Basic Brake System - Lancer Evolution: Removal & Installation Mitsubishi Lancer X

Mechanical - Hydraulic 14 illustrations ~499 words

BRAKE PAD REPLACEMENT

CAUTIONTake care not to contact the parts or tools to the caliper because the paint of caliper will be scratched. And if there is brake fluid on the caliper, wipe it off quickly. Whenever a pad must be replaced, replace both LH and RH wheel pads as a set to prevent the vehicle from pulling to one side when braking.

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18
  1. While pressing the cross spring by hand, remove the pin from the brake caliper assembly.
  2. Remove the cross spring from the brake caliper assembly.
  3. Remove the following parts from the brake caliper assembly. Shim Brake pad assembly CAUTION: Keep grease or other soiling off the pad and brake disk friction surfaces.
  4. Clean the piston, then press the piston into the cylinder using the piston expander (Special tool: MB990520).
  5. Apply grease to the pad as shown in the figure. Grease: Between pad and shim: Repair kit grease, Molykote AS880N or equivalent Shoulder section: Repair kit grease, Molykote 7439 or equivalent
  6. Install the shim to the brake pad assembly. Then, install the brake pad assembly to the brake caliper assembly so that the direction of shim arrow points to the same direction as the brake disk rotation direction of when the vehicle travels forward. NOTE: Install the brake pad assembly (with wear indicator) to outside the vehicle.
  7. Install the cross spring to the brake caliper assembly.
  8. While pressing the cross spring by hand, install the pin to the brake caliper assembly.

REMOVAL AND INSTALLATION

CAUTIONDo not apply grease or lubricant to the switch and the switch installation section to avoid malfunction of the switch. In addition, do not use gloves which have grease on them.

Scheme 19

Scheme 19
Scheme 19

>> A << VACUUM HOSE INSTALLATION

Align the mark as shown in the figure to assemble the vacuum hose.

Scheme 20

Scheme 20: >> A << VACUUM HOSE INSTALLATION
Scheme 20: >> A << VACUUM HOSE INSTALLATION
CAUTIONTake care not to contact the parts or tools to the caliper because the paint of caliper will be scratched. And if there is brake fluid on the caliper, wipe it off quickly.

Scheme 21

Scheme 21
Scheme 21

<< A >> FRONT BRAKE DISK REMOVAL

If the front brake disk removal is difficult, install bolts (M8 x 1.25 mm) shown in the figure, and tighten them evenly and gradually to remove the front brake disk.

Scheme 22

Scheme 22: << A >> FRONT BRAKE DISK REMOVAL
Scheme 22: << A >> FRONT BRAKE DISK REMOVAL

Scheme 23

Scheme 23: >> A << BRAKE HOSE INSTALLATION
Scheme 23: >> A << BRAKE HOSE INSTALLATION
  1. Pass the brake hose through the hole in the body-side bracket.
  2. Install the brake hose to the brake caliper.
  3. Install the brake hose at the two fixing points.
  4. Twist the brake hose toward the lesser torsion between the brake hose and body-side bracket as shown in the figure, and fix it to the body-side bracket with a clip.

<< A >> PISTON BOOT/PISTON REMOVAL

CAUTIONDo not remove one piston completely before trying to remove the other piston, because it will become impossible to remove other pistons.

Remove the pistons by pumping in air slowly from the brake hose connection. Be sure to use a wood block and adjust the height of the four pistons so that the pistons protrude evenly.

<< B >> PISTON SEAL REMOVAL

CAUTIONTo prevent damage to inner cylinder, do not use a flat-tipped screwdriver or other tool.

Scheme 24

Scheme 24
Scheme 24
  1. Remove the piston seal with finger tip.
  2. Clean the piston surface and cylinder inner face with alcohol or specified brake fluid. Brake fluid: DOT3 or DOT4
CAUTIONTake care not to contact the parts or tools to the caliper because the paint of caliper will be scratched. And if there is brake fluid on the caliper, wipe it off quickly.

Scheme 25

Scheme 25
Scheme 25

If the rear brake disk removal is difficult, install bolts (M8 x 1.25 mm) shown in the figure, and tighten them evenly and gradually to remove the rear brake disk.

CAUTIONDo not remove one piston separately before trying to remove the other piston, because it will become impossible to remove other pistons.

Remove the pistons by pumping in air slowly from the brake hose connection. Be sure to use a wood block and adjust the height of the two pistons while so that the pistons protrude evenly.

CAUTIONTo prevent damage to inner cylinder, do not use a flat-tipped screwdriver or other tool.

Scheme 26

Scheme 26
Scheme 26
  1. Remove the piston seal with finger tip.
  2. Clean the piston surface and cylinder inner face with alcohol or specified brake fluid. Brake fluid: DOT3 or DOT4
