Body - Lancer Evolution: Diagnosis Mitsubishi Lancer X

Windows 53 illustrations ~19016 words

TROUBLESHOOTING STRATEGY

Use these steps to plan your diagnostic strategy. If you follow them carefully, you will be sure that you have exhausted most of the possible ways to find a hood fault.

  1. Gather information from the customer.
  2. Verify that the condition described by the customer exists.
  3. Find the malfunction by following the Symptom Chart.
  4. Verify malfunction is eliminated.

TROUBLE SYMPTOM CHART

SymptomReference page
Difficult locking and unlockingINSPECTION PROCEDURE 1: DIFFICULT LOCKING AND UNLOCKING
Uneven body clearanceINSPECTION PROCEDURE 2: UNEVEN BODY CLEARANCE
Uneven heightINSPECTION PROCEDURE 3: UNEVEN HEIGHT

TROUBLE SYMPTOM CHART

DIAGNOSIS

  1. STEP 1. Check that the release cable is routed correctly. Q: Is the release cable routed correctly? YES : Go to Step 2. NO : Re-route the release cable. Then go to Step 4 .
  2. STEP 2. Check the engagement of the hood latch and hood striker. Q: Are the hood latch and hood striker engaged correctly? YES : Go to Step 3. NO : Adjust the hood latch (Refer to «ADJUSTMENT OF CLEARANCE AROUND HOOD»(ref-289409-S29494723162008063000000) ). Then go to Step 4 .
  3. STEP 3. Check for proper lubrication of release cable. Q: Is the release cable properly lubricated? YES : Go to Step 4. NO : Lubricate, then go to Step 4.
  4. STEP 4. Retest the system. Q: Does the hood lock operate easily? YES : The procedure is complete. NO : Return to Step 1 .
  1. STEP 1. Check the clearance around the hood. Q: Is the clearance around the hood even? YES : Go to Step 2. NO : Adjust the hood (Refer to «ADJUSTMENT OF CLEARANCE AROUND HOOD»(ref-289409-S29494723162008063000000) ). Then go to Step 2.
  2. STEP 2. Retest the system. Q: Are the clearances between body panels even? YES : The procedure is complete. NO : Return to Step 1 .
  1. STEP 1. Check the hood damper height. Q: Is the hood damper height proper? YES : Go to Step 2. NO : Adjust the hood damper (Refer to «ADJUSTMENT OF HOOD HEIGHT»(ref-289409-S38884957862008063000000) ). Then go to Step 2.
  2. STEP 2. Retest the system. Q: Are the hood and body height even? YES : The procedure is complete. NO : Return to Step 1 .

Scheme 24

Scheme 24: ADJUSTMENT OF CLEARANCE AROUND HOOD
Scheme 24: ADJUSTMENT OF CLEARANCE AROUND HOOD
  1. Loosen the hood hinge mounting bolts but do not remove them. Move the hood hinge back/forth and left/right to align the hood level.
  2. After the adjustment, tighten the hood hinge mounting bolts to 12 ± 2 N.m (102 ± 22 in-lb).

WINDOW GLASS DIAGNOSTIC TROUBLESHOOTING STRATEGY

Use these steps to plan your diagnostic strategy. If you follow them carefully, you will be sure that you have exhausted most of the possible ways to find a window glass fault.

  1. Gather information from the customer.
  2. Verify that the condition described by the customer exists.
  3. Find the malfunction by following the Symptom Chart.
  4. Verify malfunction is eliminated.

WINDOW GLASS DIAGNOSTIC TROUBLE SYMPTOM CHART

SymptomInspection procedure
Water leak through windshield1
Water leak through rear window glass

WINDOW GLASS DIAGNOSTIC TROUBLE SYMPTOM CHART

  1. STEP 1. Check if the seal is faulty. Q: Is the seal faulty? YES : Repair the seal, then go to Step 3 . NO : Go to Step 2.
  2. STEP 2. Check if the body flange is deformed. Q: Is the body flange deformed? YES : Replay the body flange, then go to Step 3. NO : Go to Step 3.
  3. STEP 3. Retest the system. Q: Is any water leaking? YES : Return to Step 1 . NO : This diagnosis complete.

Refer to CONTENTS OF TROUBLESHOOTING .

CAUTIONDuring diagnosis, a diagnostic trouble code associated with other system may be set when the ignition switch is turned on with connector(s) disconnected. On completion, check all systems for diagnostic trouble code(s). If diagnostic trouble code(s) are set, erase them all.
Trouble symptomReference page
Central door locking system does not work at all.INSPECTION PROCEDURE 1: Central Door Locking System does not work at All
Central door locking system does not operate even when door lock switch of power window main switch operated (door lock switch of front power window sub switch operate normally).INSPECTION PROCEDURE 2: CENTRAL DOOR LOCKING SYSTEM DOES NOT OPERATE EVEN WHEN DOOR LOCK SWITCH OF POWER WINDOW MAIN SWITCH OPERATED (DOOR LOCK SWITCH OF FRONT POWER WINDOW SUB SWITCH OPERATE NORMALLY).
Central door locking system does not operate even when door lock switch of front power window sub switch operated (door lock switch of power window main switch operate normally).INSPECTION PROCEDURE 3: CENTRAL DOOR LOCKING SYSTEM DOES NOT OPERATE EVEN WHEN DOOR LOCK SWITCH OF FRONT POWER WINDOW SUB SWITCH OPERATED (DOOR LOCK SWITCH OF POWER WINDOW MAIN SWITCH OPERATE NORMALLY).
A door cannot be locked or unlocked by the central door locking system.INSPECTION PROCEDURE 4: A DOOR CANNOT BE LOCKED OR UNLOCKED BY THE CENTRAL DOOR LOCKING SYSTEM.
Selector "P" Position-linked Door Unlock Function does not Operate Normally. < Vehicles with TC-SST >INSPECTION PROCEDURE 5: SELECTOR "P" POSITION-LINKED DOOR UNLOCK FUNCTION DOES NOT OPERATE NORMALLY. < VEHICLES WITH TC-SST >

TROUBLE SYMPTOM CHART

INSPECTION PROCEDURE 1: Central Door Locking System does not work at All

CAUTIONBefore replacing the ECU, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.

Scheme 25

Scheme 25
Scheme 25

TROUBLESHOOTING HINTS

  1. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector
  2. The ETACS-ECU may be defective

DIAGNOSTIC PROCEDURE

Required Special Tools

  1. MB992006: Extra fine probe
  2. MB991223: Harness set
  3. MB991958 Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827 M.U.T.-III USB Cable MB991910 M.U.T.-III Main Harness A

Scheme 26

Scheme 26
Scheme 26
  1. STEP 1. Checking keyless entry system operation Check that the keyless entry system works normally. Q: Is the check result normal? YES : Go to Step 2. NO < Vehicles with KOS > : Refer to «INSPECTION PROCEDURE 14 "KEYLESS ENTRY SYSTEM DOES NOT WORK AT ALL»(ref-289389-S14994322132008063000000) ". NO < Vehicles with WCM > : Refer to «INSPECTION PROCEDURE 5 "KEYLESS ENTRY SYSTEM DOES NOT WORK AT ALL»(ref-289390-S16081007632008063000000) ".
  2. STEP 2. Using scan tool MB991958, read the diagnostic trouble code. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(ref-289389-S36745525782008063000000) ". Turn the ignition switch to the "ON" position. Check whether the ETACS-ECU related DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES : Diagnose the ETACS-ECU. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-289392-S29242288832008063000000) . NO : Go to Step 3.
  3. STEP 3. Using scan tool MB991958, check data list. Check the signals related to the central door locking system operation. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(ref-289389-S36745525782008063000000) ". Turn the ignition switch to the "ON" position. Check the data list of the ETACS. Turn the door lock switch (power window main switch or front power window sub switch) to the lock direction. DATA LIST Item No. Item name Normal condition 270 Dr door lock switch Lock 271 Dr door unlock switch Not unlock Turn the door lock switch (power window main switch or front power window sub switch) to the unlock direction. CONDITION CHART Item No. Item name Normal condition 270 Dr door lock switch Not lock 271 Dr door unlock switch Unlock Turn the ignition switch to the "LOCK" (OFF) position. OK: Normal conditions are displayed for all items. Q: Are the check result normal? YES : Go to Step 4. NO : Refer to «INSPECTION PROCEDURE 4 "THE FRONT DOOR LOCK ACTUATOR (DRIVER'S SIDE) SIGNAL IS NOT RECEIVED»(ref-289392-S29823951022008063000000) ".
  4. STEP 4. Check joint connector (1) connector C-101, joint connector (3) connector C-103, ETACS-ECU connector C-301 and C-315 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Are joint connector (1) connector C-101, joint connector (3) connector C-103, ETACS-ECU connector C-301 and C-315 in good condition? YES : Go to Step 5. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Check that the sunroof works normally.
  5. STEP 5. Check the wiring harness between joint connector (1) connector C-101 (terminal No. 5) and ETACS-ECU connector C-301 (terminal No. 2), joint connector (3) connector C-103 (terminal No. 21) and ETACS-ECU connector C-315 (terminal No. 15). Q: Are the wiring harness between joint connector (1) connector C-101 (terminal No. 5) and ETACS-ECU connector C-301 (terminal No. 2), joint connector (3) connector C-103 (terminal No. 21) and ETACS-ECU connector C-315 (terminal No. 15) in good condition? YES : Go to Step 6. NO : The wiring harness may be damaged or the connector may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Verify that the central door locking system works normally.
  6. STEP 6. Retest the system. Check that the central door locking system works normally. Q: Is the check result normal? YES : No action is necessary and testing is complete. NO : Replace the ETACS-ECU. Check that the central door locking system normally.

INSPECTION PROCEDURE 2: Central Door Locking System does not Operate even when Door Lock Switch of Power Window Main Switch Operated (Door Lock Switch of Front Power Window Sub Switch Operate Normally)

CAUTIONBefore replacing the ECU, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.

Scheme 27

Scheme 27
Scheme 27
  1. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector
  2. The power window main switch may be defective

Scheme 28

Scheme 28: DIAGNOSTIC PROCEDURE
Scheme 28: DIAGNOSTIC PROCEDURE
  1. STEP 1. Checking central door locking system operation Check that the central door locking system works normally. Q: Is the check result normal? YES : Go to Step 2. NO : Refer to «INSPECTION PROCEDURE 1: Central Door Locking System does not work at All»(ref-289409-S07214580022008112100000) ".
  2. STEP 2. Check power window main switch connector E-15 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is power window main switch connector E-15 in good condition? YES : Go to Step 3. NO : Repair or check the connector. Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Verify that all the doors can be locked and unlocked normally.
  3. STEP 3. Check the power window main switch (door lock switch). Remove the power window main switch. Refer to «REMOVAL AND INSTALLATION»(ref-289409-S23728506612008063000000) . CONDITION CHART Switch position Tester connection Specified condition LOCK 14 - Ground Continuity exists (2 ohms or less) UNLOCK 13 - Ground Continuity exists (2 ohms or less) Q: Does the power window main switch work normally? YES : Go to Step 4. NO : Replace the power window main switch. Verify that all the doors can be locked and unlocked normally.
  4. STEP 4. Check joint connector (1) connector C-101, joint connector (3) connector C-103 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Are joint connector (1) connector C-101, joint connector (3) connector C-103 in good condition? YES : Go to Step 5. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Check that the sunroof works normally.
  5. STEP 5. Check the wiring harness between power window main switch connector E-15 (terminals Nos. 13 and 14), joint connector (3) connector C-103 (terminal No. 20) and joint connector (1) connector C-101 (terminal No. 4). NOTE: Also check intermediate connector C-129 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector C-129 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Q: Are the wiring harness between power window main switch connector E-15 (terminals Nos. 13 and 14), joint connector (3) connector C-103 (terminal No. 20) and joint connector (1) connector C-101 (terminal No. 4) in good condition? YES : Go to Step 6. NO : The wiring harness may be damaged or the connector may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Verify that the central door locking system works normally.
  6. STEP 6. Retest the system. Check that the central door locking system works normally. Q: Is the check result normal? YES : No action is necessary and testing is complete. NO : Replace the power window main switch. Check that the central door locking system normally.

