Window Glass - Except Lancer Evolution Mitsubishi Lancer Evolution X

ADHESIVES

ADHESIVES SPECIFICATIONS (1 OF 2)

ADHESIVES SPECIFICATIONS (2 OF 2)

LUBRICANT

LUBRICANT

GENERAL

The windshield, rear window glass are attached by an urethane-base adhesive to the window frame. This adhesive provides improved glass holding and sealing, and also gives body openings a greater structural strength.

ITEMS

GENERAL ITEMS

WINDOW GLASS INSTALLATION

Scheme 1

INTRODUCTION TO WINDOW GLASS DIAGNOSIS

If water emerges from the following points, there is a problem in the seal or body flange.

1. Windshield
2. Rear window glass

WINDOW GLASS DIAGNOSTIC TROUBLESHOOTING STRATEGY

Use these steps to plan your diagnostic strategy. If you follow them carefully, you will be sure that you have exhausted most of the possible ways to find a window glass fault.

1. Gather information from the customer.
2. Verify that the condition described by the customer exists.
3. Find the malfunction by following the DIAGNOSTIC TROUBLE SYMPTOM CHART.
4. Verify malfunction is eliminated.

DIAGNOSTIC TROUBLE SYMPTOM CHART

DIAGNOSTIC TROUBLE SYMPTOM CHART

DIAGNOSIS

1. STEP 1. Check if the seal is faulty. Q: Is the seal faulty? YES: Repair the seal, then go to Step 3 . NO: Go to Step 2.
2. STEP 2. Check if the body flange is deformed. Q: Is the body flange deformed? YES: Replay the body flange, then go to Step 3. NO: Go to Step 3.
3. STEP 3. Retest the system. Q: Is any water leaking? YES: Return to Step 1 . NO: This diagnosis complete.

SPECIAL TOOL

SPECIAL TOOL Tool Tool number and name Supersession Application MB990480 Glass holder General service tool Removal and installation of window glass

Scheme 2

Scheme 3

Required Special Tool

1. MB990480: Glass Holder

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

1. To protect the body (paint surface), apply protective tapes to all body areas around the installed windshield glass.
2. Make mating marks on the windshield glass and body.
3. Using piano wire. Using a sharp-point drill, make a hole in the windshield adhesive. Pass the piano wire from the inside of the vehicle through the hole. CAUTION: Do not let the piano wire touch the edge of the windshield glass. Pull the piano wire alternately from the inside and outside along the windshield glass to cut the adhesive. CAUTION: Inserting the glass adhesive knife too deeply into windshield adhesive may damage windshield glass.
4. Using glass adhesive knife Keep glass adhesive knife at right angles with the windshield glass edge, and put the blade at windshield glass edge and surface. Then cut away adhesive along the windshield glass edge.
5. Use special tool MB990480 to remove the windshield glass. CAUTION: Be careful not to remove more adhesive than is necessary. Be careful also not to damage the paint on the body surface with the knife. If the paint is damaged, repair the damaged area with touch-up paint.
6. Use a knife to cut away the remaining adhesive so that the thickness is within 2 mm (0.08 inch) around the entire circumference of the body flange.
7. Finish the flange surfaces so that they are smooth. CAUTION: Allow the cleaned area to dry for at least three minutes. Do not touch any surface that has been cleaned.
8. When reusing the windshield glass, remove the adhesive still adhering to the windshield glass, and clean with 3M™ AAD Part number 8906 or equivalent.
9. Clean the body side in the same way.

>> A << WINDSHIELD SPACER/GLASS STOPPER/WINDSHIELD UPPER MOLDING/WINDSHIELD SIDE MOLDING INSTALLATION

Scheme 9

Scheme 10

1. Use 3M™ AAD Part number 8906 or equivalent to degrease the inside and outside of the windshield glass and the body flanges.
2. Install the windshield spacer and glass stoppers to the specified positions so that there are no adrift or warped surfaces inside the windshield glass.
3. Install the adhesive tape (double-sided tape) to the windshield glass.
4. Install the windshield molding and front deck garnish retainer to the windshield glass.

Scheme 11

Scheme 12

1. When replacing the windshield glass, temporarily set the windshield glass against the body, and place a mating mark on the windshield glass and body. CAUTION: The primer strengthens the adhesive, so be sure to apply it evenly around the entire circumference. However, a too thick application will weaken the adhesive. Do not touch the coated surface. Do not apply the primer on the remaining adhesive because of weakening the adhesive.
2. Soak a sponge in the primer, and apply evenly to the windshield glass and the body in the specified places.
3. Allow the windshield glass to dry for at least 3 minutes after applying primer.
4. Fill a sealant gun with adhesive. Then apply the adhesive evenly around the windshield glass within 30 minutes after applying the primer. NOTE: Cut the tip of the sealant gun nozzle into a V shape to simplify adhesive application.
5. Align the mating marks on the windshield glass and the body, and lightly press the windshield glass evenly so that it adheres completely.
6. Use a spatula or similar tool to remove any excessive adhesive. Clean the surface with 3M™ AAD Part number 8906 or equivalent. Avoid moving the vehicle until the adhesive sets. CAUTION: Do not move the vehicle unless absolutely necessary. When testing for water leakage, do not apply strong water pressure.
7. Wait 30 minutes or more, and then test for water leakage.

Scheme 13

Scheme 14

<< A >> REAR WINDOW GLASS REMOVAL

Remove the rear window glass using the same procedures as for the windshield glass (Refer to WINDSHIELD ).

Note. Use a piano wire to remove the rear window glass.

>> A << FASTENER/REAR WINDOW SPACER/GLASS STOPPER/REAR WINDOW UPPER DAM/REAR WINDOW SIDE DAM INSTALLATION

Scheme 15

Scheme 16

Scheme 17

1. Use 3M™ AAD Part number 8906 or equivalent. to degrease the inside and outside edges of the rear window glass and the surface of the body flange.
2. Install the fastener, rear window spacers, and glass stoppers to the specified positions so that there are no adrift or warped surfaces inside the rear window glass.
3. Install the fasteners to the specified positions on the body flange.
4. Install the rear window upper dam and side dam to the rear window glass.

>> B << REAR WINDOW GLASS INSTALLATION

1. Apply the primer and adhesive.
2. Install the rear window glass in the same way as for the windshield glass installation (Refer to «WINDSHIELD»(/mitsubishi/lancer-evolution/x-2007-2016/remont/windows/#window-glass-except-lancer-evolution) ).

Scheme 18

Scheme 19

Scheme 20

1. Cut the tape that is wrapped around the rear floor wiring harness and clip with a knife or a similar tool. Then, remove the rear floor wiring harness.
2. Remove the rear floor wiring harness from the liftgate.

<< B >> LIFTGATE WINDOW GLASS REMOVAL

Remove the liftgate window glass by the same procedures as for the windshield glass (Refer to WINDSHIELD ).

Note. Use a piano wire to remove the liftgate window glass.

>> A << LIFTGATE DAM/GLASS STOPPER/FASTENER INSTALLATION

Scheme 21

1. Use 3M™ AAD Part number 8906 or equivalent to degrease the inside circumference of the liftgate window glass and the liftgate flanges. Fastener and glass stopper installation position
2. Install the liftgate dam, glass stopper, and fastener to the specified position.
3. Install the fasteners to the specified positions on the liftgate flange.

Scheme 22

1. Apply the primer and adhesive.
2. Install the liftgate window glass by the same procedures as for the windshield glass (refer to «WINDSHIELD»(/mitsubishi/lancer-evolution/x-2007-2016/remont/windows/#window-glass-except-lancer-evolution) ).
