SPECIAL TOOL
SPECIAL TOOL CHART Tool Tool number and name Supersession Application MB990480 Glass holder General service tool Removal and installation of window glass
Scheme 122
Scheme 123
Required Special Tool
- MB990480: Glass Holder
Scheme 124
Scheme 125
Scheme 126
Scheme 127
Scheme 128
- To protect the body (paint surface), apply cloth tape to all body areas around the installed windshield.
- Make mating marks on the windshield and body.
- Using piano wire. Using a sharp-point drill, make a hole in the windshield adhesive. Pass the piano wire from the inside of the vehicle through the hole. CAUTION: Do not let the piano wire touch the edge of the windshield. Pull the piano wire alternately from the inside and outside along the windshield to cut the adhesive. CAUTION: Inserting the glass adhesive knife too deeply into windshield adhesive may damage windshield.
- Using glass adhesive knife Keep glass adhesive knife at right angles with the windshield edge, and put the blade at windshield edge and surface. Then cut away adhesive along the windshield edge.
- Use special tool MB990480 to remove the windshield. CAUTION: Be careful not to remove more adhesive than is necessary. Be careful also not to damage the paint on the body surface with the knife. If the paint is damaged, repair the damaged area with touch-up paint.
- Use a knife to cut away the remaining adhesive so that the thickness is within 2 mm (0.08 inch) around the entire circumference of the body flange.
- Finish the flange surfaces so that they are smooth. CAUTION: Allow the cleaned area to dry for at least three minutes. Do not touch any surface that has been cleaned.
- When reusing the windshield, remove the adhesive still adhering to the windshield, and clean with 3M™ AAD Part number 8906 or equivalent.
- Clean the body side in the same way.
SPECIAL TOOLS
SPECIAL TOOLS CHART Tool Tool number and name Supersession Application MB990480 Glass holder General service tool Removal of power window regulator assembly MB990900 or MB991164 Door adjusting wrench MB990900-01 Adjustment of door fit MB990925 Bearing and oil seal installer set MB990939 Remover bar MB990925-01 or General service tool Adjustment of door striker MB990211 Slider hammer MB990211-01 MB990241 Axle shaft puller MB990243 Body puller MB990241-01 or General service tool MB991958 MB991824 MB991827 MB991910 MB991911 MB991914 MB991825 MB991826 Scan tool (M.U.T.-III sub assembly) Vehicle communication interface (V.C.I.) M.U.T.-III USB cable M.U.T.-III main harness A (Vehicles with CAN communication system) M.U.T.-III main harness B (Vehicles without CAN communication system) M.U.T.-III main harness C (for Daimler Chrysler models only) M.U.T.-III measurement adapter M.U.T.-III trigger harness MB991824-KIT NOTE: G: MB991826 M.U.T.-III Trigger Harness is not necessary when pushing V.C.I. ENTER key. Communication line check (ECU check and service data) CAUTION: For vehicles with CAN communication, use M.U.T.-III main harness A to send simulated vehicle speed. If you connect M.U.T.-III main harness B instead, the CAN communication does not function correctly. MB991223 Harness set MB991219 Test harness MB991220 LED harness MB991221 LED harness adapter MB991222 Probe General service tools Making voltage and resistance measurement during troubleshooting Connector pin contact pressure inspection Power circuit inspection Power circuit inspection Commercial tester connection MB992006 Extra fine probe - Making voltage and resistance measurement during troubleshooting
Scheme 129
Scheme 130
Scheme 131
Scheme 132
Scheme 133
SPECIAL TOOLS CHART Tool Tool number and name Supersession Application MB991223 Harness set MB991219 Test harness MB991220 LED harness MB991221 LED harness adapter MB991222 Probe General service tools Making voltage and resistance measurement during troubleshooting Connector pin contact pressure inspection Power circuit inspection Power circuit inspection Commercial tester connection MB992006 Extra fine probe - Making voltage and resistance measurement during troubleshooting
Scheme 134
SPECIAL TOOLS CHART Tool Tool number and name Supersession Application MB991958 MB991824 MB991827 MB991910 MB991911 MB991914 MB991825 MB991826 Scan tool (M.U.T.-III sub assembly) Vehicle communication interface (V.C.I.) M.U.T.-III USB cable M.U.T.-III main harness A (Vehicles with CAN communication system) M.U.T.-III main harness B (Vehicles without CAN communication system) M.U.T.-III main harness C (for Daimler Chrysler models only) M.U.T.-III measurement adapter M.U.T.-III trigger harness MB991824-KIT NOTE: G: MB991826 M.U.T.-III Trigger Harness is not necessary when pushing V.C.I. ENTER key. Communication line check (ECU check and service data) CAUTION: For vehicles with CAN communication, use M.U.T.-III main harness A to send simulated vehicle speed. If you connect M.U.T.-III main harness B instead, the CAN communication does not function correctly. MB991223 Harness set MB991219 Test harness MB991220 LED harness MB991221 LED harness adapter MB991222 Probe General service tools Making voltage and resistance measurement during troubleshooting Connector pin contact pressure inspection Power circuit inspection Power circuit inspection Commercial tester connection MB992006 Extra fine probe - Making voltage and resistance measurement during troubleshooting