Scheme 29

Scheme 29: INSPECTION PROCEDURE 3: Central Door Locking System does not Operate even when Door Lock Switch of F
Scheme 29: INSPECTION PROCEDURE 3: Central Door Locking System does not Operate even when Door Lock Switch of F
  1. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector
  2. The front power window sub switch may be defective

Scheme 30

Scheme 30: DIAGNOSTIC PROCEDURE
Scheme 30: DIAGNOSTIC PROCEDURE

Scheme 31

Scheme 31
Scheme 31
  1. STEP 1. Checking central door locking system operation Check that the central door locking system works normally. Q: Is the check result normal? YES : Go to Step 2. NO : Refer to «INSPECTION PROCEDURE 1: Central Door Locking System does not work at All»(ref-289409-S07214580022008112100000) ".
  2. STEP 2. Check front power window sub switch connector E-08 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is front power window sub switch connector E-08 in good condition? YES : Go to Step 3. NO : Repair or check the connector. Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Verify that all the doors can be locked and unlocked normally.
  3. STEP 3. Check the front power window sub switch (door lock switch). Remove the front power window sub switch. Refer to «REMOVAL AND INSTALLATION»(ref-289409-S23728506612008063000000) . TESTER CONNECTION SPECIFIED CONDITION Switch position Tester connection Specified condition LOCK 3 - 4 Continuity exists (2 ohms or less) UNLOCK 2 - 4 Continuity exists (2 ohms or less) Q: Does the front power window sub switch work normally? YES : Go to Step 4. NO : Replace the front power window sub switch. Verify that all the doors can be locked and unlocked normally.
  4. STEP 4. Check the ground circuit to the front power window sub switch. Measure the resistance at front power window sub switch connector E-08. Disconnect front power window sub switch connector E-08 and measure the resistance available at the wiring harness side of the connector. Measure the resistance value between terminal 4 and ground. The resistance should be 2 ohms or less. Q: Is the measured resistance 2 ohms or less? YES : Go to Step 5. NO : Go to Step 6 .
  5. STEP 5. Check the wiring harness between front power window sub switch connector E-08 and ground. NOTE: Also check intermediate connector C-116 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector C-116 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Q: Is the wiring harness between front power window sub switch connector E-08 (terminal No. 4) and ground in good condition? YES : No action is necessary and testing is complete. NO : The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Check that the sunroof works normally.
  6. STEP 6. Check joint connector (1) connector C-101, joint connector (3) connector C-103 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Are joint connector (1) connector C-101, joint connector (3) connector C-103 in good condition? YES : Go to Step 7. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Check that the sunroof works normally.
  7. STEP 7. Check the wiring harness between front power window sub switch connector E-08 (terminals Nos. 2 and 3), joint connector (3) connector C-103 (terminal No. 19) and joint connector (1) connector C-101 (terminal No. 3). NOTE: Also check intermediate connector C-24 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector C-24 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Q: Are the wiring harness between front power window sub switch connector E-08 (terminals Nos. 2 and 3), joint connector (3) connector C-103 (terminal No. 19) and joint connector (1) connector C-101 (terminal No. 3) in good condition? YES : Go to Step 8. NO : The wiring harness may be damaged or the connector may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Verify that the central door locking system works normally.
  8. STEP 8. Retest the system. Check that the central door locking system works normally. Q: Is the check result normal? YES : No action is necessary and testing is complete. NO : Replace the front power window sub switch. Check that the central door locking system normally.

Scheme 32

Scheme 32: INSPECTION PROCEDURE 4: A Door cannot be Locked or Unlocked by The Central Door Locking System
Scheme 32: INSPECTION PROCEDURE 4: A Door cannot be Locked or Unlocked by The Central Door Locking System

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34
  1. The door lock actuator may be defective
  2. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector
  3. The ETACS-ECU may be defective

Scheme 35

Scheme 35: DIAGNOSTIC PROCEDURE
Scheme 35: DIAGNOSTIC PROCEDURE

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38
  1. STEP 1. Confirmation of the defective door lock actuator. Q: Which door is not locked normally? Driver's door : Go to Step 2. Front passenger's door : Go to Step 6 . Rear right door : Go to Step 10 . Rear left door : Go to Step 14 .
  2. STEP 2. Check front door lock actuator (LH) connector E-16 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is front door lock actuator (LH) connector E-16 in good condition? YES : Go to Step 3. NO : Repair or check the connector. Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Verify that all the doors can be locked and unlocked normally.
  3. STEP 3. Check the front door lock actuator (LH). Remove the front door lock actuator (LH). The illustration shows when the door lock actuator is viewed from inside the door. Refer to «DOOR HANDLE AND LATCH»(ref-289409-S13737525032008063000000) . BATTERY CONNECTION LEVER OPERATION CHART Lever position Battery connection Lever operation At the "LOCK" position Connect terminal No.4 and the negative battery terminal. Connect terminal No.6 and the positive battery terminal. The lever moves from the "LOCK" position to the "UNLOCK" position. At the "UNLOCK" position Connect terminal No.6 and the negative battery terminal. Connect terminal No.4 and the positive battery terminal. The lever moves from the "UNLOCK" position to the "LOCK" position. Q: Does the front door lock actuator (LH) work normally? YES : Go to Step 4. NO : Replace the front door lock actuator (LH). Verify that all the doors can be locked and unlocked normally.
  4. STEP 4. Check ETACS-ECU connector C-315 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is ETACS-ECU connector C-315 in good condition? YES : Go to Step 5. NO : Repair or check the connector. Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Verify that all the doors can be locked and unlocked normally.
  5. STEP 5. Check the wiring harness between ETACS-ECU connector C-315 (terminals Nos. 5 and 6) and front door lock actuator (LH) connector E-16 (terminals Nos. 6 and 4). NOTE: Also check joint connector (3) C-103, intermediate connector C-129 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If joint connector (3) C-103, intermediate connector C-129 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Q: Is the wiring harness between ETACS-ECU connector C-315 (terminals Nos. 5 and 6) and front door lock actuator (LH) connector E-16 (terminals Nos. 6 and 4) in good condition? YES : Go to Step 18 . NO : The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair or replace the damaged component(s). Verify that all the doors can be locked and unlocked normally.
  6. STEP 6. Check front door lock actuator (RH) connector E-07 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is front door lock actuator (RH) connector E-07 in good condition? YES : Go to Step 7. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Verify that all the doors can be locked and unlocked normally.
  7. STEP 7. Check the front door lock actuator (RH). Remove the front door lock actuator (RH). The illustration shows when the door lock actuator is viewed from inside the door. Refer to «DOOR HANDLE AND LATCH»(ref-289409-S13737525032008063000000) . BATTERY CONNECTION LEVER OPERATION CHART Lever position Battery connection Lever operation At the "LOCK" position Connect terminal No.4 and the negative battery terminal. Connect terminal No.6 and the positive battery terminal. The lever moves from the "LOCK" position to the "UNLOCK" position. At the "UNLOCK" position Connect terminal No.6 and the negative battery terminal. Connect terminal No.4 and the positive battery terminal. The lever moves from the "UNLOCK" position to the "LOCK" position. Q: Is the front door lock actuator (RH) normal? YES : Go to Step 8. NO : Replace the front door lock actuator (RH). Verify that all the doors can be locked and unlocked normally.
  8. STEP 8. Check ETACS-ECU connector C-315 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is ETACS-ECU connector C-315 in good condition? YES : Go to Step 9. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Verify that all the doors can be locked and unlocked normally.
  9. STEP 9. Check the wiring harness between ETACS-ECU connector C-315 (terminals Nos. 5 and 6) and front door lock actuator (RH) connector E-07 (terminals Nos. 6 and 4). NOTE: Also check joint connector (3) C-103, intermediate connector C-24 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If joint connector (3) C-103, intermediate connector C-24 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Q: Is the wiring harness between ETACS-ECU connector C-315 (terminals Nos. 5 and 6) and front door lock actuator (RH) connector E-07 (terminals Nos. 6 and 4) in good condition? YES : Go to Step 18 . NO : The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Verify that all the doors can be locked and unlocked normally.
  10. STEP 10. Check rear door lock actuator (RH) connector E-19 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is rear door lock actuator (RH) connector E-19 in good condition? YES : Go to Step 11. NO : Repair or check the connector. Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Verify that all the doors can be locked and unlocked normally.
  11. STEP 11. Check the rear door lock actuator (RH). Remove the rear door lock actuator (RH). The illustration shows when the door lock actuator is viewed from inside the door. Refer to «DOOR HANDLE AND LATCH»(ref-289409-S13737525032008063000000) . BATTERY CONNECTION LEVER OPERATION CHART Lever position Battery connection Lever operation At the "LOCK" position Connect terminal No.4 and the negative battery terminal. Connect terminal No.6 and the positive battery terminal. The lever moves from the "LOCK" position to the "UNLOCK" position. At the "UNLOCK" position Connect terminal No.6 and the negative battery terminal. Connect terminal No.4 and the positive battery terminal. The lever moves from the "UNLOCK" position to the "LOCK" position. Q: Is the rear door lock actuator (RH) normal? YES : Go to Step 12. NO : Replace the rear door lock actuator (RH). Verify that all the doors can be locked and unlocked normally.
  12. STEP 12. Check ETACS-ECU connector C-311 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is ETACS-ECU connector C-311 in good condition? YES : Go to Step 13. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Verify that all the doors can be locked and unlocked normally.
  13. STEP 13. Check the wiring harness between ETACS-ECU connector C-311 (terminals Nos. 6 and 9) and rear door lock actuator (RH) connector E-19 (terminals Nos. 6 and 4). NOTE: Also check joint connector (4) C-43, intermediate connector D-01 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If joint connector (4) C-43, intermediate connector D-01 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Q: Is the wiring harness between ETACS-ECU connector C-311 (terminals No. 6 and 9) and rear door lock actuator (RH) connector E-19 (terminals No. 6 and 4) in good condition? YES : Go to Step 18 . NO : The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Verify that all the doors can be locked and unlocked normally.
  14. STEP 14. Check rear door lock actuator (LH) connector E-26 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is rear door lock actuator (LH) connector E-26 in good condition? YES : Go to Step 15. NO : Repair or check the connector. Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Verify that all the doors can be locked and unlocked normally.
  15. STEP 15. Check the rear door lock actuator (LH). Remove the rear door lock actuator (LH). The illustration shows when the door lock actuator is viewed from inside the door. Refer to «DOOR HANDLE AND LATCH»(ref-289409-S13737525032008063000000) . BATTERY CONNECTION LEVER OPERATION CHART Lever position Battery connection Lever operation At the "LOCK" position Connect terminal No.4 and the negative battery terminal. Connect terminal No.6 and the positive battery terminal. The lever moves from the "LOCK" position to the "UNLOCK" position. At the "UNLOCK" position Connect terminal No.6 and the negative battery terminal. Connect terminal No.4 and the positive battery terminal. The lever moves from the "UNLOCK" position to the "LOCK" position. Q: Is the rear door lock actuator (LH) normal? YES : Go to Step 16. NO : Replace the rear door lock actuator (LH). Verify that all the doors can be locked and unlocked normally.
  16. STEP 16. Check ETACS-ECU connector C-311 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is ETACS-ECU connector C-311 in good condition? YES : Go to Step 17. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Verify that all the doors can be locked and unlocked normally.
  17. STEP 17. Check the wiring harness between ETACS-ECU connector C-311 (terminals Nos. 6 and 9) and rear door lock actuator (LH) connector E-26 (terminals Nos. 6 and 4). NOTE: Also check joint connector (4) C-43, intermediate connector D-24 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If joint connector (4) C-43, intermediate connector D-24 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Q: Is the wiring harness between ETACS-ECU connector C-311 (terminals Nos. 6 and 9) and rear door lock actuator (LH) connector E-26 (terminals Nos. 6 and 4) in good condition? YES : Go to Step 18. NO : The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Verify that all the doors can be locked and unlocked normally.
  18. STEP 18. Retest the system. Check that the central door locking system works normally. Q: Is the check result normal? YES : No action is necessary and testing is complete. NO : Replace the ETACS-ECU. Check that the central door locking system normally.

INSPECTION PROCEDURE 5: Selector "P" Position-linked Door Unlock Function does not Operate Normally. < Vehicles with TC-SST >

CAUTIONWhenever the ECU is replaced, ensure that the input and output signal circuits are normal.

Scheme 39

Scheme 39
Scheme 39
  1. Malfunction of shift lever
  2. Malfunction of ETACS-ECU
  3. Damaged wiring harness and connectors

Required Special Tools

  1. MB992006: Extra fine probe
  2. MB991223: Harness set
  3. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A
  1. STEP 1. Checking central door locking system operation Check that the central door locking system works normally. Q: Is the check result normal? YES : Go to Step 2. NO : Refer to «INSPECTION PROCEDURE 1: Central Door Locking System does not work at All»(ref-289409-S07214580022008112100000) ".
  2. STEP 2. Check the customize function. Check that either of the followings other than "Disable" is set for "Auto door unlock by P position" with the customization function. Always enabled Q: Is the check result normal? YES : Go to Step 3. NO : Set either of the followings other than "Disable" for "Auto door unlock by P position" with the customization function (Refer to «CONFIGURATION FUNCTION»(ref-289409-S05012347782008063000000) ).
  3. STEP 3. Using scan tool MB991958, read CAN bus the diagnostic trouble code. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(ref-289389-S36745525782008063000000) ". Turn the ignition switch to the "ON" position. Check whether the CAN bus lines related DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES : Repair the CAN bus line (Refer to «CAN BUS DIAGNOSTICS TABLE»(ref-289394-S27719724372008063000000) ). NO : Go to Step 4.
  4. STEP 4. Using scan tool MB991958, read the diagnostic trouble code. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(ref-289389-S36745525782008063000000) ". Turn the ignition switch to the "ON" position. Check whether the shift lever related DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES : Diagnose the shift lever. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-289384-S12029117772008063000000) . NO : Go to Step 5.
  5. STEP 5. Retest the system. Check that shifting the selector lever to the P position unlocks the doors. Q: Is the check result normal? YES : No action is necessary and testing is complete. NO : Replace the ETACS-ECU. Check that the selector lever to the P position unlocks the doors normally.

