ADHESIVES
| Item | Specified adhesive |
|---|---|
| Windshield | 3 M™ AAD part No. 8609 super fast urethane and 3 M™ AAD part No. 8608 super fast urethane primer or equivalent |
| Rear window glass |
ADHESIVES SPECIFICATION
| Item | Specified adhesive |
|---|---|
| Windshield | Adhesive tape: Double-sided tape [6.5 mm (0.25 in) width, 100 mm (3.93 in) length and 0.4 mm (0.015 in) thickness] |
ADHESIVES SPECIFICATION
LUBRICANT
| Item | Specified lubricant | Quantity | |
|---|---|---|---|
| Deagrase agent | Grease and dirt removal from parts surface | 3M™ ADD Part No. 8906 or equivalent | As required |
LUBRICATION SPECIFICATION
GENERAL
The windshield, rear window glass are attached by an urethane-base adhesive to the window frame. This adhesive provides improved glass holding and sealing, and also gives body openings a greater structural strength.
ITEMS
| Item | Application | Quantity |
|---|---|---|
| Wire (diameter x length) | For cutting adhesive | Five pieces of wire 0.6 mm x 1 m (0.02 in x 3.3 ft) |
| Glass adhesive knife | For cutting adhesive | One |
| Sealant gun | For adhesive application | One |
| Wiping shop towels | As required | |
| Sealer | For prevention of water and wind leaks after adhesive application | As required |
| 3M™ AAD Part No. 8906 or equivalent | For cleaning or degreasing body parts and glasses | As required |
| Glass holder MB990480 | For securing of window glass | Two |
WIRE DIAMETER SPECIFICATION
WINDOW GLASS INSTALLATION
| CAUTION | Do not apply primer on the adhesion surface, as adhesion may be reduced. |
Scheme 23
INTRODUCTION TO WINDOW GLASS DIAGNOSIS
If water emerges from the following points, there is a problem in the seal or body flange.
- Windshield
- Rear window glass
WINDOW GLASS DIAGNOSTIC TROUBLESHOOTING STRATEGY
Use these steps to plan your diagnostic strategy. If you follow them carefully, you will be sure that you have exhausted most of the possible ways to find a window glass fault.
- Gather information from the customer.
- Verify that the condition described by the customer exists.
- Find the malfunction by following the Symptom Chart.
- Verify malfunction is eliminated.
WINDOW GLASS DIAGNOSTIC TROUBLE SYMPTOM CHART
| Symptom | Inspection procedure | Reference |
|---|---|---|
| Water leak through windshield | 1 | INSPECTION PROCEDURE 1: WATER LEAK THROUGH WINDSHIELD/REAR WINDOW GLASS |
| Water leak through rear window glass |
WINDOW GLASS DIAGNOSTIC TROUBLE SYMPTOM CHART
DIAGNOSIS
- STEP 1. Check if the seal is faulty. Q: Is the seal faulty? YES: Repair the seal, then go to Step 3 . NO: Go to Step 2.
- STEP 2. Check if the body flange is deformed. Q: Is the body flange deformed? YES: Replay the body flange, then go to Step 3. NO: Go to Step 3.
- STEP 3. Retest the system. Q: Is any water leaking? YES: Return to Step 1 . NO: This diagnosis complete.
SPECIAL TOOL
SPECIAL TOOL SPECIFICATION Tool Tool number and name Supersession Application MB990480 Glass holder General service tool Removal and installation of window glass
Scheme 24
Scheme 25
Required Special Tool
- MB990480: Glass Holder
Scheme 26
Scheme 27
Scheme 28
Scheme 29
Scheme 30
- Using piano wire. Using a sharp-point drill, make a hole in the windshield adhesive. Pass the piano wire from the inside of the vehicle through the hole. CAUTION: Do not let the piano wire touch the edge of the windshield. Pull the piano wire alternately from the inside and outside along the windshield to cut the adhesive. CAUTION: Inserting the glass adhesive knife too deeply into windshield adhesive may damage windshield.
