A) Rear Wiper Motor Assembly Removal
Close the trunk lid slightly and lower the trunk lid torsion bar slightly when removing the rear wiper motor assembly. If you fail to do this, the rear wiper motor assembly will interfere with the trunk lit torsion bar. (Scheme 4)
Scheme 4
A) Rear Wiper Motor Assembly Installation
Close the trunk lid slightly and lower the trunk lid torsion bar slightly when installing the rear wiper motor assembly. If you fail to do this, the rear wiper motor assembly will interfere with the trunk lid torsion bar. (Scheme 4)
B) Wiper Blade Installation
When installing the wiper blade, check that the backing inside the wiper blade is warped toward the wiper arm. (Scheme 8)
C) Wiper Blade Assembly Installation
Before installing the rear wiper arm blade assembly, operate the rear wiper motor so that the motor stops at the predetermined park position. Install the rear wipe arm and blade assembly and adjust the rear wiper blade position so that the blade end stops at the predetermined position. Standard position; A) 33-43 mm (1.3-1.7 inch). (Scheme 5)
Scheme 5
Scheme 6
A) Windshield Wiper Motor Assembly Removal
- Remove the windshield wiper motor assembly mounting bolt.
- Use the flat-tipped screwdriver to disengage the link between the windshield wiper motor assembly and the link assembly to remove the windshield wiper motor assembly. (Scheme 7)
Scheme 7
A) Wiper Blade Installation
| CAUTION | The driver's side wiper blade in not warped. |
When installing the passenger's wiper blade, check that the backing inside the wiper blade is warped toward the wiper arm. (Scheme 8)
Scheme 8
B) Wiper Blade Assembly Installation
Install the wiper blade at the specified position. Standard Value; A) 29-39 mm (1.1-1.5 inch). (Scheme 9)