Refer to CONTENTS OF TROUBLESHOOTING .

DIAGNOSTIC TROUBLE CODE CHART

CAUTIONOn troubleshooting, if the ignition switch is turned ON while disconnecting connector(s), diagnostic trouble code(s) associated with other system may be set. On completion, check all systems for diagnostic trouble code(s). If diagnostic trouble code(s) are set, erase them all.
Diagnostic trouble code No.Diagnostic item
L0730P/W (DR) SW pulse1 disconnection
L0732P/W (DR) SW pulse2 disconnection
L0734P/W (DR) Above window position
L0736P/W (DR) Sensor fail (ground)
L0740P/W (DR) 3 times jam - protection
L0746P/W (DR) Parameter read fail
L0750P/W (DR) Position read fail

DIAGNOSTIC TROUBLE CODE CHART

CAUTIONDuring diagnosis, a diagnostic trouble code associated with other system may be set when the ignition switch is turned on with connector(s) disconnected. On completion, check all systems for diagnostic trouble code(s). If diagnostic trouble code(s) are set, erase them all.
Trouble symptomReference page
Power windows do not work at all.INSPECTION PROCEDURE 1: POWER WINDOWS DO NOT WORK AT ALL.
Driver's power window does not work by means of the power window main switch.INSPECTION PROCEDURE 2: DRIVER'S POWER WINDOW DOES NOT WORK BY MEANS OF THE POWER WINDOW MAIN SWITCH.
Relevant power window(s) does not work by means of the front and rear passenger's power window sub switches.INSPECTION PROCEDURE 3: RELEVANT POWER WINDOW(S) DOES NOT WORK BY MEANS OF THE FRONT AND REAR PASSENGER'S POWER WINDOW SUB SWITCHES.
Front and/or rear passenger's power window(s) do not work by means of the power window main switch.INSPECTION PROCEDURE 4: FRONT AND/OR REAR PASSENGER'S POWER WINDOW(S) DO NOT WORK BY MEANS OF THE POWER WINDOW MAIN SWITCH.
The power window timer function does not work normally.INSPECTION PROCEDURE 5: THE POWER WINDOW TIMER FUNCTION DOES NOT WORK NORMALLY.
Power window anti-trap function does not work normally (driver's side seat).INSPECTION PROCEDURE 6: POWER WINDOW ANTI-TRAP FUNCTION DOES NOT WORK NORMALLY. < DRIVER'S SIDE SEAT >
The window glass lowers automatically while it is rising.INSPECTION PROCEDURE 7: THE WINDOW GLASS LOWERS AUTOMATICALLY WHILE IT IS RISING.

TROUBLE SYMPTOM CHART

COMMENTS ON TROUBLE SYMPTOM

If the pulse 1 signal from the front power window motor (LH) cannot be received, the power window main switch sets the diagnosis trouble code No. L0730.

  1. STEP 1. Check power window main switch connector E-15, front power window motor (LH) connector E-14 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Are power window main switch connector E-15, front power window motor (LH) connector E-14 in good condition? YES : Go to Step 2. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Verify that the power window works normally.
  2. STEP 2. Check the wiring harness between power window main switch connector E-15 (terminals Nos. 8, 9 and 12) and front power window motor (LH) connector E-14 (terminals Nos. 3, 5 and 6). Q: Is the wiring harness between power window main switch connector E-15 (terminals Nos. 8, 9 and 12) and front power window motor (LH) connector E-14 (terminals Nos. 3, 5 and 6) in good condition? YES : Go to Step 3. NO : The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Verify that the power window works normally.
  3. STEP 3. Diagnostic trouble code recheck Replace the front power window motor (LH). Recheck if the diagnostic trouble code is set. Erase the diagnostic trouble code. Operate the driver's door window switch on the power window main switch. Check if the diagnostic trouble code is set. Q: Is the diagnostic trouble code set? YES : Replace the power window main switch. NO : The procedure is complete. Verify that the power window works normally.

If the pulse 2 signal from the front power window motor (LH) cannot be received, the power window main switch sets the diagnosis trouble code No. L0732.

  1. STEP 1. Check power window main switch connector E-15, front power window motor (LH) connector E-14 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Are power window main switch connector E-15, front power window motor (LH) connector E-14 in good condition? YES : Go to Step 2. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Verify that the power window works normally.
  2. STEP 2. Check the wiring harness between power window main switch connector E-15 (terminals Nos. 9, 11 and 12) and front power window motor (LH) connector E-14 (terminals Nos. 5, 2 and 6). Q: Is the wiring harness between power window main switch connector E-15 (terminals Nos. 9, 11 and 12) and front power window motor (LH) connector E-14 (terminals Nos. 5, 2 and 6) in good condition? YES : Go to Step 3. NO : The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Verify that the power window works normally.
  3. STEP 3. Diagnostic trouble code recheck Replace the front power window motor (LH). Recheck if the diagnostic trouble code is set. Erase the diagnostic trouble code. Operate the driver's door window switch on the power window main switch. Check if the diagnostic trouble code is set. Q: Is the diagnostic trouble code set? YES : Replace the power window main switch. NO : The procedure is complete. Verify that the power window works normally.

If the driver's door window glass exceeds the fully closed position, power window main switch sets the diagnostic trouble code No. L0734.

  1. STEP 1. Check the power window fully closed position Carry out the learning procedures of the power window fully closed position. Refer to «LEARNING PROCEDURES OF THE POWER WINDOW FULLY CLOSED POSITION < DRIVER'S SIDE >»(ref-289409-S24524489632008063000000) . Recheck if the diagnostic trouble code is set. Erase the diagnostic trouble code. Press the driver's door window switch (on the power window main switch) down to open the window, and pull up the driver's door window switch to fully close the window. Check if the diagnostic trouble code is set. Q: Is the check result normal? YES : The procedure is complete. NO : Go to Step 2.
  2. STEP 2. Diagnostic trouble code recheck Replace the front power window motor (LH). Recheck if the diagnostic trouble code is set. Erase the diagnostic trouble code. Press the driver's door window switch (on the power window main switch) down to open the window, and pull up the driver's door window switch to fully close the window. Check if the diagnostic trouble code is set. Q: Is the diagnostic trouble code set? YES : Replace the power window main switch. NO : The procedure is complete. Verify that the power window works normally.

If the ground fault of the front power window motor (LH) sensor power supply is detected, power window main switch sets the diagnosis trouble code No. L0736

  1. STEP 1. Check power window main switch connector E-15, front power window motor (LH) connector E-14 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Are power window main switch connector E-15, front power window motor (LH) connector E-14 in good condition? YES : Go to Step 2. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Verify that the power window works normally.
  2. STEP 2. Check the wiring harness between power window main switch connector E-15 (terminal No. 12) and front power window motor (LH) connector E-14 (terminal No. 6). Q: Is the wiring harness between power window main switch connector E-15 (terminal No. 12) and front power window motor (LH) connector E-14 (terminal No. 6) in good condition? YES : Go to Step 3. NO : The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Verify that the power window works normally.
  3. STEP 3. Diagnostic trouble code recheck Replace the front power window motor (LH). Recheck if the diagnostic trouble code is set. Erase the diagnostic trouble code. Turn the ignition switch from the LOCK (OFF) position to the ON position. Check if the diagnostic trouble code is set. Q: Is the diagnostic trouble code set? YES : Replace the power window main switch. NO : The procedure is complete. Verify that the power window works normally.

If the anti-trap function is activated consecutively three times or more, power window main switch sets the diagnostic trouble code No. L0740.

  1. STEP 1. Check the power window fully closed position Carry out the learning procedures of the power window fully closed position. Refer to «LEARNING PROCEDURES OF THE POWER WINDOW FULLY CLOSED POSITION < DRIVER'S SIDE >»(ref-289409-S24524489632008063000000) . Recheck if the diagnostic trouble code is set. Erase the diagnostic trouble code. Turn the ignition switch from the LOCK (OFF) position to the ON position. Check if the diagnostic trouble code is set. Q: Is the check result normal? YES : The procedure is complete. NO : Go to Step 2.
  2. STEP 2. Diagnostic trouble code recheck Replace the front power window motor (LH). Recheck if the diagnostic trouble code is set. Erase the diagnostic trouble code. Turn the ignition switch from the LOCK (OFF) position to the ON position. Check if the diagnostic trouble code is set. Q: Is the diagnostic trouble code set? YES : Replace the power window main switch. NO : The procedure is complete. Verify that the power window works normally.
  1. If the power window main switch information signals cannot be read, power window main switch sets the diagnostic trouble code No. L0746.
  2. If the driver's door window glass position cannot be read, power window main switch sets the diagnostic trouble code No. L0750.

Diagnostic trouble code recheck

Recheck if the diagnostic trouble code is set.

  1. Erase the diagnostic trouble code.
  2. Turn the ignition switch from the LOCK (OFF) position to the ON position.
  3. Check if the diagnostic trouble code is set.

Q: Is the diagnostic trouble code set?

YES : Replace the power window main switch.

NO : The procedure is complete. Verify that the power window works normally.

INSPECTION PROCEDURE 1: Power Windows do not work at All

CAUTIONBefore replacing the ECU, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.

Scheme 40

Scheme 40
Scheme 40
  1. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector
  2. The power window main switch may be defective
  3. The ETACS-ECU may be defective

Required Special Tools

  1. MB992006: Extra fine probe
  2. MB991223: Harness set
  3. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44
  1. STEP 1. Check the power supply system. With the ignition switch in the LOCK (OFF) position, check if the following function operates normally: Hazard warning light Q: Is the check result normal? YES : Go to Step 2. NO : Refer to «MALFUNCTION OF ETACS-ECU POWER SUPPLY CIRCUIT»(ref-289392-S39748373222008063000000) .
  2. STEP 2. Using scan tool MB991958, read the diagnostic trouble code. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(ref-289389-S36745525782008063000000) ". Turn the ignition switch to the "ON" position. Check whether the ETACS-ECU related DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES : Diagnose the ETACS-ECU. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-289416-S29060959692008063000000) . NO : Go to Step 3.
  3. STEP 3. Using scan tool MB991958, check data list. Check the signals related to the power window operation. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(ref-289389-S36745525782008063000000) ". Turn the ignition switch to the "ON" position. Check the data list of the ETACS. Turn the ignition switch to the LOCK (OFF) position. DATA LIST Item No. Item name Normal condition 254 IG voltage Battery voltage Turn the ignition switch to the "LOCK" (OFF) position. OK: Normal condition is displayed. Q: Is the check result normal? YES : Go to Step 4. NO : Refer to «INSPECTION PROCEDURE 2: ETACS-ECU DOES NOT RECEIVE ANY SIGNAL FROM THE IGNITION SWITCH (IG1)»(ref-289392-S05543681702008063000000) .
  4. STEP 4. Check ETACS-ECU connector C-309 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is ETACS-ECU connector C-309 in good condition? YES : Go to Step 5. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Verify that the power window works normally.
  5. STEP 5. Check the fusible link (34) line of power supply circuit to the ETACS-ECU. Measure the voltage at ETACS-ECU connector C-309. Disconnect ETACS-ECU connector C-309 and measure the voltage available at the wiring harness side of the connector. Measure the voltage between terminal 1 and ground. The voltage should measure approximately 12 volts (battery positive voltage). Q: Is the measured voltage approximately 12 volts (battery positive voltage)? YES : Go to Step 7 . NO : Go to Step 6.
  6. STEP 6. Check the wiring harness between ETACS-ECU connector C-309 (terminal 1) and fusible link (34). Q: Is the wiring harness between ETACS-ECU connector C-309 (terminal 1) and fusible link (34) in good condition? YES : No action is necessary and testing is complete. NO : The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Check that the power window works normally.
  7. STEP 7. Check ETACS-ECU connector C-307 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is ETACS-ECU connector C-307 in good condition? YES : Go to Step 8. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Verify that the power window works normally.
  8. STEP 8. Check the fusible link (36) line of power supply circuit to the ETACS-ECU. Measure the voltage at ETACS-ECU connector C-307. Disconnect ETACS-ECU connector C-307 and measure the voltage available at the wiring harness side of the connector. Measure the voltage between terminal 2 and ground. The voltage should measure approximately 12 volts (battery positive voltage). Q: Is the measured voltage approximately 12 volts (battery positive voltage)? YES : Go to Step 10 . NO : Go to Step 9.
  9. STEP 9. Check the wiring harness between ETACS-ECU connector C-307 (terminal 2) and fusible link (36). Q: Is the wiring harness between ETACS-ECU connector C-307 (terminal 2) and fusible link (36) in good condition? YES : No action is necessary and testing is complete. NO : The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Check that the power window works normally.
  10. STEP 10. Check power window main switch connector E-15 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is power window main switch connector E-15 in good condition? YES : Go to Step 11. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Verify that the power window works normally.
  11. STEP 11. Check the ETACS-ECU connector C-315 line circuit to the power window main switch. Measure the voltage at power window main switch connector E-15. Disconnect power window main switch connector E-15 and measure the voltage available at the wiring harness side of the connector. Measure the voltage between terminal 5 and ground. The voltage should measure approximately 12 volts (battery positive voltage). Q: Is the measured voltage approximately 12 volts (battery positive voltage)? YES : Go to Step 14 . NO : Go to Step 12.
  12. STEP 12. Check ETACS-ECU connector C-315 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is ETACS-ECU connector C-315 in good condition? YES : Go to Step 13. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Verify that the power window works normally.
  13. STEP 13. Check the wiring harness between ETACS-ECU connector C-315 (terminal 10) and power window main switch connector E-15 (terminal 5). NOTE: Also check intermediate connector C-128 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector C-128 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Q: Is the wiring harness between ETACS-ECU connector C-315 (terminal 10) and power window main switch connector E-15 (terminal 5) in good condition? YES : No action is necessary and testing is complete. NO : The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Check that the power window works normally.
  14. STEP 14. Check the ground circuit to the power window main switch. Measure the resistance at power window main switch connector E-15. Disconnect power window main switch connector E-15 and measure the resistance available at the wiring harness side of the connector. Measure the resistance value between terminal 10 and ground. The resistance should be 2 ohms or less. Q: Is the measured resistance 2 ohms or less? YES : Go to Step 16 . NO : Go to Step 15.
  15. STEP 15. Check the wiring harness between power window main switch connector E-15 (terminal 10) and ground. NOTE: Also check intermediate connector C-128 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If intermediate connector C-128 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Q: Is the wiring harness between power window main switch connector E-15 (terminal 10) and ground in good condition? YES : No action is necessary and testing is complete. NO : The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Check that the power window works normally.
  16. STEP 16. Retest the system. Check that the all power windows work. Q: Is the check result normal? YES : No action is necessary and testing is complete. NO : Replace ETACS-ECU. Check that the power window works normally.

