Charging System - Lancer Evolution: Overhaul Mitsubishi Lancer X

Charging System 3 illustrations ~109 words

RECTIFIER ASSEMBLY

Use the analog type tester to make sure the electrical continuity of each diode meets the table.

Unless the electrical continuity of each diode meets the CONTINUITY CHART , replace the rectifier.

(-) side(+) sideElectrical continuity
EP1, P2, P3, P4, P5, P6Yes
BNo
P1, P2, P3, P4, P5, P6ENo
BYes

CONTINUITY CHART

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22: BRUSH
Scheme 22: BRUSH

Scheme 23

Scheme 23
Scheme 23
  1. Measure the length of the protrusion of the brush. Replace the brush if the protrusion length is shorter than the limit. Limit: 2 mm (0.1 inch) minimum
  2. Unsolder the lead of the brush. The brush will come out, becoming ready for removal.
  3. Install a new brush by pushing it into the holder as shown in the illustration and soldering the lead.
