>> A << SEAL RING INSTALLATION
| CAUTION | Apply Vaseline when installing the seal rings. Do not reuse the seal rings. |
Install the seal rings (small and big) on the input shaft.
>> B << SNAP RING INSTALLATION
| CAUTION | Be careful not to strain the snap ring by expanding it excessively. Do not reuse the snap ring. |
Install the input shaft on the forward clutch drum, and attach the snap ring.
>> C << SNAP RING INSTALLATION
| CAUTION | Do not reuse the snap ring. |
Install the snap ring on the forward clutch drum.
>> D << INTERNAL GEAR INSTALLATION
Install the internal gear on the forward clutch drum.
>> E << SNAP RING INSTALLATION
| CAUTION | Do not reuse the snap ring. |
Install the snap ring on the forward clutch drum.
<< B >> REDUCTION GEAR BEARING REMOVAL
| CAUTION | Align the tang of special tool as shown in the illustration. |
Scheme 158
Scheme 159
Using the special tools MB990810, MB990947 and MD999566, remove the inner race of reduction gear bearing (converter housing side) from the reduction gear sub-assembly.
Scheme 160
Using the special tools MB990984 and MD998917, remove the outer race of reduction gear bearing (transaxle case side) from the reduction gear sub-assembly.
>> A << REDUCTION GEAR BEARING INSTALLATION
| CAUTION | Do not reuse the inner race. Replace the inner race together with the outer race. |
Scheme 161
Using the special tools MD998812, MD998813 and MD998819, install the inner race of reduction gear bearing (transaxle case side) on the reduction gear sub-assembly.
>> B << REDUCTION GEAR BEARING INSTALLATION
| CAUTION | Do not reuse the inner race. Replace the inner race together with the outer race. |
Scheme 162
Using the special tools MD998812, MD998813 and MD998819, install the inner race of reduction gear bearing (converter housing side) on the reduction gear sub-assembly.
Scheme 163
Install the nut on the reduction gear sub-assembly to the specified torque.
Tightening torque: 250 N.m (184 ft-lb)
>> B << OIL SEAL INSTALLATION
| CAUTION | Pay attention to the transfer case that can possibly twist when the pin projection is too large. |
Scheme 164
Scheme 165
Scheme 166
- Adjust the projection allowances of the two pins of the special tool, Oil Seal Installer (MB992154) to be 0.2 ± 0.1 mm (0.007 ± 0.003 in). NOTE: The two pins are inserted into the special tool, Oil Seal Installer (MB992154). When the oil seal is replaced, the traces are found on the transfer case so that the replacement using the specified special tool can be recognized.
- Apply specified grease to the oil seal lip area. Specified grease: Retinax A
- Using the special tool MD998812 and MB992154, install the oil seal.
- Check whether the two traces are found on the transfer case.
Scheme 167
- Using the special tool MB992075 and MB992142, install the oil seal.
- Apply specified grease to the oil seal lip area.
Specified grease: Retinax A
Scheme 168
- Using the special tool MB990936, install the oil seal.
- Apply transfer oil to the lip of oil seal.