INSPECTION PROCEDURE 2: Driver's Power Window does not work by means of The Power Window Main Switch

CAUTIONBefore replacing the ECU, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.

Scheme 45

Scheme 45
Scheme 45
  1. The power window main switch may be defective
  2. The front power window motor (LH) may be defective
  3. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector

Required Special Tools

  1. MB992006: Extra fine probe
  2. MB991223: Harness set
  3. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A
  1. STEP 1. Using scan tool MB991958, read the diagnostic trouble code. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(ref-289389-S36745525782008063000000) ". Turn the ignition switch to the "ON" position. Check whether the power window main switch related DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES : Diagnose the power window main switch. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-289409-S15160603032008063000000) . NO : Go to Step 2.
  2. STEP 2. Check the power window main switch. Check that the passenger's or rear power window works by means of the power window main switch. Q: Is the check result normal? YES : Go to Step 3. NO : Refer to «INSPECTION PROCEDURE 1 "POWER WINDOWS DO NOT WORK AT ALL»(ref-289409-S01410724122008063000000) ".
  3. STEP 3. Check power window main switch connector E-15, front power window motor (LH) connector E-14 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Are power window main switch connector E-15, front power window motor (LH) connector E-14 in good condition? YES : Go to Step 4. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Verify that the power window works normally.
  4. STEP 4. Check the wiring harness between power window main switch connector E-15 (terminals Nos. 2 and 6) and front power window motor (LH) connector E-14 (terminals Nos. 4 and 1). Q: Is the wiring harness between power window main switch connector E-15 (terminals Nos. 2 and 6) and front power window motor (LH) connector E-14 (terminals Nos. 4 and 1) in good condition? YES : Go to Step 5. NO : The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Check that the power works normally.
  5. STEP 5. Retest the system. Check that the driver's power window works by means of the power window main switch. Q: Is the check result normal? YES : No action is necessary and testing is complete. NO : Replace the front power window motor (LH). Check that the power works normally.

INSPECTION PROCEDURE 3: Relevant Power Window(s) does not work by means of The Front and Rear Passenger's Power Window Sub Switches

CAUTIONBefore replacing the ECU, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.

Scheme 46

Scheme 46
Scheme 46

Scheme 47

Scheme 47
Scheme 47

Scheme 48

Scheme 48
Scheme 48
  1. The power window main switch may be defective
  2. The front power window sub switch may be defective
  3. The rear power window sub switches may be defective
  4. The front power window motor (RH) may be defective
  5. The rear power window motors may be defective
  6. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector

Scheme 49

Scheme 49: DIAGNOSTIC PROCEDURE
Scheme 49: DIAGNOSTIC PROCEDURE

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51
Scheme 51

Scheme 52

Scheme 52
Scheme 52

Scheme 53

Scheme 53
Scheme 53

Scheme 54

Scheme 54
Scheme 54

Scheme 55

Scheme 55
Scheme 55

Scheme 56

Scheme 56
Scheme 56

Scheme 57

Scheme 57
Scheme 57

Scheme 58

Scheme 58
Scheme 58
  1. STEP 1. Check the power window lock switch. Q: Is the power window lock switch in the "UNLOCK" position? YES : Go to Step 2. NO : Operate the power window lock switch to the "UNLOCK" position. When the power window sub switch is operated, the power windows should raise and lower normally.
  2. STEP 2. Check power window main switch connector E-15 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is power window main switch connector E-15 in good condition? YES : Go to Step 3. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . When the power window sub switch is operated, the power windows should raise and lower normally.
  3. STEP 3. Determine a trouble spot. Q: Which power window does not work? Front passenger's door : Go to Step 4. Rear left door : Go to Step 13 . Rear right door : Go to Step 22 .
  4. STEP 4. Check front power window sub switch connector E-09 and front power window motor (RH) connector E-10 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Are front power window sub switch connector E-09 and front power window motor (RH) connector E-10 in good condition? YES : Go to Step 5. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . When the front power window sub switch (RH) is operated, the front power window (RH) should raise and lower normally.
  5. STEP 5. Check the front power window sub switch for continuity. Remove the front power window sub switch. Refer to «DOOR GLASS AND REGULATOR»(ref-289409-S15917655512008063000000) . Check continuity when the front power window sub switch is operated to "UP" or "DOWN" position. CONTINUITY CHART Switch position Tester connection Specified condition UP 4 - 5, 6 - 7 Continuity exists (2 ohms or less) OFF 4 - 5, 7 - 8 Continuity exists (2 ohms or less) DOWN 4 - 6, 7 - 8 Continuity exists (2 ohms or less) Q: Is the front power window sub switch normal? YES : Go to Step 6. NO : Replace the front power window sub switch. When the front power window sub switch is operated, the front power window should raise and lower normally.
  6. STEP 6. Check the front power window motor (RH). Remove the front power window regulator (RH). Refer to «DOOR GLASS AND REGULATOR»(ref-289409-S15917655512008063000000) . Connect a battery to the motor terminal, and check that the motor runs freely. BATTERY CONNECTION SLIDER POSITION CHART Battery connection Slider position Connect terminal 1 to the negative battery terminal Connect terminal 4 to the positive battery terminal UP Connect terminal 4 to the negative battery terminal Connect terminal 1 to the positive battery terminal DOWN Q: Is the front power window motor (RH) normal? YES : Go to Step 7. NO : Replace the front power window regulator (RH). When the front power window sub switch (RH) is operated, the front power window (RH) should raise and lower normally.
  7. STEP 7. Check the battery power supply circuit to the front power window sub switch. Measure the voltage at front power window sub switch connector E-09. Disconnect front power window sub switch connector E-09 and measure the voltage available at the wiring harness side of the connector. Measure the voltage between terminal 6 and ground. The voltage should measure approximately 12 volts (battery positive voltage). Q: Is the measured voltage approximately 12 volts (battery positive voltage)? YES : Go to Step 10 . NO : Go to Step 8.
  8. STEP 8. Check ETACS-ECU connector C-315 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is ETACS-ECU connector C-315 in good condition? YES : Go to Step 9. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . When the front power window sub switch (RH) is operated, the front power window (RH) should raise and lower normally.
  9. STEP 9. Check the wiring harness between ETACS-ECU connector C-315 (terminal No. 8) and front power window sub switch connector E-09 (terminal No. 6). NOTE: Also check intermediate connector C-116. If intermediate connector C-116 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Q: Is the wiring harness between ETACS-ECU connector C-315 (terminal No. 8) and front power window sub switch connector E-09 (terminal No. 6) in good condition? YES : No action is necessary and testing is complete. NO : The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. When the front power window sub switch is operated, the front power window (RH) should raise and lower normally.
  10. STEP 10. Check the ground circuit to the front power window sub switch. Measure the resistance at front power window sub switch connector E-09. Disconnect front power window sub switch connector E-09 and measure the resistance available at the wiring harness side of the connector. Measure the resistance value between terminal 5 and ground, and also between terminal 8 and ground. The resistance should be 2 ohms or less. Q: Is the measured resistance 2 ohms or less? YES : Go to Step 12 . NO : Go to Step 11.
  11. STEP 11. Check the wiring harness between power window main switch connector E-15 (terminals Nos. 1 and 3) and front power window sub switch connector E-09 (terminals Nos. 8 and 5). NOTE: Also check intermediate connectors C-116 and C-128. If intermediate connector C-116 or C-128 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Q: Is the wiring harness between power window main switch connector E-15 (terminals Nos. 1 and 3) and front power window sub switch connector E-09 (terminals Nos. 8 and 5) in good condition? YES : Replace the power window main switch. When the front power window sub switch (RH) is operated, the front power window (RH) should raise and lower normally. NO : The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. When the front power window sub switch (RH) is operated, the front power window (RH) should raise and lower normally.
  12. STEP 12. Check the wiring harness between front power window sub switch connector E-09 (terminals Nos. 4 and 7) and front power window motor (RH) connector E-10 (terminals Nos. 1 and 4). Q: Is the wiring harness between front power window sub switch connector E-09 (terminals Nos. 4 and 7) and front power window motor (RH) connector E-10 (terminals Nos. 1 and 4) in good condition? YES : No action is necessary and testing is complete. NO : The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. When the front power window sub switch (RH) is operated, the front power window (RH) should raise and lower normally.
  13. STEP 13. Check rear power window sub switch (LH) connector E-24 and rear power window motor (LH) connector E-25 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Are rear power window sub switch (LH) connector E-24 and rear power window motor (LH) connector E-25 in good condition? YES : Go to Step 14. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . When the rear power window sub switch (LH) is operated, the rear power window (LH) should raise and lower normally.
  14. STEP 14. Check the rear power window sub switch (LH) for continuity. Remove the rear power window sub switch (LH). Refer to «DOOR GLASS AND REGULATOR»(ref-289409-S15917655512008063000000) . Check continuity when the rear power window sub switch (LH) is operated to "UP" or "DOWN" position. TESTER CONNECTION SPECIFIED CONDITION Switch position Tester connection Specified condition UP 4 - 5, 6 - 7 Continuity exists (2 ohms or less) OFF 4 - 5, 7 - 8 Continuity exists (2 ohms or less) DOWN 4 - 6, 7 - 8 Continuity exists (2 ohms or less) Q: Is the rear power window sub switch (LH) normal? YES : Go to Step 15. NO : Replace the rear power window sub switch (LH). When the rear power window sub switch (LH) is operated, the rear power window (LH) should raise and lower normally.
  15. STEP 15. Check the rear power window motor (LH). Remove the rear power window regulator (LH). Refer to «DOOR GLASS AND REGULATOR»(ref-289409-S15917655512008063000000) . Connect a battery to the motor terminal, and check that the motor runs freely. BATTERY CONNECTION SLIDER POSITION CHART Battery connection Slider position Connect terminal 4 to the negative battery terminal Connect terminal 1 to the positive battery terminal UP Connect terminal 1 to the negative battery terminal Connect terminal 4 to the positive battery terminal DOWN Q: Is the rear power window motor (LH) normal? YES : Go to Step 16. NO : Replace the rear power window regulator (LH). When the rear power window sub switch (LH) is operated, the rear power window (LH) should raise and lower normally.
  16. STEP 16. Check the battery power supply circuit to the rear power window sub switch (LH). Measure the voltage at rear power window sub switch (LH) connector E-24. Disconnect rear power window sub switch (LH) connector E-24 and measure the voltage available at the wiring harness side of the connector. Measure the voltage between terminal 6 and ground. The voltage should measure approximately 12 volts (battery positive voltage). Q: Is the measured voltage approximately 12 volts (battery positive voltage)? YES : Go to Step 19 . NO : Go to Step 17.
  17. STEP 17. Check ETACS-ECU connector C-311 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is ETACS-ECU connector C-311 in good condition? YES : Go to Step 18. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . When the rear power window sub switch (LH) is operated, the rear power window (LH) should raise and lower normally.
  18. STEP 18. Check the wiring harness between ETACS-ECU connector C-311 (terminal No. 12) and rear power window sub switch (LH) connector E-24 (terminal No. 6). NOTE: Also check joint connector (5) D-27, intermediate connector D-24. If joint connector (5) D-27, intermediate connector D-24 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Q: Is the wiring harness between ETACS-ECU connector C-311 (terminal No. 12) and rear power window sub switch (LH) connector E-24 (terminal No. 6) in good condition? YES : No action is necessary and testing is complete. NO : The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. When the rear power window sub switch (LH) is operated, the rear power window (LH) should raise and lower normally.
  19. STEP 19. Check the ground circuit to the rear power window sub switch (LH). Measure the resistance at rear power window sub switch (LH) connector E-24. Disconnect rear power window sub switch (LH) connector E-24 and measure the resistance available at the wiring harness side of the connector. Measure the resistance value between terminal 5 and ground, and also between terminal 8 and ground. The resistance should be 2 ohms or less. Q: Is the measured resistance 2 ohms or less? YES : Go to Step 21 . NO : Go to Step 20.
  20. STEP 20. Check the wiring harness between power window main switch connector E-15 (terminals Nos. 18 and 19) and rear power window sub switch (LH) connector E-24 (terminals Nos. 5 and 8). NOTE: Also check intermediate connectors C-42, C-128 and D-24. If intermediate connectors C-42, C-128 or D-24 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Q: Is the wiring harness between power window main switch connector E-15 (terminals Nos. 18 and 19) and rear power window sub switch (LH) connector E-24 (terminals Nos. 5 and 8) in good condition? YES : Replace the power window main switch. When the rear power window sub switch (LH) is operated, the rear power window (LH) should raise and lower normally. NO : The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. When the rear power window sub switch (LH) is operated, the rear power window (LH) should raise and lower normally.
  21. STEP 21. Check the wiring harness between rear power window sub switch (LH) connector E-24 (terminals Nos. 4 and 7) and rear power window motor (LH) connector E-25 (terminals Nos. 4 and 1). Q: Is the wiring harness between rear power window sub switch (LH) connector E-24 (terminals Nos. 4 and 7) and rear power window motor (LH) connector E-25 (terminals Nos. 4 and 1) in good condition? YES : Replace the power window main switch. When the rear power window sub switch (LH) is operated, the rear power window (LH) should raise and lower normally. NO : The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. When the rear power window sub switch (LH) is operated, the rear power window (LH) should raise and lower normally.
  22. STEP 22. Check rear power window sub switch (RH) connector E-21 and rear power window motor (RH) connector E-20 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Are rear power window sub switch (RH) connector E-21 and rear power window motor (RH) connector E-20 in good condition? YES : Go to Step 23. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . When the rear power window sub switch (RH) is operated, the rear power window (RH) should raise and lower normally.
  23. STEP 23. Check the rear power window sub switch (RH) for continuity. Remove the rear power window sub switch (RH). Refer to «DOOR GLASS AND REGULATOR»(ref-289409-S15917655512008063000000) . Check continuity when the rear power window sub switch (RH) is operated to "UP" or "DOWN" position. CONTINUITY CHART Switch position Tester connection Specified condition UP 4 - 5, 6 - 7 Continuity exists (2 ohms or less) OFF 4 - 5, 7 - 8 Continuity exists (2 ohms or less) DOWN 4 - 6, 7 - 8 Continuity exists (2 ohms or less) Q: Is the rear power window sub switch (RH) normal? YES : Go to Step 24. NO : Replace the rear power window sub switch (RH). When the rear power window sub switch (RH) is operated, the rear power window (RH) should raise and lower normally.
  24. STEP 24. Check the rear power window motor (RH). Remove the rear power window regulator (RH). Refer to «DOOR GLASS AND REGULATOR»(ref-289409-S15917655512008063000000) . Connect a battery to the motor terminal, and check that the motor runs freely. BATTERY CONNECTION SLIDER POSITION CHART Battery connection Slider position Connect terminal 4 to the negative battery terminal Connect terminal 1 to the positive battery terminal UP Connect terminal 1 to the negative battery terminal Connect terminal 4 to the positive battery terminal DOWN Q: Is the rear power window motor (RH) normal? YES : Go to Step 25. NO : Replace the rear power window regulator (RH). When the rear power window sub switch (RH) is operated, the rear power window (RH) should raise and lower normally.
  25. STEP 25. Check the battery power supply circuit to the rear power window sub switch (RH). Measure the voltage at rear power window sub switch (RH) connector E-21. Disconnect rear power window sub switch (RH) connector E-21 and measure the voltage available at the wiring harness side of the connector. Measure the voltage between terminal 6 and ground. The voltage should measure approximately 12 volts (battery positive voltage). Q: Is the measured voltage approximately 12 volts (battery positive voltage)? YES : Go to Step 28 . NO : Go to Step 26.
  26. STEP 26. Check ETACS-ECU connector C-311 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is ETACS-ECU connector C-311 in good condition? YES : Go to Step 27. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . When the rear power window sub switch (RH) is operated, the rear power window (RH) should raise and lower normally.
  27. STEP 27. Check the wiring harness between ETACS-ECU connector C-311 (terminal No. 12) and rear power window sub switch (RH) connector E-21 (terminal No. 6). NOTE: Also check joint connector (5) D-27, intermediate connector D-01. If joint connector (5) D-27, intermediate connector D-01 is damaged, repair or replace the connector as described in «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Q: Is the wiring harness between ETACS-ECU connector C-311 (terminal No. 12) and rear power window sub switch (RH) connector E-21 (terminal No. 6) in good condition? YES : No action is necessary and testing is complete. NO : The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. When the rear power window sub switch (RH) is operated, the rear power window (RH) should raise and lower normally.
  28. STEP 28. Check the ground circuit to the rear power window sub switch (RH). Measure the resistance at rear power window sub switch (RH) connector E-21. Disconnect rear power window sub switch (RH) connector E-21 and measure the resistance available at the wiring harness side of the connector. Measure the resistance value between terminal 5 and ground, and also between terminal 8 and ground. The resistance should be 2 ohms or less. Q: Is the measured resistance 2 ohms or less? YES : Go to Step 30 . NO : Go to Step 29.
  29. STEP 29. Check the wiring harness between power window main switch connector E-15 (terminals Nos. 15 and 17) and rear power window sub switch (RH) connector E-21 (terminals Nos. 5 and 8). NOTE: Also check intermediate connectors C-23, C-128 and D-01. If intermediate connectors C-23, C-128 or D-01 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Q: Is the wiring harness between power window main switch connector E-15 (terminals 15 and 17) and rear power window sub switch (RH) connector E-21 (terminals 5 and 8) in good condition? YES : Replace the power window main switch. When the rear power window sub switch (RH) is operated, the rear power window (RH) should raise and lower normally. NO : The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. When the rear power window sub switch (RH) is operated, the rear power window (RH) should raise and lower normally.
  30. STEP 30. Check the wiring harness between rear power window sub switch (RH) connector E-21 (terminals Nos. 4 and 7) and rear power window motor (RH) connector E-20 (terminals Nos. 4 and 1). Q: Is the wiring harness between rear power window sub switch (RH) connector E-21 (terminals Nos. 4 and 7) and rear power window motor (RH) connector E-20 (terminals Nos. 4 and 1) in good condition? YES : No action is necessary and testing is complete. NO : The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. When the rear power window sub switch (RH) is operated, the rear power window (RH) should raise and lower normally.

