Multifunction Electronic Modules System: Removal & Installation Mercury Monterey VIII

Communication Devices 1 illustration ~135 words

Removal and Installation

  1. Disconnect the battery. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-234519) .
  2. Remove the driver seat. For additional information, refer to «SEATING»(ref-234523) .
  3. Remove the DSM screw. To install, tighten to 7 Nm (62 lb-in).
  4. Disconnect the electrical connectors and remove the DSM.
  5. To install, reverse the removal procedure.

Scheme 62

Scheme 62: Smart Junction Box (SJB)
  1. Disconnect the battery. For additional information, refer to «BATTERY, MOUNTING AND CABLES»(ref-234519) .
  2. Remove the steering column cover and reinforcement. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-234528) .
  3. Disconnect the front SJB electrical connectors.
  4. Remove the SJB nuts. To install, tighten to 7 Nm (62 lb-in).
  5. Remove the SJB bracket screw. To install, tighten to 7 Nm (62 lb-in).
  6. Disconnect the rear SJB electrical connectors.
  7. To install, reverse the removal procedure.
