<< A >> WINDSHIELD WIPER MOTOR ASSEMBLY REMOVAL
- Remove the windshield wiper motor assembly mounting bolt. CAUTION: Be careful not to damage the windshield glass when the windshield wiper motor assembly is removed.
- Use the fiat-tipped screwdriver to disengage the link between the windshield wiper motor assembly and the link assembly to remove the windshield wiper motor assembly.
Scheme 18
>> A << WIPER BLADE INSTALLATION
| CAUTION | Ensure that the backings are bent toward the shown direction, and then install the backings to the wiper blade. |
Scheme 19
>> B << WIPER BLADE ASSEMBLY INSTALLATION
Install the wiper blade at the specified position (standard value).
Standard value: (A) 34 +/- 5 mm (1.3 +/- 0.20 inch)
Scheme 20
>> A << WASHER TANK ASSEMBLY INSTALLATION
| CAUTION | Take care not to confuse the two washer motor connectors when connecting them to the washer motor. Connect the green connector to the rear washer motor, and the milky white connector to the front washer motor, respectively. |
>> B << REAR WASHER HOSE INSTALLATION
Align the marking on the rear washer hose with the clip as shown.