INSPECTION PROCEDURE 4: Front and/or Rear Passenger's Power Window(s) do not work by means of The Power Window Main Switch

CAUTIONBefore replacing the ECU, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.

Scheme 59

Scheme 59
Scheme 59

TROUBLESHOOTING HINT

  1. The power window main switch may be defective
  2. The front power window sub switch may be defective
  3. The rear power window sub switches may be defective
  4. The ETACS-ECU may be defective
  5. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector

Required Special Tools

  1. MB992006: Extra fine probe
  2. MB991223: Harness set
  3. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A (Vehicles with CAN communication system)

Scheme 60

Scheme 60
Scheme 60
  1. STEP 1. Check the power window main switch. Check that the driver's power window works by means of the power window main switch. Q: Is the check result normal? YES : Go to Step 2. NO : Refer to «INSPECTION PROCEDURE 2 "DRIVER'S POWER WINDOW DOES NOT WORK BY MEANS OF THE POWER WINDOW MAIN SWITCH»(ref-289409-S41994566822008063000000) ".
  2. STEP 2. Check the power window sub switch. Check that each power window works by means of the respective power window sub switch when the power window lock switch is turned off. Q: Is the check result normal? YES : Go to Step 3. NO : Refer to «INSPECTION PROCEDURE 3 "RELEVANT POWER WINDOW(S) DOES NOT WORK BY MEANS OF THE FRONT AND REAR PASSENGER'S POWER WINDOW SUB SWITCHES»(ref-289409-S17262769782008063000000) ".
  3. STEP 3. Check the power supply system. With the ignition switch in the LOCK (OFF) position, check if the following function operates normally: Hazard warning light Q: Is the check result normal? YES : Go to Step 4. NO : Refer to «MALFUNCTION OF ETACS-ECU POWER SUPPLY CIRCUIT»(ref-289392-S39748373222008063000000) .
  4. STEP 4. Using scan tool MB991958, read the diagnostic trouble code. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(ref-289389-S36745525782008063000000) ". Turn the ignition switch to the "ON" position. Check whether the ETACS-ECU related DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES : Diagnose the ETACS-ECU. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-289416-S29060959692008063000000) . NO : Go to Step 5.
  5. STEP 5. Check power window main switch connector E-15 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is power window main switch connector E-15 in good condition? YES : Go to Step 6. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . When the power window main switch is operated, the front and/or rear passenger's power windows should raise and lower normally.
  6. STEP 6. Check the ETACS-ECU connector C-315 line circuit to the power window main switch. Measure the voltage at power window main switch connector E-15. Disconnect power window main switch connector E-15 and measure the voltage available at the wiring harness side of the connector. Measure the voltage between terminal 4 and ground. The voltage should measure approximately 12 volts (battery positive voltage). Q: Is the measured voltage approximately 12 volts (battery positive voltage)? YES : Go to Step 9 . NO : Go to Step 7.
  7. STEP 7. Check ETACS-ECU connector C-315 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is ETACS-ECU connector C-315 in good condition? YES : Go to Step 8. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . When the When the power window main switch is operated, the front and/or rear passenger's power windows should raise and lower normally.
  8. STEP 8. Check the wiring harness between ETACS-ECU connector C-315 (terminal No. 8) and power window main switch connector E-15 (terminal No. 4). NOTE: Also check intermediate connector C-128. If intermediate connector C-128 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Q: Is the wiring harness between ETACS-ECU connector C-315 (terminal No. 8) and power window main switch connector E-15 (terminal No. 4) in good condition? YES : No action is necessary and testing is complete. NO : The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. When the When the power window main switch is operated, the front and/or rear passenger's power windows should raise and lower normally.
  9. STEP 9. Retest the system. Replace the power window main switch. Check that the front and/or rear passenger's power windows work by means of the power window main switch. Q: Is the check result normal? YES : No action is necessary and testing is complete. NO : Replace ETACS-ECU. Check that the power window works normally.

INSPECTION PROCEDURE 5: The Power Window Timer Function does not work Normally

CAUTIONBefore replacing the ECU, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.

If the power window timer does not work normally, a malfunction of the power window main switch or ETACS-ECU is suspected.

Required Special Tools

  1. MB992006: Extra fine probe
  2. MB991223: Harness set
  3. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A
  1. STEP 1. Check the power supply system. With the ignition switch in the LOCK (OFF) position, check if the following function operates normally: Hazard warning lamp Q: Is the check result normal? YES : Go to Step 2. NO : Refer to «MALFUNCTION OF ETACS-ECU POWER SUPPLY CIRCUIT»(ref-289392-S39748373222008063000000) .
  2. STEP 2. Using scan tool MB991958, check data list. Check the signals related to the power window timer function operation. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(ref-289389-S36745525782008063000000) ". Turn the ignition switch to the "ON" position. Check the data list of the ETACS. Turn the ignition switch to the LOCK (OFF) position. Close the driver's door. Close the passenger's door. VOLTAGE REFERENCE CHART Item No. Item name Normal condition 254 IG voltage Battery voltage 256 Dr door ajar switch Close 257 As door ajar switch Close Turn the ignition switch to the "LOCK" (OFF) position. OK: Normal condition is displayed. Q: Is the check result normal? YES < Normal conditions are displayed for all the items. > : Go to Step 3. NO < Normal condition is not displayed for item No. 254. > : Refer to «INSPECTION PROCEDURE 2: "THE IGNITION SWITCH (IG1) SIGNAL IS NOT RECEIVED»(ref-289392-S05543681702008063000000) ". NO < Normal condition is not displayed for item No. 256. > : Refer to «INSPECTION PROCEDURE 5: "THE FRONT DOOR SWITCH (DRIVER'S SIDE) SIGNAL IS NOT RECEIVED»(ref-289392-S20622045972008063000000) ". NO < Normal condition is not displayed for item No. 257. > : Refer to «INSPECTION PROCEDURE 6: THE FRONT DOOR SWITCH (PASSENGER'S SIDE) SIGNAL IS NOT RECEIVED.»(ref-289392-S09465174222008063000000) .
  3. STEP 3. Retest the system. Check that the power window timer function works normally. Q: Is the check result normal? YES : No action is necessary and testing is complete. NO : Replace the power window main switch. Check that the power window timer function works normally.

Malfunction of the power window motor revolution detection sensor is suspected.

