 2. Using scan tool MB991958, diagnose the CAN bus line. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(ref-592655-S12263955692014011000000) ." Turn the ignition switch to the "ON" position. Diagnose the CAN bus line. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the CAN bus line found to be normal? YES: Go to Step 3. NO: Repair the CAN bus line (Refer to «CONTROLLER AREA NETWORK (CAN) - LANCER EVOLUTION»(ref-592596) ).
3. STEP 3. Using scan tool MB991958, read the radio and CD player diagnostic trouble code. Check if DTC is set to the radio and CD player. Q: Is the DTC set? YES: Troubleshoot the radio and CD player (Refer to «RADIO AND CD PLAYER - LANCER EVOLUTION»(ref-592601) ). NO: Go to Step 4.
4. STEP 4. Check the diagnosis mode Check if the hands free module can be switched to the diagnosis mode. (Refer to «DIAGNOSIS MODE < VEHICLES WITH RADIO AND CD PLAYER >»(ref-592655-S40668600972014011000000) .) Q: Is the check result normal? YES: Go to Step 5. NO: Perform Inspection Procedure 5: "DIAGNOSIS MODE cannot be made an entry." (Refer to «INSPECTION PROCEDURE 5: DIAGNOSIS MODE CANNOT BE MADE AN ENTRY. < VEHICLES WITH RADIO AND CD PLAYER >»(ref-592655-S22277711072014011000000) .)
5. STEP 5. Replace the hands free module temporarily, and check the trouble symptom. Q: Is the check result normal? YES: Replace the hands free module. NO: Replace the radio and CD player.

Inspection Procedure 8: Voice Guide "Unable To Obtain Vehicle Speed - Please Try Again Or Contact Your Dealer For Service" Is Sent From The Speaker < Vehicles With MMCS >

Required Special Tools

1. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)

1. STEP 1. Check the combination meter. Check whether the speed meter works normally. (Refer to «SPEEDOMETER CHECK»(ref-592598-S13268979982014011000000) .) Q: Is the check result normal? YES: Go to Step 2. NO: Diagnose the combination meter (Refer to «COMBINATION METER - LANCER EVOLUTION»(ref-592598) ).
2. STEP 2. Check the multivision operation check if the own vehicle mark is dislocated while driving. Q: Is the check result normal? YES: Go to Step 3. NO: Diagnose the MMCS (Refer to «TROUBLE SYMPTOM CHART»(ref-592655-S14437871562014011000000) .)
3. STEP 3. Using scan tool MB991958, read the CAN box unit diagnostic trouble code. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(ref-592655-S12263955692014011000000) ." Turn the ignition switch to the "ON" position. Check if DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES: Troubleshoot the MMCS (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-592603-S21819533662014011000000) ). NO: Go to Step 4.
4. STEP 4. Check the diagnosis mode Check if the hands free module can be switched to the diagnosis mode. (Refer to «DIAGNOSIS MODE < VEHICLES WITH MMCS >»(ref-592655-S06563619622014011000000) .) Q: Is the check result normal? YES: Go to Step 5. NO: Perform Inspection Procedure 6: "DIAGNOSIS MODE cannot be made an entry. Mobile Phone item is not displayed on the INFOR screen of MMCS." (Refer to «INSPECTION PROCEDURE 6: DIAGNOSIS MODE CANNOT BE MADE AN ENTRY. MOBILE PHONE ITEM IS NOT DISPLAYED ON THE INFOR SCREEN OF MMCS. < VEHICLES WITH MMCS >»(ref-592655-S02162925672014011000000) .)
5. STEP 5. Replace the hands free module temporarily, and check the trouble symptom. Q: Is the check result normal? YES: Replace the hands free module. NO: Replace the multivision display.
