Basic Brake System - Lancer: Maintenance Mitsubishi Lancer X

BRAKE FLUID LEVEL SWITCH CHECK

The brake fluid level switch is normal when the following conditions are met: When the brake fluid level is above "MIN," continuity is detected; and when the level is below "MIN," no continuity is detected.

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

Scheme 92

1. Visually check the thickness of brake pad from the inspection hole of the caliper body. Standard value: 10.0 mm (0.39 inch) Minimum limit: 2.0 mm (0.08 inch)
2. When the thickness is lower than the limit value, replace both brake pads (right and left) as a set.
3. Remove the parts indicated in the figure, swivel the caliper assembly upward and retain it with a wire or similar tool.
4. Remove the following parts from the caliper assembly. Shim Pad assembly < front> Pad & clip assembly < rear> Pad & wear indicator assembly Clip
5. In order to measure the brake drag force after pad installation, measure the hub sliding torque with no pad attached (Refer to «FRONT DISC BRAKE ASSEMBLY»(ref-291270-S21583465722008072500000) ).
6. Install the pad and caliper assembly, and check the brake drag force (Refer to «FRONT DISC BRAKE ASSEMBLY»(ref-291270-S21583465722008072500000) ).