Required Special Tools

  1. MB992006: Extra fine probe
  2. MB991223: Harness set
  3. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A
  1. STEP 1. Using scan tool MB991958, read the diagnostic trouble code. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(ref-289389-S36745525782008063000000) ". Turn the ignition switch to the "ON" position. Check whether the power window main switch related DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES : Diagnose the power window main switch. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-289409-S15160603032008063000000) . NO : Go to Step 2.
  2. STEP 2. Check the power window operating current. Check that the power window operating current is normal (Refer to «POWER WINDOW OPERATING CURRENT CHECK»(ref-289409-S02889585732008063000000) ). Q: Is the check result normal? YES : Door window glass adjustment (Refer to «DOOR WINDOW GLASS ADJUSTMENT»(ref-289409-S21389429512008063000000) ). Then go to Step 3. NO : Replace the power window motor. Verify that the power window anti-trap function works normally.
  3. STEP 3. Confirm the power window learning function. Check that the power window switch has learned the fully closed position of the windows. Q: Is the check result normal? YES : Go to Step 4. NO : Make the power window switch learn the fully closed position of the windows (Refer to «LEARNING PROCEDURES OF THE POWER WINDOW FULLY CLOSED POSITION < DRIVER'S SIDE >»(ref-289409-S24524489632008063000000) ). Verify that the power window anti-trap function works normally.
  4. STEP 4. Retest the system. Check that the power window anti-trap function works. Q: Is the check result normal? YES : No action is necessary and testing is complete. NO : Replace the front power window motor (LH). Verify that the power window anti-trap function works normally.

If the sliding resistance is too great when the window is being raised or the window glass encounters an object, the window glass will lower by approximately 150 mm (5.9 inches).

  1. STEP 1. Determine a trouble spot. Q: Which type of the power window is installed on vehicle? Driver's side seat : Go to Step 2. Except driver's side seat : Go to Step 3 ..
  2. STEP 2. Check the power window anti-trap function. Check that the power window anti-trap function works. Refer to «POWER WINDOW SAFETY MECHANISM CHECK < DRIVER'S SIDE >»(ref-289409-S15751237572008063000000) . Q: Is the check result normal? YES : Go to Step 3. NO : Refer to «INSPECTION PROCEDURE 6 "POWER WINDOW ANTI-TRAP FUNCTION DOES NOT WORK NORMALLY»(ref-289409-S01972849662008063000000) ".
  3. STEP 3. Check that the door window glasses are installed correctly. Check that the door window glasses are installed correctly. Refer to «DOOR WINDOW GLASS ADJUSTMENT»(ref-289409-S21389429512008063000000) . Q: Is the check result normal? YES : Go to Step 4. NO : Adjust the door window glass (Refer to «DOOR WINDOW GLASS ADJUSTMENT»(ref-289409-S21389429512008063000000) ).
  4. STEP 4. Retest the system. Check that the power window does not lower while it is being raised. Q: Is the check result normal? YES : No action is necessary and testing is complete. NO : Replace the power window motor of the defective window.

Scheme 61

Scheme 61: POWER WINDOW MAIN SWITCH
Scheme 61: POWER WINDOW MAIN SWITCH
Terminal No.Check itemsCheck conditionsNormal conditions
1Output to power window motor (Passenger's side)
2Output to power window motor (Driver's side)
3Output to power window motor (Passenger'side)
4Power supplyPower window relay: ONBattery voltage
5Power supplyAlwaysBattery voltage
6Output to power window motor (Driver's side)
7LIN communication line (between ETACS-ECUs)Always0 to 12 V (pulse signal)
8Input from power window motor (pulse sensor signal)When the power windows are operating0 to 5 V (pulse signal)
9Input from power window motor (pulse sensor ground)0 V
10GroundAlways0 V
11Input from power window motor (pulse sensor signal)When the power windows are operating0 to 5 V (pulse signal)
12Input from power window motor (power supply to pulse sensor)When the power windows are operating5 V
13
14
15Output to power window motor (Rear right side)
16
17Output to power window motor (Rear right side)
18Output to power window motor (Rear left side)
19Output to power window motor (Rear left side)

CONNECTOR TERMINAL REFERENCE CHART

GLASS AND DOOR DIAGNOSTIC TROUBLESHOOTING STRATEGY

Use these steps to plan your diagnostic strategy. If you follow them carefully, you will be sure that you have exhausted most of the possible ways to find a glass and door fault.

  1. Gather information from the customer.
  2. Verify that the condition described by the customer exists.
  3. Find the malfunction by following the Symptom Chart.
  4. Verify malfunction is eliminated.

SYMPTOM CHART

SymptomReference page
Water leak through door window glassINSPECTION PROCEDURE 1: WATER LEAK THROUGH DOOR WINDOW GLASS
Door window malfunctionINSPECTION PROCEDURE 2: DOOR WINDOW GLASS MALFUNCTION
Water leak through door edgeINSPECTION PROCEDURE 3: WATER LEAK THROUGH DOOR EDGE
Water leak from door centerINSPECTION PROCEDURE 4: WATER LEAK FROM DOOR CENTER
Door hard to openINSPECTION PROCEDURE 5: DOOR HARD TO OPEN
Door does not open or close completelyINSPECTION PROCEDURE 6: DOOR DOES NOT OPEN OR CLOSE COMPLETELY
Uneven gap between bodyINSPECTION PROCEDURE 7: UNEVEN GAP BETWEEN BODY
Wind noise around doorINSPECTION PROCEDURE 8: WIND NOISE AROUND DOOR

SYMPTOM CHART

  1. STEP 1. Check the door window glass installation. Q: Is the door window glass installed correctly? YES : Go to Step 2. NO : Assemble the door window glass again. Refer to «DOOR ASSEMBLY»(ref-289409-S03792750902008063000000) . Then go to Step 3 .
  2. STEP 2. Check the clearance at the top of the door window glass. Q: Is the clearance at the top of the door window glass correct? YES : Go to Step 3. NO : Adjust the door window glass. Refer to «DOOR WINDOW GLASS ADJUSTMENT»(ref-289409-S21389429512008063000000) . Then go to Step 3.
  3. STEP 3. Retest the system. Q: Is any water leaking? YES : Return to Step 1 . NO : The procedure is complete.
  1. STEP 1. Check the door window glass installation condition. Q: Is the door window glass installed correctly? YES : Go to Step 2. NO : Assemble the door window glass again. (Refer to «DOOR GLASS AND REGULATOR»(ref-289409-S15917655512008063000000) .) Then go to Step 4 .
  2. STEP 2. Check the door sash. Q: Is the door sash in good condition? YES : Go to Step 3. NO : Repair or replace the door sash, then go to Step 4 .
  3. STEP 3. Inspect the window regulator assembly. Q: Is the window regulator assembly in good condition? YES : Go to Step 4. NO : Repair or replace the window regulator assembly, then go to Step 4.
  4. STEP 4. Retest the system. Q: Does the door window glass operate correctly? YES : The procedure is complete. NO : Return to Step 1 .
  1. STEP 1. Check the weatherstrip. Q: Is the weatherstrip in good condition? YES : Go to Step 2. NO : Replace the weatherstrip, then go to Step 3 .
  2. STEP 2. Check the door fit (alignment). Q: Is the door fit (alignment) correct? YES : Go to Step 3. NO : Adjust the door fit. Refer to «DOOR FIT ADJUSTMENT»(ref-289409-S37992549312008063000000) . Then go to Step 3.
  3. STEP 3. Retest the system. Q: Is any water leaking? YES : Return to Step 1 . NO : The procedure is complete.
  1. STEP 1. Check the drain hole. Q: Is the drain hole clogged? YES : Clean the drain hole, then go to Step 3 . NO : Go to Step 2.
  2. STEP 2. Check the weatherstrip. Q: Is the weatherstrip in good condition? YES : Go to Step 3. NO : Repair or replace the weatherstrip, then go to Step 3.
  3. STEP 3. Retest the system. Q: Is any water leaking? YES : Return to Step 1 . NO : The procedure is complete.
  1. STEP 1. Adjust the latch and striker engagement. Refer to «DOOR FIT ADJUSTMENT»(ref-289409-S37992549312008063000000) . Q: Is the latch and striker engagement adjusted? YES : Go to Step 2. NO : Adjust the latch and striker. Refer to «DOOR FIT ADJUSTMENT»(ref-289409-S37992549312008063000000) . Then go to Step 4 .
  2. STEP 2. Check for lock rod damage. Q: Is the lock rod damaged? YES : Repair or replace the lock rod, then go to Step 4 . NO : Go to Step 3.
  3. STEP 3. Check the door handle flexibility (amount of movement of handle required to open door). Q: Is the door handle flexibility good? YES : Go to Step 4. NO : Adjust the door handle. Refer to «DOOR OUTSIDE HANDLE PLAY CHECK»(ref-289409-S20230751232008063000000) and «DOOR INSIDE HANDLE CHECK»(ref-289409-S19010765252008063000000) . Then go to Step 4.
  4. STEP 4. Retest the system. Q: Does the door open easily? YES : The procedure is complete. NO : Return to Step 1 .
  1. STEP 1. Check the door hinge position. Q: Is the door hinge correct? YES : Go to Step 2. NO : Adjust the door hinge. Refer to «DOOR FIT ADJUSTMENT»(ref-289409-S37992549312008063000000) . Then go to Step 4 .
  2. STEP 2. Check the door. Q: Is the door in good condition? YES : Go to Step 3. NO : Repair or replace door, then go to Step 4 .
  3. STEP 3. Check the grease. Q: Is the door check or door hinge grease sufficient? YES : Go to Step 4. NO : Apply the grease, then go to Step 4.
  4. STEP 4. Retest the system. Q: Does the door open and close correctly? YES : The procedure is complete. NO : Return to Step 1 .

Adjust the door fit. Refer to DOOR FIT ADJUSTMENT . Then check that the gap has been improved.

  1. STEP 1. Check the weatherstrip for holding condition. Q: Is the weatherstrip holding firmly? YES : Go to Step 2. NO : Adjust fit of door. Refer to «POWER WINDOW CHECK»(ref-289409-S37531005752008063000000) . Then go to Step 5 .
  2. STEP 2. Check the weatherstrip for installation condition. Q: Is the weatherstrip for installed properly? YES : Go to Step 3. NO : Repair or replace the weatherstrip. Then go to Step 5 .
  3. STEP 3. Check the clearance. Q: Are the door glass and the door weatherstrip holder assembled correctly? YES : Go to Step 4. NO : Adjust the door glass and the door weatherstrip. Refer to «GLASS SLIDING MECHANISM CHECK AND ADJUSTMENT»(ref-289409-S09314165262008063000000) . Then go to Step 5 .
  4. STEP 4. Check the door. Q: Is the door deformed? YES : Repair or replace the door. then go to Step 5. NO : Go to Step 5.
  5. STEP 5. Retest the system. Q: Has the wind noise been improved? YES : Return to Step 1 . NO : This diagnosis complete.

Scheme 62

Scheme 62: HOW TO LOCATE WIND NOISE
Scheme 62: HOW TO LOCATE WIND NOISE

Scheme 63

Scheme 63
Scheme 63

Scheme 64

Scheme 64
Scheme 64

Scheme 65

Scheme 65
Scheme 65
  1. Attach cloth tape to every place, such as panel seams, projections, molding seams, glass and body seams, etc. which might conceivably be the source of wind noise.
  2. Then make a road test to check that the places not covered by tape are not sources of wind noise.
  3. Remove the strips of tape one by one, making a road test after each is removed, until a wind noise source is discovered.
  4. When such a place is found, cover it again and repeat the procedure to check if there are any other noise source.
  5. If no others are found, the last remaining tape is the only source.
  6. Cut the remaining piece of tape into smaller pieces, attach it again as it was before, and then remove the pieces one by one to narrow down the source.
  7. Check that wind noise occurs when the last remaining tape is removed, and that noise does not occur when it is re-attached.
  8. When the source(s) of the wind noise is finally located, attach butyl tape, body sealer or similar material to obstruct this source as much as possible.

TRUNK LID DIAGNOSTIC TROUBLESHOOTING STRATEGY

Use these steps to plan your diagnostic strategy. If you follow them carefully, you will be sure that you have exhausted most of the possible ways to find a trunk lid fault.

