TRANSAXLE MODEL
W1CJA and F1CJA models has been established.
| Transaxle model | Engine model | Vehicle model |
|---|---|---|
| W1CJA-1-B3X | 4B12 | CY5A |
| F1CJA-2-D3W | 4B11 | CY4A, CX4A |
| F1CJA-1-B3X | 4B12 | CY5A, CX5A |
TRANSAXLE MODELS
Scheme 309
Scheme 310
Scheme 311
SEALANTS AND ADHESIVES
| Item | Specified sealant and adhesive |
|---|---|
| Converter housing | Loctite 509 |
TRANSAXLE SEALANTS AND ADHESIVES
| Item | Specified sealant and adhesive |
|---|---|
| Cover | 3M™ATD Part No. 8660 or equivalent |
TRANSFER SEALANTS AND ADHESIVES
FORM-IN-PLACE GASKET (FIPG)
This transaxle has several areas where the form-in-place gasket (FIPG) is used for sealing. To ensure that the FIPG fully serves its purpose, it is necessary to observe some precautions when applying it. Bead size, continuity and location are of paramount importance.
Too thin a bead could cause leaks. Too thick a bead, on the other hand, could be squeezed out of location, causing blocking or narrowing of fluid passages. To prevent leaks or blocking of passages, therefore, it is absolutely necessary to apply the FIPG evenly without a break, while observing the correct bead size.
FIPG hardens as it reacts with the moisture in the atmospheric air, and it is usually used for sealing metallic flange areas.
| CAUTION | When re-applying liquid gasket (FIPG), be sure that: Residues of FIPG are cleared from all the ins and outs of parts; Use Mitsubishi genuine parts cleaner (MZ100387) or equivalent to well de-grease the FIPG-applied surface. FIPG is correctly applied in accordance with FIPG Application. |
Surface Preparation
Thoroughly remove all substances deposited on the FIPG application surface, using a gasket scraper.
Make sure that the FIPG application surfaces is flat and smooth. Also make sure that the surface is free from oils, greases and foreign substances. Do not fail to remove old FIPG that may remain in the fastener fitting holes.
LUBRICANTS
| Item | Specified lubricant |
|---|---|
| CVT fluid application parts | Mitsubishi Motors Genuine CVTF-J4 |
| Vaseline application parts | White Vaseline (main ingredient: isoparaffinic hydrocarbon) |
TRANSAXLE LUBRICANTS
| Item | Specified lubricant |
|---|---|
| Grease application parts | Retinax A |
| Hypoid gear oil application parts | Mitsubishi Motors Genuine hypoid gear oil API classification GL-5 SAE 80 |
TRANSFER LUBRICANTS
INPUT SHAFT AND INTERNAL GEAR
Check if there is a damage or deformation, and replace if any defect is found.
Scheme 312
Required special tools
- MB990810: Side bearing puller
- MB990947: Lower arm push arbor
- MD999566: Crow
- MB990984: Mount bushing lower roll insulator arbor
- MD998917: Bearing remover
- MD998812: Installer Cap
- MD998813: Installer-100
- MD998819: Installer adapter (40)
Scheme 313
Remove the nut from the reduction gear sub-assembly.
