Windshield Wiper and Washer - Evolution: Other Mitsubishi Lancer IX

Wiper/washer Systems 5 illustrations ~156 words

FRONT WIPER MOTOR CHECK

Inspect the windshield wiper motor by removing the harness connector with the motor attached to the vehicle.

WINDSHIELD WIPER AND WINDSHIELD WASHER SWITCH CHECK

Check continuity between the switch terminals.

Scheme 23

Scheme 23: WINDSHIELD WIPER AND WINDSHIELD WASHER SWITCH CHECK
Scheme 23: WINDSHIELD WIPER AND WINDSHIELD WASHER SWITCH CHECK

Scheme 24

Scheme 24
Scheme 24

WINDSHIELD INTERMITTENT WIPER VOLUME CHECK

Check that the resistance varies between 0 and 1 kohm when the windshield intermittent volume is turned from FAST to SLOW by after measuring resistance between connector terminals 3 and 6 at the column switch.

Scheme 25

Scheme 25: WINDSHIELD INTERMITTENT WIPER VOLUME CHECK
Scheme 25: WINDSHIELD INTERMITTENT WIPER VOLUME CHECK

Scheme 26

Scheme 26: REMOVAL AND INSTALLATION
Scheme 26: REMOVAL AND INSTALLATION

Note. For removal and installation of the wiper and washer switch, refer to COLUMN SWITCH .

FRONT WASHER MOTOR CHECK

  1. Remove the washer tank assembly with the washer hose attached. Then fill the washer tank with water.
  2. Check to see that the water is vigorously sprayed. When connecting the positive battery terminal to terminal number 2 and terminal number 1 to the negative battery terminal.

Scheme 27

Scheme 27
Scheme 27