  1. Gather information from the customer.
  2. Verify that the condition described by the customer exists.
  3. Find the malfunction by following the Symptom Chart.
  4. Verify malfunction is eliminated.
SymptomReference page
Difficult locking and unlockingINSPECTION PROCEDURE 1: DIFFICULT LOCKING AND UNLOCKING
Uneven body clearanceINSPECTION PROCEDURE 2: UNEVEN BODY CLEARANCE
Uneven heightINSPECTION PROCEDURE 3: UNEVEN HEIGHT

TROUBLE SYMPTOM CHART

  1. STEP 1. Check the release cable routing condition. Q: Is the release cable routing condition good? YES : Go to Step 3 . NO : Repair the release cable routing, then go to Step 2.
  2. STEP 2. Check the engagement of the trunk lid latch and trunk lid striker. Q: Are the trunk lid latch and trunk lid striker engaged correctly? YES : Then go to Step 3. NO : Adjust the trunk lid striker. Refer to «TRUNK LID STRIKER ADJUSTMENT»(ref-289409-S39905701012008063000000) .
  3. STEP 3. Retest the system. Q: Does the trunk lid lock operate easily? YES : The procedure is complete. NO : Return to Step 1 .
  1. STEP 1. Check the clearance around the trunk lid.. Q: Are the apertures between the trunk lid and the adjacent body panels aligned correctly? YES : Then go to Step 2. NO : Adjust the trunk lid panel assembly. Refer to «ADJUSTMENT OF CLEARANCE AROUND TRUNK LID»(ref-289409-S42458946142008063000000) .
  2. STEP 2. Retest the system. Q: Are the clearances between the body panels even? YES : The procedure is complete. NO : Return to Step 1 .
  1. STEP 1. Check the trunk lid height. Q: Is the trunk lid hinge height proper? YES : Then go to Step 2. NO : Adjust the trunk lid hinge. Refer to «ADJUSTMENT AT TRUNK LID HINGE-SIDE»(ref-289409-S38629869772008063000000) .
  2. STEP 2. Retest the system. Q: Are the trunk lid and body height even? YES : The procedure is complete. NO : Return to Step 1 .

Refer to TROUBLESHOOTING CONTENTS .

CAUTIONOn troubleshooting, if the ignition switch is turned ON while disconnecting connector(s), diagnostic trouble code(s) associated with other system may be set. On completion, check all systems for diagnostic trouble code(s). If diagnostic trouble code(s) are set, erase them all.
Diagnosis Code No.Diagnostic item
L0630S/R Power supply
L0632S/R Switch fail
L0634S/R Sensor signal
L0637S/R Position
L0640S/R Over load

DIAGNOSTIC TROUBLE CODE CHART

Note. S/R: Abbreviation of sunroof

CAUTIONDuring diagnosis, a diagnostic trouble code associated with other system may be set when the ignition switch is turned on with connector(s) disconnected. On completion, check all systems for diagnostic trouble code(s). If diagnostic trouble code(s) are set, erase them all.
Trouble symptomReference page
Sunroof does not work at all.INSPECTION PROCEDURE 1: SUNROOF DOES NOT WORK AT ALL.
The sunroof lid glass does not tilt-up (tilt-down, open, and close normally).INSPECTION PROCEDURE 2: THE SUNROOF LID GLASS DOES NOT TILT-UP (TILT-DOWN, OPEN, AND CLOSE NORMALLY).
The sunroof lid glass does not open (tilt-up, tilt-down, and close normally).INSPECTION PROCEDURE 3: THE SUNROOF LID GLASS DOES NOT OPEN (TILT-UP, TILT-DOWN, AND CLOSE NORMALLY).
The sunroof lid glass does not tilt-down or close (tilt-up and open normally).INSPECTION PROCEDURE 4: THE SUNROOF LID GLASS DOES NOT TILT-DOWN OR CLOSE (TILT-UP AND OPEN NORMALLY).
Sunroof safety function does not work.INSPECTION PROCEDURE 5: SUNROOF SAFETY FUNCTION DOES NOT WORK NORMALLY.
Sunroof timer lock function does not work.INSPECTION PROCEDURE 6: THE SUNROOF TIMER FUNCTION DOES NOT WORK.

TROUBLE SYMPTOM CHART

When the terminal voltage of the sunroof motor assembly is 8 V or less, or 18 V or more, and if it continues for 60 seconds, the sunroof motor assembly will set the diagnostic trouble code No. L0630.

  1. STEP 1. Check sunroof motor assembly connector D-06 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is sunroof switch connector D-06 in good condition? YES : Go to Step 2. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Check that the sunroof works normally.
  2. STEP 2. Check the wiring harness between sunroof motor assembly connector D-06 (terminal 6) and fusible link (34). NOTE: Also check ETACS-ECU connectors C-309 and C-316 for loose, corroded, or damaged terminals, or terminals pushed back in the connector. If ETACS-ECU connectors C-309 and C-316 is damaged, repair or replace the damaged component(s) as described in «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Q: Is the wiring harness between sunroof motor assembly connector D-06 (terminal 6) and fusible link (34) in good condition? YES : Go to Step 3. NO : The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Check that the sunroof works normally.
  3. STEP 3. Diagnostic trouble code recheck Recheck if the diagnostic trouble code is set. Erase the diagnostic trouble code. Turn the ignition switch from the LOCK (OFF) position to the ON position. Check if the diagnostic trouble code is set. Q: Is the diagnostic trouble code set? YES : Replace the sunroof motor assembly. NO : The procedure is complete.

If each switch (UP, OPEN, CLOSE/DOWN) of the sunroof switch is in the ON status for 60 seconds, the sunroof motor assembly will set the diagnostic trouble code No. L0632.

  1. STEP 1. Check sunroof switch connector D-05 and sunroof motor assembly D-06 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Are sunroof switch connector D-05 and sunroof motor assembly D-06 in good condition? YES : Go to Step 2. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Check that the sunroof works normally.
  2. STEP 2. Check the wiring harness between sunroof switch connector D-05 (terminals No. 3, 5, 6) and sunroof motor assembly connector D-06 (terminals No. 4, 5, 10). Q: Is the wiring harness between sunroof switch connector D-05 (terminal 3, 5, 6) and sunroof motor assembly connector D-06 (terminal No. 4, 5, 10) in good condition? YES : Go to Step 3. NO : The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Check that the sunroof works normally.
  3. STEP 3. Diagnostic trouble code recheck Replace the sunroof switch. Recheck if the diagnostic trouble code is set. Erase the diagnostic trouble code. Turn the ignition switch from the LOCK (OFF) position to the ON position. Check if the diagnostic trouble code is set. Q: Is the diagnostic trouble code set? YES : Replace the sunroof motor assembly. NO : The procedure is complete.

If one of two signals from the sunroof lid glass position detection sensor cannot be detected, the sunroof motor assembly will set the diagnostic trouble code No. L0634.

Diagnostic trouble code recheck

Recheck if the diagnostic trouble code is set.

  1. Erase the diagnostic trouble code.
  2. Turn the ignition switch from the LOCK (OFF) position to the ON position.
  3. Check if the diagnostic trouble code is set.

Q: Is the diagnostic trouble code set?

YES : Replace the sunroof motor assembly.

NO : The procedure is complete.

If the roof lid glass position is out of the specified range, ETACS-ECU will set the diagnostic trouble code No. L0637.

  1. STEP 1. Check the sunroof fully closed position Carry out the learning procedures of the sunroof fully closed position. Refer to «LEARNING PROCEDURES OF THE SUNROOF FULLY CLOSED POSITION»(ref-289409-S29538099092008063000000) . Recheck if the diagnostic trouble code is set. Erase the diagnostic trouble code. Turn the ignition switch from the LOCK (OFF) position to the ON position. Check if the diagnostic trouble code is set. Q: Is the check result normal? YES : The procedure is complete. NO : Go to Step 2.
  2. STEP 2. Diagnostic trouble code recheck Recheck if the diagnostic trouble code is set. Erase the diagnostic trouble code. Turn the ignition switch from the LOCK (OFF) position to the ON position. Check if the diagnostic trouble code is set. Q: Is the diagnostic trouble code set? YES : Replace the sunroof motor assembly. NO : The procedure is complete.

If the over load (foreign material pinched) is detected consecutively five times during a sunroof operation, ETACS-ECU will set the diagnostic trouble code No. L0640.

  1. STEP 1. Check the sunroof fully closed position Carry out the learning procedures of the sunroof fully closed position. Refer to «LEARNING PROCEDURES OF THE SUNROOF FULLY CLOSED POSITION»(ref-289409-S29538099092008063000000) . Recheck if the diagnostic trouble code is set. Erase the diagnostic trouble code. Turn the ignition switch from the LOCK (OFF) position to the ON position. Check if the diagnostic trouble code is set. Q: Is the check result normal? YES : The procedure is complete. NO : Go to Step 2.
  2. STEP 2. Diagnostic trouble code recheck Recheck if the diagnostic trouble code is set. Erase the diagnostic trouble code. Turn the ignition switch from the LOCK (OFF) position to the ON position. Check if the diagnostic trouble code is set. Q: Is the diagnostic trouble code set? YES : Replace the sunroof motor assembly. NO : The procedure is complete.

INSPECTION PROCEDURE 1: Sunroof does not work at All

CAUTIONBefore replacing the ECU, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.

Scheme 66

Scheme 66
Scheme 66

Required Special Tools

  1. MB992006: Extra fine probe
  2. MB991223: Harness set
  3. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A

Scheme 67

Scheme 67
Scheme 67

Scheme 68

Scheme 68
Scheme 68

Scheme 69

Scheme 69
Scheme 69

Scheme 70

Scheme 70
Scheme 70
  1. STEP 1. Using scan tool MB991958, read CAN bus the diagnostic trouble code. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(ref-289389-S36745525782008063000000) ". Turn the ignition switch to the "ON" position. Check whether the CAN bus lines related DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES : Repair the CAN bus line (Refer to «CAN BUS DIAGNOSTICS TABLE»(ref-289394-S27719724372008063000000) ). NO : Go to Step 2.
  2. STEP 2. Using scan tool MB991958, read the diagnostic trouble code. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(ref-289389-S36745525782008063000000) ". Turn the ignition switch to the "ON" position. Check whether the sunroof motor assembly related DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES : Diagnose the sunroof motor assembly. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-289409-S18706077262008063000000) . NO : Go to Step 3.
  3. STEP 3. Check sunroof switch connector D-05 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is sunroof switch connector D-05 in good condition? YES : Go to Step 4. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Check that the sunroof works normally.
  4. STEP 4. Sunroof switch check Remove the sunroof switch. Refer to «SUNROOF»(ref-289409-S08615684252008063000000) . Check continuity when the sunroof switch is operated to "OPEN", "TILT-UP" or "CLOSE/TILT-DOWN" position. CONTINUITY CHART Switch position Terminal No. Normal value Tilt-up 3 - 4 Continuity exists (2 ohms or less) OFF 3 - 4, 4 - 5, 4 - 6 Open circuit Open 4 - 5 Continuity exists (2 ohms or less) Close/tilt-down 4 - 6 Continuity exists (2 ohms or less) Q: Is the sunroof switch normal? YES : Go to Step 5. NO : Replace the sunroof switch. Check that the sunroof works normally.
  5. STEP 5. Check the ground circuit to the sunroof motor assembly. Measure the resistance at sunroof switch connector D-05. Disconnect sunroof switch connector D-05 and measure the resistance available at the wiring harness side of the connector. Measure the resistance value between terminal 4 and ground. The resistance should be 2 ohms or less. Q: Is the measured resistance 2 ohms or less? YES : Go to Step 6. NO : Go to Step 8 .
  6. STEP 6. Check sunroof motor assembly connector D-06 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is sunroof motor assembly connector D-06 in good condition? YES : Go to Step 7. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Check that the sunroof works normally.
  7. STEP 7. Check the wiring harness between sunroof switch connector D-05 (terminal 4) and sunroof motor assembly connector D-06 (terminal 1). Q: Is the wiring harness between sunroof switch connector D-05 (terminal 4) and sunroof motor assembly connector D-06 (terminal No. 1) in good condition? YES : No action is necessary and testing is complete. NO : The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Check that the sunroof works normally.
  8. STEP 8. Check sunroof motor assembly connector D-06 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is sunroof motor assembly connector D-06 in good condition? YES : Go to Step 9. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Check that the sunroof works normally.
  9. STEP 9. Check the ground circuit to the sunroof motor assembly. Measure the resistance at sunroof motor assembly connector D-06. Disconnect sunroof motor assembly connector D-06 and measure the resistance available at the wiring harness side of the connector. Measure the resistance value between terminal 2 and ground. The resistance should be 2 ohms or less. Q: Is the measured resistance 2 ohms or less? YES : Go to Step 11 . NO : Go to Step 10.
  10. STEP 10. Check the wiring harness between sunroof motor assembly connector D-06 (terminal 2) and ground. Q: Is the wiring harness between sunroof motor assembly connector D-06 (terminal 2) and ground in good condition? YES : No action is necessary and testing is complete. NO : The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Check that the sunroof works normally.
  11. STEP 11. Retest the system. Check that the sunroof works normally. Q: Is the check result normal? YES : No action is necessary and testing is complete. NO : Replace the sunroof motor assembly. Check that the sunroof works normally.

INSPECTION PROCEDURE 2: The Sunroof Lid Glass does not Tilt-up (Tilt-down, Open, and Close Normally)

CAUTIONBefore replacing the ECU, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.