- Using glass adhesive knife Keep glass adhesive knife at right angles with the windshield edge, and put the blade at windshield edge and surface. Then cut away adhesive along the windshield edge.
- Use special tool MB990480 to remove the windshield. CAUTION: Be careful not to remove more adhesive than is necessary. Be careful also not to damage the paint on the body surface with the knife. If the paint is damaged, repair the damaged area with touch-up paint.
- Use a knife to cut away the remaining adhesive so that the thickness is within 2 mm (0.08 inch) around the entire circumference of the body flange.
- Finish the flange surfaces so that they are smooth. CAUTION: Allow the cleaned area to dry for at least three minutes. Do not touch any surface that has been cleaned.
- When reusing the windshield, remove the adhesive still adhering to the windshield, and clean with 3M™ AAD Part number 8906 or equivalent.
- Clean the body side in the same way.
>>A<< WINDSHIELD SPACER/GLASS STOPPER/WINDSHIELD UPPER MOLDING/WINDSHIELD SIDE MOLDING INSTALLATION
| CAUTION | Leave the degreased parts for 3 or more minutes to dry well, before starting on the next step. Do not touch the degreased parts. |
Scheme 31
Scheme 32
- Use 3M™ AAD Part number 8906 or equivalent to degrease the inside and outside of the windshield and the body flanges.
- Install the windshield spacer and glass stoppers to the specified positions so that there are no adrift or warped surfaces inside the windshield.
- Install the adhesive tape to the windshield.
- Install the windshield molding and front deck garnish retainer to the windshield.
Scheme 33
Scheme 34
- When replacing the windshield, temporarily set the windshield against the body, and place a mating mark on the windshield and body. CAUTION: The primer strengthens the adhesive, so be sure to apply it evenly around the entire circumference. However, a too thick application will weaken the adhesive. Do not touch the coated surface. Do not apply the primer on the remaining adhesive because of weakening the adhesive.
- Soak a sponge in the primer, and apply evenly to the windshield and the body in the specified places.
- Allow the windshield to dry for at least three minutes after applying primer.
- Fill a sealant gun with adhesive. Then apply the adhesive evenly around the windshield within 30 minutes after applying the primer. NOTE: Cut the tip of the sealant gun nozzle into a V shape to simplify adhesive application.
- Align the mating marks on the windshield and the body, and lightly press the windshield evenly so that it adheres completely.
- Use a spatula or similar tool to remove any excessive adhesive. Clean the surface with 3M™ AAD Part number 8906 or equivalent. Avoid moving the vehicle until the adhesive sets. CAUTION: Do not move the vehicle unless absolutely necessary. When testing for water leakage, do not apply strong water pressure.
- Wait 30 minutes or more, and then test for water leakage.
Scheme 35
< > REAR WINDOW GLASS REMOVAL
Remove the rear window glass using the same procedure as for the windshield (Refer to WINDSHIELD ).
Note. Use a piano wire to remove the rear window glass.
>>A<< FASTENER/REAR WINDOW SPACER/GLASS STOPPER/REAR WINDOW UPPER DAM/REAR WINDOW SIDE DAM INSTALLATION
| CAUTION | Leave the degreased parts for 3 or more minutes to dry well, before starting on the next step. Do not touch the degreased parts. |
Scheme 36
Scheme 37
Scheme 38
- Use 3M™ AAD Part number 8906 or equivalent. to degrease the inside and outside edges of the rear window glass and the surface of the body flange.
- Install the fastener, rear window spacers, and glass stoppers to the specified positions so that there are no adrift or warped surfaces inside the rear window glass.
- Install the fasteners to the specified positions on the body flange.
- Install the rear window upper dam and side dam to the rear window glass.
>>B<< REAR WINDOW GLASS INSTALLATION
- Apply the primer and adhesive.
- Install the rear window glass in the same way as for the windshield glass installation (Refer to «WINDSHIELD»(/mitsubishi/lancer-evolution/x-2007-2016/remont/windows/#window-glass-lancer-evolution) ).