Scheme 71

Scheme 71
Scheme 71
  1. The sunroof switch may be defective
  2. The sunroof motor assembly may be defective
  3. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector

Required Special Tools

  1. MB992006: Extra fine probe
  2. MB991223: Harness set
  3. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A
  1. STEP 1. Using scan tool MB991958, read the diagnostic trouble code. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(ref-289389-S36745525782008063000000) ". Turn the ignition switch to the "ON" position. Check whether the sunroof motor assembly related DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES : Diagnose the sunroof motor assembly. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-289409-S18706077262008063000000) . NO : Go to Step 2.
  2. STEP 2. Check sunroof switch connector D-05 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is sunroof switch connector D-05 in good condition? YES : Go to Step 3. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Check that the sunroof works normally.
  3. STEP 3. Sunroof switch check Remove the sunroof switch. Refer to «SUNROOF»(ref-289409-S08615684252008063000000) . Check continuity when the sunroof switch is operated to "TILT-UP" position. CONTINUITY CHART Switch position Terminal No. Normal value Tilt-up 3 - 4 Continuity exists (2 ohms or less) OFF 3 - 4, 4 - 5, 4 - 6 Open circuit Q: Is the sunroof switch normal? YES : Go to Step 4. NO : Replace the sunroof switch. Check that the sunroof works normally.
  4. STEP 4. Check sunroof motor assembly connector D-06 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is sunroof motor assembly connector D-06 in good condition? YES : Go to Step 5. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Check that the sunroof works normally.
  5. STEP 5. Check the wiring harness between sunroof switch connector D-05 (terminal 3) and sunroof motor assembly connector D-06 (terminal 4). Q: Is the wiring harness between sunroof switch connector D-05 (terminal 3) and sunroof motor assembly connector D-06 (terminal No. 4) in good condition? YES : Go to Step 6. NO : The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Check that the sunroof works normally.
  6. STEP 6. Retest the system. Check that the sunroof lid glass tilts up. Q: Is the check result normal? YES : No action is necessary and testing is complete. NO : Replace the sunroof motor assembly. Check that the sunroof works normally.

INSPECTION PROCEDURE 3: The Sunroof Lid Glass does not Open (Tilt-up, Tilt-down, And Close Normally)

CAUTIONBefore replacing the ECU, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.

Scheme 72

Scheme 72
Scheme 72
  1. The sunroof switch may be defective
  2. The sunroof motor assembly may be defective
  3. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector

Required Special Tools

  1. MB992006: Extra fine probe
  2. MB991223: Harness set
  3. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A
  1. STEP 1. Using scan tool MB991958, read the diagnostic trouble code. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(ref-289389-S36745525782008063000000) ". Turn the ignition switch to the "ON" position. Check whether the sunroof motor assembly related DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES : Diagnose the sunroof motor assembly. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-289409-S18706077262008063000000) . NO : Go to Step 2.
  2. STEP 2. Check sunroof switch connector D-05 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is sunroof switch connector D-05 in good condition? YES : Go to Step 3. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Check that the sunroof works normally.
  3. STEP 3. Sunroof switch check Remove the sunroof switch. Refer to «SUNROOF»(ref-289409-S08615684252008063000000) . Check continuity when the sunroof switch is operated to "OPEN" position. CONTINUITY CHART Switch position Terminal No. Normal value Open 4 - 5 Continuity exists (2 ohms or less) OFF 3 - 4, 4 - 5, 4 - 6 Open circuit Q: Is the sunroof switch normal? YES : Go to Step 4. NO : Replace the sunroof switch. Check that the sunroof works normally.
  4. STEP 4. Check sunroof motor assembly connector D-06 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is sunroof motor assembly connector D-06 in good condition? YES : Go to Step 5. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Check that the sunroof works normally.
  5. STEP 5. Check the wiring harness between sunroof switch connector D-05 (terminal 5) and sunroof motor assembly connector D-06 (terminal 5). Q: Is the wiring harness between sunroof switch connector D-05 (terminal 5) and sunroof motor assembly connector D-06 (terminal No. 5) in good condition? YES : Go to Step 6. NO : The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Check that the sunroof works normally.
  6. STEP 6. Retest the system. Check that the sunroof lid glass open. Q: Is the check result normal? YES : No action is necessary and testing is complete. NO : Replace the sunroof motor assembly. Check that the sunroof works normally.

INSPECTION PROCEDURE 4: The Sunroof Lid Glass does not Tilt-down or Close (Tilt-up and Open Normally)

CAUTIONBefore replacing the ECU, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.

Scheme 73

Scheme 73
Scheme 73
  1. The sunroof switch may be defective
  2. The sunroof motor assembly may be defective
  3. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector

Required Special Tools

  1. MB992006: Extra fine probe
  2. MB991223: Harness set
  3. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A
  1. STEP 1. Using scan tool MB991958, read the diagnostic trouble code. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(ref-289389-S36745525782008063000000) ". Turn the ignition switch to the "ON" position. Check whether the sunroof motor assembly related DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES : Diagnose the sunroof motor assembly. Refer to «SUNROOF DIAGNOSIS»(ref-289409-S22368571742008063000000) . NO : Go to Step 2.
  2. STEP 2. Check sunroof switch connector D-05 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is sunroof switch connector D-05 in good condition? YES : Go to Step 3. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Check that the sunroof works normally.
  3. STEP 3. Sunroof switch check Remove the sunroof switch. Refer to «SUNROOF»(ref-289409-S08615684252008063000000) . Check continuity when the sunroof switch is operated to "CLOSE/TILT-DOWN" position. CONTINUITY CHART Switch position Terminal No. Normal value Close/tilt-down 4 - 6 Continuity exists (2 ohms or less) OFF 3 - 4, 4 - 5, 4 - 6 Open circuit Q: Is the sunroof switch normal? YES : Go to Step 4. NO : Replace the sunroof switch. Check that the sunroof works normally.
  4. STEP 4. Check sunroof motor assembly connector D-06 for loose, corroded or damaged terminals, or terminals pushed back in the connector. Q: Is sunroof motor assembly connector D-06 in good condition? YES : Go to Step 5. NO : Repair or replace the damaged component(s). Refer to «HARNESS CONNECTOR INSPECTION»(ref-289377-S30386868932008063000000) . Check that the sunroof works normally.
  5. STEP 5. Check the wiring harness between sunroof switch connector D-05 (terminal 6) and sunroof motor assembly connector D-06 (terminal 10). Q: Is the wiring harness between sunroof switch connector D-05 (terminal 6) and sunroof motor assembly connector D-06 (terminal No. 10) in good condition? YES : Go to Step 6. NO : The wiring harness may be damaged or the connector(s) may have loose, corroded or damaged terminals, or terminals pushed back in the connector. Repair the wiring harness as necessary. Check that the sunroof works normally.
  6. STEP 6. Retest the system. Check that the sunroof lid glass tilts down/close. Q: Is the check result normal? YES : No action is necessary and testing is complete. NO : Replace the sunroof motor assembly. Check that the sunroof works normally.

INSPECTION PROCEDURE 5: Sunroof Safety Function does not work Normally

CAUTIONBefore replacing the ECU, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.
  1. The sunroof motor assembly may be defective
  2. Incorrect learning of the sunroof fully closed position

Required Special Tools

  1. MB992006: Extra fine probe
  2. MB991223: Harness set
  3. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A
  1. STEP 1. Using scan tool MB991958, read the diagnostic trouble code. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(ref-289389-S36745525782008063000000) ". Turn the ignition switch to the "ON" position. Check whether the sunroof motor assembly related DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES : Diagnose the sunroof motor assembly. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-289409-S18706077262008063000000) . NO : Go to Step 2.
  2. STEP 2. Check the trouble symptom. Check the sunroof trouble symptom according to the following procedures. Carry out the learning procedures of the sunroof fully closed position (Refer to «LEARNING PROCEDURES OF THE SUNROOF FULLY CLOSED POSITION»(ref-289409-S29538099092008063000000) ). Check the trouble symptom. Q: Is the check result normal? YES : No action is necessary and testing is complete. NO : Replace the sunroof motor assembly. Check that the sunroof works normally.

INSPECTION PROCEDURE 6: The Sunroof Timer Function does not work

CAUTIONBefore replacing the ECU, ensure that the power supply circuit, the ground circuit and the communication circuit are normal.
  1. The front door switch may be defective
  2. The sunroof motor assembly may be defective
  3. The wiring harness or connectors may have loose, corroded, or damaged terminals, or terminals pushed back in the connector

Required Special Tools

  1. MB992006: Extra fine probe
  2. MB991223: Harness set
  3. MB991958: Scan Tool (M.U.T.-III Sub Assembly) MB991824: Vehicles Communication Interface (V.C.I.) MB991827: M.U.T.-III USB Cable MB991910: M.U.T.-III Main Harness A
  1. STEP 1. Check the power supply system. With the ignition switch in the LOCK (OFF) position, check if the following function operates normally: Hazard warning light Central door locking system Q: Is the check result normal? YES : Go to Step 2. NO : Refer to «MALFUNCTION OF ETACS-ECU POWER SUPPLY CIRCUIT»(ref-289392-S39748373222008063000000) .
  2. STEP 2. Using scan tool MB991958, read CAN bus the diagnostic trouble code. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(ref-289389-S36745525782008063000000) ". Turn the ignition switch to the "ON" position. Check whether the CAN bus lines related DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES : Repair the CAN bus line (Refer to «CAN BUS DIAGNOSTICS TABLE»(ref-289394-S27719724372008063000000) ). NO : Go to Step 3.
  3. STEP 3. Using scan tool MB991958, read the diagnostic trouble code. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT SCAN TOOL (M.U.T.-III)»(ref-289389-S36745525782008063000000) ". Turn the ignition switch to the "ON" position. Check whether the ETACS-ECU related DTC is set. Turn the ignition switch to the "LOCK" (OFF) position. Q: Is the DTC set? YES : Diagnose the ETACS-ECU. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-289416-S29060959692008063000000) . NO : Go to Step 4.
  4. STEP 4. Using scan tool MB991958, check data list. Check the signals related to the sunroof timer function operation. CAUTION: To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958. Connect scan tool MB991958. Refer to " «HOW TO CONNECT THE SCAN TOOL (M.U.T.-III)»(ref-289389-S36745525782008063000000) ". Turn the ignition switch to the "ON" position. Check the data list of the ETACS. Turn the ignition switch to the LOCK (OFF) position. Close the driver's door. Close the passenger's door. DATA LIST Item No. Item name Normal condition 254 IG voltage Battery voltage 256 Dr door ajar switch Close 257 As door ajar switch Close Turn the ignition switch to the "LOCK" (OFF) position. OK: Normal conditions are displayed for all the items. Q: Are the check result normal? YES < Normal conditions are displayed for all the items. > : Go to Step 5. NO < Normal condition is not displayed for item No. 254. > : Refer to «INSPECTION PROCEDURE 2: THE IGNITION SWITCH (IG1) SIGNAL IS NOT RECEIVED»(ref-289392-S05543681702008063000000) . NO < Normal condition is not displayed for item No. 256. > : Refer to «INSPECTION PROCEDURE 5: THE FRONT DOOR SWITCH (DRIVER'S SIDE) SIGNAL IS NOT RECEIVED.»(ref-289392-S20622045972008063000000) . NO < Normal condition is not displayed for item No. 257. > : Refer to «INSPECTION PROCEDURE 6: THE FRONT DOOR SWITCH (PASSENGER'S SIDE) SIGNAL IS NOT RECEIVED.»(ref-289392-S09465174222008063000000) .
  5. STEP 5. Retest the system. Check that the sunroof timer function works normally. Q: Is the check result normal? YES : No action is necessary and testing is complete. NO : Replace the ETACS-ECU. Check that the sunroof timer function works normally.

Scheme 74

Scheme 74: SUNROOF MOTOR ASSEMBLY TERMINAL CHECK
Scheme 74: SUNROOF MOTOR ASSEMBLY TERMINAL CHECK
Terminal numberCheck itemsCheck conditionsNormal conditions
1GroundAlways0 V
2GroundAlways0 V
3Battery power supplyIgnition switch: ONBattery voltage
4Input from sunroof switch (tilt-up)Sunroof switch: Up0 V
5Input from sunroof switch (open)Sunroof switch: Open0 V
6Battery power supplyAlwaysBattery voltage
7LIN communication line (between ETACS-ECU)Always0 to 12 V (pulse signal)
8
9
10Input from sunroof switch (close or down)Sunroof switch: Close or down0 V

SUNROOF MOTOR ASSEMBLY TERMINAL CONNECTOR TERMINAL REFERENCE

WATER TEST

Check if there are any leaks in the sunroof by the following procedure.

Scheme 75

Scheme 75: WATER TEST
Scheme 75: WATER TEST
  1. Fully close the roof lid glass.
  2. Adjust the water pressure so that water comes out of the hose to a height of approximately 50 cm (19.7 inches) when the hose is held vertically facing upwards.
  3. Hold the end of the hose approximately 30 cm (11.8 inches) above the roof and let the water run onto the weatherstrip for 5 minutes or more.
  4. Check if any water leaks can be found in the room while watering. Even though there are any water leaks around the roof lid glass, it can be acceptable as long as water is caught in the drip area.

Scheme 76

Scheme 76: SUNROOF FIT ADJUSTMENT
Scheme 76: SUNROOF FIT ADJUSTMENT
  1. Fully close the sunroof lid glass.
  2. Fully open the sunshade.
  3. Loosen the sunroof lid glass assembly mounting screws. Adjust the sunroof lid glass height by moving the sunroof lid glass assembly along the sunroof lid guide oblong hole so that the clearance between the sunroof lid glass and the vehicle body is even throughout the circumference.
  4. After adjustment, check that the sunroof operates smoothly.

More articles — Body - Lancer Evolution
